Dwyer Instruments ISDP series Installation and operating instructions

Bulletin A-25
Series ISDP Intrinsically Safe Differential Pressure Transmitter
Specifications - Installation and Operating Instructions
DWYER INSTRU ENTS, INC. Phone: [phone] www.dwyer-inst.com
P.O. BOX 373 • ICHIGAN CITY, IN 46360, U.S.A. Fax: [phone] e-mail: [email protected]
www. .com [e-mail]1.800.561.8187

25/32
[21.18]
1-15/16
[48.97]
1-5/16
[33]
1-17/32
[38.61] 45/64
[17.78]
5-7/32
[132.54]
4-23/32
[120]
3-7/16
[87.12] BRACKETS
ARE OPTIONAL
4X ø3/16 [4.76] CLEARANCE
HOLES FOR MOUNTING
3-17/64
[83]
MOUNTING HOLE
PATTERN
4-1/8
[105]
1-5/32
[29.59]
#8-36 SLOTTED MACHINE SCREW
#8 LOCK
WASHER
BRACKET ASSEMBLY
1-45/64
[43.18]
2-31/32
[75.39]
4-23/32
[120]
4-9/64
[105.17]
1
DI ENSIONS
OPTIONAL A-438 BRACKET
OUNTING DIAGRA
Shown with Optional A-438 ounting Bracket
www. .com [e-mail]1.800.561.8187

2
SPECIFICATIONS
Service: Air and non-corrosive gases.
Wetted aterials: Ranges 5˝ and greater: glass, PVC, silicon, alumina ceramic, epoxy,
RTV, gold, aluminum, stainless steel and nickel; Ranges 1˝ and lower: stainless steel,
silicone, gold and ceramic.
Housing aterials: Aluminum, glass.
Accuracy: ±0.5% at 77°F (25°C) including hysteresis and repeatability (after 1 hour
warm-up).
Stability: < ±1% per year.
Pressure Limits: Ranges ≤ 2.5 in. w.c. = 2 psi;
5˝: 5 psi; 10˝: 5 psi; 25˝: 5 psi; 50˝: 5 psi; 100˝: 9 psi.
Temperature Limits: 32 to 161.6°F (0 to 72°C).
Compensated Temperature Limits: 32 to 140°F (0 to 60°C).
Thermal Effects: 0.020%/°F (0.036/°C) from 77°F (25°C).
Power Requirements: 10-35 VDC.
Output Signal: 4-20 mA DC.
Zero & Span Adjustments: Accessible via menus.
Response Time: 250 ms (dampening set to 1).
Display: 4 digit LCD 0.6˝ height.
Electrical Connections: M12 4 P N Connector.
Process Connections: 1/8 female NPT.
Enclosure Rating: Designed to meet NEMA 4x ( P66).
ounting Orientation: Mount unit in horizontal plane.
Size: 4.73˝ x 4.73˝ x 3.43˝ (120 mm x 120 mm x 87.1 mm).
Weight: 2 lb 10 oz (1.19 kg).
Agency Approvals: FM Approved: S / , , / 1 / ABCDEFG / T4 Ta = 0°C to 72° - 19-
443480-50; ENT TY; TYPE 4X (US AND CANADA) / 0 AEx ia / C / T4 Ta = 0°C to 72°
- 19-443480-50; ENT TY; TYPE 4X (US) / 0 / Ex ia / C / T4 Ta = 0°C to 72° - 19-
443480-50; ENT TY; TYPE 4X (CANADA) CE. CENELEC EN 61326/55024: 2003; EC
61000-4-2/3/4/6: 2001/2006/2004/2005; CENELEC EN 55011: 2006; 2004/108/EC EMC
Directive.
Intrinsic Safety Information
Entity Parameters
Ui = 28VDC
i = 93mA
Ci = 22 nF
Li = 400 uH
Pi = 651mW
Notes:
1. Remove power from the instrument before carrying out any servicing.
2. Use only FM approved Associated Apparatus.
3. The earth terminal on the housing must be wired to a local earth ground in the
hazardous area.
4. Refer to control drawing 19-443480-50, Page 15, for installation requirements.
www. .com [e-mail]1.800.561.8187

