Swift EB518D User manual

40V LITHIUM-ION CORDLESS HEDGE TRIMMER
Model: EB518D
Operations Manual

TABLE OF CONTENTS
•Symbols…………………….........2
•Safety Instructions………………2
•Major Parts of the
Hedge Trimmer………………….8
•Technical Specifications….…….9
•Assembly and Operation……….9
•Maintenance and Care……….14
•Disposal………………………..15
•Guarantee/Warranty………….15
These instructions should be read in conjunction with the
instruction manual for the battery pack and charger.
SYMBOLS
General Safety Warning
1. To avoid accidental operation
and injury, the battery should
always be removed whenever
you are not using the tool,
before checking, cleaning, or
performing other work on the
unit, and if the unit starts
vibrating excessively.
2. This trimmer is equipped with a
dual switch safety feature. The
saw will not operate unless
both the front handle switch
and the rear handle switch are
engaged. NEVER attempt to
interfere with this safety
feature by taping or clamping
the switches.
3. Protect the battery contacts
when the battery is not being
used. Loose metal parts may
short-circuit the contacts -
Explosion and fire hazard!
Before using this tool, read the
operations manual. Read all safety
warnings and all instructions.
Failure to follow the warnings and
instructions may result in electric
shock, fire and/or serious injury
Protective goggles/visor, protective
helmet & hearing protection.
Wear non-slip, heavy-duty
protective gloves.
Do not expose to rain.
Do not throw batteries and other
electrical products into the
household waste, fire, or water.
Safety Instructions
User
This garden tool is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the machine by a person responsible
for their safety.
Never allow children or people unfamiliar with these
instructions to use the garden tool. Supervise children.
This will ensure that children do not play with the unit.
Intended Use
This garden tool is
-intended for cutting and trimming hedges and bushes
which have a maximum branch thickness of 22
mm;
- designed for maintaining hedges and bushes in the
private sector,
- not suitable ifor work above shoulder height,
- to use according to the descriptions and safety
instructions indicated in this operating manual.
Any other use is not as intended. Improper use is not
covered by the warranty and the manufacturer will reject
any liability. The user is liable for all injuries to third parties
and damage to their property.
Operate the unit only in the technical condition as
stipulated and delivered by the manufacturer.
Arbitrary changes to the unit will exclude the manufacturer
from any liability for resulting injury and/or damage.
General Power Tool Safety
Warnings
The term "power tool" in the warnings refers to your
battery-operated (cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you to
lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the
risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.There is an increased risk of electric shock
if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase the
risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
the cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is

unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the influence
of drugs, alcohol, or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce the risk of
injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to the power
source and/or battery pack, picking up, or carrying
the tool. Carrying power tools with your finger on the
switch or power tools that have been turned on invite’s
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may increase the risk of
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair
can be caught by moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure that these
are connected and properly used. Use of dust collection
can reduce dust-related hazards.
Power Tool Use and Care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it is designed.
2. Do not use the power tool if it can’t be turned on and
off by its switch. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making any
adjustments, changing accessories, or before storing
the power tool. Such preventive safety measure reduces
the risk of starting the power tool accidentally.
4. Store idle power tools out of reach of children and do
not allow persons unfamiliar with the power tool or
these instructions to operate it. Power tools are
dangerous in the hands of untrained users.
5. Maintain the power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Battery Tool Use and Care
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
2. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
3. When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or fire.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If you accidentally
contact the battery liquid, flush it with water. If the
battery liquid contacts the eyes, seek medical help as
soon as possible. Liquid ejected from the battery may
cause irritation or burns.
Safety Instructions for Hedge Trimmers
1. Keep all body parts away from the cutter. Never
attempt to remove the clippings while the blade is
running or hold material which is to be cut. Before
removing any jammed clippings, switch off the unit
2. A moment of inattention when using the hedge
trimmer may result in serious injuries.
