SWIT Electronics FLOW2000T Series User manual

Model： FLOW2000Tx/FLOW2000 Rx
2000ft Wireless HD
User Manual
Please read this user manual throughout before using
Ver：C
SWIT ELECTRONICS CO., LTD.

Preface
All internal technologies of this product are protected, including device, software and trademark.
Reproduction in whole or in part without written permission is prohibited.
All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative
trademarks in this user manual are the property of their respective owners.
Due to constant effort of product development, SWIT reserves the right to make changes and
improvements to the product described in this manual without prior notice.
The warranty period of this product is one years, and does not cover the following:
(1) Physical damage to the products
(2) Any damage or breakdown caused by use, maintenance, or storage not according to the user
manual’s introductions.
(3) The attenuation of signal quality resulting from being used in any special environments.
(4) Any damage caused by not powering the product by package supplied power adaptor.
(5) Any damage or breakdown not caused by the product’s design, workmanship,
manufacturing, quality, or unauthorized repairs or parts replacement or other operations.
For any suggestions and requirements on this products, please contact us, please contact us
through phone, fax, Email, etc.
SWIT Electronics Co., Ltd.
Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,
Nanjing 210038, P.R.China
Phone: [phone]
Fax: [phone]
Email: [e-mail]
http://www.swit.cc

Safety Precautions
Please follow the safety precautions before using. The following conditions are not covered by
warranty.
1. Unauthorized repairs or other Unauthorized operations.
2. Inappropriate placement including but not limited to lighting, fire, exposure to rain, water or gas.
3. Using the wrong power supply.
Warning
Do not get any liquid inside the products
Do not block the ventilation openings or put substances inside, in order to avoid short circuit,
fire or electric shock.
Do not place the product in the rain or moisture to avoid electric shock or fire.
Danger
Switch the power off before connecting other devices.
Power socket: Make sure the power socket under the voltage range of the product to avoid
short circuit, electric shock and fire.
Power cable: Make sure the power cable is not pressed or tightened by any items or weights.
Power Load: Do not exceed the load on the wall outlet, extension cable or other porous receptacle
to avoid fire or electric shock.
Lightning: Disconnect the power cable if it is lightning or not using in a long period of time.
Working environment
Please don't lay the product on any unstable place to avoid fallen damage.
Please don’t use the product in a place overheating, undercooling or with lots of moisture,
or near by strong magnetic devices.
Please don’t lay the product on metal shelf, in order to ensure the effective wireless transmission.
No.
1
2
3
4
5
6
7
8
Packing details
Transmitter
Receiver
Antenna
D-tap to lockable pole cable (0.6m)
Power adaptor
User manual
Warranty card
Articulating arm trestle
Quantity
X 1
X 1
X 6
X 1
X 1
X 1
X 1
X 1
Packing list This wireless system includes below accessories:

1. Product Introduction
2. Features
FLOW2000 includes transmitter and receiver, adopts the latest encrypted transmission technology,
Supports SDI and HDMI wirelessly transmitted in 600 meters scale (Line-of-Sight), 2 channels SDI/HDMI
digital video transmission, auto pairing and OLED display. FLOW2000 is equipped with DC power
connector, compact size, portable, and the receiving signal is very stable.
Remark:
1. The transmission distance may be different, and depend on surroundings, radio wave conditions,
buildings, etc., the 600 meters transmission distance may be not guaranteed.
2. The wireless transmission might be interrupted if there’re other devices of 5GHz wireless
bandwidth Used in the same location.
3. Signal reception may be affected by the position, height and angle of devices. If reception video is not
stable, please physically adjust placement for the optimized signal.
4. Set the antennas straight up and set receiver higher to enhance the transmission efficiency.
5. The product offers the AES 128-bit encryption to protect the wireless transmission. Please still be
aware of the intentional signal interception from third person. Do not use it for important
communication.
3G/HD/SD-SDI and HDMI transmission
Support up to 1080p 50/60Hz SDI & HDMI wireless transmission.
600 meters transmission distance
In open outdoor area, the effective transmission distance is approx. 600 meters （line of sight）
Wireless frequency
The system adopts 5180~5220MHz and
5760~5820MHz Wireless frequency band
（FLOW2000 Tx）.
The system adopts 5182.5~5282.5MHz and
5762.5~5822.5MHz Wireless frequency band
（FLOW2000 Rx）.
Pairing mode
Support auto pairing connection and manual
switching of frequency points. Support one
transmitter to multi-recevier mode.
OLED Display
Display the current working parameter, such
as signal format, wireless channel, signal
strength, and so on.
High quality & Wall through mode
Support 1 transmitter to unlimited receivers
and High quality & Wall through mode
choose.
Encryption
Support AES 128-bit encryption to protect the
transmission.
All-Metal Shell
Both the transmitter and receiver adopt metal
shell which is durable and solid.
All hardware design
The wireless system is hardware and
plug-and-play designed, without installing
software, easy to set up。
Multiple battery plates change
Transmitter can choose different battery plate
according to demand.
Frequency Band and Frequency Point
CH00
CH01
CH02
CH03
5180MHz
5200MHz
5220MHz
5760MHz
CH04
CH05
CH06
/
5780MHz
5800MHz
5820MHz
/
Frequency Band and Frequency Point
CH00
CH01
CH02
CH03
5180MHz
5200MHz
5220MHz
5760MHz
CH04
CH05
CH06
/
5780MHz
5800MHz
5820MHz
/