MAXIMUM VALUE (1250Ω)
OPERATING 
REGION
R LMAX= Vps-10.0
20mA DC
VDC
05101315
20 25 30 35
TOT
AL RECEIVER RESISTANCE (Ω)
1500
1400
1300
1200
1100
1000
900
800
700
600
500
400
300
200
100
50
40
ISDP
TRANSMITTER
RECEIVER
POWER
SUPPLY
10-35 VDC
mA
3
-------2-Wire Operation- An external power supply delivering 10 - 35 VDC with minimum
current capability of 40 mA DC (per transmitter) must be used to power the control loop.
See Fig. C for connection of the power supply, transmitter, and receiver. The range of the
appropriate receiver load resistance (RL) for the DC power supply voltage available is
expressed by the formula and graph in Fig. D.
POWER SUPPLY VOLTAGE - VDC (2-WIRE CONNECTION)
A-231 M-12 Cable Colors
P N 1 is Brown (positive)
P N 3 is Blue (negative)
Use Model A-231 shielded cable with 4 pin Female M-12 connection.
-12 Connector
2-WIRE CONNECTION
Fig. C
3
2
1
4
+
Fig. D
www. .com [e-mail]1.800.561.8187

4
MENUMENU
EE
HO E POSITION
FUNCTION
Allows access to
the menus
Displays full scale
range of unit
AIN ENU
FUNCTION
Return to home
position
Sequences through menus
Sequences through menus
Enter into SUB MENU
SUB ENU
FUNCTION
Return to previous menu
ncrements a value
Decrements a value
Changes a value or
setting. Press ENTER and
display will blink. Adjust
with UP or DOWN arrows.
Press ENTER to store.
Display will stop blinking.
Peak/Valley SUB MENU
resets display to present
value.
MENU
UP
ARROW
DOWN
ARROW
ENTER
KEY FUNCTIONS
INSTALLATION
Mount the instrument in a location that will not be subject to excessive temperature, shock
or vibration.
Pressure Connections
Use 1/8˝ male NPT fittings. When tightening fittings, grasp the brass fitting on the SDP
with a 1/2˝ wrench to prevent the fitting on the SDP from turning.
www. .com [e-mail]1.800.561.8187

5
MENU MAPMENU MAP
CONTINUED
CONTINUED
SETTINGSSETTINGS
MAIN MENUS SUB MENUS
MENUS
UNAVAILABLE
FOR
BI-DIRECTIONAL
RANGES AND
RANGES ABOVE
25 IN. W.C.
EE
MENUMENU
ENU AP
MA N MENUS SUB MENUS SETT NGS
CONT NUED
MENUS
UNAVA LABLE
FOR
B -D RECT ONAL
RANGES AND
RANGES ABOVE
25 N. W.C.
www. .com [e-mail]1.800.561.8187

6
CONTINUEDCONTINUED
EE
MENUMENU
CONT NUED
www. .com [e-mail]1.800.561.8187

MAIN MENUS SUB MENUS SETTINGS
7
Menus present only
in pressure operation
EE
MENUMENU
MA N MENUS SUB MENUS SETT NGS
www. .com [e-mail]1.800.561.8187