3. Carry the hedge trimmer by the handle when the
blade has stopped. When transporting or storing the
hedge trimmer, always remove the battery and pull
on the guard. Handle the unit carefully to reduce the
risk of injury from the blade.
4. Hold the electric power tool by the insulated
handle surfaces only, as the cutter may touch
concealed power lines. If the cutter comes into
contact with a live line, metallic parts of the unit may
become energized and cause an electric shock.
Additional Safety Instructions
1. This unit is not designed to be used by persons
(including children) who have limited physical,
sensory or mental abilities or who have
inadequate experience and/or knowledge of the
unit, unless they are supervised by a person
responsible for their safety or they have been
instructed by the person how to use the unit
Children should be supervised to ensure that
they do not play with the unit.
2. Switch the unit off and remove the battery under
the following conditions:
- if the unit is left unattended;
- before checking, cleaning or performing other work
on the unit;
- if the unit starts vibrating excessively.
3. While cutting, ensure that there are no persons
(particularly children) or animals in the working
area. Ensure that children do not play with the unit.
4. Before switching on the hedge trimmer, ensure
that the working area is free of stones and pieces
of wire. Look out for them while cutting and search
the hedge for concealed objects, such as wire
fences.
5. Use the unit only in daylight or in good artificial
lighting.
6. Use the unit in dry conditions only. Protect it
from rain and moisture.

7. Ensure that the cutter does not touch the ground
or other objects.
8. Wait until the electric power tool has come to a
standstill before putting it down.
9. When interrupting work, never leave the unit
unattended and keep it in a safe place.
10. Always switch the hedge trimmer off before
transporting it to other workplaces.
11. Never grasp the blade of the hedge trimmer.
12. Ensure that all guards and handles are fitted
before using the unit. Never attempt to switch on an
incompletely assembled unit or a unit which has
unauthorized modifications.
13. Operate the unit only in the technical condition
stipulated and delivered by the manufacturer.
Unauthorized changes to the unit exclude liability of
the manufacturer for any resulting damage and/or
injury.
14. Spare parts must conform to the requirements
specified by the manufacturer. Therefore, use
original spare parts only or spare parts authorized by
the manufacturer. When replacing parts, please follow
the supplied installation instructions and remove the
battery beforehand.
15. Have repairs carried out exclusively by a qualified
technician or a service center.
Safety Instructions for The Battery
Charger
1. Keep the battery charger away from rain or
moisture. Penetration of water in the battery charger
increases the risk of an electric shock.
2. Keep the battery charger clean. Contamination can
lead to danger of an electric shock.
3. Before each use, check the battery charger, cable
and plug. If damage is detected, do not use the battery
charger. Never open the battery charger yourself. Have
repairs performed only by a qualified technician and
only using original spare parts. Damaged battery
chargers, cables and plugs increase the risk of an
electric shock.
4. Do not place any objects on the battery charger and
do not place the battery charger on soft surfaces.
5. There is a risk of fire.
6. Always check that the mains voltage matches the
voltage indicated on the rating plate of the battery
charger.
7. Never use the charger if cable, plug or the unit itself
has been damaged by external influences. Take the
charger to the nearest service center.
8. Never open the battery charger. If the battery
charger is defective, take it to a service center.
Safety Instructions for Li-Ion Batteries
1. Do not open the battery. There is a risk of a short
circuit.
2. Protect the battery from heat, e.g. from continuous
exposure to sunlight, fire, water and humidity.
3. There is a risk of explosion.
4. In case of damage and improper use of the battery,
vapors may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapors can
irritate the respiratory system.
5. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help.
6. Liquid ejected from the battery may cause
irritation or bums.
7. Use only original batteries with the voltage
indicated on the rating plate of your electric
power tool. If other batteries are used, e.g.
imitations, reconditioned batteries or third-party
products, there is a risk of injuries as well as damage
caused by exploding batteries.
