SWI TR420E/E6 User manual

TR420E/E6 FLOAT LEVEL
TRANSMITTER
Continuous Output Float Level Transmitter
For Hazardous Locations
INSTALLATION AND OPERATIONS MANUAL

2TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
This manual provides information on the TR420E/
E6 Continuous Output Transmitter. It is
important that all instructions are read carefully and
followed sequentially. The QuickStart Installation
instructions are a brief guide to the sequence of steps
for experienced technicians to follow when installing
the equipment. Detailed instructions are included in
the Complete Installation section of this manual.
Conventions Used in this Manual
Certain conventions are used in this manual to convey
specic types of information. General technical
material, support data and safety information are
presented in narrative form. The following styles are
used for notes, cautions and warnings:
Notes
Notes contain information that augments or claries
an operating step. Notes do not normally contain
actions and often follow the procedural steps to
which they refer.
Cautions
Cautions alert the technician to special conditions
that could injure personnel, damage equipment, or
reduce a component’s mechanical integrity. Cautions
are also used to alert the technician of unsafe
practices, the need for special protective equipment,
or specic materials. In this manual, a caution
indicates a potentially hazardous situation which, if
not avoided, may result in minor to moderate injury.
Warnings
Warnings identify potentially dangerous situations, or
serious hazards. In this manual, a warning indicates
an imminently hazardous situation which, if not
avoided, may result in serious injury or death.
Safety Messages
Follow all standard industry procedures for servicing
electrical and computer equipment when working with,
or around high voltage. Always shut off the power
supply before touching any components. Although
high voltage is not present in this system, it may be
present in other systems.
Electrical components are sensitive to electrostatic
discharge. To prevent equipment damage, observe all
safety precautions when working with electrostatic-
sensitive components.
WARNING!
DO NOT CONNECT OR DISCONNECT THE
TRANSMITTERS UNLESS THE POWER HAS BEEN
SWITCHED OFF.
Low Voltage Directive
If the equipment is used in a manner not specied by
the manufacturer, protection provided by equipment
may be impaired.
Notice of Copyright and Limitations
Copyright © 2016 Solutions With Innovation, LLC;
All rights reserved.
Solutions With Innovation reserves the right to make
changes to the product described in this manual at
any time without notice. Solutions With Innovation
makes no warranty with respect to the accuracy of the
information in this manual.
Warranty
All Solutions With Innovation Electronic Level and
Flow Controls are warranted free of defects in materials
and workmanship for one full year from the date of
the original factory shipment. If returned within the
warranty period; and, upon factory inspection of
the control, the cause of the claim is determined to
be covered under the warranty; then, Solutions With
Innovation will repair or replace the product at no cost
to the purchaser (or owner) other than transportation.
Solutions With Innovation shall not be liable for
misapplication, labor claims, direct or consequential
damage, or expenses arising from the installation or
use of the equipment. There are no other warranties
expressed or implied, except special written warranties
covering specic Solutions With Innovation products.
Quality Assurance
The Quality Assurance System in place at Solutions
With Innovation guarantees the highest level
of quality throughout the company. Solutions With
Innovation is committed to providing full customer
satisfaction; both in quality products and in quality
service.
Contacts
Phone: 203-729-6434 Mon-Fri, 9 AM - 5 PM EST
Fax: 203-729-0541 for General Inquiries
Email: sales@innovativesensing.com
READ THIS MANUAL PRIOR TO INSTALLATION