3. Appearance Instruction
Transmitter FLOW2000
⑴ Antenna
⑵ Product label
⑶ Link：Wireless status indicator
⑷ Video：Video signal indicator
⑸ Power：Power status indicator
⑹ OLED：0.96-inch OLED
⑺ Five-direction switch：Five-direction adjustment button (adjust the display menu to switch and
confirm in five directions: up, down, left, right, and vertical)
⑻ Installation thread：1/4”-20 thread. Use the package supplied articulating arm trestle to install
the device to the camera.
⑼ USB：Micro USB, software upgrade interface
⑽ HDMI in： HDMI input (HDMI-A type connector)
⑾ Battery plate：Power supply via D & F & U model battery plate. Model D battery we recommend
SWIT battery: S-8D98、S-8D58 、S-8D62 which is compatible with Panasonic CGA
series ;CGA-D54S/D28S、VBD series SVW-VBD58；Model F battery we recommend SWIT battery:
S-8972、S-8970、S-8770、S-8975，which is compatible with SONY L series NP-F770/970；Model U
battery we recommend SWIT battery LB-SU98，，which is compatible with PXW-FX series
BP-U60/U30/U90.
⑿ SDI LOOP：SDI Loop out (BNC connector)
⒀ SDI in：SDI input (BNC connector)
⒁ ON/OFF：Power switch
⒂ DC in：Support DC 7-34V voltage input, 5.5mm (outer diameter) /2.1mm (inner diameter).
Outside: negative, Inside: positive
Status
Constant On
Off
Constant On
Flash
Constant On
Flash
Description
Power connected and switched on
Power disconnected and switched off
There is recognizable video signal input
There is no recognizable video signal input
The wireless network connection is normal
The wireless network connection is abnormal
Device
FLOW2000
Transmitter
LED indicator
Power
Video
Link
The description of LED status indicator
(1)
(2)
(4)
(3)
(5)
(6) (10)
(9)
(7)
(11)
(12)
(8)
(15)
(14)
(13)

Receiver FLOW2000
⑴ Antenna
⑵ ON/OFF：Power switch
⑶ USB：Micro USB, software upgrade interface
⑷ Link：Wireless status indicator
⑸ Video：Video signal indicator
⑹ Power：Power status indicator
⑺ DC in：Support DC 7-34V voltage input, 5.5mm (outer diameter) /2.1mm (inner diameter).
Outside: negative, Inside: positive
⑻ OLED：0.96-inch OLED
⑼ Five-direction switch：Five-direction adjustment button. (adjust the display menu to switch and con
firm in five directions up, down, left, right, and vertical)
⑽ Installation thread：1/4”-20 thread, Use the package supplied articulating arm trestle to install the
device to the camera
⑾ HDMI OUT: HDMI output (HDMI-A type connector)
⑿ SDI out: SDI output (BNC connector)
⒀ Battery plate： Power supply via D & F & U model battery plate. Model D battery we recommend SWIT
battery: S-8D98、S-8D58 、S-8D62 which is compatible with Panasonic CGA series ;CGA-D54S/D28S、
VBD series SVW-VBD58；Model F battery we recommend SWIT battery: S-8972、S-8970、S-8770、
S-8975，which is compatible with SONY L series NP-F770/970；Model U battery we recommend SWIT
battery LB-SU98，which is compatible with PXW-FX series BP-U60/U30/U90
Status
Constant On
Off
Constant On
Flash
Constant On
Flash
Description
Power connected and switched on
Power disconnected and switched off
There is recognizable video signal input
There is no recognizable video signal input
The wireless network connection is normal
The wireless network connection is abnormal
Device
FLOW2000
Receiver
LED indicator
Power
Video
Link
The description of LED status indicator
(1)
(6)
(7)
(5)
(2) (8)
(11)
(9)
(12)
(10) (13)
(4)
(3)