8. The battery voltage must match the battery
charging voltage of the battery charger.
Otherwise, there is a risk of fire and explosion.
9. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
10. Pointed objects, such as nails or screw-drivers,
or external forces may damage the battery. This
may cause internal short-circuit and the battery to
bum, smoke, explode or overheat.
Noise and Vibration
NOTE: Values for the A-weighted sound pressure level
and for the total vibration values can be found in the
"Product Specifications" table.
CAUTION: The indicated measurements refer to new
power tools. Daily use causes the noise and vibration
values to change.
NOTE: The vibration emission level given in this
information sheet has been measured in accordance with
a standardized test given in EN 60745 and may be used
to compare one tool with another. It may be used for a
preliminary assessment of exposure. The declared
vibration emission level represents the main applications
of the tool. However, if the tool is used for different
applications, with different accessories or poorly
maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total
working period. However, if the tool is used for different
applications, with different accessories or poorly
maintained, the vibration emission may differ. This may
significantly decrease the exposure level over the total
working period. Identify additional safety measures to
protect the operator from the effects of vibration such as:
maintain the tool and the accessories, keep the hands
warm, organization of work patterns.
CAUTION: Wear ear protection at a sound pressure
above 85 dB(A).
Service
Have your power tool serviced by a qualified repair
professional using only the identical replacement parts.
This will ensure that the safety of the power tool is
maintained.

HEDGE TRIMMER PARTS
1. Handlebar
2. Safety switch
3. Protection shield
4. Rear handle, swiveling
5. Switch
6. Switch interlock
7. Release button for rotating the rear handle
8. Insertion slot for battery
9. Housing
10. Ventilation openings
11. Cutting bar
12. Impact guard
13. Protection hood
14. Battery (EB20)
15. LED state of charge indicator
16. Release button for battery
17. Battery charger (EBC05)
TECHNICAL SPECIFICATIONS ASSEMBLY AND OPERATION
GENERAL SAFETY WARNING #1!
Before Initial Operation
Unpack the garden tool and accessories and check that
no parts are missing or damaged.
NOTE: The batteries (optional; depending on delivery
scope) are not fully charged on delivery. Prior to initial
operation, charge the batteries fully. See user manual of
the battery charger.
Inserting/Replacing the Battery
•Charging the battery as described in the user manual of
the charger.
•Press the charged battery into the power tool until it
clicks into place.
Tool
Hedge Trimmer
Model
EB518D
Rated Voltage
40V DC
Linear No-Load
Speed
1300 rpm
Blade Length
17.72”
Weight (without
battery pack)
6.39 lbs. (2.9 kg)
Guaranteed Sound
Power Level
81.7 dB(A)
Vibration
Uncertainty K=
1.5m/s2
＜2.46m/s2
Battery Pack
EB20
Battery Charger
EBC05

•To remove, press the release button (1) and pull out the
battery (2).
Adjusting the Rear Handle
GENERAL SAFETY WARNING #3!
Depending on the planned use the rear handle can be
rotated from the middle position by 90° in either direction.
•Press the release button downwards (1) and
simultaneously rotate the rear handle to the left or right
(2), until it clicks.
NOTE: The hedge trimmer will not turn on when the rear
handle is not securely engaged in the respective end
position.
Switching the Trimmer On/Off
GENERAL SAFETY WARNING #2!
NOTE: Two-hand safety circuit
The hedge trimmer is switched on and operated with both
hands. One hand operates the switch on the rear handle,
the second hand the safety switch on the handlebar, if you
release either of the two switches, the cutter bar
automatically stops.
Switching On
1. Hold the hedge trimmer firmly with both hands and
ensure that there are no persons (particularly children)
or animals in the immediate vicinity.
2. Press and hold down the switch interlock (1).
3. Press the switch (2) and the safety switch (3). The
hedge trimmer runs.
Switching Off
Release either of the two switches. The cutter bar stops.
