Swift Sundance 530LP User manual

Swift
Motorhomes
Warranty & Service Handbook

Signed .........................................................................................Date .......................................
Your Swift motorhome has a three year SuperSure Manufacturer's
Warranty. The items covered during years one, two and three vary,
and are clearly explained on pages 2 and 3 of this booklet.
Your dealer should fully explain the terms of the warranty, which is
also subject to annual service requirements, at the time of the official
handover of your product.
Please sign this form to say that you have had the details of the
warranty and the annual service arrangements fully explained.
Signing this document in no way affects your statutory rights under
the Sale of Goods Act.
Your Warranty Explained
Motorhome Details
IMPORTANT Enter all your motorhome details on this page (see specification in this handbook).
Supplied and Pre-delivery Inspection by:
Registration Number
Serial Number
Chassis Number
Delivery Date
Key Number
Overall Length
Overall Width
Maximum External Height
Mass in Running Order
User Payload
Maximum Technical Permissible Laden Mass
Tyre Size Front: Rear:
Service History
Signed/Dealer Date

CONTENTS
Warranty............................................................................2
What to do if you Require Assistance ..............................4
Annual Service/Inspection Record ...................................5
Specifications....................................................................8
Capacities - Water and Gas ...........................................10
Towing Capabilities .........................................................11
Jacking............................................................................13
Wiring Diagrams..............................................................14
Bulb Replacement ..........................................................17
Owners Club ...................................................................18
Change of Ownership .....................................................19

Warranty
2
All the illustrations and descriptive matter in
this handbook are intended to give a general
idea of the motorhome. Changing market
and supply situations and our policy of
continuous product development may
prevent us from maintaining the exact
specifications detailed in this handbook. We
therefore reserve the right to alter
specifications as materials and conditions
demand.
Dealers are not agents of Swift Group
Limited, the manufacturer of Swift Group
motorhomes and have absolutely no
authority to bind the manufacturer by any
express or implied undertaking or
representation.
All motorhomes (other than the engine,
chassis cab and associated parts referred to
earlier in this handbook which are subject to
the relevant chassis manufacturer's
warranty) have a 3 year SuperSure
manufacturer's warranty from the date of
purchase (or hire purchase), which is subject
to a chargeable annual service and
inspection being carried out at an authorised
Swift Group Service Centre.
During the warranty period, subject to the
exclusions set out in this section of the
handbook, the manufacturer, Swift Group
Limited, will repair (or at its option, replace)
all defective parts of the motorhome. For any
engine, chassis cab and associated parts
warranty issues please contact your local
Fiat Agent.
The manufacturer will honour the warranty
until 36 months from the date of sale,
provided that the motorhome has been
serviced annually within 90 days before or
60 days after each anniversary of the original
date of sale. The third service must,
however, be carried out before the expiry of
the 36 month period from the original date of
sale.
In the first 12 months the warranty will
cover:
Faults arising from a manufacturing defect
but not those which are a result of normal
wear and tear or those which relate to
replacement light bulbs.
Also not covered under the first year are
faults resulting from accidental damage or
damage caused by misuse of any
component part of the motorhome.
In the years two and three the warranty
will cover:
1. All original components of the motorhome
including permanently fitted equipment
forming part of the manufacturer's
original specification.
2. Water ingress and body delamination
Specific exclusions to Supersure Warranty
during Years 2 and 3
• Glass including heat shields, sink lids,
mirrors.
• Paintwork including all exterior paint, heat
shields, heater cases and all other
painted surfaces.
• Decals, mirror transfers, resin badges.
• GRP/ABS wheel spats and skirts.
•Cosmetic finishes to kitchen sinks,
cooker tops, vanity units, shower trays.
• Soft furnishings including upholstery,
curtains, pelmets.
• Carpets, lino and floor coverings
including door mats, shower mats.
• Work surfaces, tables, and flaps.
• Wallboards, ceiling boards and all other
interior décor finishes.
• Window catches, stays and associated
fittings.
• Blinds and flyscreens including door, Heki
and other rooflights.
•All hinges, catches, knobs, stays and
handles (interior and exterior).
• Adjustment of external doors and lockers.