3
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
TR420E/E6 FLOAT LEVEL
TRANSMITTER
For Hazardous Locations
TABLE OF CONTENTS
1.0 Quickstart Installation
1.1 Getting Started...................................................................4
1.1.1 Equipment and Tools...............................................4
1.1.2 Conguration Information.....................................4
2.0 Complete Installation
2.1 Unpacking...........................................................................5
2.2 Installation Location.........................................................5
2.3 Electrostatic Discharge Handling Procedure................6
2.4 Before You Begin...............................................................6
2.4.1 Site Preparation..........................................................6
2.4.2 Equipment and Tools...............................................6
2.4.3 Optional Considerations..........................................7
2.5 Mounting............................................................................7
2.5.1 TR420E/E6 Probe Installation..............................7
2.6 Wiring..................................................................................8
2.6.1Non-Incendive...........................................................8
2.6.2 Intrinsically Safe........................................................9
2.6.3Explosion-Proof........................................................9
2.7 Calibrating TR420E/E6 Transmitters.........................10
2.7.1Calibration................................................................10
2.7.2 Adjustment Procedure............................................10
2.7.3 Fault Mode...............................................................10
3.0 Reference Information
3.1Description.......................................................................11
3.2 Theory of Operation......................................................11
3.2.1 Basic Operating Principle......................................11
3.2.2 TR420E/E6 Probe.................................................11
3.2.3 TR420E/E6 Control Board..................................11
3.3 Troubleshooting..............................................................12
3.3.1 TR420E/E6 Transmitter Problems.....................12
3.4 Agency Approvals...........................................................12
3.5 Specications...................................................................12
3.5.1Functional...........................................................12-13
3.5.2 Process Conditions.................................................13
3.5.3 Replacement Parts...................................................13
3.5.4 Physical.....................................................................14
3.6 Model Congurator........................................................14
3.7 Notes.................................................................................15

4TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
1.0 QUICKSTART INSTALLATION
The Quickstart Installation procedures provide key steps for mounting, wiring and conguring the TR420E/
E6 Continuous Output Transmitter for Hazardous Locations. These procedures are intended for experienced
installers of electronic level measurement instruments. Refer to Section 2.0: Complete Installation for
detailed installation instructions.
WARNING! TR420E/E6 TRANSMITTER PROBES SHOULD BE INSTALLED WHERE THE MAXIMUM OVERFILL
LEVEL IS AT A MINIMUM OF 1” (24.5 mm) BELOW THE PROCESS CONNECTION. THIS MAY INCLUDE UTILIZING
A NOZZLE OR SPOOL PIECE TO RAISE THE PROBE. CONSULT THE MANUFACTURER TO ENSURE PROPER
INSTALLATION.
CAUTION! THIS UNIT CONTAINS REED SWITCHES THAT MAY BE PERMANENTLY DAMAGED BY MECHANICAL
SHOCK OR VIBRATION. AVOID DROPPING OR HITTING THE DEVICE AGAINST HARD SURFACES.
1.1 GETTING STARTED
Before beginning the Quickstart Installation procedures, have the proper equipment, tools and information
readily available.
1.1.1 Equipment and Tools
• Open-End Wrenches or An Adjustable Wrench to Fit the Process Connection Size and Type
• Small Flat Blade Screwdriver
• Cable Cutter & Wire Strippers
• Digital Multimeter or Digital Volt/Ammeter
• 24 VDC Power Supply
1.1.2 Conguration Information
The TR420E/E6 Continuous Output Transmitter for Hazardous Locations is factory-calibrated.
Conguration is not required. Refer to Section 2.7 for calibration instructions.

