Sylvania SRCD223 User manual

COLOR TV/DVD/VHS
SRCD223
(23 inch) SRCD227 (27 inch)
OWNER’S
MANUAL
As an ENERGY STAR
Partner, our company has
determined that this product meets
the ENERGY STAR guidelines for
energy efficiency. ENERGY STAR is
a U.S. registered mark.
®
®
®
If you need additional operating assistance after reading this owner’s
manual, please call
TOLL FREE : 1-800-968-3429.
Please read before using this equipment
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
This Owner’s Manual is
made of recycled paper. SUPPLIED ACCESSORIES
Batteries
Remote Control Unit
ACCESSORIES
2 AA Batteries
NE204UD
PART NO.
TD530/601_01-36 02.4.5 6:32 PM Page 1

1.Read instructions-All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions
should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions
should be followed.
5.Cleaning-Unplug TV/DVD/VHS from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possi-
bility of the loss of an authorization code for a CATV con-
verter, is not intended to be unplugged by the user for clean-
ing or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description other-
wise required in item 5.
6.Attachments-Do not use attachments not recommended by
the TV/DVD/VHS manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this TV/DVD/VHS near
water-for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool,
and the like.
8.Accessories-Do not place this TV/DVD/VHS on an unstable
cart, stand, tripod, bracket, or table. The TV/DVD/VHS may
fall, causing serious injury to someone, and serious damage
to the appliance. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with the
TV/DVD/VHS. Any mounting of
the appliance should follow the
manufacturer’s instructions and
should use a mounting accessory
recommended by the manufacturer.
An appliance and cart combination
should be moved with care.Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.
AMEUBLES- Cet appareil ne doit
être placéque sur un meuble (avec
ou sans roulettes) recommandépar
le fabricant. Si vous l’installez sur
un meuble àroulettes, déplacez les
deux ensembles avec précaution.
Un arrêt brusque, l’utilisation
d’une force excessive et des sur-
faces irrégulières risquent de désta-
biliser l’ensemble et de le renverser.
9. Ventilation-Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of the TV/DVD/VHS and to protect it from over-
heating, and these openings must not be blocked or cov-
ered. The openings should never be blocked by placing the
TV/DVD/VHS on a bed, sofa, rug, or other similar surface.
This TV/DVD/VHS should never be placed near or over a
radiator or heat register. This TV/DVD/VHS should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
10.Power Sources-This TV/DVD/VHS should be operated
only from the type of power source indicated on the mark-
ing label. If you are not sure of the type of power supply to
your home, consult your appliance dealer or local power
company. For TV/DVD/VHSs intended to operate from
battery power, or other sources, refer to the operating
instructions.
11.Grounding or Polarization-This TV/DVD/VHS is
equipped with a polarized alternating-current line plug(a
plug having one blade wider than the other). This plug will
fit into the power outlet only one way. This is a safety fea-
ture. If you are unable to insert the plug fully into the out-
let, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
12.Power-Cord Protection-Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying par-
ticular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
- 2 - EN
1B15
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSON-
NEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THIS SYMBOL INDICATES THAT DAN-
GEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
The caution marking is located on the rear of the cabinet.
IMPORTANT SAFEGUARDS
PORTABLE CART WARNING
S3126A
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
S3126A
TD530/601_01-36 02.4.5 6:32 PM Page 2

- 3 - EN
1B15
13.Outdoor Antenna grounding-If an outside antenna or
cable system is connected to the TV/DVD/VHS, be sure
the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with respect to
proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements
for the grounding electrode. (Fig. A)
14.Lightning-For added protection for this TV/DVD/VHS
receiver during a lightning storm, or when it is left unat-
tended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the TV/DVD/VHS due to
lightning and power-line surges.
15.Power Lines-An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind
into this TV/DVD/VHS through openings as they may
touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any
kind on the TV/DVD/VHS.
18.Servicing-Do not attempt to service this TV/DVD/VHS
yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
19.Damage Requiring Service-Unplug this TV/DVD/VHS
from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the
TV/DVD/VHS.
c. If the TV/DVD/VHS has been exposed to rain or water.
d. If the TV/DVD/VHS does not operate normally by follow-
ing the operating instructions. Adjust only those controls
that are covered by the operating instructions, as improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the TV/DVD/VHS to its normal operation.
e. If the TV/DVD/VHS has been dropped or damaged in any
way.
f. When the TV/DVD/VHS exhibits a distinct change in per-
formance-this indicates a need for service.
20.Replacement Parts-When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other haz-
ards.
21.Safety Check-Upon completion of any service or repairs to
this TV/DVD/VHS, ask the service technician to perform
routine safety checks to determine that the TV/DVD/VHS
is in proper operating condition.
22.Heat-This TV/DVD/VHS product should be situated away
from heat sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that produce heat.
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
S2898A
WIRE
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRODE SYSTEM
(NEC ART 250, PART H)
SERVICE
EQUIPMENT
CLAMP
ANTENNA
LEAD IN
ANTENNA
POWER SERVICE GROUNDING
GROUND
ELECTRIC
FIGURE A
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
TD530/601_01-36 02.4.5 6:32 PM Page 3

- 4 - EN
1B15
RADIO-TV INTERFERENCE
This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be deter-
mined by turning the equipment off and on, the
user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment into an outlet on a cir-
cuit different from that to which the receiver is
connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
FCC WARNING- This equipment may gener-
ate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction man-
ual. The user could lose the authority to oper-
ate this equipment if an unauthorized change
or modification is made.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public perfor-
mance and lending of discs are prohibited.
LASER SAFETY
This unit employs a laser. Only a qualified service
person should remove the cover or attempt to ser-
vice this device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUST-
MENTS OR PERFORMANCE OF PROCE-
DURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN AND INTERLOCK
DEFEATED. DO NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK
MECHANISM.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est con-
forme à la norme NMB-003 du Canada.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC
ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU’AU FOND.
PRECAUTIONS
TD530/601_01-36 02.4.5 6:33 PM Page 4

- 5 - EN
1C29
AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
LOCATION
For safe operation and satisfactory performance of
your TV/DVD/VHS, keep the following in mind
when selecting a place for its installation:
•Shield it from direct sunlight and keep it away from
sources of intense heat.
•Avoid dusty or humid places.
•Avoid places with insufficient ventilation for proper
heat dissipation. Do not block the ventilation holes at
the top and bottom of the unit. Do not place the unit
on a carpet because this will block the ventilation
holes.
•Install unit in a horizontal position.
•Avoid locations subject to strong vibration.
•Do not place the TV/DVD/VHS near strong magnetic
fields.
•Avoid moving TV/DVD/VHS to locations where
temperature differences are extreme.
•Do not handle the power cord with wet hands.
•Do not pull on the power cord when disconnecting
it from an AC wall outlet. Grasp it by the plug.
•If, by accident, water is spilled on your unit, unplug
the power cord immediately and take the unit to our
Authorized Service Center for servicing.
•Do not put your fingers or objects into the
TV/DVD/VHS disc loading tray.
•Do not place anything directly on top of the unit.
WARNING
Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. If a DVD is played in a TV/DVD/
VHS which has moisture, it may damage the DVD
and TV/DVD/VHS. Therefore when the condensation
occurs inside the unit, turn the POWER button on
and allow at least 2 hours for the unit to dry out.
The serial number of this product may be found on the back of the unit. No other TV/DVD/VHS has the same
serial number as yours. You should record the number and other vital information here and retain this book as
a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regula-
tions concerning chemical wastes.
TD530/601_01-36 02.4.5 6:33 PM Page 5

