Swing Catalyst 3D MOTION PLATE User manual

For Swing Catalyst Studio Installations
INSTALLATION GUIDE
3D MOTION PLATE

CONTENTS
3
Installation guide 3D Motion Plate 2016
2006-2017 © Initial Force AS
Swing Catalyst®
Introduction.........................................................................................................4
Part 1: Studio Overview
Studio Components..........................................................................................6
Dimensions - indoor studio............................................................................7
Dimensions - garage bay................................................................................8
Cameras.................................................................................................................9
Part 2: Cabling
Video setup........................................................................................................10
3D Motion Plate setup...................................................................................11
TV & feedback screen setup........................................................................12
Part 3: Flooring & Specications
Building oor structure.................................................................................13
Mounting rail specs........................................................................................16
3D Motion Plate specs...................................................................................17
Building podium structure...........................................................................19
Part 4: Studio Lights
LED lighting setup...........................................................................................22
Support......................................................................................................................23

4
INTRODUCTION
The Swing Catalyst team has over the years gained extensive
experience from studio installations all around the world.
This knowledge is now passed on to you as a valued Swing Catalyst
customer.
This guide oers recommendations regarding space requirements,
positioning of lighting, cameras and cabling, and some other
thoughts that you should consider when setting up your Swing
Catalyst Studio.
Detailed information on a specic topic may be found at:
www.swingcatalyst.com/help

4
4
1
1
3
3
2
2
7
7
6
6
5
5
8
8
Hitting
direction
Hitting
direction
* These are the recommended distances. Please note that more
space is required if you consider using a radar based launch
monitor. If you have less space please contact us for other camera
options.
76
STUDIO COMPONENTS
Face on camera left
Face on camera right
Down the line camera
Overhead camera
3D Motion Plate / Balance Plate
PC table
Optional wall mounted at screen
Optional student screen
Part 1 Studio Overview Part 1 Studio Overview
DIMENSIONS - INDOOR STUDIO
6.0m / 19’ 8”
6.0m / 19’ 8”
3.5m / 11’ 6”
3.0m / 9’ 10” *
3.0m / 9’ 10” *

Hitting
direction
Hitting
direction
4
132
4
1
3
2
98
DIMENSIONS - GARAGE BAY CAMERAS
* These are the recommended distances. Please note that more
space is required if you consider using a radar based launch
monitor. If you have less space please contact us for other camera
options.
6.0m / 19’ 8”
4.0m / 13’ 1”
3.5m / 11’ 6”
3.5m / 11’ 6”
1.1m / 3’ 8”
1.1m / 3’ 8”
1.1m / 3’ 8”
3.0m / 9’ 10” *
3.0m / 9’ 10” *
Face on camera left
Face on camera right
Down the line camera
Overhead camera
Camera height measured from oor to lens:
Recommended minimum height from oor to lens:
Part 1 Studio Overview Part 1 Studio Overview

Hitting
direction
1110
Coaxial for CCTV
Ethernet for GigE Vision
USB for USB cameras
Power outlet, 110-220V AC
Video cables (depending on camera type):
VIDEO SETUP
Part 2 Cabling
USB for 3D Motion Plate
3D MOTION PLATE SETUP
Sensor Plate cable:
Part 2 Cabling
USB for Balance Plate
All electronics connected to the 3D Motion Plate must
have ground. The power grid should have adequate
grounding. We recommend using surge protectors to
prevent damage to your electronics.

Hitting
direction
1312
HDMI for atscreen TV and feedback screen
Power outlet, 110-220V AC
Note: The setup for atscreen TV and feedback
screen is optional.
TV & FEEDBACK SCREEN SETUP
Part 2 Cabling
Screen cables:
Part 3 Flooring & Specications
BUILDING FLOOR STRUCTURE
Place the 3D Motion Plate on a at and level oor to ensure
accurate data readings.

1514
Logo mat
Balance Plate
Logo mat
Force Plate
Mounting rail
Wood stud
Board
Turf
Minimum 3 cm/1.2 in
gap between the sensor
plates and the wood
construction.
Ensure space to connect USB
cable, create a cut-out in the
oor boards if necessary.
Same height as
sensor plates +
logo mat.
Side view
Top view
Board cut-out for USB chord
Wood stud Wood stud
Board
7,9 cm /
3.11’’
1 cm /
0.4’’
ø1
ø1
ø1: Mounting holes. Use screws to x
mounting rail to the oor.
Insert two of the feet into the mounting rail.
Part 3 Flooring & Specications
Part 3 Flooring & Specications

1716
MOUNTING RAIL SPECS
38 mm / 1.5’’ 998 mm / 39.3’’
a: 41,4 mm / 1.63’’
b: 19 mm / 0.75’’
c: 123,7 mm / 4.87’’
d: 145,8 mm / 5.74’’
ø1: 7,62mm / 0.3”
ø2: 18,75mm / 0.738”
Part 3 Flooring & Specications
3D MOTION PLATE SPECS
518 mm / 20.4’’
998 mm / 39.3’’
153 mm / 6.0’’
407 mm / 16.0’’
Force plate connector
89 mm / 3.5”
49 mm / 1.93’’
Part 3 Flooring & Specications
Bottom view
Side view Balance Plate connector
874,5 mm / 34.43’’
811 mm / 31.93’’
956,8 mm / 37.67’’
ø1
b
c
d
a
ø1
b
c
d
aø2

1918 Part 3 Flooring & Specications
Feet on the oor
Important! To ensure accurate data readings the 3D Motion
Plate must be level and have all 4 feet in contact with the oor.
Make sure the plate is level before mounting the Balance Plate.
It’s important to account for the height of the Balance Plate when
adjusting the Force Plate to make the install ush with the turf.
BUILDING PODIUM STRUCTURE
Follow construction details from the previous pages. Choose
desired moldings for a good nish.
Part 3 Flooring & Specications

Hitting
direction
Hitting
direction
2120
3D Motion Plate hole
3D Motion Plate hole
minimum 1.2m / 3’ 93’’
minimum:
1.2m / 3’ 93’’
Top view
Side view
Part 3 Flooring & Specications
Hitting
direction
Part 4 Studio Lights
LED LIGHTING SETUP
Recommended lighting setup:
Lumen: 30,000 lumen
Beam angle: 45 degrees
Number of spot lights: 15-30
Recommended lux measurements:
Hip-height horizontally: 1300 lux
Floor below golfer: 2300 lux
Walls: 500 lux

2322
If you have any questions, please contact support:
suppor[email protected]
SUPPORT
Follow Swing Catalyst to
receive the latest updates:
