Swift 2002 MH User manual

Swift Motorhome Owner’s
Service Handbook

Motorhome Details
IMPORTANT Enter all your motorhome details on this page (see specification in this handbook).
Supplied and Pre-delivery Inspection by:
Registration Number
Serial Number
Chassis Number
Delivery Date
Key Number
Overall Length
Overall Width
Maximum External Height
Mass in Running Order
User Payload
Maximum Technical Permissible Laden Mass
Tyre Size Front: Rear:
Service History
Signed/Dealer Date

CONTENTS
Annual Inspection Record.................................................2
Annual Servicing Record..................................................4
Warranty............................................................................7
Specifications....................................................................8
Water Capacities.............................................................10
Jacking............................................................................11
Wiring Diagrams..............................................................12
Bulb Replacement ..........................................................16
Owners Club ...................................................................18
Change of Ownership .....................................................19

Annual Inspection
MOTORHOMES - ANNUAL INSPECTION RECORD
In order to comply with the warranty, you must have your motorhome inspected and
serviced by an authorised Swift Group Service Centre at least once per year.
It is important that the owner’s handbook is stamped on the appropriate page by the
authorised Swift Group Service Centre. Failure to do this will invalidate the warranty and the
transfer of the warranty on the change of ownership.
The inspection should take approximately two hours and will cover the areas dealt with in
the annual service check list. Any areas requiring service and/or maintenance will be
highlighted by your dealer and we recommend that you authorise any necessary work to be
carried out.
NB. It is essential, to validate the warranty, that an annual inspection be carried out by an
authorised Swift Group Service Centre covering the items listed.
1. Damp and lamination test.
2. Chassis and chassis to body security.
3. Corner steadies.
4. Motorhome step.
5. Road lights, wiring and reflectors.
6. Internal lights and 12V DC system.
7. Water heater - gas and 230V AC.
8. Hob, grill and oven.
9. Refrigerator 230V AC, 12V DC
and gas.
10. Gas system.
11. Water pump, taps and water system.
12. Mains 230V AC system.
13. Windows and fittings.
14. Roof lights.
15. Furniture hinges/stays etc.
16. Exterior locks and hinges.
17. All internal vents.
18. Seals.
19. Blinds and fly screens.
20. Blown air heating and gas fire systems.
2

Inspection Record
ANNUAL INSPECTION RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
3
1st INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
2nd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
3rd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
4th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
5th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
6th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.

Servicing
4
MOTORHOMES - ANNUAL SERVICE RECORD
Just as the engine/gearbox/roadwheels need regular servicing by your chassis dealer,
so there are components in your conversion that need regular maintenance by your
motorhome dealer.
These include the gas and electrical systems and the seals in the bodywork. Your dealer
will complete the record in this handbook to show that the work has been carried out.
1. Chassis and chassis to body security.
2. Corner steadies.
3. Motorhome step.
4. Tyres and tyre pressures.
5. Torque wheel nuts.
6. Road lights, wiring and reflectors.
7. Internal lights and 12V DC system.
8. Damp and lamination test.
9. Water heater — gas and 230V AC.
10. Hob, grill and oven.
11. Refrigerator 230V AC, 12V DC
and gas.
12. Gas system.
13. Water pump, taps and water system.
14. Mains 230V AC system.
15. Windows and fittings.
16. Roof lights.
17. Furniture hinges/stays etc.
18. Exterior locks and hinges.
19. All internal vents.
20. Seals.
21. Blinds and fly screens.
22. Blown air heating and gas fire systems.

Service Record
5
ANNUAL SERVICE RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
1st SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
2nd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
3rd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
4th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

6
5th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
6th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
7th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
8th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
9th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
10th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