8
ain enu Selections (Upper Right Display Reads MENU )
SECr Security - Lock out access to menus and settings.
OPEr Operation - Selection of Pressure, Velocity or Flow and corresponding
engineering units.
dS Display - Monitor and adjust display related settings: Peak, Valley, display
resolution, % output and dampening.
AdU Advanced functions - Modify advanced function parameters, transmitter
output scaling, and calibration.
odel Chart
odel
SDP-002
SDP-004
SDP-005
SDP-006
SDP-007
DSP-008
SDP-009
SDP-010
SDP-011
SDP-012
SDP-013
SDP-014
SDP-015
SDP-016
SDP-017
Range
0-0.25˝
0-1˝ WC
0-2.5˝ WC
0-5˝ WC
0-10˝ WC
0-25˝ WC
0-50˝ WC
0-100˝ WC
-0.1/+0.1˝ WC
-0.25/+0.25˝ WC
-0.5/+0.5˝ WC
-1.0/+1.0˝ WC
-2.5/+2.5˝ WC
-5.0/+5.0˝ WC
-10/+10˝ WC
www. .com [e-mail]1.800.561.8187

9
AIN ENUS and SUB ENUS
SECr (Security) AIN ENU
SECr is the only SUB MENU in the security MENU. When the security SUB MENU
is selected, the present security level is displayed in the upper right hand display. To
change the security level, adjust the number displayed to the number shown in the
following table for the desired security level.
The password values shown in the table cannot be altered, so retain a copy
of these pages for future reference.
OPEr (Operation) AIN ENU
The OPEr MENU selects the measurement type of the instrument.
The SUB MENUS are:
PrES - Pressure KFAC - K Factor XDIM - X Dimension
UEL - Velocity ArEA - Area YDIM - Y Dimension
FLO - Flow DIA - Diameter
f the instrument is set for Velocity, the
OPEr MENU will have an additional KFAC SUB
MENU. f the instrument is set for Flow, the
OPEr MENU will have additional KFAC and
ArEA SUB MENUS. These will be discussed under Velocity and Flow. When scrolling
through the
OPEr SUB MENUS, the measurement type the unit is currently set for will
show the units in the upper right display. The other measurement types will have a blank
upper right display.
Security Level
Displayed
1
2
Access
All menus access
All settings locked
Password Value
to Enter
10
70
Units visible, so unit
is presently set to
measure pressure
is presently set to
measure pressure
Units not visibleUnits not visible Units not visibleUnits not visible
www. .com [e-mail]1.800.561.8187

10
PrES (Pressure) SUB ENU
For pressure measurement, the following units are available:
Table 1 Pressure Range vs. Available Units
INWC
.1000
.2500
.5000
1.000
2.500
5.000
10.00
25.00
50.00
100.0
FTWC
.2083
.4167
.8333
2.083
4.167
8.333
WC
2.540
6.350
12.70
25.40
63.50
127.0
254.0
635.0
1270
2540
C WC
.2540
.6350
1.270
2.540
6.350
12.70
25.40
63.50
127.0
254.0
PSI
.1806
.3613
.9032
1.806
3.613
INHG
.1839
.3678
.7356
1.839
3.678
7.356
HG
.1868
.4671
.9342
1.868
4.671
9.342
18.68
46.71
93.42
186.8
BAR
.2491
.6227
1.245
2.491
6.227
12.45
24.91
62.27
124.5
249.1
PA
24.91
62.27
124.5
249.1
622.7
1245
2491
6227
KPA
.1245
.2491
.6227
1.245
2.491
6.227
12.45
24.91
HPA
.2491
.6227
1.245
2.491
6.227
12.45
24.91
62.27
124.5
249.1
OZIN
.1445
.2890
.5780
1.445
2.890
5.780
14.45
28.90
57.80
UEL (Velocity) SUB ENU
For velocity measurement, the following units are available:
SFPM - Standard feet per minute
M/S - Meters per second
Table 2 Available Velocity Ranges
NOTE: Air velocity and flow readings are based upon standard dry air conditions with an
ambient temperature of 70°F and a barometric pressure of 29.92 NHG.
INPUT RANGE INWC
0 - 0.1
0 - 0.25
0 - 0.5
0 - 1
0 - 2.5
0 - 5
0 - 10
0 - 25
SFP RANGE
0 - 1266
0 - 2002
0 - 2832
0 - 4004
0 - 6332
0 - 8954
0 - 12.66 x K
0 - 20.02 x K
/S RANGE
0 - 6.431
0 - 10.17
0 - 14.39
0 - 20.35
0 - 32.17
0 - 45.48
0 - 64.33
0 - 101.7
INWC - nches of water column
FTWC - Feet of water column
MMWC - Millimeters of water column
CMWC - Centimeters of water column
PSI - Pounds per square inch
INHG - nches of mercury
MMHG - Millimeters of mercury
MBAR - Millibar
PA - Pascal
KPA - Kilopascals
HPA - Hectopascals
OZIN - Ounce inches
NOTE: OVFL (over flow) or UnFL (under flow) will appear when the ranges have been
exceeded above or below full scale by 2%.
www. .com [e-mail]1.800.561.8187