5
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.0 COMPLETE INSTALLATION
This section provides detailed procedures on properly installing and conguring the TR420E/E6 Continuous
Output Transmitter for Hazardous Locations.
CAUTION! IF THE EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, PROTECTION
PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED.
CAUTION! THIS UNIT CONTAINS REED SWITCHES THAT MAY BE PERMANENTLY DAMAGED BY MECHANICAL
SHOCK OR VIBRATION. AVOID DROPPING OR HITTING THE DEVICE AGAINST HARD SURFACES.
2.1 UNPACKING
Unpack the instrument, carefully. Make sure that all components have been removed from the packing
material. Inspect all components for damage. Report any concealed damage to the carrier within 24 hours
of receiving. Compare the contents with the packing slip and report any discrepancies to the factory
immediately. Record the sales order number and/or serial number for future reference when ordering parts.
Before Proceeding to Installation, Complete the Following:
• Inspect all components for damage. Report any damage to the carrier within 24 hours of receiving.
• Verify that the laser marked model number located on the probe and transmitter correspond to the
packing slip and purchase order.
• Record the model and serial numbers for future reference when ordering parts.
Model Number
Serial Number
2.2 INSTALLATION LOCATION
TR420E/E6 Continuous Output Transmitter sensors should be located within easy access for service,
calibration and monitoring. Sensors should not be exposed to ambient temperatures below -40° F (-40° C) or
above +185° F (+85° C). Special precaution should be made to prevent exposure to corrosive atmospheres,
excessive vibration, shock and physical damage.
It is common practice to use the metal tank wall as the reference ground. In such cases, it is required that
the probe housing makes a good electrical connection to the tank wall. If there is any doubt about this
connection due to the use of PTFE thread tape, gaskets, paint, rust or any other reason, a separate strap
should be installed between the probe housing and tank.
CAUTION! THIS UNIT CONTAINS ELECTRONICS WHICH MAY BE DAMAGED BY STATIC ELECTRICITY. DO
NOT TOUCH ANY SEMI-CONDUCTOR DEVICES UNLESS YOU ARE PROPERLY GROUNDED.

6TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.3 ELECTROSTATIC DISCHARGE (ESD) HANDLING PROCEDURE
Solutions With Innovation’s electronic instruments are manufactured to the highest
quality standards. These instruments use electronic components that may be damaged
by static electricity present in most work environments.
THE FOLLOWING STEPS ARE RECOMMENDED TO REDUCE THE RISK OF
COMPONENT FAILURE DUE TO ELECTROSTATIC DISCHARGE:
• Ship and store circuit boards in anti-static bags. If an anti-static bag is not available,
wrap the board in aluminum foil. Do not place boards on foam packing materials.
• Use a grounding wrist strap when installing and removing circuit boards. A grounded
workstation is recommended.
• Handle all circuit boards only by their edges. Do not touch board components or
connector pins.
• Make sure that all electrical connections are completely secure and none are partial
or oating. Ground all equipment to a good, earth ground.
2.4 BEFORE YOU BEGIN
2.4.1 Site Preparation
1 Each TR420E/E6 Continuous Output Transmitter is built to the specications indicated during the
ordering process. Make sure that the probe connection is correct for the threaded or anged mounting
on the vessel or tank where the transmitter will be placed. Refer to Section 2.5: Mounting.
2 Ensure that the wiring between the power supply and TR420E/E6 electronics are complete and
appropriate for the type of installation. Refer to Section 3.5: Specications.
3 When installing the TR420E/E6 Continuous Output Transmitter in a non-incendive, intrinsically safe or
hazardous area, all local, state and federal regulations/guidelines must be observed. Refer to Section 2.6: Wiring.
2.4.2 Equipment and Tools
No special equipment or tools are required to install the TR420E/E6 Continuous Output Transmitter.
The Following Are Recommended:
• Grounding Wrist Strap and ESD Workstation (For safety usage with electronic components)
• Open-End Wrenches or an Adjustable Wrench (To fit the process connection size and type)
• 1/8” Wide, Small Flat Blade Screwdriver
• Cable Cutter & Wire Strippers
• Digital Multimeter or Digital Volt/Ammeter
• 24 VDC Power Supply