Warranty
3
• Replacement of bulbs, fluorescent tubes,
fuses and electrical connections including
12n and 12s plugs, high level brake lights
and bulb contacts.
• Adjustment and natural movement of
internal doors, flaps and furniture.
• Audio equipment including radios,
speakers, aerials and associated parts.
• Bent corner steadies.
•Fair wear and tear, accidental damage or
any damage caused by the misuse of any
component fitted by the manufacturer.
• Routine maintenance items which are
part of the annual service including
lubricants, rubber gas hose, the cleaning
of the heater and fridge flues, the
replacement of gas jets, the resealing
and/or replacement of shower room
sealant, and the adjustment and
lubrication of locks.
General terms applying to all three years
of the warranty period
The motorhome is not covered for:-
• The failure of a component for reasons of
fair wear and tear.
• Damage resulting from accidents.
•Misuse of any component.
• Normal deterioration or negligence of any
person other than the Swift Group
Limited which causes stoppage of or
impairment to the function of any
component of the motorhome.
• Replacement of parts which have
reached the end of their effective working
life because of age and/or usage.
• Cleaning or adjustment of any
assemblies.
The warranty will be invalidated if the
motorhome has been neglected, misused or
modified. The warranty on all internal
components will be invalidated if the
motorhome has been used for hire or
reward. The motorhome will be deemed to
have been neglected if it has not been
serviced and maintained as stated in this
handbook.
The warranty only applies to motorhome
purchased and used within the UK, and for
continuous journeys abroad of no longer
than 90 days per journey.
The cost of transporting, towing or moving
the motorhome by any means to or from the
place of repair is the responsibility of the
owner.
The benefit of this warranty may be
transferred to a new owner if the motorhome
is sold, provided that the motorhome has
been serviced by an authorised Swift Group
Service Centre in accordance with the
requirements of this handbook, and details
of the change of ownership have been
supplied to Swift Group using the change of
ownership form set out in this handbook.
Failure to notify Swift Group of a change of
ownership within 14 days of such a change
will invalidate the warranty.
This warranty only applies to motorhomes
purchased in the UK.
You have legal rights under UK law
governing the sale of consumer goods. This
warranty does not affect your legal rights.
The name and address of the warranty
provider is:-
Swift Group Limited
Dunswell Road
Cottingham
East Yorkshire
HU16 4JX
To make a claim under this warranty, contact
the Swift Group Service Centre which
supplied your motorhome. Alternatively,
details of your nearest authorised Swift
Group Service Centre can be obtained by
contacting the Swift Group Customer Care
Department on 01482 875740, or enquiring
on the website www.swiftleisure.co.uk

Assistance
4
WHAT TO DO IF YOU REQUIRE ASSISTANCE
Congratulations on purchasing a Swift product. We are confident that you will enjoy many
happy holidays. However, should you have an enquiry or require assistance with a problem,
we hope that this guide will be of assistance to you.
If you have a problem, or enquiry with regards to your new motorhome, please follow
these steps:
1. Check the Owners Handbook, paying particular attention to the fault finding advice at
the back of the book.
2. Contact your supplying dealer for assistance.
If you need to contact the Swift Group, please be aware of the following:
1. When contacting Swift Supercare, please quote your name, postcode and serial number
of your caravan, or build number of your motorhome.
2. In most instances, the Customer Care Team will involve your dealer in resolving the issue
you are experiencing.
3. If you are contacting the company by email, letter or fax, the Customer Care Team will
respond to you within five working days from the date of receiving the correspondence.
4. If you are calling the Customer Care Team, please avoid where possible, Mondays and
lunch times.
5. Please be aware that the Swift Group cannot send parts direct from the factory. In all
cases, without exception, your dealer must place the order for you.