- 6 - EN
1C29
TABLE OF CONTENTS
CIMPORTANT SAFEGUARDS . . . . .2
CPRECAUTIONS . . . . . . . . . . . . . . . .4
LOCATION . . . . . . . . . . . . . . . . . . .5
AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE .5
WARNING . . . . . . . . . . . . . . . . . . . .5
CFEATURES . . . . . . . . . . . . . . . . . . . .7
COPERATING CONTROLS AND
FUNCTIONS . . . . . . . . . . . . . . . . . . .9
CPREPARATION FOR USE . . . . . . .11
ANTENNA/CABLE
CONNECTIONS . . . . . . . . . . . . . . .11
CONNECTIONS TO FRONT A/V
JACKS . . . . . . . . . . . . . . . . . . . . . .12
INSTALLING THE BATTERIES . .12
CONNECTING TO A STEREO
SYSTEM . . . . . . . . . . . . . . . . . . . .13
CONNECTING TO AN AMPLIFIER
EQUIPPED WITH DIGITAL INPUT
JACKS, MD DECK OR DAT DECK
(for DVD) . . . . . . . . . . . . . . . . . . . .13
CONNECTING TO A DOLBY
DIGITAL DECODER
OR DTS DECODER (for DVD) . . .14
CSET UP FOR USE . . . . . . . . . . . . .15
CHANNEL SET UP
FOR THE FIRST TIME . . . . . . . . .15
DELETING (OR ADDING)
CHANNEL . . . . . . . . . . . . . . . . . . .15
CHANNEL SET UP AGAIN . . . . . .16
SELECTING THE LANGUAGE . .16
DAYLIGHT-SAVING TIME . . . . . .16
CLOCK SET UP
(AUTO / MANUAL) . . . . . . . . . . . .17
TV/VCR SECTION
CTV OPERATION . . . . . . . . . . . . . . .19
WATCHING A TV PROGRAM . . .19
DEGAUSSING . . . . . . . . . . . . . . . .19
PICTURE CONTROL . . . . . . . . . . .19
CLOSED CAPTION SYSTEM . . . .20
V-CHIP SET UP . . . . . . . . . . . . . . .21
CMTS(Multi-Channel Television
sound)SYSTEM . . . . . . . . . . . . . . . .23
CHECKING THE SELECTED
MTS MODE . . . . . . . . . . . . . . . . . .23
MTS RECORDING/MONITOR
MODE . . . . . . . . . . . . . . . . . . . . . .23
SELECTING THE MTS SYSTEM .24
CVIDEO CASSETTE . . . . . . . . . . . . .25
CC
PLAYBACK . . . . . . . . . . . . . . . . . . .26
NORMAL PLAYBACK . . . . . . . . .26
TRACKING ADJUSTMENT . . . . .26
SLOW MOTION . . . . . . . . . . . . . .26
PICTURE SEARCH . . . . . . . . . . . .26
STILL PICTURE . . . . . . . . . . . . . .26
VERTICAL HOLD CONTROL . . .26
CSPECIAL PLAYBACK . . . . . . . . . .27
RENTAL PLAYBACK . . . . . . . . . .27
AUTO REPEAT PLAYBACK . . . . .27
CSEARCH . . . . . . . . . . . . . . . . . . . . .28
ZERO RETURN . . . . . . . . . . . . . . .28
TIME SEARCH . . . . . . . . . . . . . . .28
INDEX SEARCH . . . . . . . . . . . . . .29
CSPECIAL FEATURES . . . . . . . . . .29
REAL TIME TAPE COUNTER . . .29
AUTO REWIND-EJECT . . . . . . . .29
CRECORDING . . . . . . . . . . . . . . . . .30
NORMAL RECORDING . . . . . . . .30
SKIPPING UNWANTED SCENES
DURING
RECORDING . . . . . . . . . . . . . . . . .30
OTR (One Touch Recording) . . . . . .31
COPYING A VIDEO CASSETTE
(Requires a VCR or camcorder) . . .31
CTIMER . . . . . . . . . . . . . . . . . . . . . .32
AUTOMATIC
TIMER RECORDING . . . . . . . . . .32
TIMER PROGRAM EXTENSION .33
HINTS FOR AUTOMATIC TIMER
RECORDING . . . . . . . . . . . . . . . . .34
AUTO RETURN . . . . . . . . . . . . . . .34
SLEEP TIMER . . . . . . . . . . . . . . . .34
CON SCREEN DISPLAY . . . . . . . . .35
CCABLE CHANNEL
DESIGNATIONS . . . . . . . . . . . . . .35
DVD SECTION
CABOUT THE DISCS . . . . . . . . . . . .36
PLAYABLE DISCS . . . . . . . . . . . .36
DISC TYPES . . . . . . . . . . . . . . . . .36
SYMBOLS USED IN
THIS MANUAL . . . . . . . . . . . . . . .36
CPLAYING A DISC . . . . . . . . . . . . . .37
PLAYING A DVD VIDEO OR AN
AUDIO CD . . . . . . . . . . . . . . . . . . .36
USING THE DVD MENUS . . . . . .36
USING THE TITLE MENU . . . . . .36
RESUMING PLAYBACK
FROM THE POINT WHERE
PLAYBACK STOPPED . . . . . . . . .38
FAST FORWARD/REVERSE . . . . .38
PAUSING PLAYBACK OR DIS-
PLAYING
A STILL PICTURE . . . . . . . . . . . . .38
STEPPING THROUGH FRAMES .38
SLOW MOTION . . . . . . . . . . . . . .39
PLAYING FROM A DESIRED
TITLE OR CHAPTER . . . . . . . . . .39
STARTING FROM A DESIRED
TIME COUNT . . . . . . . . . . . . . . . . .39
STARTING FROM A DESIRED
TRACK . . . . . . . . . . . . . . . . . . . . . .39
REPEAT . . . . . . . . . . . . . . . . . . . . .40
A-B REPEAT . . . . . . . . . . . . . . . . .40
MARKER . . . . . . . . . . . . . . . . . . . .41
PROGRAM (Audio CD) . . . . . . . . .41
RANDOM (Audio CD) . . . . . . . . . .42
ZOOM PLAYBCK . . . . . . . . . . . . .42
PLAYING AN MP3 DISC . . . . . . . .42
CHANGING THE ONSCREEN
DISPLAY DURING MP3
DISC PLAY . . . . . . . . . . . . . . . . . .43
PLAYING AN MP3 DISC FROM
A DESIRED TRACK . . . . . . . . . . .43
PLAYING AN MP3 DISC IN A
PROGRAMMED WAY . . . . . . . . . .43
PLAYING AN MP3 DISC AT
RANDOM . . . . . . . . . . . . . . . . . . . .44
CSETTINGS . . . . . . . . . . . . . . . . . . .44
CHANGING THE AUDIO
LANGUAGE OR SOUND MODE .44
CHANGING THE SUBTITLE
LANGUAGE . . . . . . . . . . . . . . . . .45
CHANGING THE CAMERA
ANGLE (Multi-Angle Pictures) . . . .45
CHANGING THE ON-SCREEN
DISPLAY . . . . . . . . . . . . . . . . . . . .46
CCHANGING THE SETUP ITEMS .47
LANGUAGE SETTINGS . . . . . . . .47
DISPLAY SETTINGS . . . . . . . . . . .48
AUDIO SETTINGS . . . . . . . . . . . .49
PARENTAL LOCK . . . . . . . . . . . . .50
CLANGUAGE CODE LIST . . . . . . . .51
CTROUBLESHOOTING GUIDE . . .52
CMAINTENANCE . . . . . . . . . . . . . . .55
DISC HANDLING . . . . . . . . . . . . .55
CSPECIFICATIONS . . . . . . . . . . . . .56
CWARRANTY . . . . . . . . . . .Back Cover
TD530/601_01-36 02.4.5 6:33 PM Page 6