7
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.4.3 Optional Considerations
Operating specications vary based on the probe model number. Refer to Section 3.5: Specications.
2.5 MOUNTING
The TR420E/E6 Continuous Output Transmitter for Hazardous Locations is mounted vertically inside
a tank using a variety of process connections. Generally, a threaded or anged connection is used. For
information about the sizes and types of connections available, refer to Section 3.6: Model Congurator.
WARNING! TR420E/E6 TRANSMITTER PROBES SHOULD BE INSTALLED WHERE THE MAXIMUM
OVERFILL LEVEL IS AT A MINIMUM OF 1” (25.4 mm) BELOW THE PROCESS CONNECTION. CONSULT THE
MANUFACTURER TO ENSURE PROPER INSTALLATION.
WARNING! DO NOT DISASSEMBLE THE PROBE WHEN IT IS IN SERVICE AND/OR UNDER PRESSURE.
CAUTION! DO NOT ADJUST THE ELECTRICAL ENCLOSURE’S ORIENTATION RELATIVE TO THE MOUNT’S
POSITION. DAMAGE TO THE INTERNAL WIRING WILL OCCUR.
2.5.1 TR420E/E6 Probe Installation
Before Installing, Verify:
• The probe has adequate room for installation and has an unobstructed entry to the bottom of the
vessel. Refer to Section 3.5.4: Physical Specications.
• The process temperature, pressure and specic gravity are within the probe specications for the
installation. Refer to Section 3.5: Specications.
How To Install The TR420E/E6 Probe:
1 Make sure the process connection is at least 1 ½” NPT, 2” NPT or a anged mounting.
2 Carefully, place the probe into the vessel. Align the gasket on anged installations.
3 Align the probe process connection with the threaded or anged mounting on the vessel.
4 For threaded connections, tighten the hex nut of the probe process connection.
For flanged connections, tighten and torque the ange bolts.

8TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.6 WIRING
Within the transmitter enclosure, connections are made to the terminal strip and the ground connections.
The instructions for wiring the TR420E/E6 Continuous Output Transmitter depend on the application:
2.6.1 Non-Incendive (Class I, Div. II)
2.6.2 Intrinsically Safe
2.6.3 Explosion-Proof
CAUTION! THE TR420E/E6 TRANSMITTER ELECTRONICS OPERATE AT VOLTAGES OF 20 - 28 VDC. A
HIGHER VOLTAGE WILL DAMAGE THE TRANSMITTER.
WARNING! DO NOT DISCONNECT THE EQUIPMENT UNLESS THE POWER IS SWITCHED OFF. DO NOT
ATTEMPT TO WIRE THE EQUIPMENT UNLESS THE POWER IS SWITCHED OFF.
NOTE: WIRING BETWEEN THE POWER SUPPLY AND TR420E/E6 TRANSMITTER SHOULD BE MADE USING
18 - 22 AWG SHIELDED, TWISTED PAIR INSTRUMENT CABLE.
2.6.1 Non-Incendive (Class I, Div. II)
• Areas rated Non-Incendive (Class I, Div. II) have ammable media present only under abnormal
conditions (no special electrical connections are required).
• If ammable media is contained within the vessel, the transmitter must be installed per the
Class I, Div. I standards of area classication.
How To Install Non-Incendive Wiring:
1 Remove the cover of the transmitter.
2 Install the conduit plug into the unused
opening.
3 Install a conduit tting and pull the supply
wires through.
4 Connect the positive supply wire to the pwr
terminal and the negative supply wire to the
gnd terminal.
5 Connect the signal wire to the out terminal
and the return wire to the rtn terminal.
6 Run the wires to your device to make proper
terminations for signal there.
7 Re-install the cover of the transmitter.
TR420E CONTROL BOARD
pwr
gnd
out
rtn
low high
green led
red led

9
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.6.2 Intrinsically Safe
• An Intrinsically Safe (IS) installation potentially HAS ammable media present.
• An approved IS barrier must be installed in the non-hazardous (safe) area.
How To Install Intrinsically Safe Wiring:
1 Verify that the IS barrier is properly installed in the safe area (refer to local plant or facility procedures).
Complete the wiring from the barrier to the TR420E/E6 Transmitter.
2 Remove the cover of the transmitter.
3 Install the conduit plug into the unused opening.
4 Install a conduit tting and pull the supply wires through.
5 Connect the positive supply wire to the pwr terminal and the negative supply wire to the gnd terminal.
6 Connect the signal wire to the out terminal and the return wire to the rtn terminal.
7 Run the wires to your device to make proper terminations for signal there.
8 Re-install the cover of the transmitter.
2.6.3 Explosion-Proof
• An Explosion-Proof (EP) installation HAS ammable gases or vapors present where their quantities
are able to produce explosive or ignitable mixtures.
• The wiring for the transmitter must be contained in an explosion-proof conduit extending into the
non-hazardous (safe) area.
• An explosion-proof conduit tting (EY seal) must be installed between the hazardous and
non-hazardous areas.
WARNING! BEFORE ATTEMPTING TO WIRE THE DEVICE, VERIFY THE POWER IS OFF.
How To Install Explosion-Proof Wiring:
1 Install the explosion-proof conduit from the safe area to the TR420E/E6 Transmitter’s conduit
connection (refer to local plant or facility procedure).
2 Remove the cover of the transmitter.
3 Connect the positive supply wire to the pwr terminal and the negative supply wire to the gnd terminal.
4 Connect the signal wire to the out terminal and the return wire to the rtn terminal.
5 Run the wires to your device to make proper terminations for signal there.
6 Re-install the cover of the transmitter.