Service/Inspection
5
MOTORHOMES - ANNUAL SERVICE/INSPECTION RECORD
In order to comply with the warranty, you must have your motorhome inspected and
serviced by an authorised Swift Group Service Centre at least once per year.
It is important that the owner’s handbook is stamped on the appropriate page by the
authorised Swift Group Service Centre. Failure to do this will invalidate the warranty and the
transfer of the warranty on the change of ownership.
The inspection should take approximately two hours and will cover the areas dealt with in
the annual service check list. Any areas requiring service and/or maintenance will be
highlighted by your dealer and we recommend that you authorise any necessary work to be
carried out.
NB. It is essential, to validate the warranty, that an annual inspection be carried out by an
authorised Swift Group Service Centre covering the items listed.
Just as the engine/gearbox/roadwheels need regular servicing by your chassis dealer,
so there are components in your conversion that need regular maintenance by your
motorhome dealer.
These include the gas and electrical systems and the seals in the bodywork. Your dealer
will complete the record in this handbook to show that the work has been carried out.
1. Damp and lamination test.
2. Chassis and chassis to body security.
3. Corner steadies.
4. Motorhome step.
5. Road lights, wiring and reflectors.
6. Internal lights and 12V DC system.
7. Water heater - gas and 230V AC.
8. Hob, grill and oven.
9. Refrigerator 230V AC, 12V DC and gas.
10. Gas system.
11. Water pump, taps and water system.
12. Mains 230V AC system.
13. Windows and fittings.
14. Roof lights.
15. Furniture hinges/stays etc.
16. Exterior locks and hinges.
17. All internal vents.
18. Seals.
19. Blinds and fly screens.
20. Blown air heating and gas fire systems.
21. Tyres and tyre pressures.
22. Torque wheel nuts.

6
ANNUAL SERVICE/INSPECTION RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
1st SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
2nd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
3rd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
4th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
Service/Inspection

7
5th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
6th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
7th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
8th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
9th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
10th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

8
*Add 80mm for optional roof ladder. ** Add 160mm for optional TV aerial.
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. The Mass in Running Order is the mass of the unladen vehicle including a 75kg allowance for the driver plus engine coolants and 90% of the fuel tank, water tank and gas capacity.
3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTOR CARAVAN,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
4. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE LADEN MASS OF THIS MOTOR CARAVAN BE EXCEEDED.
MODEL
Roof Profile
Designated Passenger Seats
Berths (Sleeping Positions)
Overall Length
Overall Width (mirrors folded)
Overall Height
(no TV aerial or roof rack)
Maximum Technical
Permissible Laden Mass (A)
Mass in Running Order (B)
Maximum User Payload (A-B)
Essential Habitation Equipment
Thermal Insulation Grade
BED SIZES
Front Double
Front Nearside Single
Front Offside Single
Rear Double
Overcab Bed
Sundance 530LP
Low Line
1
2
5.59m/18' 4"
2.22m/7' 3"
2.94m/9' 8"**
3000kg
2654kg
346kg
14kg
TWO
2.09m x 1.33m
6'10" x 4'4"
Sundance 590RL
High Line
1
4
6.16m/20' 3"*
2.22m/7' 3"
3.10m/10' 2"
3400kg
2881kg
519kg
14kg
TWO
2.09m x 1.39m
6'10" x 4'7"
2.09m x 1.35m
6'10" x 4'5"
Sundance 590RS
High Line
3
5
6.16m/20' 3"*
2.22m/7' 3"
3.10m/10' 2"
3400kg
2865kg
535kg
14kg
TWO
1.87m x 1.20m
6'2" x 4'0"
1.87m x 0.66m
6'2" x 2'2"
1.87m x 0.87m
6'2" x 2'10"
2.09m x 1.35m
6'10" x 4'5"
Sundance 600S
High Line
3
4
6.16m/20' 3"*
2.22m/7' 3"
3.10m/10' 2"
3400kg
2889kg
511kg
14kg
TWO
1.87m x 1.20m
6'2" x 4'0"
1.87m x 0.87m
6'2" x 2'10"
2.09m x 1.35m
6'10" x 4'5"
Sundance 600FB
Low Line
1
2
6.16m/20' 3"
2.22m/7' 3"
2.94m/9' 8"**
3400kg
2821kg
579kg
14kg
TWO
1.87m x 1.30m
6'1" x 4'3"
Sundance 630L
High Line
3
6
6.99m/22' 11"*
2.22m/7' 3"
3.10m/10' 2"
3850kg
3133kg
717kg
14kg
TWO
1.87m x 1.20m
6'2" x 4'0"
1.87m x 0.87m
6'2" x 2'10"
2.09m x 1.39m
6'10" x 4'7"
2.09m x 1.35m
6'10" x 4'5"
Sundance 630G
High Line
3
6
6.99m/22' 11"*
2.22m/7' 3"
3.10m/10' 2"
3850kg
3222kg
628kg
14kg
TWO
1.87m x 1.20m
6'2" x 4'0"
1.87m x 0.87m
6'2" x 2'10"
1.93m x 1.35m
6'4" x 4'5"
2.09m x 1.35m
6'10" x 4'5"
Specifications

