6
This feature is limited to a small production batch, not a standard feature of this camera.
Placing the switch in the WiFi mode, turns the camera into a WiFi only camera. Connection to
camera can only be made via WiFi connection. Power adapter must be connected to camera,
in order to supply power to camera in WiFi mode. Placing the switch in the USB mode, allows
camera to be accessed by tablet via micro USB to mini USB cable. The cable supplies
connection and power to the camera.
WiFi Operation for BTW
1. Mount the BTW camera onto your trinocular microscope using a 0.5x c-mount adapter.
The c-mount adapter is a specific part of your microscope and should be purchased from your
microscope supplier.
2. Mount your own tablet up to 10” in diagonal size onto the spring loaded clamp situated on top
of the camera part taking care not to drop the tablet. Ensure that the tablet is securely held on
its diagonal corners so that there is no movement of the tablet within the clamp.
3. Connect the camera and the tablet to a power source.
4. Switch the camera to WiFi transmission mode.
5. Turn on your tablet and connect its WiFi system to the SSID provided with the BTW package,
6. Start the MotiConnect application and connect to the WiFi camera using the connection
interface within the application.
7. Ensure that your microscope is turned on, and if your microscope has a beamsplitter, ensure
that it is switched to a trinocular position so that there is light passing to the camera on the
trinocular tube.
8. You can now view the image live on the MotiConnect app as well as capture, measure and
annotate the image using the tools provided.
9. You can connect up to 5 other tablets or other WiFi devices to the BTW signal at the same
time in order to share the live image.
Using a WiFi device that operates with Android or IOS
1. For best performance, we recommend to use WiFi devices, such as tablets, with a screen not
smaller than 7 inches. For iOS devices we suggest using iOS 5 or higher while for Android
Devices we suggest using Version 4.0 or higher.
2. To operate and use the camera on your tablet, please download our free App called
MotiConnect. For iPad you can find this on the AppStore, for Android devices you can find this
on Google Play and Ipad
3. You can also use certain web browsers such as Chrome, Firefox, or Safari to view, measure, and
capture without the need of the App. To view the camera stream on the browser, please type in
the IP number also shown on the label on the camera. For example 192.168.1.151:8080 and
you will be connected straight to the camera.
Use WiFi setting to connect to your WiFi enabled computer
The BTW camera can also be used with Motic Images Plus software for Windows computers. If you
have a WiFi enabled laptop you can install Motic Images Plus from the CD provided. To view the
camera in our product’s MI Devices interface, simply log your computer onto the BTW camera signal,
by selecting this WiFi connection and entering the password. Then open the MI Devices interface by
clicking on the camera icon within Motic Images Plus and select Moticam X from the drop down
menu. Then click on Open.
Camera Switches and Ports –Limited Production