Battery State of Charge
Press the button to check the state of charge at the state
of charge indicator LED.
The indicator goes out after 3 seconds. If the LED lights
red, the battery must be recharged. If the LED doesn't
light up after the button is pressed, the battery is faulty
and must be replaced.
Cleaning the Cutter Bar
(after each use)
•Remove the battery.
•Clean the cutter bar after each use. Remove
contamination, remains of blades etc.
•Spray the cutter bar with maintenance oil to ensure
that the hedge trimmer has a long service life.
Preferably use environmentally friendly lubricants,
e.g. service sprays.
CAUTION! Do not oil the hedge trimmer while it is running.
Work Instructions
1. Check that all parts are firmly attached and obviously
undamaged.
2. Look over the working area and remove any
obstructions. Remove all foreign objects from the
hedge, such as wire or other parts, as these may
block or damage the cutting mechanism.
3. Cut out thick branches beforehand using pruning
shears.
4. Pick up the power tool in both hands as specified.
5. Always cut at full engine speed.
6. Start cutting only with the cutting mechanism running.
7. The impact guard protects you against unpleasant
impacts, e.g. recoil torque of the cutter, when striking
a solid object (wall, ground, etc.).
8. Never touch wire fences or the ground with the
running cutting mechanism.
9. If cutting hedges over a prolonged period, interrupt
your work more frequently and oil the cutter bar.
10. Switch the engine off and remove the battery:
-to remove blockages (jammed clippings) from the
cutting bar;
-if the unit behavior changes or it vibrates unusually;
-if you have come into contact with foreign objects or
the ground;
-when taking breaks and leaving the unit unattended.
NOTE: If the power tool is damaged or vibrates unusually,
it must be repaired by a service center before it is used
again.
11. After use, stop the motor and wait until all rotating parts
have come to a standstill.
12. Place the protection hood on the cutter bar.
Cutting Techniques
•The hedge trimmer can be guided with its double-
sided cutters forwards and backwards or in an
oscillating movement from one side to the other.

•Cut the sides of the hedge first and then the top.
- When cutting sideways, hold the handlebar
sideways.
- When cutting low down, hold the handlebar above.
•Cut the hedge from bottom to top.
•Hold the hedge trimmer at an angle of 5-10°to the
hedge to ensure a straight cut.
•Cut the hedge in a trapezoidal shape. This prevents the
lower part of the hedge from losing its foliage due to
lack of light.
•Cut the upper edges of the hedge slightly round.
•Cut in several stages if heavy trimming is required.
•Peg out a string line if you want to cut the hedge evenly.
•Trim the young hedge plants to the required shape. The
main shoot should not be damaged until the hedge has
reached the required height. All other shoots can be cut
back to half their height.
•Dispose of the clippings properly and in an
environmentally friendly manner.
•Cutting times:
- Deciduous hedges: June and October
- Evergreen hedges: April and August
- Fast growing hedges (e.g. conifers): from May
approximately every 6 weeks
NOTE: Beware of nesting birds in the hedge. Do not cut the
hedge until birds have fledged or do not cut this part of the
hedge.
Operating the Hedge Trimmer
1. Do not force the hedge trimmer through heavy
shrubbery. This can cause the blades to bind and slow
down. If the blades slow down, reduce the pace
2. Do not try to cut stems or twigs that are larger than 15
mm thick, or those obviously too large to feed into the
cutting blade. Use a hand saw or pruning cutters to trim
large stems.
3. An easy way to keep your hedge level is to run a
string line guide. Stretch a piece of string along the
hedge just below your intended cutting line. Trim the
hedge just above this guide line.
4. Trim the side of a hedge so that it tapers slightly
towards the top (the hedge will be slightly wider at the
bottom than at the top. This improves the strength of
the hedge and allows light to reach the leaves.
5. If the blades do become jammed, release the trigger
switch and allow the blades to stop. Remove the
battery pack before attempting to remove the
obstruction.
