Swisson XWL-T User manual

XWL-T Wireless DMX Transmitter
XWL-R Wireless DMX Receiver
User Manual

2
UM-XWL-D0-LEN-V01-00.DOC 18/12/23

3
Index
Index..................................................................................................................................................................................3
Introduction ......................................................................................................................................................................4
Safety Information ............................................................................................................................................................5
Device Overview ...............................................................................................................................................................6
Transmission Standards....................................................................................................................................................7
Establishing a Wireless Link ..............................................................................................................................................8
Link LED.............................................................................................................................................................................9
Position of the Antenna ..................................................................................................................................................10
Technical Data.................................................................................................................................................................11
Ordering Information......................................................................................................................................................12

4
Introduction
The XWL series encompasses CRMX compatible and compact wireless DMX transmitters and receivers.
Multiple XWL-R receivers can be linked to a single XWL-T transmitter. Each model supports CRMX (by LumenRadio),
which is one of the leading DMX transmission solutions; Thus, each XWL is compatible with a large number of
wireless DMX receivers or wireless DMX transmitters that use that same protocol family.
The built-in power supply allows for a reliable operation at a wide voltage range and the powerCON inlet from
Neutrik makes it easy to connect your XWL to the mains.
Its mechanical design allows for installing the XWL flexibly, such that the user is able to put the antenna in a
convenient position within any setup. The built-in 3/8” thread allows the use of a microphone stand. Further, a
clamp for truss-mounting can be fixed to the M10/M12 thread of the XWL’s rugged aluminum housing.
Fields of Application
•Architectural lighting
•TV sets
•Theme parks
•Theater
•Multimedia shows
•Concert lighting
Typical Application
XWL-R
Wireless DMX receiver
Light controller
board
XWL-R
Wireless DMX receiver
XWL -T
WirelessDMX transmitter
Unpacking
The XWL is packaged in a cardboard box. The following items are included:
•The device
•1 antenna
•This user manual

5
Safety Information
Carefully, read this user manual and seek out the advice of qualified person in case of any doubt.
Take all safety precautions, and follow the operation instructions and warning notes listed in
this user manual prior to connecting, setting up, or using the device.
This product is not a household appliance and it should be used in accordance with local laws
and regulations.
Safety Precautions
•Disconnect the device from AC power when not in use and before removing any cover or
replacing a part, including safety fuse.
•Ensure that the device is electrically connected to ground (earth) and that all grounding
leads and cables are stable and intact
•Only use a source of AC power that complies with local building and electrical codes and
has both overload and ground-fault (earth fault) protection.
•Before using the device, check if the device itself, the power distribution equipment and
cables are in perfect condition and has the correct current ratings.
•Disconnect the device from power immediately if the power cable or the power plug are
damaged, defective, wet, or if it shows signs of overheating.
•Do not attempt to bypass any fuse. Replace a defective fuse with one of the same
specified type and rating only.
•Do not expose the device to rain or moisture.
•Do not operate the device if the housing or any other component is damaged or
deformed.
•Provide unrestricted airflow around the device.
•Do not operate the device if the ambient temperature is above 55°C (131°F).
•In case of any questions related to operations not described in this manual, please refer to
SWISSON.
•Do not modify the device in any way not described in this manual or install other than
genuine parts provided by SWISSON.
•When suspending the device, ensure that the setup supporting structure and all hardware
used can support at least 10 times the weight of all devices suspended from them.
•When suspending the device, implement a second safety mechanism. For instance, a
safety cable that is approved by an official body such as TÜV.

6
•The safety cable must comply with EN 60598-2-17 Section 17.6.6 and be capable of
bearing a static suspended load 10 times the weight of the device.
•Make sure that all external covers and rigging hardware are securely fastened.
•Block access below the work area whenever installing, servicing or moving an overhead
device.
Device Overview
1. Power input
2. 3/8” thread
3. DMX input port (on transmitter only)
4. DMX output port (on receiver only)
5. M10 and M12 thread for clamp
6. Power indicator
7. DMX signal indicator
8. Signal strength indicator (on receiver only)
9. Link button and Link LED
10. Antenna connector and antenna
Mains Connection
The user must use a suitable blue Neutrik powerCON NAC3FCA power cable to supply the XWL, then either hard-wire
it to the building’s electrical installation, providing an easily accessible power on/off switch close to the device, or
install on the power cable a grounding-type (earthed) mains plug that is suitable for the local power outlets, and
follows manufacturer’s instructions for the power plug.
Consult a qualified electrician, if you have any doubts about proper installation.
1
2
3
5
1
2
4
5
6
7
6
7
8
9
9
10
10
XWL
-T wireless
DMX
transmitter
XWL
-R wireless
DMX
receiver