- 7 - EN
1C29
•
Hi-Fi system –The Hi-Fi stereo recording system
offers you excellent sound quality with a dynamic
range of 80dB, frequency response from 20Hz to
20kHz, and 0.005% wow and flutter.
•
Rotary 4-head Record/Playback System–Four heads
ensure excellent picture quality and special effects playback.
•Index Search–
Fast-forwards to start of next recording.
•Slow Motion–View recorded program at slower
than normal speed.
•Infrared remote control
•Trilingual on screen tv/vcr setup display selec-
table in English or Spanish or French
•
Real time counter–This shows the elapsed recording
or playback time in hours, minutes, and seconds. The
“–” indication will appear when the tape is rewound
further than the tape counter position “0:00:00”.
•181 channel capability PLL frequency synthesiz-
er tuner with direct station call–(A converter may
be necessary to view scrambled cable channels.)
•Auto Clock Setting–Allows you to set the clock
function from a PBS broadcast station.
•Closed caption system–You may view specially
labeled (cc) TV programs, movies, news, prere-
corded tapes, etc. with either a dialogue caption or
text display added to the program.
•Auto power on and off system–Automatically
turns on the TV/DVD/VHS when you insert the
cassette, turns off after auto-rewind, and ejects
when the beginning of the tape is reached.
•Auto rewind when the end of a tape is
reached–This function doesn’t occur when using
timer recording.
•Smooth mode change–TV/VCR mode, DVD
mode automatically changes without control.
•2 Step picture search operation–You can view a
video program at a high speed or super high speed
in either a forward or reverse direction in LP and
SLP mode. For SP mode only high speed.
•Three different playback tape speeds : SP/LP/SLP
•Two different recording tape speeds : SP/SLP
•Auto Head Cleaner–Automatically cleans video
heads as you insert or remove a cassette.
•Zero Return–The tape returns to counter of
0:00:00 by rewinding or fast forwarding.
•Still–“Freeze”the picture at any time, for close
viewing of a particular scene.
•Digital Auto Tracking (DTR)–Automatically
adjusts the tracking for each tape you play.
•Rental play mode–Improves playback picture
quality from worn tapes, such as rental tapes.
•Auto repeat–Allows you to repeat the playing of a
tape indefinitely without pressing the PLAY button.
•Time search–Let you set the TV/DVD/VHS to
advance the tape by entering the desired playback
time you want to skip.
•OTR (One Touch Recording)–Instant timed
recording from 30 to 480 minutes is possible at the
push of the REC/OTR button.
•1 Year, 8 events (including Daily and Weekly
Timer Recording)–The built-in timer allows you to
record up to 8 programs at different times on dif-
ferent channels up to 1 year in advance. The Daily
timer allows recordings to be made of daily broad-
casts, and the Weekly timer allows recording to be
made once a week up to the end of the tape.
•Auto return–After timer recording is finished, the
TV/DVD/VHS can return to the beginning of the
recording.
•Sleep timer–Allows you to have the
TV/DVD/VHS
automatically turn on or off at a desired time.
Timer Program Extension–Allow you to shift the
time schedule for automatic timer recording.
•V-CHIP–Enables parents to prevent their children
from watching inappropriate material on TV.
FEATURES
TV/VCR
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regula-
tions concerning chemical wastes.
TD530/601_01-36 02.4.5 6:33 PM Page 7