Specifications
9
*Add 80mm for optional roof ladder. ** TV aerial adds 30mm to high line and 160mm to low line models.
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. The Mass in Running Order is the mass of the unladen vehicle including a 75kg allowance for the driver plus engine coolants and 90% of the fuel tank, water tank and gas capacity.
3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTOR CARAVAN,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
4. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE LADEN MASS OF THIS MOTOR CARAVAN BE EXCEEDED.
MODEL
Roof Profile
Designated Passenger Seats
Berths (Sleeping Positions)
Overall Length
Overall Width (mirrors folded)
Overall Height
(no TV aerial or roof rack)
Maximum Technical
Permissible Laden Mass (A)
Mass in Running Order (B)
Maximum User Payload (A-B)
Essential Habitation Equipment
Thermal Insulation Grade
BED SIZES
Front Double
Front Nearside Single
Front Offside Single
Rear Double
Rear Nearside Single
Rear Offside Single
Overcab Bed
Kon-Tiki 600
Low Line
1
2
6.64m/21' 9"*
2.34m/7' 8"
2.89m/9' 6"**
3400kg
3135kg
265kg
23kg
THREE
1.90m x 1.36m
6'3" x 4'5"
Kon-Tiki 600 Maxi
Low Line
1
2
6.64m/21' 9"*
2.34m/7' 8"
2.89m/9' 6"**
3850kg
3185kg
665kg
23kg
THREE
1.90m x 1.36m
6'3" x 4'5"
Kon-Tiki 610
Low Line
1
2
6.64m/21' 9"*
2.34m/7' 8"
2.89m/9' 6"**
3400kg
3092kg
308kg
23kg
THREE
2.14m x 1.75m
7'0" x 5'9"
1.75m x 0.73m
5'9" x 2'5"
1.90m x 0.73m
6'3" x 2'5"
Kon-Tiki 610 Maxi
Low Line
1
2
6.64m/21' 9"*
2.34m/7' 8"
2.89m/9' 6"**
3850kg
3142kg
708kg
23kg
THREE
2.14m x 1.75m
7'0" x 5'9"
1.75m x 0.73m
5'9" x 2'5"
1.90m x 0.73m
6'3" x 2'5"
Kon-Tiki 615
High Line
1
4
6.64m/21' 9"
2.34m/7' 8"
2.92m/9' 7"**
3850kg
3283kg
567kg
23kg
THREE
2.14m x 1.75m
7'0" x 5'9"
1.75m x 0.73m
5'9" x 2'5"
1.90m x 0.73m
6'3" x 2'5"
2.00m x 1.33m
6'6" x 4'4"
Kon-Tiki 635
High Line
3
5
7.48m/24' 6"
2.34m/7' 8"
2.92m/9' 7"**
4000kg
3479kg
521kg
23kg
THREE
1.90m x 0.96m
6'3" x 3'2"
1.98m x 1.33m
6'6" x 4'4"
2.00m x 1.33m
6'6" x 4'4"
Kon-Tiki 645
High Line
3
5
7.48m/24' 6"
2.34m/7' 8"
2.92m/9' 7"**
3850kg
3443kg
407kg
23kg
THREE
1.90m x 0.96m
6'3" x 3'2"
2.14m x 1.75m
7'0" x 5'9"
1.90m x 0.73m
6'3" x 2'5"
1.75m x 0.73m
5'9" x 2'5"
2.00m x 1.33m
6'6" x 4'4"
Kon-Tiki 650
Low Line
3
2
7.48m/24' 6"*
2.34m/7' 8"
2.89m/9' 6"**
3850kg
3377kg
473kg
23kg
THREE
2.14m x 1.82m
7'0" x 6'0"
1.82m x 0.73m
6'0" x 2'5"
1.90m x 0.96m
6'3" x 3'2"
Kon-Tiki 655
High Line
3
4
7.48m/24' 6"
2.34m/7' 8"
2.92m/9' 7"**
3850kg
3456kg
394kg
23kg
THREE
2.14m x 1.82m
7'0" x 6'0"
1.82m x 0.73m
6'0" x 2'5"
1.90m x 0.96m
6'3" x 3'2"
2.00m x 1.33m
6'6" x 4'4"
Kon-Tiki 660
Low Line
1
2
7.48m/24' 6"*
2.34m/7' 8"
2.89m/9' 6"**
3850kg
3323kg
527kg
23kg
THREE
2.14m x 1.40m
7'0" x 4'7"
1.90m x 1.36m
6'3" x 4'5"
Kon-Tiki 665
High Line
1
4
7.48m/24' 6"
2.34m/7' 8"
2.92m/9' 7"**
3850kg
3402kg
448kg
23kg
THREE
2.14m x 1.40m
7'0" x 4'7"
1.90m x 1.36m
6'3" x 4'5"
2.00m x 1.33m
6'6" x 4'4"