Warranty
All the illustrations and descriptive matter in
this handbook are intended to give a
general idea of the motorhome. Changing
market and supply situations and our policy
of continuous product development may
prevent us from maintaining the exact
specifications detailed in this handbook.
We therefore reserve the right to alter
specifications as materials and conditions
demand.
Dealers are not agents of Swift Group
Limited, the manufacturer of Swift Group
motorhomes, and have absolutely no
authority to bind the manufacturer by any
express or implied undertaking or
representation.
All motorhomes (other than the engine,
chassis cab and associated parts referred
to earlier in this handbook which are
subject to the relevant chassis
manufacturer's warranty) have a 3 year
SuperSure warranty from the date of
purchase (or hire purchase), which is
subject to a chargeable annual service and
inspection being carried out at an
authorised Swift Group Service Centre.
In the first 12 months this covers faults
arising from a manufacturing defect but not
those which are a result of normal wear and
tear. The manufacturer will honour the
warranty until 36 months from the date of
sale, and providing that the motorhome has
been serviced annually within 90 days
before or 30 days after the anniversary of
the original sale. The third service must,
however, be carried out before the expiry of
the 36 month period from the original date
of sale.
In years two and three the warranty will
cover:
i) All original components of the motorhome
conversion including permanently fitted
equipment forming part of the
manufacturer’s original specification.
ii) Water ingress and body delamination.
Specific exclusions to SuperSure
warranty:
Glass, paint, brightwork and all similar trim
and finish. Soft furnishings, carpets, floor
coverings, work surfaces and all other
décor. Window catches, stays and
associated fittings. Blinds, hinges, catches,
stays and doors. Replacement of bulbs,
fluorescent tubes, fuses and electrical
connections. Natural movement of internal
doors and furniture. Audio equipment. Fair
wear and tear.
The warranty will be invalidated if the
motorhome has been neglected, misused
or modified. The warranty on all internal
components will be invalidated if the
motorhome has been used for hire or
reward. The motorhome will be deemed to
have been neglected if it has not been
serviced and maintained as stated in this
handbook.
The warranty only applies to motorhomes
purchased and used within the UK, and for
continuous journeys abroad of no longer than
90 days per journey.
The cost of transporting, towing or moving the
motorhome by any means to or from the place
of repair is the responsibility of the owner.
The benefit of this warranty may be transferred
to a new owner if the motorhome is sold,
provided that the motorhome has been
serviced by an authorised service centre in
accordance with the requirements of this
handbook, and details of the change of
ownership have been supplied to Swift using
the change of ownership form set out in this
handbook. Failure to notify Swift of a change
of ownership within 14 days of such change
will invalidate the warranty.
This warranty only applies to motorhomes
purchased in the UK.
The above conditions in no way affect your
statutory rights in respect of the motorhome.
7

Specification
8
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTOR CARAVAN,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
3. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICALLY PERMISSIBLE LADEN MASS OF THIS MOTOR CARAVAN BE EXCEEDED.
*Estimated
MODEL Mondial GT Sundance 530S Sundance 530L Sundance 590RL Sundance 590RS Sundance 600S Sundance 630L Sundance 630G
Designated Passenger Seats 2 2 1 1 3 3 3 1 (plus 2 opt)
Overall Length 5.01m/16'6" 5.53m/18'1" 5.53m/18'1" 6.10m/20'0" 6.10m/20'0" 6.10m/20'0" 6.93m/22'8" 6.93m/22'8"
Overall Width (mirrors folded) 2.18m/7'2" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3"
Overall Height 2.66m/8'9" 3.10m/10'1" 3.10m/10'1" 3.10m/10'1" 3.10m/10'1" 3.10m/10'1" 3.10m/10'1" 3.10m/10'1"
Maximum Technical 2900kg 3000kg 3000kg 3400kg 3400kg 3400kg 3400kg 3400kg
Permissible Laden Mass (A) (3850kg opt)
Mass in Running Order (B) 2414kg 2547kg 2547kg 2632kg 2663kg 2688kg* 2850kg* 2943kg (2993kg opt)
Maximum User Payload (A-B) 486kg 453kg 453kg 768kg 737kg 712kg* 550kg* 457kg (857kg opt)
Essential Habitation Equipment 87kg 133kg 133kg 133kg 133kg 133kg 133kg 133kg
BED SIZES
Front Double 1.76m x 1.46m 2.09m x 1.33m 2.09m x 1.33m -1.87m x 1.20m 1.87m x 1.20m 1.87m x 1.20m 1.87m x 1.20m
5'8" x 4'9" 6'10" x 4'4" 6'10" x 4'4" 6'2" x 4'0" 6'2" x 4'0" 6'2" x 4'0" 6'2" x 4'0"
Front Single - - - - 1.87m x 0.66m - - -
6’2” x 2’2”
Front Single - - - - 1.87m x 0.87m 1.87m x 0.87m 1.87m x 0.87m 1.87m x 0.87m
6'2" x 2'10" 6'2" x 2'10" 6'2" x 2'10" 6'2" x 2'10"
Rear Double - - - 2.09m x 1.39m - - 2.09m x 1.39m 2.03m x 1.37m
6'10" x 4'7" 6'10" x 4'7" 6'8"x 4'6"
Nearside Single 1.83m x 0.66m - - - - - - -
6'0" x 2'2"
Offside Single 1.83m x 0.56m - - - - - - -
6'0" x 1'10"
Overcab Bed -2.09m x 1.33m 2.09m x 1.33m 2.09m x 1.33m 2.09m x 1.33m 2.09m x 1.33m 2.09m x 1.33m 2.09m x 1.33m
6'10" x 4'4" 6'10" x 4'4" 6'10" x 4'4" 6'10" x 4'4" 6'10" x 4'4" 6'10" x 4'4" 6'10" x 4'4"