7
Warning! For protection from hazardous situations and electric shocks, the device must be grounded
(earthed). The local AC power source must have both overload and ground-fault (earth fault) protection.
Important! The powerCON is a connector without breaking capacity, i.e. the powerCON should not be
connected or disconnected under load or live!
DMX Connections
The DMX input of the XWL-T and the DMX output of the XWL-R are isolated.
Models of the XWL are available with 3-pin or 5-pin XLR connectors.
Line Termination
The DMX input of the XWL-T has a built-in line termination.
A missing termination at the end of a DMX chain may lead to significant reflection issues. Additional termination
resistors in the middle of a chain may cause an unwanted drop of the signal level. Line termination is also known to
reduce the susceptibility to environmental noise.
Transmission Standards
The XWL is available with the following transmission type:
CRMX™(Cognitive Radio MultipleXer) by LumenRadio, which is very reliable and widely used in the professional
lighting industry.
5 Pin XLR connector
3 Pin XLR connector
Pin
Connection
Pin
Connection
1
Ground
1
Ground
2
Data -
2
Data -
3
Data +
3
Data +
4
Not connected
5
Not connected

8
Establishing a Wireless Link
To transmit DMX data wirelessly, a transmitter and one or more receivers are used. The receivers have to be linked
to the transmitter as shown below.
Linking
Ensure that all receivers in the desired setup are unlinked (the Link LED of the receivers is turned off) before linking.
If required, follow the procedure described below under Unlinking.
Transmitter Link
Link
Receiver
Receiver
On transmitter:
Press the Link button to link all unlinked receivers in the
range of the transmitter.
On receivers:
During the link process, the Link LED blinks.
The Link LED turns permanently on when the link is
established and DMX is received from the transmitter.
When a link is established, but no DMX data is received, the
Link LED is lit most of the time but turns dark very briefly
about once a second.
Unlinking
Transmitter
3sec
Receiver
Receiver
3sec 3sec
On transmitter:
Press and hold the Link button for 3 seconds to unlink all
devices previousely linked to the transmitter.
On receivers:
Press and hold the Link button for 3 seconds to unlink the
device.
When the receiver has been successfully unlinked, its Link
LED is turend off.

9
Link LED
The Link LED shows different information depending on the model.
XWL-T-WDMX and XWL-R-WDMX models
The Link LED provides the following information on XWL-T-WDMX transmitters or XWL-R-WDMX receivers,
respectively.
XWL-T-CRMX and XWL-R-CRMX models
The Link LED provides the following information on XWL-T-CRMX transmitters or XWL-R-CRMX receivers,
respectively.

10
Position of the Antenna
Try to position the antennas in parallel.
Good Bad
Try to position the antennas as highly as possible. Avoid operating the XWL near ground.
Bad
Good
A crowd will absorb the signal.
Bad Better Best
It is better to place the device itself at an elevated location rather than to use an antenna cable.
Good
Not good
B
ad

11
Technical Data
Depth ........................................................................................... 164.5 mm (6.5 “)
Width ........................................................................................... 92 mm (3.6 “)
Height........................................................................................... 44.4 mm (1.75 “)
Weight.......................................................................................... 0.58 kg (1.18 lbs)
Operating temperature................................................................ -30°C –55°C (-22°F –131°F)
System latency ............................................................................. 5 ms
Broadcast power (transmitter) .................................................... 100 mW (20 dBm)
Radio frequency band.................................................................. 2.4 GHz
Mains supply................................................................................ 100-240 VAC 50/60 Hz
Power consumption..................................................................... 2 W
DMX standard .............................................................................. ANSI E1.11
Electrical standard of signal ports................................................ EIA-485

12
Ordering Information
Transmitters
10 19 30
XWL-T-CRMX-3
Wireless DMX transmitter, CRMX type, 3-pin XLR.
10 19 31
XWL-T-CRMX-5
Wireless DMX transmitter, CRMX type, 5-pin XLR.
Receivers
10 19 50
XWL-R-CRMX-3
Wireless DMX receiver, CRMX type, 3-pin XLR.
10 19 51
XWL-R-CRMX-5
Wireless DMX receiver, CRMX type, 5-pin XLR.