10 TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
2.7 CALIBRATING TR420E/E6 TRANSMITTERS
2.7.1 Calibration
The TR420E/E6 Continuous Output Transmitter for Hazardous Locations requires minimal to no initial
calibration depending on the media. The device is shipped from the manufacturer with its 4 mA (0%)
point set on empty indication and its 20 mA (100%) point set on full indication. The 4 mA and/or 20 mA
points can be readjusted by the end user if necessary.
2.7.2 Adjustment Procedure
This procedure should be used when the process level can be moved from empty to full, or from the
actual 4 to 20 mA points. A digital multimeter is recommended, but not required for calibration.
1 Connect the digital multimeter (set to read
20.0 mA full scale) to the control board on the
transmitter. Attach the “common” or black
lead from the meter to the rtn terminal on the
control board. Then, attach the “mA” or red
lead from the meter to the out terminal on the
control board.
2 Connect the transmitter to a 24 VDC power
supply.
3 A green LED will illuminate on the PCB to
indicate that the board is powered up.
4 Lower the oat on the probe all the way to
the bottom, indicating an empty tank. The
multimeter should read 4.0 mA. If necessary,
adjust the low trim pot with a small at
blade screwdriver. By turning the screwdriver
clockwise, the output will rise. By turning the
screwdriver counter-clockwise, the output will
lower. Turn accordingly to achieve an output
of 4.0 mA.
5 Raise the oat on the probe to the top of the indication length, signaling a full tank. The multimeter
should read 20.0 mA. If necessary, adjust the high trim pot with a small at blade screwdriver. By
turning the screwdriver clockwise, the output will rise. By turning the screwdriver counter-clockwise,
the output will lower. Turn accordingly to achieve an output of 20.0 mA.
6 Cycle the oat from the bottom to the top of the indication length, verifying the outputs at both
positions. Repeat steps 4 & 5, if necessary to obtain the best accuracy.
2.7.3 Fault Mode
A “fault” condition will show by illuminating the red LED on the control board. If this occurs, the output
signal has been wired incorrectly, or not wired at all.
pwr
gnd
out
rtn
low high
green led
red led