4. OLED Display menu
Initial interface （One-to-one mode）
When no signal input，the transmitter is consistent
with the receiver display content. See Fig. 1
Initial interface （One-to-one mode）
When Transmitter and receiver video signal con-
nection normal, the transmitter is consistent with
the receiver display content. See Fig. 2
No signal input
Frequency channel display
Signal strength display
No signal input
Frequency channel display
One-to-multi mode display
No signal input
Frequency channel display
Signal strength display
Fig. 1
Signal source display
Signal format
Frequency channel Display
Signal strength display
Signal source display
Signal format
Frequency channel Display
One-to-multi mode display
Signal source display
Signal format
Frequency channel Display
Signal strength display
Fig. 2
Fig. 3 Fig. 4
Fig. 5 Fig. 6
SDI
1080P
60HZ
AUTO
M
NO
SYNC
AUTO
M
NO
SYNC
AUTO
M
SDI
1080p
60HZ
AUTO
M
NO
SYNC
AUTO
SDI
1080p
60HZ
AUTO
Initial interface （One-to-multi mode）
When the transmitter has no signal input,
see Fig. 3
Initial interface （One-to-multi mode）
When the receiver has no signal input,
see Fig. 5
Initial interface （One-to-multi mode）
When the receiver video signal is connected
normally, as shown in Fig. 6
Initial interface （One-to-multi mode）
When the transmitter video signal is connected
normally, as shown in Fig. 4
Tips:
1. Using joystick(up and down) to change frequency channel, 7 channel in total.
2. After changing to 0ne-to-multi mode, There will be a “M” show on the bottom

6.Connection
⑴ Connecting SDI IN/HDMI IN interface of FLOW2000 transmitter with SDI OUT/HDMI OUT interface of
camera or video output device. Connecting SDI loop out interface of FLOW2000 transmitter with SDI IN
interface of monitor or switcher.
5. Pairing
Interface changing
a ：Changing interface in transmitter via using joystick(left and right),see fig .7、8、9.
b : Changing interface in receiver via using joystick(left and right),see fig .7、9.
MULTI
CAST
ON
OFF
PREF.
HIGH
QUAL
WALL
THRU
FIRM-
WARE
YES
PAIR
YES
Fig.7 Fig.8 Fig.9
One to multi mode High quality mode Firmware upgrade
Pair
Wall through mode
OFF
ON
Tips:
1. The menu content of transmitter and receiver is different: Quality mode and wall through
mode can only be selected in transmitter, see fig.8
2. The“MULTI CAST” should change to“ON” in both transmitter and receiver to open one-to-multi
mode.(Both transmitter and receiver need to choose “MULTI CAST ON”)
3. Support firmware upgrading via USB interface.
4. Both transmitter and receiver support manually switch frequency channel.
5. Factory setting is “MULTI CAST OFF”.
6. Choose “MULTI CAST ON”(The transmitter need to pair with every receiver before using
one-to-multimode）
⑴ Switch on both FLOW2000 transmitter and receiver; The “POWER” indicator light in every
receiver should light up when there are multiple receiver, Waiting for jumping to main interface.
⑵ Right pushing the joystick to “PAIR” interface and choose “YES” in both transmitter and
receiver, the“LINK”indicator flashing quickly during pairing(Every receiver should pair with
the transmitter separately when using one-to-multi mode) .
⑶ “LINK” indicator will stop flashing after pairing successful. Device in encrypted transmission
state.
Fig.10
FIRM-
WARE
YES
PAIR
YES
1. Transmitter and receiver should pair in the same time. Every receiver should be paired with the
transmitter separately when using one-to-multi mode.
2. Make sure every receiver have already paired successful before using one-to-multi mode.
3. The paired receiver and transmitter, automatically connected after boot, no need to pair again.
4. Keep 1-2 m distance between transmitter and receiver when pairing to avoid pairing failure.
5. Do not using more than 4 group wireless transmission device to avoid disturbing.
Tips:

