Digital Photo Frame Operation Manual
Model NO.: SDPF651-BLACK-D

Cautions
Precautions and maintenance
For indoor use only
To avoid risk of fire or electric shock, do not expose the unit to moisture or
condensation.
To avoid overheating, do not block the ventilation holes on the back of the Digital Photo
Frame.
Keep the Digital Photo Frame out of direct sunlight.
Always use the eject buttons on the memory storage card slots to remove the storage
cards.
Do not dismantle the Digital Photo Frame. There is a risk of electric shock and there are
no user-serviceable parts inside. Dismantling the Digital Photo Frame will void your
warranty.
Cleaning the LCD Screen
Treat the screen carefully. Because the screen of the Digital Photo Frame is made of
glass and it would easily be broken or scratched.
If fingerprints or dust accumulate on the LCD screen, we recommend using a soft,
non-abrasive cloth such as a camera lens cloth to clean the LCD screen.
Moisten the cleaning cloth with the cleaning solution and apply the cloth to the screen.
Introduction:
Thank you for your purchase of the Digital Photo Frame. It is designed to allow quick and
easy view of photos taken from your digital camera, mobile phone, or from a memory
storage card. Please read this User Manual carefully to learn the correct way to use the
Digital Photo Frame.
WARNING:
Please power off the unit before inserting or removing a card or
USB device.
Failure to do so may cause damage to the card/USB and the unit.
To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
1

Features:
1. Support Photo format: JPEG
2. Support Memory Card: SD/SDHC/MMC
3. USB Connection: USB2.0 HOST
4. Built-in 8M Flash Memory
5. Support viewing pictures in thumbnail mode
6. Auto Slideshow when insert Memory Card
7. Built-in Clock and calendar with slideshow
8. Copy and delete function
9. Image-display mode: slideshow, preview, zoom, rotate function.
10.Adjustable slideshow speed and above 10 kinds of transition slideshow
11.Adjustable brightness, contrast, saturation
12. Slideshow mode: single window, two windows, tripe windows and four windows.
13.
Packaging Check List:
1. 7 inch digital photo frame
2. User manual
3. AC/DC adapter
4. Warranty card
5. Stand
1 piece
1 piece
1 piece
1 piece
1 piece
2
OSD languages: English,French,Italian,German,Spanish,Portuguese,Swedish,Dutch

CONTENTS
1. Product Diagram··························································································4
1.1 Left Side of Frame·················································································4
1.2 Rear of Frame ······················································································4
2. Getting Started·····························································································4
3. Operating Instruction·····················································································5
3.1 Card and USB ······················································································5
3.2 Picture Mode························································································5
3.3 Save/Copy & Delete function···································································6
4. File············································································································6
5. Calendar·····································································································7
6. Setup·········································································································7
7. Stand Instruction ··························································································7
8. Technical Specifications·················································································8
9. Troubleshooting Guide ··················································································8
3

1. Product Diagram
1.1 Left Side of Frame
1.2 Rear of Frame
2.Getting Started
2.1 Extend the digital photo frame bracket on the back of the frame to the widest position for
greatest stability, and then plug one end of the included AC/DC adapter into a standard
100-240V AC electrical outlet andtheother endinto theright side the frame.
2.2 Remove the protective film covering the LCD.
2.3 Power on the unit by connecting the power or pressing the Power button on the back
side.
1.Power on/off
2.UP
3. Play/Pause/OK
4. Left
5. Right
6.Down
7.Menu/Exit
1.SD/SDHC/MMC CARD
2.USB PORT
3.DC IN
4

3. Operating Instruction
3.1 Card and USB
Note: Make sure there are supported picture files in the Card or USB device.
3.2 Picture Mode
Note: In thumbnail mode, press to select the picture, press again to start slideshow
It supports SD/SDHC/MMC and USB 2.0.
After inserting a card or USB device,
slideshow will play automatically, then press
MENU twice to access to Photo, File,
Calendar and Setup. Press to confirm.
In the main menu, Highlight Photo, press
to access to thumbnail mode, use
to choose the picture you want to display,
press to play the picture in single window.
Press to start slideshow pictures in the
selected slide mode(single window/ two/four
windows/tripe windows).
After turning on the unit, it will show the
memory card you insert.
5

3.3 Copy/Save & Delete function
Note: System will show “Memory Full” if remaining built-in memory size is not enough to
store the photo.
4.File
Delete
Select File, then press to access to file
interface. In this mode, you can browse all
the picture files in the memory card or the
built-in memory.
Use to select the picture you want to
delete. Long Press MENU to enter the
delete interface, press to confirm.
Copy/Save pictures to built-in memory: In the
pause state of single picture, long press
MENU to enter copy interface, press to
copythe picture to built-in memory.
Delete pictures in built-in memory or memory
card：
In thumbnail mode, use to select
the picture you want to delete, then long
press MENU to enter the delete interface,
press to confirm.
6

5. Calendar
6. Setup
7. Stand Instruction
Insert the bracket into the slot of the digital photo frame,rotate the bracket to choose
standing horizontally or vertically until it is locked in place. Please refer to the illustration
shown below.
Select Calendar from the main menu, press
to enter, the calendar is displayed and
any photos on the connected memory are
shown as a slideshow tothe side. Browse the
calendar by using .
Select Setup from the main menu, then press
to access toSetup interface. Use to
select the item you want to set up. Press
to show the sub menu, select with , then
press to confirm.
You could select language, set time, choose
picture mode and so on.
7

8. Technical Specifications
Adapter:
Input:AC 100-240V 50/60HZ 150mA
Output: DC 5V/1A
Picture Format: JPEG
Memory Cards: SD/SDHC/MMC
USB connection: USB 2.0
Screen Parameter:
Screen Size: 7 inch TFT
Resolution: 800* 480
Contrast: 300:1
Aspect Ratio: 16:9
Brightness: 250-300 cd/m2
Response Time: 20ms
Viewing Angle: 60°(left/right/vertical), 40°(horizontal)
Working Temperature: 0 °C~40 °C, Humidity: 10-85%
9.Troubleshooting Guide
If you have problems with your player, please consult both this guide and manual.If you
need further assistance, please contact Technical Support.
No power:
Please check whether the plug is inserted correctly.
Can not read the CARD or USB:
Please confirm whether there is storage in the card or USB device.
Empty devices cannot be read.
Can not play the file:
Please confirm if the file format is compatible with the player.
Display too bright or too dark:
Please adjust the brightness or contrast in the setup menu.
The color is light or no color:
Please adjust the color and contrast setup.