11
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
3.0 REFERENCE INFORMATION
This section illustrates an overview of the TR420E/E6 Continuous Output Transmitter operation, as well as
information on troubleshooting common problems, agency approval listings, replacement parts, and detailed
physical, functional and performance specications.
3.1 DESCRIPTION
The vertically-mounted TR420E/E6 Continuous Output Level Transmitter for Hazardous Locations
is equipped with an integral signal conditioner and provides a reliable 4-20 mA, 0-5 VDC or 1-5 VDC
proportional electronic output in tank levels up to 15 feet. It can be used to input programmable controllers,
meters and other digital receivers for accurate and continuous measurement in many liquid level applications.
The TR420E/E6 is FM-approved with an explosion-proof rating for Class II, Div. I, Groups E, F & G
hazardous (classied) locations, indoor/outdoor (Type 4, 4X). Float materials are available in stainless steel
with a variety of mounting types. Additional options include high and low level alarms as well as SPST or
SPDT switch contacts.
3.2 THEORY OF OPERATION
3.2.1 Basic Operating Principle
The TR420E/E6 Continuous Output Transmitter for Hazardous Locations contains a series of magnetic
reed switches within its vertical sensor stem. As the oat travels along the transmitter’s stem in correlation
to the uid level inside the tank, its internal magnets actuate the series of reed switches. Then, a signal is
electronically conditioned through the built-in transmitter board to provide a current output.
3.2.2 TR420E/E6 Probe
Each probe segment contains 64 discrete resistors, forming a resistive daisy chain
or series circuit. The segments have been congured as a voltage divider where the
magnetic reed switches serve as the tapping point to the circuit. As each switch closes,
the voltage divider varies in proportion to the switch position. Ultimately, the probe
connectors allow the voltage divider to extend the length of the probe.
3.2.3 TR420E/E6 Control Board
The control is a current transmitter that accepts high-level signal inputs from the
resistive probe and drives a standard 4-20 mA current loop to enable valves, actuators
and other devices commonly used in the process. During the transmission, the input
signal is buffered by an input amplier that is used to scale the input signal. The signal
is then divided by voltage and fed back to the input signal. There is limited interaction
between setpoints, which allows the user to set each trimpot once and avoid several
attempts to lock-in the values.
A red LED light illuminates to notify the user of an open 4-20 mA loop or noncompliance
of the output stage. In the event the wire from the HDR1 Pin 3 is opened, the LED will
light up. If a large input overdrive forces the signal too close to the input power supply
voltage, the LED will also signify a problem.
Alternatively, a green LED light is present on the control board to indicate power to the board. If the
green LED is illuminated, the control board is powered up and ready for use.

12 TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
3.3 TROUBLESHOOTING
The TR420E/E6 Continuous Output Transmitter for Hazardous Locations is designed and manufactured
for trouble-free performance across a wide range of operating conditions. Common transmitter problems
are discussed in terms of their symptoms and recommended corrective actions. Information on how to
handle material build-up on the probe is also provided in this section.
WARNING! EXPLOSION HAZARD. DO NOT CONNECT OR DISCONNECT THE EQUIPMENT UNLESS POWER
HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
3.3.1 TR420E/E6 Transmitter Problems
SYMPTOM PROBLEM SOLUTION
THE OUTPUT IS INACCURATE. THE CALIBRATION IS QUESTIONABLE. RECALIBRATE THE TRANSMITTER.
THE OUTPUT IS REPETATIVE, BUT IT IS
CONSISTENTLY HIGH OR LOW FROM THE
ACTUAL OUTPUT BY A FIXED AMOUNT.
THE CALIBRATION IS QUESTIONABLE. RECALIBRATE THE TRANSMITTER.
THE OUTPUT FLUCTUATES. TURBULENCE. RELOCATE THE PROBE TO A LESS
TURBULENT LOCATION OR PURCHASE
A SLOSH SHIELD ASSEMBLY.
THE OUTPUT READING IS LOW VERSUS
THE ACTUAL OUTPUT.
COATING OR BUILD-UP IS PRESENT ON
THE FLOAT AND STEM.
CLEAR THE FLOAT AND STEM OF ANY
CONTAMINANTS.
COATING, CLUMPING OR BUILD-UP IS
PRESENT ON THE STEM.
CLEAR THE STEM OF ANY
CONTAMINANTS.
If you are still in doubt about the condition or performance of your control, consult the factory for further instructions.
3.4 AGENCY APPROVALS
AGENCY APPROVED MODEL(S) FILE NUMBER AREA CLASSIFICATION
FM TR420E/E6 3031861 EXPLOSION-PROOF:
CLASS I, DIV I, GROUPS A, B, C & D
DUST IGNITION-PROOF:
CLASS II/CLASS III, DIV I GROUPS E, F & G, TYPE 4, 4X
3.5 SPECIFICATIONS
3.5.1 Functional
INPUT
MEASUREMENT PRINCIPLE: Voltage Divider Network
MEASURED VARIABLE: Level, Determined by the Float Position Closing Reed Switches and a
Proportionally Conditioned Output Signal
INDICATION LENGTH: 6” to 180” (15 cm to 458 cm)
POWER: 10 to 30 VDC (Non-Incendive, Intrinsically Safe or Explosion-Proof)
OUTPUT
SIGNAL: 4-20 mA, 0-5 VDC or 1-5 VDC (Analog)
RANGE: 3.6 to 20.5 mA Usable or 0 to 5.5 VDC Usable (Analog)
RESOLUTION: 0.01 mA or 0.01 VDC (Analog)