Capacities
10
Fresh Water Waste Water Water Toilet Tank
Tank Tank Heater (Flushing)
Sundance - 590RL, 590RS, 600S, 630L and 630G 100 litre 80 litre 10 litre 0 litre
Sundance - 530LP and 600FB 82 litre 80 litre 10 litre 0 litre
Kon-Tiki - 600, 650, 655, 660 and 665 125 litre 100 litre 12 litre 7 litre
Kon-Tiki - 610, 615, 635 and 645 110 litre 100 litre 12 litre 7 litre
Water Tank Capacities
Capacity
Sundance - All models 2 x 7kg
Kon-Tiki - 635, 645, 650, 655, 660 and 665 2 x 7kg or 1 x 13kg
Kon-Tiki - 600, 610 and 615 2 x 7kg
Gas Capacities
The above are recommended gas bottle sizes
NOTICE
For technical data on the base vehicle please refer to manufacturer's handbook

Towing Capabilities
11
Model Engine / Chassis MTPLM Permissible Permissible Gross Train Maximum Maximum
Front Axle Load Rear Axle Load Weight Towing Weight Nose weight
Sundance 590RS 2.0L JTD Ducato 15 MWB 3400 1750 1900 5000 Not Recommended
Sundance 590RS 2.3L JTD Ducato 15 MWB 3400 1750 1900 5400 1150 10
Sundance 590RS 2.8L JTD Ducato 15 MWB 3400 1750 1900 5400 1150 10
Sundance 590RS 2.8L JTD Ducato 18 MWB 3500 1850 2120 5500 1150 80
Sundance 590RL 2.0L JTD Ducato 15 MWB 3400 1750 1900 5000 750 50
Sundance 590RL 2.3L JTD Ducato 15 MWB 3400 1750 1900 5400 750 50
Sundance 590RL 2.8L JTD Ducato 15 MWB 3400 1750 1900 5400 750 50
Sundance 590RL 2.8L JTD Ducato 18 MWB 3500 1850 2120 5500 1150 80
Sundance 600S 2.0L JTD Ducato 15 MWB 3400 1750 1900 5000 Not Recommended
Sundance 600S 2.3L JTD Ducato 15 MWB 3400 1750 1900 5400 Not Recommended
Sundance 600S 2.8L JTD Ducato 15 MWB 3400 1750 1900 5400 Not Recommended
Sundance 600S 2.8L JTD Ducato 18 MWB 3500 1850 2120 5500 750 50
Sundance 630G 2.8L JTD Ducato 18 LWB 3850 1850 2120 5500 Not Recommended
Sundance 630L 2.8L JTD Ducato 18 LWB 3850 1850 2120 5500 750 50
Sundance 530LP 2.0L JTD Ducato 11 SWB 3000 1600 1650 4600 Not Recommended
Sundance 600FB 2.3L JTD Ducato 15 LWB 3400 1750 1900 5400 1150 80
To ensure adequate road holding, the load on the front axle, under all conditions, must not be less than 42% of the total weight.
The permissible payloads and MTPLM must not be exceeded under any circumstances.
Nose weight figures are set based on meeting the 'maximum rear axle' loading and 'minimum front axle' loading. These figures are based on loading
conditions in an MRO and MTPLM condition. It is your responsibility to ensure that loading in any other condition meets the requirements stated above.
Sundance Towing Capabilities

