LOGIClink
MANUAL
Document Version 1.0/March 2018
LOGIClink

LOGIClink | 3
CONTENTS
1. Safety................................................................................................................5
1.1 General safety regulations and obligations .......................5
1.2 Qualified persons.......................................................................5
1.3 Liability ........................................................................................ 6
2 Product description..................................................................................8
2.1 Intended use............................................................................ 8
2.2 Compatibility........................................................................... 9
3. Installation ................................................................................................. 11
3.1 Assembly.................................................................................11
5.2 System setup with standard cable.................................. 13
4 Operation ....................................................................................................21
4.1 Adjust table height.............................................................. 21
4.2 Restart..................................................................................... 21
5. APP and API..............................................................................................22
5.1 Bluetooth pairing................................................................. 22
6. Maintenance .............................................................................................22
7. Disassembly and disposal ..................................................................23

4 | LOGIClink LOGIClink | 5
1. SAFETY
1.1 General safety regulations and obligations
In general, the following safety regulations and obligations apply when handling the product:
• The product may only be operated in a clean and perfect condition.
• Do not remove, change, bridge or bypass any protection, safety or monitoring equipment.
• Do not convert or modify the product without written approval from Swedstyle.
• In the event of malfunction or damage, the product must be replaced immediately.
• Repairs are prohibited. Defective products are to be replaced as a whole.
• Hardware replacement or changes to the system configuration are only allowed in a
de-energized state.
• Only qualified persons are allowed to work on the product.
• For the operation of the system, the national worker protection conditions and
the national safety and accident prevention regulations apply.
1.2 Qualified persons
Products from Swedstyle may only be installed and commissioned by qualified persons who are
authorized for installation planning, installation, commissioning or maintenance/servicing and
who have read and understood the product documentation.
Qualified persons have the necessary expertise to test, assess and manage electrical and mechat-
ronic products and systems in accordance with the generally accepted standards and guidelines
of electrical engineering and furniture manufacturing through their education, work experience
and recent professional activity. They know and adhere to the basic regulations on occupational
safety and accident prevention and the basic norms and specialist standards applicable to the
specific application.
All safety standards and guidelines relevant to the application must be taken into account.
The furniture manufacturer performs a safety assessment of the entire system and is
responsible for the certification of the entire system.
1.3 Liability
The information in this documentation describes the properties of the products without
guaranteeing them. The products satisfy current state of the art standards as well as
the applicable health and safety regulations. Nevertheless, dangers can result from incorrect
operation or misuse. Swedstyle is not liable for damages caused by:
• Improper use of the products
• Disregard of the documentation
• Unauthorized changes to the products
• Improper work on and with the product
• Operation of a product, although it is damaged
• Wear parts
• Improperly performed repairs
• Unauthorized, improper change of operating parameters
• Disasters, external influence and force majeure
Responsible for the LOGICDATA products in the specific application and compliance with the
relevant directives, standards and laws is the manufacturer of the height-adjustable tables in
which the LOGICDATAproducts are installed. Swedstyle shall not be held liable for any damage
that is directly or indirectly attributable to the delivery, performance or use of this document.
2. PRODUCT DESCRIPTION
LOGIClink is a connectivity hub for intelligent, electrically height-adjustable desks.
The product is available in two variants – Personal and Corporate. LOGIClink has a presence
sensor, a status LED, control buttons for use as a hand switch, Bluetooth, NFC and USB.
The Corporate version is also WiFi-enabled.
1 DOWNkey
2 UPkey
3 Presencesensor
4 Minifit