Specification
9
*Estimated
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTORHOME,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
3. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICALLY PERMISSIBLE LADEN MASS OF THIS MOTORHOME BE EXCEEDED.
MODEL Gazelle F59 Gazelle F61 Gazelle F63 Gazelle F59 Highline Gazelle F63 Highline Kon-Tiki L Kon-Tiki S Kon-Tiki Z
Designated Passenger Seats 3 1 2 (plus 1 opt) 3 3 3 2 2
Overall Length 5.90m/19'5" 6.30m/20'8" 7.13m/23'4" 5.95m/19'6 7.13m/23'4"* 7.25m/24'0" 6.95m/23'0" 7.25m/24'0"
Overall Width (mirrors folded) 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3"
Overall Height 2.90m/9'6" 2.90m/9'6" 2.90m/9'6" 3.03m/9'11" 3.03m/9'11" 2.98m/9'9" 2.98m/9'9" 2.98m/9'9"
Maximum Technical 3400kg 3400kg 3400kg 3400kg 3850kg 3850kg 3850kg 3850kg
Permissible Laden Mass (A) (3850kg option) (3850kg option)
Mass in Running Order (B) 2784kg 2803kg* 2953kg 2835kg 3098kg 3153kg* 3092kg* 3091kg
(3003 option) (2885kg option)
Maximum User Payload (A-B) 616kg 597kg* 447kg 565kg 752kg 697kg 758kg* 759kg
(847kg option) (965kg option)
Essential Habitation Equipment 128kg 128kg 151kg 180kg 180kg 160kg 160kg 158kg
BED SIZES
Front Double 1.87m x 2.05m -1.89m x 1.20m 1.87m x 2.05m -1.87m x 1.28m 2.05m x 1.79 -
6'2" x 6'9' 6'2" x 3'11" 6'2" x 6'9" 6'2" x 4'2" 6'9" x 5'10"
Front Single 1.87m x 0.69m -1.87m x 0.87m 1.87m x 0.65m - - 1.89m x 0.98m -
6'2' x 2'2' 6'2" x 2'10" 6'2' x 2'2" 6'3" x 3'3"
Front Single 1.87m x 0.87m - - 1.87m x 0.87m 1.87m x 0.90m -1.79m x 0.68m -
6'2" x 2'10" 6'2" x 2'10" 6'2" x 2'11" 5'11" x 2'3"
Rear Double -1.89m x 2.05m 2.05m x 1.35m -1.91m x 1.46m 2.05m x 1.40m -1.97m x 1.40m
6'3" x 6'9" 6'9" x 4'5" 6'3" x 4'9" 6'9" x 4'7" 6'6" x 4'7"
Rear Single -1.89m x 0.71 - - - 1.89m x 0.71m - -
6'3" x 2'4" 6'3" x 2'4"
Rear Single -1.89m x 0.71 - - - 1.90m x 0.67m - -
6'3" x 2'4" 6'3" x 2'2"
Overcab Bed 1.98m x 1.30m 1.98m x 1.30m 1.98m x 1.30m 2.05m x 1.36m 2.05m x 1.36m 1.90m x 0.67m 1.90m x 0.67m 1.90m x 0.67m
6'6" x 4'3" 6'6" x 4'3" 6'6" x 4'3" 6'9" x 4'6" 6'9" x 4'6" 6'3" x 2'2" 6'3" x 2'2" 6'3" x 2'2"