Towing Capabilities
12
Model Engine / Chassis MTPLM Permissible Permissible Gross Train Maximum Maximum
Front Axle Load Rear Axle Load Weight Towing Weight Nose weight
Kon-tiki 600 2.8L JTD Ducato 15 / Al-Ko Low Frame 3.4T 3400 1690 1900 5200 1800 < 2000 80
Kon-tiki 600 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 610 2.8L JTD Ducato 15 / Al-Ko Low Frame 3.4T 3400 1690 1900 5200 1800 < 2000 80
Kon-tiki 610 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 615 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 635 2.8L JTD Ducato 18 / Al-Ko Low Frame 4.0T 4000 1850 2300 5500 1500 < 2000 80
Kon-tiki 645 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1500 < 2000 80
Kon-tiki 645 2.8L JTD Ducato 18 / Al-Ko Low Frame 4.0T 4000 1850 2300 5500 1500 < 2000 80
Kon-tiki 650 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 650 2.8L JTD Ducato 18 / Al-Ko Low Frame 4.0T 4000 1850 2300 5500 1500 < 2000 80
Kon-tiki 655 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 655 2.8L JTD Ducato 18 / Al-Ko Low Frame 4.0T 4000 1850 2300 5500 1500 < 2000 80
Kon-tiki 660 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
Kon-tiki 665 2.8L JTD Ducato 18 / Al-Ko Low Frame 3.85T 3850 1850 2120 5500 1650 < 2000 80
To ensure adequate road holding, the load on the front axle, under all conditions, must not be less than 42% of the total weight.
The permissible payloads of the axles and MTPLM must not be exceeded under any circumstances.
Nose weight figures are set based on meeting the 'maximum rear axle' loading and 'minimum front axle' loading. These figures are based on loading
conditions in an MRO and MTPLM condition. It is your responsibility to ensure that loading in any other condition meets the requirements stated above.
Kon-Tiki Towing Capabilities

Jacking
13
SUNDANCE
KON-TIKI
Jacking Points:

Wiring Diagrams
14
SUNDANCE RANGE

Wiring Diagrams
15
KON-TIKI RANGE

Wiring Diagrams
16
KON-TIKI RANGE - WITH FRIDGE FREEZER

Bulb Replacement
17
Type Power Sundance Kon-Tiki
EXTERIOR LIGHTS
Front Road lights
Full beam headlight H4 12V-55/60W ✓✓
Dipped beam headlight H4 12V-55/60W ✓✓
Front side lights R5W 12V-5W ✓✓
Front directional indicators P21W 12V-21W ✓✓
Side directional indicators W5W 12V-5W ✓✓
Rear Road Lights
Rear directional indicators PY21W 12V-21W ✓ ✓
Brake lights P21W 12V-21W ✓✓
Reverse light P21W 12V-21W ✓✓
Rear foglight P21W 12V-21W ✓✓
Running Light R5W 12V-5W ✓ ✓
High level brake light Capless 12V-2.3W ✓✓
Other exterior Lights
Front marker light W5W 12V-5W ✓✓
Rear marker light W5W 12V-5W ✓ ✓
Red/white side marker light C5W 12V-5W ✓
Amber side marker light W5W 12V-5W ✓
Number plate light CW5 12V-5W ✓✓
Number plate light F239 12V-5W ✓
Awning light P21W 12V-21W ✓✓
INTERIOR LIGHTS
Ceiling lights Switched Halogen G4 Bi-Pin 12V-20W ✓
Downlight (Unswitched) Halogen G4 Bi-Pin 12V-10W ✓ ✓
Downlight (Switched) Halogen G4 Bi-Pin 12V-10W ✓ ✓
Reading lights Halogen G4 Bi-Pin 12V-10W ✓ ✓
Extractor hood lights Enclosed Dichroic 12V-10W ✓
Luton flourescent light 300mm Flourescent 12V-8W ✓
Cab interior ceiling light CW5 12V-10W ✓✓
Luton base aux. reading light 245S 12V-5W ✓
Luton base aux. reading light eyeball 245S 12V-10W ✓
Note: Not all lights and bulbs feature on all models within a range

Owners Club
18
SWIFT MOTORHOME
OWNERS CLUB
Congratulations on your choice of motorhome.
Now that you are the proud owner of a Swift
Motorhome, perhaps you would like to
consider spending the occasional weekend or
holiday in the company of other proud Swift
Motorhome owners. For details of the
Motorhome Owners Club contact:
Customer Services Dept.
Swift Group Limited,
Dunswell Road,
Cottingham,
Hull,
East Yorkshire HU16 4JX
or see our web site:
www.swiftleisure.co.uk