5 Restartbutton
6 MicroUSB
FIG1:PRODUCTOVERVIEW

6 | LOGIClink LOGIClink | 7
2.1 Intended use
LOGIClink is an electrical appliance for home use. It may only be used in dry indoor areas
and according to the product description. The setup location must be level, vibration-free and
free from dirt, dust, etc. Ensure that there is no excessive exposure to dust or toxic or corrosive
gases and vapors or excessive heat at the setup location.
This device may be used by children 8 years old and over, and by persons with reduced physical,
sensory or mental abilities, or lack of experience and knowledge, if they are supervised or have
been instructed in the safe use of the device and understand the resulting hazards.
Do not allow children to play with the device. Do not allow children to perform the cleaning
without supervision.
After the mechatronic system has been built into a table, the table manufacturer is responsible
for risk analysis and evaluation of the entire table and for creating the user documentation.
2.2 Compatibility
LOGIClink is compatible with the following products from LOGICDATA:
Controllers
Compact-e, SMART-e and SMARTneo.
The COMPACT-e+ and SMART-e+ controllers are not compatible and must never be connected.
Hand switch (only allowed in conjunction with the RetroFit cable)
TOUCHbasic-down, TOUCHbasic-inlay, TOUCHfx, TOUCHinlay and TOUCHdown.
3. INSTALLATION
The table system may only be assembled by qualified persons. The workplace must be clean,
dry and ESD-protected.
CAUTION. Pay attention to ESD-compliant handling. Errors that can be attributed
to electrostatic discharge will void warranty claims.
3.1 Assembly
You also need:
• Mounting screws suitable for your table top. The mounting opening consists of
mounting holes
• Pen for marking the drill holes
• Drill
• Screwdriver suitable for screwing in your mounting screws
Procedure:
1. Mark the drill holes on the underside of the table top. Please note that the status LED
on the front edge of the table is visible and that LOGIClink requires at least 5 cm clearance
to metal parts and cables on all sides.
2. Drill the holes as indicated in Fig. 2.
3. Attach LOGIClink using the mounting screws.
3.2 System setup with standard cable
Use this system setup for the following configuration:
• LOGIClink is used as the only control element.
• No additional hand switch is connected.
• The type plate of the controller has Works with LOGIClink printed on it.
FIG2:DRILLHOLES
MANUAL LOGICLINK // PAGE 11
5 INSTALLATION
ESD-protected.
CAUTION
Pay attention to ESD-compliant handling. Errors that can be
attributed to electrostatic discharge will void warranty claims.
5.1 ASSEMBLY
You also need:
• Mounting screws suitable for your table top. The mounting opening consists of mounting holes
• Pen for marking the drill holes
• Drill
• Screwdriver suitable for screwing in your mounting screws
Procedure:
1. Mark the drill holes on the underside of the table top. Please note that the status LED on the front
cables on all sides.
4.409 "
112,0 mm
1.593 "
40,45 mm
3.425 "
87,0 mm
Fig. 2: Drill holes
2. Drill the holes as indicated in Fig. 2 .
3. Attach LOGIClink using the mounting screws.
FIG3:MOUNTLOGICLINK
MANUAL LOGICLINK // PAGE 12
NOTICE We recommend installing LOGIClink at a distance of ap-
prox.70cm from the user.
Fig. 3: Mount LOGIClink
4. Align the presence sensor to the user.
If LOGIClink is mounted to the left of the user, turn the presence sensor towards L. If LOGIClink
is mounted to the right of the user, turn the presence sensor towards R.
Fig. 4: Align presence sensor
MANUAL LOGICLINK // PAGE 13
5.2 SYSTEM SETUP WITH STANDARD CABLE
Use this system setup for the following conguration:
• LOGIClink is used as the only control element.
• No additional hand switch is connected.
• The type plate of the controller has Works with LOGIClink printed on it.
Fig. 5:
Standard cable
The standard cable has 2 connectors:
• DIN (is plugged into the hand switch socket of the control)
• 10-pin minit (LOGIClink)
Fig. 6: Standard cable LOG-CBL-LOGICLINK-CB-STANDARD
NOTICE. We recommend
installing LOGIClink at a
distance of approx.
70 cm from the user.