Water Capacities
10
CAPACITIES (litres) Fresh Water Tank Waste Water Tank Water Heater
Mondial 59 41 10
Sundance 100 80 10
Gazelle 100 80 10
High Gazelle 130 130 12
Kon-Tiki S and L 106 80 14
Kon-Tiki Z 106 80 12
NOTICE
For technical data on the base vehicle please refer to the manufacturer's handbook

Jacking
11
SUNDANCE
KON-TIKI
MONDIAL
GAZELLE
Jacking Points:

Wiring Diagrams
12
MONDIAL RANGE

Wiring Diagrams
13
SUNDANCE RANGE

Wiring Diagrams
GAZELLE RANGE
14

Wiring Diagrams
KON-TIKI RANGE
15

Bulb Replacement
16
Type Power Mondial Sundance Gazelle Kon-Tiki
Exterior Lights
Fiat Cab
Full beam headlight H4 12V-55/60W ✓ ✓ ✓ ✓
Dipped beam headlight H4 12V-55/60W ✓ ✓ ✓ ✓
Front side lights R5W 12V-5W ✓ ✓ ✓ ✓
Front directional indicators P21W 12V-21W ✓ ✓ ✓ ✓
Side directional indicators W5W 12V-5W ✓ ✓ ✓
Fiat Rear Light Cluster (Chassis Cab)
Rear directional indicators PY21W 12V-21W ✓ ✓
Brake lights P21W 12V-21W ✓ ✓
Reversing lights (RH side) P21W 12V-21W ✓ ✓
Rear foglight (LH side) P21W 12V-21W ✓ ✓
Side light R5W 12V-5W ✓ ✓
Fiat Rear Light Cluster (Hightop)
Rear directional indicators PY21W 12V-21W ✓
Brake lights P21W 12V-21W ✓
Reversing lights P21W 12V-21W ✓
Rear foglight/taillight (Twin bulb) P21/4W 12V-21/4W ✓
Britax Valeo Rear Light Cluster
Rear directional indicator P21W 12V-21W ✓
Stop lamp P21W 12V-21W ✓
Position Lamp R10W 12V-10W ✓
Reverse lamp P21W 12V-21W ✓
Fog lamp P21W 12V-21W ✓
Note: Not all lights and bulbs feature on all models within a range

Bulb Replacement
17
Type Power Mondial Sundance Gazelle Kon-Tiki
EXTERIOR LIGHTS
Number plate lights
Fiat number plate light CW5 12V-5W ✓ ✓
Number plate light R19-10W 12V-10W ✓
Number plate light C11-5W 12V-5W ✓
Exterior lights
Front marker light W5W 12V-5W ✓
Rear marker light W5W 12V-5W ✓
Red/white side marker light C5W 12V-5W ✓ ✓
Amber side marker light W5W 12V-5W ✓ ✓
Awning light P21W 12V-21W ✓ ✓ ✓
INTERIOR LIGHTS
Ceiling light Halogen G4 Bi-Pin 12V-10W ✓ ✓ ✓
Downlight (switched) Halogen G4 Bi-Pin 12V-10W ✓ ✓ ✓
Adjustable downlight Halogen G4 Bi-Pin 12V-10W ✓ ✓ ✓
Spotlight Halogen G4 Bi-Pin 12V-5W ✓ ✓ ✓
Wardrobe/cocktail cabinet light Halogen G4 Bi-Pin 12V-5W ✓
Cab interior ceiling light CW5 12V-10W ✓ ✓ ✓ ✓
Cab rear door light CW10 12V-15W ✓
Note: Not all lights and bulbs feature on all models within a range

SWIFT MOTORHOME
OWNERS CLUB
Congratulations on your choice of
motorhome. Now that you are the proud
owner of a Swift Motorhome, perhaps you
would like to consider spending the
occasional weekend or holiday in the
company of other proud Swift Motorhome
owners. For details of the Motorhome
Owners Club contact:
Customer Services Dept.
Swift Group Limited,
Dunswell Road,
Cottingham,
Hull,
East Yorkshire HU16 4JX
18
Owners Club
