Swift Mondial GT User manual

Swift Motorhome Owner's
Service Handbook

Motorhome Details
IMPORTANT Enter all your motorhome details on this page (see specification in rear of this handbook).
Supplied and Pre-delivery Inspection by:
Registration Number
Registration Date
Delivery Date
Chassis Number
Body Number
Key Number
Overall Length
Overall Width
Maximum External Height
Mass in Running Order
User Payload
Maximum Technical Permissible Laden Mass
Tyre Size Front: Rear:
Service History
Signed/Dealer Date

CONTENTS
Annual Inspection Record.................................................2
Annual Servicing Record..................................................4
Warranty............................................................................7
Specifications....................................................................8
Water Capacities.............................................................10
Jacking............................................................................11
Wiring Diagrams..............................................................13
Bulb Replacement ..........................................................19
Owners Club ...................................................................21
Change of Ownership

Annual Inspection
MOTORHOMES - ANNUAL INSPECTION RECORD
In order to comply with the warranty, you must have your motorhome inspected and
serviced by an authorised appointed Swift Group Dealer at least once per year.
It is important that the owner’s handbook is stamped on the appropriate page by the
appointed Swift Group Servicing Dealer. Failure to do this will invalidate the warranty and
the transfer of the warranty on the change of ownership.
The inspection should take approximately two hours and will cover the areas dealt with in
the annual service check list. Any areas requiring service and/or maintenance will be
highlighted by your dealer and we recommend that you authorise any necessary work to be
carried out.
NB. It is essential, to validate the warranty, that an annual inspection be carried out by an
appointed Swift Group Dealer covering the items listed.
1. Damp and lamination test.
2. Chassis and chassis to body security.
3. Corner steadies.
4. Motorhome step.
5. Road lights, wiring and reflectors.
6. Internal lights and 12V DC system.
7. Water heater - gas and 240V AC.
8. Hob, grill and oven.
9. Refrigerator 240V AC, 12V DC
and gas.
10. Gas system.
11. Water pump, taps and water system.
12. Mains 240V AC system.
13. Windows and fittings.
14. Roof lights.
15. Furniture hinges/stays etc.
16. Exterior locks and hinges.
17. All internal vents.
18. Seals.
19. Blinds and fly screens.
20. Blown air heating and gas fire systems.
2

Inspection Record
ANNUAL INSPECTION RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
3
1st INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
2nd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
3rd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
4th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
5th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
6th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.

Servicing
MOTORHOMES - ANNUAL SERVICE RECORD
Just as the engine/gearbox/roadwheels need regular servicing by your Peugeot/Fiat/VW
dealer, so there are components in your conversion that need regular maintenance by your
motorhome dealer.
These include the gas and electrical systems and the seals in the bodywork. Your dealer
will complete the record in this handbook to show that the work has been carried out.
4
1. Damp and lamination test.
2. Chassis and chassis to body security.
3. Corner steadies.
4. Motorhome step.
5. Road lights, wiring and reflectors.
6. Internal lights and 12V DC system.
7. Water heater — gas and 240V AC.
8. Hob, grill and oven.
9. Refrigerator 240V AC, 12V DC
and gas.
10. Gas system.
11. Water pump, taps and water system.
12. Mains 240V AC system.
13. Windows and fittings.
14. Roof lights.
15. Furniture hinges/stays etc.
16. Exterior locks and hinges.
17. All internal vents.
18. Seals.
19. Blinds and fly screens (if fitted).
20. Blown air heating and gas fire systems.

Service Record
5
ANNUAL SERVICE RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
1st SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
2nd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
3rd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
4th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

6
5th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
6th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
7th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
8th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
9th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
10th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

Warranty
All the illustrations and descriptive matter in
this service handbook are intended to give
a general idea of the motorhome. Changing
market and supply situations and our policy
of continuous product development may
prevent us from maintaining the exact
specifications detailed in this service
handbook. We therefore reserve the right to
alter specifications as materials and
conditions demand.
Dealers are not agents of Swift Group
Limited, and have absolutely no authority to
bind the manufacturer by any express or
implied undertaking or representation.
All motorhomes (other than the engine,
chassis cab and associated parts referred
to earlier in this handbook which are
subject to the relevant Fiat/Peugeot/VAG
warranty) have a 12 month warranty from
the date of purchase (or hire purchase). This
covers faults arising from a manufacturing
defect but not those which are a result of
normal wear and tear. The manufacturer will
honour the warranty for up to 60 days after
the end of the 12 months to enable the first
chargeable annual service to be carried out
and the SuperSure extended warranty (see
below) to commence.
The warranty will be invalidated if the
motorhome has been neglected, misused,
modified or used for hire or reward. The
motorhome will be deemed to have been
neglected if it has not been serviced and
maintained as stated in this handbook.
Every owner of a new motorhome benefits
automatically from the SuperSure extended
warranty, covering the conversion element
of the motorhome, (i.e. other than the
engine, chassis cab and associated parts
referred to earlier in this handbook which
are subject to the relevant
Fiat/Peugeot/VAG warranty) for years 2 and
3 from the date of purchase. The detailed
terms of the extended warranty are set out
in the separate SuperSure policy document.
Your dealer should register you for cover
under the SuperSure extended warranty at
the time your new motorhome is handed
over to you. It is important to check this
registration has been completed to confirm
that the motorhome is registered under the
SuperSure Extended Warranty Scheme for
years 2 & 3.
The cost of transporting, towing or moving the
motorhome by any means to or from the place
of repair is the responsibility of the owner.
The benefit of this warranty may be transferred
to a new owner if the motorhome is sold,
provided that the motorhome has been
serviced by an authorised dealer in
accordance with the requirements of this
handbook, and details of the change of
ownership form set out in this handbook.
Failure to notify a change of ownership within
14 days of such change will invalidate the
warranty.
The benefit of the SuperSure extended
warranty may be transferred to a new owner if
the motorhome is sold in accordance with the
procedure detailed in the separate SuperSure
policy document.
This warranty only applies to motorhomes
purchased in the UK.
The above conditions in no way affect your
statutory rights in respect of the motorhome.
7