FLO (Flow) SUB ENU
For flow measurements the following units are available:
SCFM - Standard cubic feet per minute
M^3H - Cubic meters per hour
FLO r (Flow Range) SUB ENU
LO - 99.99 x 1K flow range
HI - 999.9 x 1K flow range
Tables 3 -6 show the flow ranges available, and the maximum duct size that can be set for
each input range.
Table 3
FLOr = LO aximum Duct Size (English)
RANGE
IN WC
0.1
0.25
0.5
1
2.5
5
10
25
SCF
RANGE
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
AX. DUCT
SIZE, SQ. FT.
78.9
49.9
35.3
24.9
15.7
11.1
7.8
4.9
Table 4
FLOr = HI aximum Duct Size (English)
RANGE
IN WC
0.1
0.25
0.5
1
2.5
5
10
25
SCF
RANGE
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
AX. DUCT
SIZE, SQ. FT.
789.8
499.5
353.1
249.7
157.9
111.7
78.9
49.9
Table 5
FLOr = LO aximum Duct Size ( etric)
RANGE
IN WC
0.1
0.25
0.5
1
2.5
5
10
25
ˆ3/Hr
RANGE
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
99.99 x 1K
AX. DUCT
SIZE ˆ2
4.32
2.73
1.93
1.37
0.86
0.61
0.43
0.27
Table 6
FLOr = HI aximum Duct Size ( etric)
RANGE
IN WC
0.1
0.25
0.5
1
2.5
5
10
25
ˆ3/Hr
Range
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
999.9 x 1K
AX. DUCT
SIZE, ˆ2
43.19
27.31
19.3
13.64
8.63
6.10
4.31
2.73
KFAC SUB ENU
KFAC K Factor - becomes accessible if the instrument is set for Velocity or Flow. When
the Digihelic® Controller is used with a Pitot tube, the manufacturer may specify a K
Factor. The adjustment range is 0.01 to 2.00. The factory setting is 1.
11
www. .com [e-mail]1.800.561.8187

12
ArEA , DIA , XDIM and YDIM SUB ENUS
These SUB MENUS become accessible if the instrument is set for flow. When measuring
flow, the area of the duct must be specified. Tables 3 and 4 show the input range vs
maximum flow and duct size. For a rectangular duct the maximum size is specified in
square feet or meters. For a circular duct the maximum size is specified as the diameter.
X, Y and circular dimensions are entered in feet with 0.01 foot resolution for
FLOr = LO and
0.1 foot resolution for
FLOr = HI , or entered in millimeters with 1 millimeter resolution.
ArEA - Area, select CIR for a circular duct or RECT for a rectangular duct. f a
circular duct is selected, the
DIA SUB MENU will be activated. f a rectangular duct is
selected, the
XDIM and YDIM SUB MENUS will be activated.
DIA - Diameter, enter the diameter of a duct
XDIM - Enter the “X” dimension of a duct
YDIM - Enter the “Y” dimension of a duct
d.S (Display) AIN ENU
PEAK - Peak value rESO - Resolution
VALy - Valley value Pd.S - Process display
ZERO - Zero DAMP - Dampening level
PEAK (Peak) SUB ENU
The Peak feature stores the highest pressure reading the instrument has measured
since the last reset or power up. At power up
PEAK is reset to the present
pressure reading. To manually reset the
PEAK value, press the ENTER key while in
the
PEAK SUB MENU.
VALy (Valley) SUB ENU
The valley feature stores the lowest pressure reading the instrument has measured
since the last reset or power up. At power up
VALy is reset to the present
pressure reading. To manually reset the
VALy value, press the ENTER key while in
the
VALy SUB MENU.
Y
X
www. .com [e-mail]1.800.561.8187