- 8 - EN
1C29
DVD
¡Dolby Digital surround
This player can handle Dolby Digital surround sound
having 5.1 channels when connected to a Dolby Digital
decoder.
¡Still/fast/slow/step playback
Various playback modes are available including still pic-
tures, fast forward/reverse, slow motion and step frames.
¡Random playback for audio CD and MP3
This player can shuffle the order of tracks to play them in
random order.
¡Program playback for audio CD and MP3
You can program the order of tracks to play them in any
desired order.
¡DVD menus in a desired language
You can display DVD menus in a desired language, if
available on a DVD.
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input
from the player for five minutes in the stop mode. When
the screen saver program is activated for 30 minutes, the
DVD power is automatically turned off, and "DVD"
appears on the screen.
¡Subtitles in a desired language
You can select a desired language for the display subtitles,
if that language is available on a disc.
¡Selecting a camera angle
You can select the desired camera angle, if a disc contains
sequences recorded from different angles.
¡Choices for audio language and sound mode
You can select the desired audio language and sound
mode, if different languages and modes are available on a
disc.
¡Parental lock
You can set the control level to limit playback of discs
which may not be suitable for children.
¡Automatic detection of discs
This player automatically detects if a loaded disc is DVD,
audio CD or MP3 on disc.
¡Playing an MP3 disc
You can enjoy MP3 files which are recorded on CD-
R/RW.
¡Direct Search
You can search the desired title, chapter, and track with
numeric button during playback or in stop mode.
¡On-screen display
Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.
•Sleep timer
Allows you to have the TV/DVD/VHS automatically
turn off at a desired time.
¡DTS (Digital Theater System)
You can enjoy 5.1channel surround system developed by
the Digital Theater System co. which reproduces the orig-
inal sound as truthfully as possible.
¡Search
Chapter search: Search for the chapter designated by user
is possible.
Title search: Search for the title designated by user is
possible.
Track search: Search for the track designated by user is
possible.
Time search: Search for the time designated by user is
possible.
¡Repeat
Chapter: Repeated playback of the chapter of the
disc being played is possible.
Title: Repeated playback of the title of the disc
being played is possible.
Track: Repeated playback of the track of the disc
being played is possible.
Disc
(audio CD) : Repeated playback of the entire disc being
(MP3) played is possible.
A-B: The part between A and B designated by
user is possible.
Album: Repeated playback of the folder of the
MP3 disc being played is possible.
¡Zoom
2-time and 4-time magnified screen can be displayed.
¡Marker
The part designated by user can be called back.
¡Resume Play
User can resume to playback from the part at which the
play was stopped.
¡SRS TruSurround
You can enjoy stereophonic virtual space on your existing
stereo system.
¡Bit rate indication
¡DRC (Dynamic range control)
NOTE:
•We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
a universal remote control.
If you decide to use a universal remote control with this unit, please be aware that the code number given
may not operate this unit. In this case, please call the manufacturer of the universal remote control.
This unit employs TruSurround system
of SRS Labs, Inc. as virtual
technology.
TruSurround and the symbol are trademarks of
SRS Labs, Inc.
TruSurround technology is incorporated under license
from SRS Labs, Inc.
Manufactured under license from Dolby
Laboratories. “Dolby”and the double-D sym-
bol are trademarks of Dolby Laboratories.
“DTS”and “DTS Digital Out”are trademarks
of Digital Theater Systems, Inc.
TD530/601_01-36 02.4.5 6:33 PM Page 8

- 9 - EN
1C29
OPERATING CONTROLS AND FUNCTIONS
6.OPEN/CLOSE button [DVD P.37]
Press to insert discs into or remove them from the
tray.
7.Disc loading tray
8.DVD indicator
Lights on during DVD mode.
9.SELECT button
Press to change to TV/VCR mode or DVD mode.
NOTE: For about 4 seconds just after the DVD
mode has switched to the TV mode, the button
does not work to switch back to the DVD mode.
10. TV/VCR indicator
Lights on during TV/VCR mode.
11. CHANNEL K/Lbuttons
Press to select memorized channel.
NOTE: Also use these buttons to select the front
A/V input. (See page12)
12. Recording indicator
Flashes during recording. Lights up in the Stand-
by mode for Timer Recording.
13. REC/OTR (RECORD) button [TV/VCR P.28]
Press for manual recording. Activates One Touch
Recording. (OTR is only during TV/VCR mode.)
14. REW button (for TV/VCR) [TV/VCR P.26]
Press to rewind the tape, or to view the picture
rapidly in reverse during playback mode. (Rewind
Search)
15. FWD button (for TV/VCR) [TV/VCR P.26]
Press to rapidly advance the tape, or to view the
picture rapidly in forward during playback mode.
(Forward Search)
16. STOP/EJECT button [TV/VCR P.28]
Press to stop the tape motion. Press in the Stop
mode to remove tape from the unit.
17. Remote sensor window
18. HEADPHONE jack
To connect headphone (not supplied) for personal
listening.
19. VIDEO input jack
Connect to the video output jack of a video
camera or VCR.
- REMOTE CONTROL - [Fig. 2]
1.POWER button [TV/VCR P.15 / DVD P.37]
Press to turn the power on and off.
2.VOLUME X/Ybuttons
Press to control the volume level for the DVD and TV.
3.SKIP buttons (for DVD) [P.37]
Skip chapters or tracks to a desired point.
4.PLAY button [TV/VCR P.26 / DVD P.37]
Starts playback of the disc or tape contents.
5.STOP button [P.37]
Stops operation of the disc.
- TV/DVD/VHS FRONT PANEL - [Fig.1]
12 4 5 6 1071514983 3 411 12 13 212019181716
TV/VCR DVD
STOP
SKIP
PLAY
SKIP
VOLUME
POWER
OPEN/CLOSE
SELECT
CHANNEL
REC/OTR
STOP/EJECT
F.FWD
PLAY
REW
RL
AUDIOVIDEO
HEADPHONE
SEARCH
PAUSE
PLAY
STOP
ENTER
RECORD
DISC
MENU
RETURNTITLESETUP
A
- B REPEATSEARCH MODE CLEAR
MODE ANGLESUBTITLEAUDIO
DISPLAY
SPEED C.RESET
POWER PICTURE SELECTSLEEP
CH.
VOL.
MUTEZOOM
123
456
789
0 +10
+100
34
35
23
24
26
25
(DVD) 3
(TV/VCR) 14
13
27
28
30
31
33
32
29
4
36
37
38
41
3 (DVD)
15 (TV/VCR)
43
2
11
45
44
42
5
39
40
1
22
TD530/601_01-36 02.4.5 6:33 PM Page 9

- 10 - EN
1C29
20. AUDIO L/R input jacks
Connect to the audio output jacks of a video
camera or VCR. To access the front A/V input
see ITEM 11 or ITEM 23.
21. Cassette compartment
22. PICTURE button
Press to adjust the picture.
23. Number buttons
TV Mode:
[P.15]
Press two digits to directly access the desired
channel.
Remember to press a "0" before a single digit
channel.
+100 button–
Press to select cable channels which are equal or
greater than number 100.
DVD Mode:
Press to enter the desired number.
+10 button–
Press to enter the desired numbers which are
equal or greater than number 10.
00 Numbers–
By pressing the numbers 00 automatically switch-
es the TV to the front A/V input.
24. PAUSE button [TV/VCR P.26 / DVD P.38]
Pauses the current disc or tape operation.
25. SPEED button [TV/VCR P.30]
Press to choose the desired recording speed:
SP/SLP.
26. C.RESET button [TV/VCR P.28]
Press to reset counter to 0:00:00.
Press to cancel a setting of timer program. (See
page 33.)
27. DISPLAY button
TV/VCR Mode:
Display the counter or the current channel number
and current time on the TV screen.
DVD Mode: [P.43]
Displays the current status on the TV screen for
checking purposes.
28. SETUP button [TV/VCR P.15]
Press to enter or exit the TV menu or DVD setup
mode.
29. TITLE button [DVD P.37]
Displays the title menu.
30. CLEAR button
Resets a setting.
31. MODE button [DVD P.41]
Activates program playback or random playback mode.
32. SEARCH MODE button [DVD P.39]
Press to locate a desired point.
33. AUDIO button [DVD P.44]
Press to select a desired audio language or sound
mode.
34. SUBTITLE button [DVD P.45]
Press to select a desired subtitle language.
35. REPEAT button [DVD P.40]
Repeats playback of the current disc, title, chapter
or track.
36. ANGLE button (DVD mode) [DVD P.45]
Press to change the camera angle to see the
sequence being played back from a different angle.
37. A-B REPEAT button [DVD P.40]
Repeats playback of a selected section.
38. RETURN button
Returns to the previous operation.
39. ENTER button
Press to accept a setting.
40. Arrow buttons
TV/VCR Mode:
Press to select a setting mode from the menu on
the TV screen.
Press to select or adjust from a particular menu.
DVD Mode:
Use when making settings while watching the
display on a TV screen.
41. DISC MENU button [DVD P.37]
Displays the menus in the DVD.
42. ZOOM Button [DVD P.42]
Enlarges part of a DVD-reproduced image.
43. MUTE button
Mutes the sound. Press it again to resume sound.
44. SLEEP button [TV/VCR P.34]
Sets the Sleep Timer. (See page 34.)
45. SELECT button
Press to switch TV/VCR and DVD mode. You can
see the mode (TV/VCR or DVD) on the front
panel indicator.
- TV/DVD/VHS REAR PANEL - [Fig.3]
TD530/601_01-36 02.4.5 6:33 PM Page 10

