Swiss Madison Cache SM-WS321 User manual

INSTALLATION
INSTRUCTIONS
Swiss Madison
              
Caché Wall Hung Sink
www.swissmadison.com | 1-434-623-4766 | [email protected]
Share your pictures for a feature!
using #SwissMadison
®

Prior to Installation:
If you have any questions or concerns please contact us:
Inspect sink to ensure no damages have occurred while in shipping
Observe all plumbing and building codes in accordance with your state and local requirements
Additional oor and wall preparations may be necessary to avoid damage to the product
1-434-623-4766
[email protected]om
General Recommendations: Read installation and maintenance instructions thoroughly before installing the sink.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
—1 —
Thank you for purchasing a Swiss Madison Sink.
We appreciate your business and know you will enjoy your sink for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or [email protected].
Thank you for your purchase
www.swissmadison.com
To learn more about our products, please visit:
Sincerely,
The Swiss Madison Team

WALL HUNG SINK INSTALLATION INSTRUCTIONS
1. Read the complete instruction manual before beginning installation.
2. Conrm that your model will t in intended location and plumbing xtures
are located where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model
chart.
4. Two people are recommended to install and move this product.
—2 —
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Sink.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
21.65”
17.72”
17.32”
SUGGESTED TOOLS AND MATERIALS
PARTS LIST
Swiss Madison Sink Mounting Hardware Faucet (not included)
Safety Glasses Pencil Wrench
Drill Level Screwdriver

WALL HUNG SINK INSTALLATION INSTRUCTIONS
1. Mounting the Sink
—3 —
1. Drill two holes in the required position on the wall
using a 14mm masonry drill bit, to a depth of 75mm.
3. Screw a fixing bolt into each fixing plug using a
8mm spanner until the spanner contacts the wall.
4. Place the basin in position against the wall.
Locating the fixing bolts through the holes in the rear of
the basin. Push a plastic washer followed by a metal
washer, onto each fixing bolt.
5. Screw a metal nut onto each fixing bolt to secure
the basin. Caution: Do not over-tighten, as this may
damage the ceramic.
2. Push a wall plug into each hole.
NOTE: These fixings are suitable for solid walls only. Plasterboard or stud walls may require specialist fixings (not supplied).
CAUTION: Care should be taken when drilling walls and floors to avoid any concealed wires or pipes.
Plastic Solenoid Metal Screw Plastic Gasket Metal Gasket Metal Nut

3. Attach Plumbing
Set sink into the mounting bracket.
Install faucet, most of trap, and connect supply lines.
4. Install Shroud
Slide the shroud into place.
Using a pencil mark location of holes located
on both sides of the shroud.
—4 —
5. Secure Into place
Pre-drill into wall and install anchors.
Slide shroud into place and secure using same steps as when mounting the sink.
Use cover caps to hide hardware.
NOTE: Be careful not to tighten too much as you risk cracking the ceramic.

Swiss Madison® products are made with quality materials and excellent craftsmanship to provide the
customers a long lasting product. In the case of any defects in materials or craftsmanship under regular
use were inspected in the rst year of purchase, Swiss Madison® will provide replacement parts at no
charge, or at its option, replace any product or part of the product that is deemed defective, under
normal installation, use, service and maintenance. This warranty applies only to the original purchaser.
Proof of purchase will be required in the case of a claim.
Swiss Madison® recommends the installations to be made by a licensed, professional plumber.
Swiss Madison® will not be held responsible for any damage or product failure due to improper
installation, misuse, or failure to use a licensed professional. Swiss Madison® is not responsible for any
removal or installation cost.
This One Year Limited Warranty will be voided if:
•The installation recommendations were not followed.
•The product has been moved from it’s initial place of installation.
•The product has been modied.
•The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accident or other damages.
Swiss Madison® makes no implication that products comply with any or all local building or plumbing
codes. It is the consumer’s responsibility to determine local code compliance. This warranty extends to
the original purchaser and rst consumer.
Swiss Madison® is not liable for any incidental, consequential or special damages associated with the
return, replacement, installation or use of your product. This includes freight costs, labor, travel time, lost
prot, home damages and other contingent liabilities and costs (including, without limitation, costs
associated with experts, investigations, analyses, attorneys and other professionals and services).
The Swiss Madison® warranty is a comprehensive and explicit limit of liability, and all items outside of it
are not addressable by or the responsibility of Swiss Madison®. Certain states have variances regarding
implied warranties and in those situations we remain fully compliant.
In the case of any questions or a claim contact us directly at 1-434-MADISON (623-4766).
WARNING: Content may contain sharp and other possibly harmful pieces and may cause hazard to
children and adults, Swiss Madison® is not responsible in any way for personal damage.
ONE YEAR LIMITED WARRANTY
1-434-MADISON
(623-4766)
19 Stults Rd., Dayton, NJ 08810
www.swissmadison.com
S wiss M adison
              
®