13
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
ENVIRONMENTAL
OPERATING TEMPERATURE: -40° to +176° F (-40° to +80° C)
STORAGE TEMPERATURE: -50° to +176° F (-40° to +80° C)
AMBIENT TEMPERATURE: Approximately +0.03% of Probe Length/°C
HUMIDITY: 0 to 99%, Non-Condensing
VIBRATION CLASS: ANSI/ISA-S71.03 Class VC2
SHOCK CLASS: ANSI/ISA-S71.03 Class SA1
USER INTERFACE
KEYPAD: None
INDICATION: (2) LED Lights
DIGITAL COMMUNICATION: None
PERFORMANCE
LINEARITY: ± 0.25”
RESOLUTION: ± 0.25” or ± 0.50”
REPEATABILITY: Less Than 0.25”
RESPONSE TIME: Less Than 1 Second
WARM-UP TIME: Less Than 3 Seconds
MATERIALS OF CONSTRUCTION
ENCLOSURE: Aluminum, Cast Iron (¾” Cable Entry)
PROBE MOUNT & STEM: 316 Stainless Steel > 0.50” (12.7 mm) Ø Tube
PROCESS CONNECTION: See Section 3.7: Model Numbers
FLOATS: 316 Stainless Steel
RETAINING COLLARS: 316 Stainless Steel
3.5.2 Process Conditions
STAINLESS STEEL PROBES
MAXIMUM PROCESS PRESSURE: 750 PSIG at +70° F (51.7 bar at +20° C)
MINIMUM SPECIFIC GRAVITY: 0.80
3.5.3 Replacement Parts
ITEM DESCRIPTION PART NO.
1 Control Board: 12 VDC Input, 0 to 5 VDC Output
Control Board: 12 VDC Input, 1 to 5 VDC Output
Control Board: 12 VDC Input, 4 to 20 mA Output
Control Board: 24 VDC Input, 0 to 5 VDC Output
Control Board: 24 VDC Input, 1 to 5 VDC Output
Control Board: 24 VDC Input, 4 to 20 mA Output
0950-T420-0006
0950-T420-0003
0950-T420-0004
0950-T420-0007
0950-T420-0005
0950-T420-0002
2Standoff (2 Pieces Required) 0785-0018-0250
3Junction Box: Aluminum
Junction Box: Cast Iron
0700-0000-0002
0700-0000-0004
4 Collar: 316 Stainless Steel 1/2”
Collar: 316 Stainless Steel 5/8”
0610-0500-0030
0610-0625-0003
5 Float: Stainless Steel for 1 ½” NPT Mount and Larger
Float: Stainless Steel for 2” NPT Mount and Larger
Float: Stainless Steel for 2” NPT Mount and Larger
Float: Stainless Steel for 2” NPT Mount and Larger
Float: Stainless Steel for 2 ½” NPT Mount and Larger
Float: Stainless Steel for 4” NPT Mount and Larger
2000-1513-0054
2000-2000-0052
2000-2026-0054
2000-2000-52XX
2000-2200-0054
2000-3500-0054
3
4
4
5
1
2