13
rESO (Resolution) SUB ENU
The Series SDP Controller is capable of displaying four digits of resolution.
However, at very low pressures the instability of the pressure may cause
fluctuations in the least significant digit causing the least significant digit to be of
little value.
Three digit resolution (
3DIG ) can only be active when there is at least one digit to
the right of a decimal.
3DIG - Set display for 3 digit resolution
4DIG - Set display for 4 digit resolution
Pd.S (Process Display) SUB ENU
STD - Display reads pressure, velocity, or flow values
PCT - Display reads % of full scale value
When the display is reading percent,
PCT is displayed in the upper right of the
display. The percent display is only available in pressure operation.
DAMP (Dampening) SUB ENU
Adjust from 1-16
Dampening stabilizes the display from instabilities due to things such as vibration
and excessive pressure fluctuations. The dampening setting adjusts the amount of
readings that are averaged for each display update. Adjust the dampening value
until the display reads a stable value for the application.
AdU (Advanced) AIN ENU
POL - Process output low
POH - Process output high
ZERO - Zero calibration
SPAN - Span calibration
POL and POH (Process Output Low and High) SUB ENUS
This feature is used in pressure operation only.
Process output low and high are used to scale the 4-20 mA output. Set
POL to the
desired display reading for 4mA output, and set
POH to the desired display
reading for 20 mA output.
POH must be higher than POL . POL may be adjusted 2%
BELOW minimum scale up to
POH . POH may be adjusted from POL to 2% ABOVE
maximum scale.
www. .com [e-mail]1.800.561.8187

ZERO and SPAN (Calibration of Zero and Span) SUB ENUS
The lower display reads CAL in this mode.
ZERO Calibration
NOTE: For accurate calibration, DO NOT apply any pressure when performing
this function.
With the display reading
ZERO , press the ENTER key. The upper display will blink.
Press ENTER again to complete the zeroing of the instrument or press the
MENU
key to cancel.
SPAN Calibration
With the display set to SPAN , apply full scale pressure to the unit. Press the ENTER
key. The upper display will blink. Press ENTER again to complete the calibration or
press the
MENU key to cancel.
aintenance
Upon final installation of the Series SDP intrinsically Safe Differential Pressure
Transmitter, no routine maintenance is required. The Series SDP is not field serviceable
and should not be returned if repair is needed (field repair should not be attempted and
may void warranty). Be sure to include a brief description of the problem plus any
relevant application notes. Contact customer service to receive a return goods
authorization number before shipping.
14
www. .com [e-mail]1.800.561.8187