6. Wear gloves when trimming thorny or prickly growth.
7. When trimming new growth, use a wide sweeping
action, so that the stems are fed directly into the
cutting blade. Older growth will have thicker stems
and will be trimmed easiest by using a sawing
movement.

MAINTENANCE AND CARE
GENERAL SAFETY WARNING #1!
For your own safety, perform only the maintenance work
described here by yourself. All other work, in particular
motor maintenance and repairs, must be performed by a
trained specialist, improper work may damage the power
tool and also result in injuries. Have this power tool
inspected once a year at a service center.
Cleaning
WARNING: Do not use water or liquid detergents.
CAUTION: Clean the unit after every use. Failure to dean
the unit can damage the materials and cause
malfunctions.
1. After each use, clean the hedge trimmer using a dry
cloth or a brush if the unit is very dirty.
2. Never spray the hedge trimmer with water.
3. Keep the ventilation slits clean and dust-free.
4. Clean the cutter bar after each use. Remove
contamination, remains of blades etc.
5. Spray the cutter bar with maintenance oil to ensure
that the hedge trimmer has a long service life. Preferably
use environmentally friendly lubricants, e.g. service
sprays.
6. Place the hedge trimmer on its side and apply a thin
film of oil to the cutter bar.
Blade Care
1. Lubricate the cutting blades after each use.
2. Periodically inspect the blades for damage and wear.
3. Always use the manufacturer's specified replacement
blades.
To Lubricate The Blade
1. For easier operation and longer blade life, lubricate
the hedge trimmer blade before and after each use.
2. Before lubricating, remove the battery pack and lay
hedge trimmer on a flat surface.
3. Apply light machine oil along the edge of the top
blade.
4. Always remove the battery pack before lubricating
the blades and never apply oil to moving blades
Storage
1. Clean the hedge trimmer thoroughly before storing.
2. Store the hedge trimmer with the battery removed in a
dry, well-ventilated place that is inaccessible to
children. Keep away from corrosive agents such as
garden chemicals and deicing salts.
3. Always fit the blade cover over the blades before storage.
This will protect the blades from damage and prevent injury
on the sharp blades.
3.Store and charge your batteries in a cool, dry area (50-
77 °F). Temperatures above or below normal room
temperature will shorten battery pack life.
4. Never store the battery in a discharged condition. Wait
for the battery to cool and recharge before storage.
Repair
Check the unit for damage. Repairs may be earned out by
an authorized customer service centre only.
DISPOSAL INFORMATION
Render redundant garden tools unusable:
- Main-operated tool by removing the power cord,
- Battery-operated tool by removing the battery.
For EU countries only:
Do not throw electric power tools into the household waste!
In accordance with the European Directive 2012/19/EC on
Waste Electrical and Electronic Equipment and
transposition into national law, used electric power tools
must be collected separately and recycled in an
environmentally friendly manner, same with devices,
accessories, and packaging. Plastic parts are identified for
recycling according to material type.
Do not open disused batteries. Accumuiators/batteries
should be collected, recycled or disposed of in an
environmentally friendly manner, too.
For EU countries only:
In accordance with Directive 2006/66/EC defective or
used batteries must be recycled.
Please ask your dealer about the disposal options!
GUARANTEE/WARRANTY
This product has been manufactured to the highest
quality standards. When a new product is purchased, it is
guaranteed a 24-month (hedge trimmer) and 12-month
(battery) manufacturer’s warranty which comes into force
on the date the product was purchased.
The guarantee covers only the defects which can be
attributed to a material and/or production fault as well as
non-performance of warranted characteristics.
A claim may be made under the guarantee only if the
power tool has been used as intended.
This warranty is invalid where defects are caused by or
result from:
- misuse, abuse or neglect;
- commercial use (industry, craft, rental)
- repairs attempted by unauthorized repair centers
- damage caused by external effects, foreign objects,
substances or accidents.