8 | LOGIClink LOGIClink | 9
Standard cable
The standard cable has 2 connectors:
• DIN (is plugged into the hand switch socket of the control)
• 10-pin minifit (LOGIClink)
System overview
Assemble system
1. Plug the minifit plug of the
standard cable into the LOGIClink.
Fig. 6.
2. Lay and secure the cable along
the table to the controller.
MANUAL LOGICLINK // PAGE 13
5.2 SYSTEM SETUP WITH STANDARD CABLE
Use this system setup for the following conguration:
• LOGIClink is used as the only control element.
• No additional hand switch is connected.
• The type plate of the controller has Works with LOGIClink printed on it.
Fig. 5:
Standard cable
The standard cable has 2 connectors:
• DIN (is plugged into the hand switch socket of the control)
• 10-pin minit (LOGIClink)
Fig. 6: Standard cable LOG-CBL-LOGICLINK-CB-STANDARD
FIG.4:STANDARDCABLE
LOG-CBL-LOGICLINK-CB-STANDARD
FIG.5:STANDARDCONFIGURATION
Minifit DIN
MANUAL LOGICLINK // PAGE 14
System overview
Fig. 7:
Assemble system
1.
Fig. 8:
2. Lay and secure the cable along the table to the controller.
3. Connect the blue DIN plug to the controller's hand switch socket (marked *HS* on the housing).
COMPACT
OR
SMART
MANUAL LOGICLINK // PAGE 14
System overview
Fig. 7:
Assemble system
1.
Fig. 8:
2. Lay and secure the cable along the table to the controller.
3. Connect the blue DIN plug to the controller's hand switch socket (marked *HS* on the housing).
FIG.6:PLUGMINIFITINTOLOGICLINK
3. Connect the blue DIN plug to the
controller’s hand switch socket
(marked *HS* on the housing).
4. Plug the mains cable into the controller.
5. Finally, plug the mains cable into
the power outlet. Fig 7, 8 and 9.
MANUAL LOGICLINK // PAGE 15
Fig. 9: Connection to COMPACT controller
Fig. 10: Connection to SMART controller
Fig. 11: Connection to SMARTneo controller
4. Plug the mains cable into the controller.
5. Finally, plug the mains cable into the power outlet.
MANUAL LOGICLINK // PAGE 15
Fig. 9: Connection to COMPACT controller
Fig. 10: Connection to SMART controller
Fig. 11: Connection to SMARTneo controller
4. Plug the mains cable into the controller.
5. Finally, plug the mains cable into the power outlet.
MANUAL LOGICLINK // PAGE 15
Fig. 9: Connection to COMPACT controller
Fig. 10: Connection to SMART controller
Fig. 11: Connection to SMARTneo controller
4. Plug the mains cable into the controller.
5. Finally, plug the mains cable into the power outlet.
FIG.8:CONNECTIONTOCOMPACTCONTROLLER
FIG.7:CONNECTIONTOSMARTNEOCONTROLLER FIG.9:CONNECTIONTOSMARTCONTROLLER
4. OPERATION
4.1 Adjust table height
Press the UP or DOWN button on the bottom of LOGIClink to adjust the table height.
4.2 Restart
To restart LOGIClink, press and hold the restart button for 5 seconds.
5. APP AND API
The SwedMotion app (available in the Apple App Store and Google Play Store) stores personal
workplace settings to they are immediately available after a table change. The app can track
how much time the user spends sitting and standing. This permits personal recommendations to
be derived from this, for example. Optionally, LOGIClink also includes a programming interface
(API) to help you develop apps for your visions.

10 | LOGIClink
5.2 Bluetooth pairing
1. Download the SwedMotion app for free from the Play Store or App Store.
Google/Android: Play Store
Apple/iOS: App Store
2. Double-click the restart button on the LOGIClink to start Bluetooth pairing.
3. Enter the pairing data. 000000 (6 zeros).
6. MAINTENANCE
The LOGIClink control element is maintenance-free for its entire service life. If cleaning is
necessary, wipe off LOGIClink with a soft, dry cloth.
7. DISASSEMBLY AND DISPOSAL
How to disassemble LOGIClink
1. Disconnect the power supply of the table.
2. Disconnect all cables.
3. Unscrew the three mounting screws that attach LOGIClink to the table top.
4. Dispose of all parts in course of the final decommissioning in an
environmentally sound and unmixed manner.
Disposal
The LOGIClink is an electrical and electronic device that must be disposed of
separately from household waste according to the WEEE Directive 2012/19/EU.
The products are marked with the symbol shown on the left.
Before disposing of materials and components, check their recyclability. Recycle as many parts
as possible. Dispose of all materials and parts in accordance with your local guidelines and
regulations. Ensure that the disposal is lastingly compatible for humans and nature.
MANUAL LOGICLINK // PAGE 23
9 TROUBLESHOOTING
Most errors can be remedied by restarting.
Restart
To restart LOGIClink, press and hold the restart button for 5 seconds.
Contacting support
For technical problems, please contract our support at:
Tel.: [phone]
Fax: [phone]
E-mail: o[email protected]
Always provide the product name and the revision status according to the type plate with any support re-
quest.
In case of a defect, replace LOGIClink as a whole.
10 DISASSEMBLY AND DISPOSAL
How to disassemble LOGIClink
1. Disconnect the power supply of the table.
2. Disconnect all cables.
3. Unscrew the three mounting screws that attach LOGIClink to the table top.
4. Dispose of all parts in course of the nal decommissioning in an environmentally sound and
unmixed manner.
Disposal
The LOGIClink is an electrical and electronic device that must be disposed of separate-
ly from household waste according to the WEEE Directive 2012/19/EU. The products are
marked with the symbol shown on the left.
Before disposing of materials and components, check their recyclability. Recycle as many parts as possible.
Dispose of all materials and parts in accordance with your local guidelines and regulations. Ensure that the
disposal is lastingly compatible for humans and nature.

Swedstyle AB.
Box 171, SE-567 24 Vaggeryd, Sweden
[e-mail]
[phone]
www.swedstyle.com
Smart office solutions