DWYER INSTRU ENTS, INC. Phone: [phone] www.dwyer-inst.com
P.O. BOX 373 • ICHIGAN CITY, IN 46360, U.S.A. Fax: [phone] e-mail: [email protected]
©Copyright 2014 Dwyer nstruments, nc. Printed in U.S.A. 12/14 FR# 19-443480-00 Rev. 3
ACAD2002
parties for examination without the written consent of said corporation.
to be communicated, disclosed, reproduced or used except as previously authorized in writing by such corporation and must not be submitted to outside NOTICE: This drawing and the principles and elements of design embodied therein are the exclusive property of DWYER INSTRUMENTS, INC. and are not
FR.NO.
ALL ANGLES ± ALL DECIMAL DIMENSIONS ±
STANDARD TOLERANCES UNLESS NOTED:
NO. BY/DATECHANGES
APPD CHKD
DWN BY
NAMEDATE MATERIAL
FINISH
MICHIGAN CITY, INDIANA 46360 U.S.A.
3
CD = CRITICAL DIMENSION
19-443480-50
19-443480-50
19-443480-50
01-02-08
KAS CAR
LRR
FM CONTROL DRAWING
ISDP
SCALE 1:1
1CLASS II AND CLASS III RATINGS
REMOVED ITEM 6 PER ECR #22759
KAS
01-15-08
2ADDED CLASS II AND III RATINGS PER ECR #23754
AJB
8-6-08
3REVISED NOTE 3 TO ADD CANADIAN ELECTRICAL CODE PER ECR #25003
KAS
05-05-09
4UPDATE TO ZONES PER DWK 06-11-14, ECR 35481
PFA
6-23-14
1°
.005
CATALOG NUMBERS
ISDP-001 THROUGH ISDP-017
HAZARDOUS (CLASSIFIED) LOCATION
INTRINSICALLY SAFE FOR:
CLASS I DIV. 1 GROUPS A, B, C, D
T4 Ta 0°C TO 72°C TYPE 4X
OR 1. THE INTRINSIC SAFETY ENTITY CONCEPT ALLOWS THE INTERCONNECTION OF TWO FM APPROVED INTRINSICALLY SAFE DEVICES
WITH ENTITY PARAMETERS NOT SPECIFICALLY EXAMINED IN COMBINATION AS A SYSTEM WHEN:
Voc OR Uo OR Vt < Vmax, Isc OR It < Imax< Ca OR Co > Ci + Ccable, La OR Lo > Li + Lcable, Po < Pi
2. EQUIPMENT CONNECTED TO THE ASSOCIATED APPARATUS MUST NOT USE OR GENERATE MORE THAN 250 Vrms OR VDC.
3. DIVISION 1 HAZARDOUS (CLASSIFIED) LOCATIONS INSTALLATIONS MUST BE IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE NFPA 70, ARTICLE 504;
4. NO REVISIONS WITHOUT PRIOR APPROVAL FROM FM RESEARCH.
5. THE ASSOCIATED APPARATUS MANUFACTURERS INSTALLATION INSTRUCTIONS MUST BE FOLLOWED WHEN INSTALLING THIS EQUIPMENT.
ISDP SERIES TRANSMITTER
Vmax = 28VDC
Imax = 93mA
Ci = 22nF
Li = 400uH Pi = 651mW
+ -
+ -
FM APPROVED ASSOCIATED APPARATUS
OPTIONAL SHIELD
NON-HAZARDOUS LOCATION I.S. SAFETY
GROUND
CLASS II DIV. 1 GROUPS E, F, G
CLASS III DIV. I
ZONE 0 HAZARDOUS LOCATIONS MUST BE IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE NFPA 70, ARTICLE 505; IN US. INSTALLATIONS MUST BE
CLASS I, ZONE 0, GROUPS IIC
T4 Ta 0°C TO 72°C TYPE 4X
IN ACCORDANCE WITH THE CANADIAN ELECTRICAL CODE CSA C22.1, PART 1, APPENDIX F; IN CANADA. ALL INSTALLATIONS MUST BE IN ACCORDANCE
WITH ISA RP-12.6.
6. WARNING - ENCLOSURE PARTS ARE CONSTRUCTED OF ALUMINUM. ENCLOSURE MUST BE PROTECTED FROM MECHANICAL FRICTION AND IMPACT WITH
IRON/STEEL TO PREVENT IGNITION CAPABLE SPARKS.
7. SUBSTITUTION OF PARTS MAY IMPAIR INTRINSIC SAFETY. RETURN TO MANUFACTURER FOR ANY REPAIRS.
8. ADDITIONAL SUFFIXES AT (ALUMINUM TAG), COO (CERTIFICATE OF ORGIN), FC (FACTORY CALIBRATION CERTIFICATE), NIST (NIST TRACEABLE)
www. .com [e-mail]1.800.561.8187