- 11 - EN
1C29
CABLE WITH CONVERTER/
DESCRAMBLER BOX OR SATELLITE
BOX
If your cable service supplies you with a converter
box or if you use a satellite system, you can use the
basic connection shown in the ilustration.
By using this connection you can also record scram-
bled channels. However, channel selection must be
made with the converter box or satellite box. This
means that channels cannot be changed using the
TV/DVD/VHS Remote Control. Unattended timer
recording is limited to one channel at a time.
PREPARATION FOR USE
CABLE WITHOUT CONVERTER/
DESCRAMBLER BOX
Use this connection if your cable system connects
directly to your TV/DVD/VHS without a converter
box.
By using this connection you can:
1) Use the TV/DVD/VHS remote to select channels.
2) Program one or more unscrambled channels for
Automatic Timer Recording.
NOTE: This unit will ONLYrecord and view the
same channel.
VHF/UHF SEPARATE ANTENNAS
In some areas it will be necessary to use an outdoor
antenna.
Antenna/Cable Connections
Continued on the Next Page.
ANT.
L
AUDIOOUT
R
COAXIAL
1
ANT.
IN
OUT
or
VHF/UHF Antenna
(Not supplied)
VHF/UHF
Combiner
(Not supplied)
Flat twin-lead cable
UHF Antenna
(Not supplied)
VHF Antenna (Not supplied)
From Cable
System
75-ohm Coaxial
Cable (Not
supplied)
75-ohm
Coaxial
Cable
(Not sup-
plied)
Satellite Box or
Cable Box (Not supplied)
From Cable System or
Satellite Dish
46. ANT. in jack
Connect to an antenna, cable system, or satellite
system.
47. Power cord
Connect to a standard AC outlet (120V/60Hz).
NOTE: Remove the power cord from the hook to
avoid breaking a wire before you connect
to a standard AC outlet.
48. COAXIAL digital audio out jack
Connect to the digital input of an external
amplifier or decoder.
49. AUDIO L/R output jack
Connect to the analog audio input of an external
amplifier or decoder.
[Fig. 4]
ANTENNA/CABLE CONNECTION
or
or
TD530/601_01-36 02.4.5 6:33 PM Page 11

- 12 - EN
1C29
TO RECORD A SCRAMBLED/UNSCRAM-
BLED CHANNEL
1. Set the TV/DVD/VHS channel selector to the out-
put channel of the Cable Converter Box or Satellite
Box. (Ex. CH3)
2.Select the channel to record from your Cable
Converter Box or Satellite Box.
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.
2)Insert 2 “AA”penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3)Replace the cover.
Note to CATV system installer:
This reminder is provided to call the CATV sys-
tem installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper ground-
ing and, in particular, specifies that the cable
ground shall be connected to the grounding sys-
tem of the building as close to the point of cable
entry as practical.
CONNECTIONS TO FRONT A/V
JACKS
When you watch a program recorded on an another
source (VCR or video camera), use the audio/video
input jacks on the front of the TV/DVD/VHS.
Connect the audio/video output jacks of another
source to the AUDIO L/R and VIDEO jacks of this
TV/DVD/VHS.
Then press the CHANNEL K/Lbuttons until "AUX"
appears on the screen.
You may access the front A/V Input directly by
pressing the numbers 00 on the remote control.
See page 9.
NOTE:
•When you connect a monaural VCR (another
source) to this TV/DVD/VHS, connect the Audio
output jack of the monaural VCR (another source)
to the AUDIO L jack of this TV/DVD/VHS. The
audio will output in both L and R channel equally.
L-AUDIO-R
VIDEO
HEADPHONE
[Another source]
To the audio
output jacks
Audio/Video
coaxial cable
(not supplied)
etc.
To the video
output jack
[Front of the TV/DVD/VHS]
[Fig. 5]
TD530/601_01-36 02.4.5 6:33 PM Page 12

- 13 - EN
1C29
CONNECTING TV/DVD/VHS TO AUDIO SYSTEM
ANT.
L
AUDIO OUT
R
COAXIAL
1
To Right (red) and Left (white)
AUDIO OUT jacks
Stereo system
To ANALOG AUDIO INPUT jacks
•Using industry standard audio patch cords, connect one end to the Audio Output Left (white) and Right (red)
jacks on the rear of the TV/DVD/VCR, and the other end to the audio input Left (white) and Right (red) on
the audio system.
ANALOG CONNECTION:
•The analog connection will allow you to take 2 channel stereo sound from the TV/DVD/VCR (or any source
plugged into the front of the TV) and sends the audio signal to an external audio system for amplification.
SELECTING ANALOG AND DIGITAL AUDIO SOUNDTRACKS:
•
To listen to digital multi channel DVD audio, please select the Coaxial Digital Audio input on the audio system.
•To listen to analog audio from TV/DVD/VCR (and any source plugged into the front of the A/V input jack),
please select the analog input which you connected the left and right audio jacks.
•For further solutions on selecting analog and digital audio inputs, please refer to your audio systems owners
manual.
SAFETY NOTES: Please turn of the power to all components before making any connections and refer to
the owners manual of the audio system for further installation and operational instructions.
•Using industry standard audio patch cords, connect one end to the Coaxial Digital Audio Out jack on the
rear of the TV/DVD/VCR and the other to the Coaxial Digital Input on the audio system. Then select the
Coaxial Digital Audio Input on the Audio System to listen to multichannel (5.1) DVD sound.
DIGITAL CONNECTION: DVD SOUND ONLY
•If your audio system features a COAXIAL Digital Audio Input jack and Dolby Digital/DTS multi channel
audio decoders, you may take full advantage of the multi channel surround sound capability of DVD discs.
ANT.
L
AUDIO OUT
R
COAXIAL
1
Amplifier equipped with digital
input jacks, MD deck,
DAT deck, etc.
To COAXIAL DIGITAL
AUDIO INPUT jack
To DIGITAL AUDIO OUT
(PCM/BITSTREAM)
COAXIAL jack
(only DVD AUDIO OUT)
[Fig. 6]
[Fig. 7]
ANALOG AND DIGITAL CONNECTIONS:
IMPORTANT NOTES: If you use the COAXIAL Digital audio connection for digital multi channel DVD
sound, you must also make the Analog connection to listen to TV/DVD/VCR (2 channel) and any source
plugged into the front A/V input jack.
ANT.
L
AUDIO OUT
R
COAXIAL
1
To Right (red) and Left (white)
AUDIO OUT jacks
Stereo system
To ANALOG AUDIO INPUT jacks
To COAXIAL
DIGITAL AUDIO
input
To DIGITAL AUDIO
OUT COAXIAL
JACK
[Fig. 7]
TD530/601_01-36 02.4.5 6:33 PM Page 13