Specification
8
*Estimated
MODEL Mondial GT Mondial RL Sundance 500 Sundance 520 Sundance 590RL Sundance 590RS Sundance 620 Royale 590 Royale 610
Designated Passenger Seats 2 1 1 3 1 3 3 3 1
Number of Berths 2 2 4 4 4 4 6 4 4
Overall Length 5.19m/17’1” 5.19m/17’1” 5.25m/17’3” 5.25m/17’3” 5.92m/19’5” 5.92m/19’5” 6.50m/21'4" 5.91m/19'5" 6.25m/20'6"
Overall Width 2.11m/6’10” 2.11m/6’10” 2.13m/7’0” 2.13m/7’0” 2.13m/7’0” 2.13m/7’0” 2.13m/7’0” 2.13m/7'0" 2.13m/7'0"
Overall Height 2.66m/8’9” 2.66m/8’9” 2.83m/9’3” 2.83m/9’3” 2.83m/9’3” 2.83m/9’3” 2.83m/9’3” 2.93m/9'7" 2.93m/9'7"
Maximum Technical 2800kgs 2800kgs 3000kgs 3000kgs 3400kgs 3400kgs 3400kgs 3400kgs 3400kgs
Permissible Laden Mass (A)
Mass in Running Order (B) 2405kgs 2385kgs 2376kgs 2433kgs 2573kgs 2649kgs 2749kg* 2757kgs 2778kgs
Maximum User Payload (A-B) 395kg 415kg 625kg 567kg 827kg 751kg 651kg* 643kg 622kg
Essential Habitation Equipment 100kgs 100kgs 120kgs 125kgs 143kgs 143kgs 143kg* 143kgs 152kgs
BED SIZES
Front Double 1.83m x 1.78m - - 189m x 1.20m -1.89m x 1.20m 1.89m x 1.20m 1.89m x 2.00m -
6'0" x 5'10" 6'3" x 4'0" 6'3" x 4'0" 6'3" x 4'0" 6'3" x 6'7"
Front Single - - - - - 1.89m x 0.69m -1.89m x 0.69m -
6'3" x 2'3" 6'3" x 2'3"
Front Single - - - - - 1.89m x 0.90m -1.89m x 0.90m -
6'3" x 2'11" 6'3" x 2'11"
Rear Double -1.83m x 1.22m 2.01m x 1.20m -2.01m x 1.30m - - - 1.89m x 2.00m
6'0" x 4'0" 6'7" x 4'0" 6'7" x 4'3" 6'3" x 6'7"
Rear Single - - - - - - 1.89m x 0.69m -1.89m x 0.69m
6'3" x 2'3" 6'3" x 2'3"
Rear Single - - - - - - - - 1.89m x 0.69m
6'3" x 2'3"
Rear Bunk Bed ----- - 1.76m x 0.60m - -
5'10" x 2'0"
Nearside Single 1.78m x 0.66m - - - - - - - -
5'10" x 2'2"
Offside Single 1.83m x 0.64m - - - - - - - -
6'0" x 2'1"
Overcab Bed - - 2.01 x 1.32m 2.01m x 1.32m 2.01m x 1.32m 2.01m x 1.32m 2.01m x 1.32m 2.00m x 1.32m 2.00m x 1.32m
6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4"
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTORHOME,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
3. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICALLY PERMISSIBLE LADEN MASS OF THIS MOTORHOME BE EXCEEDED.