14 TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
3.5.4 Physical
3.6 MODEL CONFIGURATOR
TECHNOLOGY OUTPUT CONFIG. INPUT MOUNT
MAT’L FLOAT INDICATION LENGTH
& DEADBAND MOUNT MOD. RES.
T Transmitter 420 4-20
mA EExplosion-
Proof 12 12
VDC 08 316
S.S. 08 316
S.S. XXXY X” = Full Inches
Y” = Deadband 08 1 ½” NPT 0 None 25 1/4”
050 0-5
VDC E6 5/8” Tube 24 24
VDC 09 2” NPT 1 High-Level
Alarm 50 1/2”
150 1-5
VDC 10 3” NPT 2 Low-Level
Alarm
11 4” NPT 3 Hi/Lo Level
Alarm
12 2 ½” NPT
64 2 ½” Sanitary Flg.
65 3” Sanitary Flg.
66 4” Sanitary Flg.
72 1 ½” #150 ANSI Flg.
73 2” #150 ANSI Flg.
74 2 ½” #150 ANSI Flg.
75 3” #150 ANSI Flg.
76 4” #150 ANSI Flg.
83 1 ½” #300 ANSI Flg.
84 2” #300 ANSI Flg.
85 2 ½” #300 ANSI Flg.
86 3” #300 ANSI Flg.
87 4” #300 ANSI Flg.
T 4 2 0 E -2 4 -0 8 0 8 -1 2 0 3 -0 9 -1-2 5
Consult the manufacturer for special configurations, materials, mountings and alarm features: 203-729-6434.
FLOAT
SANITARY
FLANGE
¾” NPT
CONDUIT PORT
INDICATION
LENGTH
3 3⁄16”
FLOAT
ANSI #150 OR
#300 FLANGE
¾” NPT
CONDUIT PORT
INDICATION
LENGTH
4 ⅛”
FLOAT
1 ½” NPT
MOUNT
¾” NPT
CONDUIT PORT
INDICATION
LENGTH
4 12⁄16”SQUARE
OR HEX
NPT Threaded
Mount
Sanitary
Flange
ANSI #150 or
#300 Flange
DEADBAND
DEADBAND
DEADBAND

15
TR420E/E6 CONTINUOUS OUTPUT TRANSMITTER FOR HAZARDOUS LOCATIONS
3.7 NOTES

Service Policy
Owners of Solutions With Innovation products may
request a return of the product, or any part of the product
for complete rebuilding or replacement. Units will be
rebuilt or replaced promptly. Products returned under
the SWI Service Policy must be returned by prepaid
transportation. Solutions With Innovation will repair or
replace the product at no cost to the purchaser (or owner)
other than transportation if:
1 Returned within the warranty period; and
2 Factory Inspection nds the cause of the claim to be
covered under the warranty.
If the problem is due to circumstances beyond Solutions
With Innovation’s liability, or is NOT covered by the
warranty, there will be charges for labor in addition to the
parts required to rebuild or replace the equipment.
In rare cases, it may be expedient to ship replacement parts;
or in extreme cases, an entire product before the damaged
product is returned. If a quick replacement service is
necessary, notify the manufacturer of the damaged product’s
model and serial number. In such cases, credit for the
returned materials will be determined on the applicability
of the warranty.
No claims for misapplication, labor, direct or consequential
damage will be allowed.
Return Material Procedure
In order to efciently process any returned materials, it is
essential that a Return Material Authorization (RMA) number
be obtained from the manufacturer prior to an item’s return.
RMA’s can be issued through local representatives, or by
contacting the factory directly.
Please supply the following information:
1 The Company’s Name
2 Description of the Material
3 Product Serial Number
4 Reason for Return
5 Product’s Application
Used units must be properly cleaned in accordance with
OSHA standards before it is returned to the manufacturer.
A Material Safety Data Sheet (MSDS) must accompany units
or materials that were used in any type of media. All return
shipments to the factory must be by done via prepaid
transportation. All product replacements will be shipped
F.O.B. manufacturer.
ASSURED QUALITY & SERVICE COST LESS
BULLETIN: IS-9211.3
EFFECTIVE: 2/16
Table of contents
Popular Transmitter manuals by other brands

Dwyer Instruments
Dwyer Instruments ISDP series Specifications-installation and operating instructions

Wear & Hear
Wear & Hear HearLink Plus BT5805A user manual

Ashcroft
Ashcroft KX1 operating instructions

Traxxas
Traxxas DR-1 operating instructions

Warner RF
Warner RF FMT5.0-2U Series manual

AMIMON
AMIMON Sky Link AMN36254 user manual