- 14 - EN
1C29
CONNECTING TO A DOLBY DIGITAL DECODER,
DTS DECODER, OR MPEG DECODER (for DVD)
If using this TV/DVD/VHS to play back a TV/DVD/VHS in a 5.1 channel Dolby Digital surround, DTS sur-
round, or MPEG surround format, the TV/DVD/VHS outputs a Dolby Digital, DTS, or MPEG data stream
from its COAXIAL DIGITAL AUDIO OUT jack. By hooking the player up to a Dolby Digital or DTS
decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound
of a professional standard such as can be heard in movie theaters.
Use an audio coaxial digital cables (not included) for the audio connections.
NOTES:
•Be sure to turn off the power to all components in the system before connecting another component.
•Refer to the Owner’s Manuals for the components to be connected to the TV/DVD/VHS.
•If output Dolby Digital audio, connect to a Dolby Digital decoder, and set Dolby Digital to on for audio
output in the setup mode.
•If output DTS audio, connect to a DTS decoder, and set DTS to ON for audio output in the setup mode.
•If played a disc indicated MPEG audio, connect to a MPEG decoder, and set MPEG to ON for audio output
in the setup mode.
•Unless connected to a Dolby Digital decoder, a DTS decoder, or a MPEG decoder, set Dolby Digital, DTS,
or MPEG to off for audio output in the setup mode. Playing a TV/DVD/VHS using incorrect settings may
generate noise distortion, and may also damage the speakers.
•When Dolby Digital is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and you
select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.
ANT.
L
AUDIO OUT
R
COAXIAL
1
Front speaker
(left)
Center
speaker Front speaker
(right)
Surround
speaker
(left)
Surround
speaker
(right)
Subwoofer
To DIGITAL AUDIO OUT
(PCM/BITSTREAM)
COAXIAL jack
To COAXIAL DIGITAL
AUDIO INPUT jack
Dolby Digital
or DTS decoder
Center
speaker for
MPEG (left)
Center
speaker for
MPEG (right)
[Fig. 8]
TD530/601_01-36 02.4.5 6:33 PM Page 14

- 15 - EN
1C29
SET UP FOR USE
You can program the tuner to scan all the channels you receive in your area.
NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just
select the TV/DVD/VHS channel selector to the output channel of the cable box or satellite box (Ex CH3).
Then select the channel to be viewed on the Cable Box or Satellite Box.
CHANNEL SET UP FOR THE
FIRST TIME
1Plug in the TV/DVD/VHS power cord
Plug the TV/DVD/VHS power cord
into a standard AC outlet.
NOTE:
•If some digits appear in the corner of
the screen, press the POWER button
without unplugging the power cord.
2Turn on the TV/DVD/VHS
Press the POWER button to turn on the TV/DVD/VHS.
3Select “ENGLISH”or “ESPAÑOL”or
“FRANÇAIS”
Select “ENGLISH”or
“ESPAÑOL”=Spanish or
“FRANÇAIS”=French using the
Arrow Bor sbutton. “[ ]”indi-
cate the selected language.
4Begin auto preset
Press the Arrow Kor Lbutton to
point to “AUTO PRESET”.
Then press the Arrow Bbutton.
The tuner scans and memorizes all
active channels in your area.
NOTES:
•The TV/DVD/VHS distinguishes between standard
TV channels and cable channels.
•If you want to play or record a video tape
BEFORE presetting the tuner, you must press the
SETUP button on the remote control. To preset the
tuner again, see “CHANNEL SET UP AGAIN”on
page 16.
•The TV/DVD/VHS may memorize TV channels as
CATV channels if reception conditions is poor. If
this happens, try AUTO MEMO action again when
reception conditions are better.
5After scanning
The tuner stops on the lowest memorized channel.
If you want to recall the selected channels, you can
select the desired channel directly with the remote
control number buttons or CHANNEL Kor L.
DELETING (OR ADDING)
CHANNEL
The channels you no longer receive or seldom watch
can be deleted from the memory. (Of course, you can
add the deleted channel into the memory again.)
1Select “CHANNEL SET UP”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “CHANNEL SET UP”.
Then, press the Arrow Bbutton.
2Select “ADD/DELETE CH”
Press the Arrow Kor Lbutton to
point to “ADD/DELETE CH”.
Press the Arrow Bbutton.
3Enter the desired channel number
Press the Arrow Kor Lbutton until
your desired channel number
appears. (You can also use the num-
ber buttons or the CHANNEL K/L
button to enter it) (Example: CH8)
4Delete (or add) it from (into) memory
Press the Arrow Bor sbutton. The channel number
changes to light red. The channel is deleted from
memory.
•To delete another channel, repeat steps [3] and [4].
•If you press the Arrow Bor sbutton again, the
channel is memorized again.
5Exit the channel setup mode
Press the SETUP button on the remote control to
returns to TV mode.
NOTE: To confirm that channel(s) has been deleted
or added, press the CHANNEL Kor Lbutton.
Added channel: Light blue.
Deleted channel: Light red.
–SET UP –
BLANGUAGE
[ENGLISH] ESP FRA
AUTO PRESET
–SET UP –
LANGUAGE
[ENGLISH] ESP FRA
BAUTO PRESET
- TV/VCR SETUP -
TIMER PROGRAMMING
SETTING CLOCK
BCHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
–CHANNEL SET UP –
BADD / DELETE CH (TV)
AUTO PRESET
08
ADD / DELETE
TV/VCR SECTION
TD530/601_01-36 02.4.5 6:33 PM Page 15