Specification
9
*Estimated
MODEL Gazelle F59 Gazelle F59 Gazelle F61/ Gazelle F63 Gazelle V61 Gazelle V63 Kon-Tiki L Kon-Tiki L Kon-Tiki S Bel-Air 750
Dinette F61 Wide Day Seat Twin Settee
Designated Passenger Seats 1 3 1 3 1 3 2 (Maxi 3) 2 (Maxi 3) 2 (Maxi 3) 3
Number of Berths 4 4 4 6 4 6 5 5 4 4
Overall Length 5.90m/19'5" 5.90m/19'5" 6.30m/20'8" 7.13m/23'4" 6.40m/21'0" 7.23m/23'8" 7.30m/24'0"* 7.30m/24'0"* 7.00m/23'0"* 7.13m/23'4"
Overall Width 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.22m/7'3" 2.27m/7'5"
Overall Height 2.90m/9'6" 2.90m/9'6" 2.90m/9'6" 2.90m/9'6" 2.90m/9'6" 2.90m/9'6" 2.98m/9'9"* 2.98m/9'9"* 2.98m/9'9"* 2.96m/9'8"
Maximum Technical 3400kg 3400kg 3400kg 3400kg 3500kg 3500kg 3400kg 3400kg 3400kg 3850kg
Permissible Laden Mass (A) (Maxi 3850kg) (Maxi 3850kg) (Maxi 3850kg)
Mass in Running Order (B) 2685kg 2725kg 2746kg 2915kg 2820kg* 2990kg 2914kg* 2914kg* 2948kg* 3271kg
(Maxi 2964kg*) (Maxi 2964kg*) (Maxi 2964kg*)
Maximum User Payload (A-B) 715kg 675kg 654kg 485kg 680kg* 510kg 486kg* 486kg* 457kg* 579kg
(Maxi 886kg*) (Maxi 886kg*) (Maxi 886kg*)
Essential Habitation Equipment 125kg 125kg 125kg 143kg 125kg 143kg 152kg 152kg 152kg 152
BED SIZES
Drop-Down - - - - - - - - - 1.30m x 2.00m
4'3" x 6'6"
Front Double 1.89m x 1.22m 1.89m x 2.00m -1.89m x 1.30m -1.89m x 1.30m 1.89m x 1.30m 1.89m x 1.30m 1.89m x 1.30m -
6'3" x 4'0" 6'3" x 6'7" 6'3" x 4'3" 6'3" x 4.3" 6'3" x 4.3" 6'3" x 4.3" 6'3" x 4.3"
Front Single -1.89m x 0.69m - - - - - - 1.89m x 0.69m 1.89m x 0.69m
6'3" x 2'3" 6'3" x 2'3" 6'3" x 2'3"
Front Single -1.89m x 0.90m - - - - - - 1.89m x 0.69m 2.00m x 0.69m
6'3" x 2'11" 6'3" x 2'3" 6'7" c 2'3"
Rear Double - - 1.89m x 2.08m 2.08m x 1.35m 1.89m x 2.08m 2.08m x 1.35m 1.89m x 1.22m 1.89m x 2.08m - -
6'3" x 6'10" 6'10" x 4'5" 6'3" x 6'10" 6'10" x 4'5" 6'3" x 4'0" 6'3" x 6'10"
Rear Single - - 1.89m x 0.69m -1.89m x 0.69m - - 1.89m x 0.70m - -
6'3" x 2'3" 6'3" x 2'3" 6'3" x 2'3"
Rear Single --1.89m x 0.69m -1.89m x 0.69m - - 1.89m x 0.70m - -
6'3" x 2'3" 6'3" x 2'3" 6'3" x 2'3"
Overcab Bed 2.08m x 1.30m 2.08m x 1.30m 2.08m x 1.30m 2.08m x 1.30m 2.08m x 1.30m 2.08m x 1.30m 1.90m x 0.70m 1.90m x 0.70m 1.90m x 0.70m -
6'10" x 4'3" 6'10" x 4'3" 6'10" x 4'3" 6'10" x 4'3" 6'10" x 4'3" 6'10" x 4'3" 6'3" x 2'3" 6'3" x 2'3" 6'3" x 2'3"
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTORHOME,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
3. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICALLY PERMISSIBLE LADEN MASS OF THIS MOTORHOME BE EXCEEDED.

Water Capacities
10
CAPACITIES (litres) Fresh Water Tank Waste Water Tank Water Heater
Bel-Air 90 70 13
Kon-Tiki 90 70 10
Gazelle 80 70 10
Royale 590 80 70 10
Royale 610 90 70 10
Sundance 80 70 10
Mondial 68 38 10
NOTICE
For technical data on the base vehicle please refer to your Fiat/Peugeot or VW handbook

Jacking
11
FIATROYALE/SUNDANCE
KON-TIKI
MONDIAL
GAZELLE
Jacking Points:

Jacking
12
BEL-AIR
Jacking Points:

Wiring Diagrams
13
KON-TIKI RANGE

Wiring Diagrams
ROYALE RANGE
14

Wiring Diagrams
SUNDANCE RANGE
15

Wiring Diagrams
MONDIAL RANGE
16

Wiring Diagrams
BEL-AIR RANGE
17

Wiring Diagrams
18
GAZELLE RANGE