⑵ Connecting SDI OUT interface of FLOW2000 receiver with SDI IN interface of monitor or switcher.
When using one-to-multi mode, every SDI OUT interface of receiver should be connected with
SDI IN interface of monitor or switcher.
⑶ Switch on both FLOW2000 transmitter and receiver, “Power”indicator light up，OLED screen
show“WAIT�”then jump to initial interface，see fig.1 or fig.3;Wait until “Link” and “Video”
indicator light up, the transmitter and receiver have identifiable signal inputs and connected
successfully. If the transmitter and receiver have identifiable signal inputs but fail to establish a
connection, the "link" indicator will flash.
Tips:1. After powering the FLOW2000 transmitter and receiver, dial the power switch on the
product to "on""
2. FLOW2000 transmitter support SDI video signal input and HDMI video signal input, the
system automatically identify input video interfaces. System will choose SDI video signal
when both HDMI and SDI interface is connected.
3. When multiple receivers are used simultaneously in the same environment, ensure that
multiple wireless devices have identifiable signal input.
7.High quality mode & Wall through mode
⑴ Connecting SDI IN/HDMI IN interface of FLOW2000 with SDI OUT/HDMI OUT interface of camera
or video output device. Connecting SDI loop out interface of FLOW2000 transmitter with SDI IN
interface of monitor or switcher.
⑵ When using one-to-multi mode, every SDI OUT interface of receiver should be connected with
SDI IN interface of monitor or switcher.
⑶ Switch on both FLOW2000 transmitter and receiver, every receiver should be switch on when
using one-to-multi mode. “Power”indicator light up，OLED screen show“WAIT�”then jump to
initial interface, see fig.1 or fig.3;Wait until “Link” and “Video” indicator light up, the transmitter
and receiver have identifiable signal inputs and connected successfully, right push the joystick
to“PREF”interface, see fig.11.
⑷ It is recommended to choose high quality mode for wireless devices under normal operating
conditions, such as better environment, stronger signal, or more than one
set of wireless devices under the same scene.
⑸ Wall through mode is recommended for wireless devices under complex
operating conditions, such as poor on-site environments, high distance
barriers and only 1-2 sets of wireless devices in the same scene.
(If more than one set is used in the same scene, it is recommended
to use a high quality mode to reduce interaction)
Tips：1. When wireless devices under normal operating condition, choose High quality mode can
get a better video quality, but transmission distance will be cut.
2. When wireless devices under complex operating condition, choose Wall through mode
can get a long transmission distance, but the video quality will be cut.
PREF.
HIGH
QUAL
WALL
THRU
Fig.11

⑴ Set the antenna on both transmitter and receiver vertically straight up.(See Fig.12)，Set the receiver
faces the transmitter to extend the transmission distance and stabilize the transmission quality.
⑶ Avoid walls, trees and water to reduce signal attenuation.
⑵ Set the receiver as high as possible to avoid interference.
8. The way to get the best effective of Wireless Transmission
Fig.12

9. Trouble shooting
10. Specification
If the receiver failed to output video correctly, the possible causes are as below; please find the solution
from following chart:
The receiving
video
No display
Poor
Video quality
Possible causes
The transmitter receiver is
not powered on
The antennas are not installed
properly and screwed tightly
Bad connection of video cable
Video format is not supported
Bad connection with video cable
The wireless transmission is
disturbed by environment
The transmission distance is out of
effective range
Solution
Check power connection and switch on
the transmitter and receiver
Install the antennas properly and screw
tightly of both transmitter and receiver
Check video cable connection of both
transmitter and receiver
Change the output video format of the
camera
Reconnect reliably
Wait for 1 minute or reboot the transmitter
and receiver
Close the transmitter to the receiver
Model
Input
Output
Video format
Wireless frequency
modulation mode
transmission distance
Power consumption
Transmitting power
Human‒Machine Interaction
Input voltage
Working environment
Dimension(without antenna and plate)
Net weight (without antenna)
FLOW2000T Transmitter FLOW2000R Receiver
SDI×1、HDMI×1
SDI×1
1080I（60/59.94/50）/1080PsF（24/23.98）/720P（60/59.94/50)/1080P
（60/59.94/50/30/29.97/25/24/23.98）
5.17GHz-5.23GHz and 5.75GHz-5.83GHz
OFDM Support 16QAM, 64QAM, QPSK, BPSK modulation mode
600m（Line of sight）
≤8W
Max CE:25mW FCC:50mW
0.96-inch OLED, Five-direction adjustment button
DC/ Battery：7～34V
Temperature ：0℃~+40℃
66×106.5×24.7（mm）
236.0g
/
HDMI×1、SDI×2
≤8W
/
106.5×66×24.7（mm）
245.0g