- 16 - EN
1C29
CHANNEL SET UP AGAIN
Make sure ...
•Press the POWER button to turn on the
TV/DVD/VHS.
1Select “CHANNEL SET UP”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “CHANNEL SET UP”.
Then, press the Arrow Bbutton.
2Begin auto preset
Press the Arrow Kor Lbutton to
point to “AUTO PRESET”.
Then, press the Arrow Bbutton.
The tuner scans and memorizes all
the active channels in your area.
3After scanning
The tuner stops on the lowest memorized channel.
SELECTING THE LANGUAGE
Make sure ...
•Press the POWER button to turn on the
TV/DVD/VHS.
NOTE: This function effects only the language on
the screen menu and not the audio source.
1Select “LANGUAGE”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “LANGUAGE”.
2Select “ENGLISH”or “ESPAÑOL”or
“FRANÇAIS”
Select “ENGLISH”or “ESPAÑOL”= Spanish or
“FRANÇAIS”= French using the Arrow Bor s
button.
3Exit the Language mode
Press the SETUP button on the remote control to
return to TV mode.
NOTE: If Spanish or French is selected accidentally,
press the SETUP button on the remote control, press
the Arrow Kbutton to point to “IDIOMA
[ESPAÑOL]”or “LANGAGE”[FRANÇAIS], then
press the Arrow Bbutton, then press the SETUP
button on the remote control.
DAYLIGHT-SAVING TIME
Select this feature and the TV/DVD/VHS’s clock
automatically will advance one hour in April, then
reverse one hour in October.
When Daylight-Saving Time is ON, the clock will
change automatically as follows:
•First Sunday of April : At 2 AM the clock imme-
diately changes to 3 AM. Any timer programming
you have set to occur between 2 AM and 3 AM
will not record.
•Last Sunday of October : At 2 AM the clock
immediately changes to 1 AM.
Make sure ...
•Press the POWER button to turn on the
TV/DVD/VHS.
1Select “SETTING CLOCK”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “SETTING CLOCK”.
Then, press the Arrow Bbutton.
2Set “D.S.T.”(Daylight-Saving Time) to [ON]
Press the Arrow Kor Lbutton to
point to “D.S.T.”.
Then, press the Arrow Bor sbut-
ton until [ON] appears.
3Exit the Daylight-Saving Time mode
Press the SETUP button on the remote control to
return to TV mode.
TO CANCEL THE DAYLIGHT-SAVING
TIME
Repeat steps [1] to [2], select [OFF] using the Arrow
Bor sbutton.
- TV/VCR SETUP -
TIMER PROGRAMMING
SETTING CLOCK
BCHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
–CHANNEL SET UP –
ADD / DELETE CH (TV)
BAUTO PRESET
- TV/VCR SETUP -
TIMER PROGRAMMING
SETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
BLANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
- TV/VCR SETUP -
TIMER PROGRAMMING
BSETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
–SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH [AUTO]
MANUAL CLOCK SET
BD.S.T. [ON]
TD530/601_01-36 02.4.5 6:33 PM Page 16

- 17 - EN
1C29
CLOCK SET UP
(AUTO / MANUAL)
Set the clock accurately for proper automatic timer
recording. If the Public Broadcasting Station (PBS) is
available in your area, follow “AUTO CLOCK SET-
TING”. If it is not, follow “MANUAL CLOCK SET-
TING”.
AUTO CLOCK SETTING
You can have the TV/DVD/VHS set the clock auto-
matically by using the Public Broadcasting Station
(PBS) channel in your area. Once you have set the
clock by using the following procedure, the
TV/DVD/VHS will automatically monitor the correct
time and date being broadcast by the PBS station in
your area, using a new service called Extended Data
Service (XDS).
Make sure ...
•TV/DVD/VHS power must be turned on.
•Confirm that the antenna connections are correct.
•The cable converter box must be turned on if your
TV/DVD/VHS is connected directly to it. (See
NOTES:)
•The channel is properly set in advance. (See page
16.)
NOTES:
•Auto clock setting only needs to be set once. But it
can be done again if the clock’s time has become
incorrect for some reason.
•If the TV/DVD/VHS is connected directly to a
cable converter box or satellite box, the local PBS
station must be selected on the cable box itself, and
the TV/DVD/VHS must be set to the output chan-
nel of the cable converter box or satellite box (usu-
ally channel 3 or 4), to be able to set up or correct
the clock automatically.
If you do not know what your local PBS station is,
then follow “Manual Clock Settings”on page 18.
The TV/DVD/VHS cannot control the channels of
the cable converter box or satellite box.
1Select “SETTING CLOCK”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “SETTING CLOCK”.
Then, press the Arrow Bbutton.
2Set “AUTO CLOCK”to [ON]
Press the Arrow Bor sbutton
repeatedly until [ON] appears.
3Enter the channel number for the PBS station
Press the Arrow Kor Lbutton to
point to “AUTO CLOCK CH”.
Then press the Arrow Bor sbut-
ton until the channel number for
your local PBS station appears.
If you do not know the PBS channel number, leave it
set to [AUTO] which is located before [2]. The
TV/DVD/VHS will search automatically all available
channels for the local PBS station, and will select
that channel.
4Exit the Auto Clock Setting
Press the SETUP button on the remote control to
return to TV mode.
5Turn off the TV/DVD/VHS
Turn the TV/DVD/VHS off. Because the Auto Clock
functions automatically while the TV/DVD/VHS is
off.
If you choose [AUTO],
•the TV/DVD/VHS must search until the PBS chan-
nel is found. It must scan each channel for a couple
of seconds to determine if that channel is transmit-
ting the XDS signal.
•if the time, that is automatically set by this selected
PBS station is incorrect, it may not be your local
PBS station, but one from a different time zone. Or
there is a case that no channel is broadcasting the
XDS signal in your area, as shown by no time. In
these cases, you must manually enter the correct
local PBS station, or set the clock manually and
turn off the Auto Clock Setting feature.
- TV/VCR SETUP -
TIMER PROGRAMMING
BSETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
–SETTING CLOCK –
BAUTO CLOCK [ON]
AUTO CLOCK CH [AUTO]
MANUAL CLOCK SET
D.S.T. [OFF]
–SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH [AUTO]
MANUAL CLOCK SET
BD.S.T. [OFF]
TD530/601_01-36 02.4.5 6:33 PM Page 17

- 18 - EN
1C29
MANUAL CLOCK SETTING
Make sure ...
•TV/DVD/VHS power must be turned on.
In the example below, the clock is to be set to:
DATE May 7th, 2002
SETTING TIME 5:40PM
1Select “SETTING CLOCK”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “SETTING CLOCK”.
Then, press the Arrow Bbutton.
2Select “MANUAL CLOCK
SET”
Press the Arrow Kor Lbutton to
point to “MANUAL CLOCK SET”.
Then, press the Arrow Bbutton.
3Select the month
Press the Arrow Kor Lbutton until
your desired month appears.
(Example: May →05)
Then, press the Arrow Bbutton.
4Select the day
Press the Arrow Kor Lbutton until
your desired day appears.
(Example: 7th →07)
Then, press the Arrow Bbutton.
5Select the year
Press the Arrow Kor Lbutton until
your desired year appears.
(Example: 2002)
Then, press the Arrow Bbutton.
6Select the hour
Press the Arrow Kor Lbutton until
your desired hour appears.
(Example: 5, PM)
Then, press the Arrow Bbutton.
7Select the minute
Press the Arrow Kor Lbutton until
the desired minute appears.
(Example: 40)
8Start the clock
Press the SETUP button on the
remote control.
Although seconds are not displayed,
they begin counting from 00 when
you press the SETUP button on the
remote control. Use this feature to synchronize the
clock with the correct time.
NOTE:
When unplugging the AC cord or if there is a power
failure for more than 30 seconds, you may have to
reset the clock.
TO CHANGE CLOCK SETTING
If you want to change the clock,
1)Follow steps [1] and [2].
2)Select where you want to change using the Arrow
Bor sbutton.
3)Enter correct numbers using the Arrow Kor L
button.
4)Press the SETUP button on the remote control to
start the clock.
PLEASE NOTE:
If there is no local PBS station in your area or on
your cable system, select “AUTO CLOCK”and
press the Arrow Bor sbutton to turn [OFF] this
function. Then you can manually adjust the clock.
- TV/VCR SETUP -
TIMER PROGRAMMING
BSETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
–SETTING CLOCK –
AUTO CLOCK [ON]
AUTO CLOCK CH [AUTO]
BMANUAL CLOCK SET
D.S.T. [OFF]
–MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / –––––––––
HOUR MINUTE
––:––––
–MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / 0 7 –––––––
HOUR MINUTE
––:––––
–MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / 0 7 TUE 2 0 0 2
HOUR MINUTE
––:––––
–MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / 0 7 TUE 2 0 0 2
HOUR MINUTE
0 5 : ––PM
–MANUAL CLOCK SET –
MONTH DAY YEAR
0 5 / 0 7 TUE 2 0 0 2
HOUR MINUTE
0 5 : 4 0 PM
5:40 PM
TD530/601_01-36 02.4.5 6:33 PM Page 18

- 19 - EN
1C29
TV OPERATION
WATCHING A TV PROGRAM
1Turn on the TV/DVD/VHS
Press the POWER button to turn on the
TV/DVD/VHS.
2Select the channel number
Press the CHANNEL Kor Lbutton to select your
desired channel number or press the number buttons
on the remote control.
Remember: If the TV/DVD/VHS is connected to a
cable box or satellite box, the TV/DVD/VHS must be
on CH3 or CH4, then the channel to be viewed must
be selected on the cable box or satellite box.
3Adjust sound
Press the VOLUME XXor YYbutton
to adjust the volume.
NOTES:
•If you press the CHANNEL oor p in the DVD
mode, you can change the TV channels.
Even if you turn off the TV/DVD/VHS in the DVD
mode, when you turn it on again, it will go into the
TV/VCR mode.
Arrow sArrow B
BRIGHT to decrease to increase
brightness brightness
CONTRAST to decrease to increase
contrast contrast
COLOR to pale to brilliant
TINT to purple to green
SHARPNESS to soft to clear
PICTURE CONTROL
The TV/DVD/VHS’s picture controls –BRIGHT,
CONTRAST, COLOR, TINT and SHARPNESS –
are preset to factory specifications. Although they are
usually the best, you may need to make some further
adjustments for a natural looking image.
NOTES:
•Procedures must be followed within 5 seconds or
the Picture Control mode will be cancelled.
•When setting the Picture Control, the Game mode
will be cancelled.
Make sure ...
•TV/DVD/VHS power must be turned on.
1Select “PICTURE CONTROL”
Press the PICTURE button on the remote control.
2Select item you want to adjust
Press the Arrow Kor Lbutton until desired control
is displayed.
BRIGHT
CONTRAST
COLOR
TINT
SHARPNESS
3Adjust the picture control
Press the Arrow Bor sbutton to adjust to your
desired level.
•If there is a power failure of any kind, the unit will
retain its memory for this feature.
VOLUME 20
C C C C C C C C C C C C
BRIGHT
–PPPPPPPPPPPPPPCCPPPPPPPPPPPPPP +
TD530/601_01-36 02.4.5 6:33 PM Page 19

- 20 - EN
1C29
CLOSED CAPTION SYSTEM
You can view specially labeled (cc) TV programs,
movies, news, pre-recorded tapes with either a dia-
logue caption or text display.
CAPTION mode: By choosing the caption mode, you
can watch dramas, movies and news while captioning
the dialogues and the contents of news.
TEXT mode: By choosing the text mode, you can
watch half screen text information if you want.
1-2: You may get these captions or text information
by selecting either “1”or “2”. Caption “2”is used,
usually for a second language if available.
NOTE:
Not all programs are broadcast with closed captions.
Your television is designed to provide error free
closed captions from high quality antenna, cable and
VCR signals. Conversely, poor quality signals are
likely to result in caption errors or no captions at all.
Common signal conditions which may cause captions
errors are listed below:
•Automobile ignition noise
•Electric motor brush noise
•Weak snowy reception on TV screen
•Multiplex signal reception displaying picture
ghosts or airplane flutter.
•Playback of poorly recorded or worn VCR tapes.
NOTE:
If the TV/DVD/VHS displays a
black box on the TV screen, this
means that the TV/DVD/VHS is set
to the TEXT mode. To clear screen,
select [CAPTION1], [CAPTION2]
or [OFF].
Make sure ...
•TV/DVD/VHS power must be turned on.
1Select “CAPTION”
Press the SETUP button on the
remote control.
Press the Arrow Kor Lbutton to
point to “CAPTION”.
2Select your desired caption menu
Press the Arrow Bor sbutton
until your desired caption menu
appears.
([CAPTION1], [CAPTION2],
[TEXT1] or [TEXT2])
3Exit the caption setting mode
Press the SETUP button on the remote control to
return to TV mode.
TO CANCEL THE CLOSED CAPTION
SYSTEM
Repeat steps [1] and [2], select [OFF] using the
Arrow Bor sbutton. Press the SETUP button on
the remote control to return to TV mode.
WHEN THE CLOSED CAPTION MODE
IS ON
The On-Screen Display will disappear after 5 sec-
onds.
•This is also true when the MUTE button is pressed,
and when the PAUSE button is pressed while
recording.
•If there is a power failure of any kind, the unit will
retain its memory for this feature.
- TV/VCR SETUP -
TIMER PROGRAMMING
SETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
BCAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
- TV/VCR SETUP -
TIMER PROGRAMMING
SETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
BCAPTION [CAPTION1]
ZERO RETURN
TIME SEARCH
INDEX SEARCH
TD530/601_01-36 02.4.5 6:33 PM Page 20
