Symbol Symbol LS9208i User manual

General Purpose Scanners
For any size company and any size budget

A scanner for your company, your budget
The general purpose scanner family from Motorola is designed to
meet a wide range of scanning needs – with high-end feature-packed
scanners for high-volume scan intensive environments to value priced
scanners for small businesses.
Choose from:
• A wide variety of price points to meet any budget;
• A wide variety of advanced data capture options, scanning everything
from canned goods and hardware to driver’s licenses and patient ID
wristbands, or capturing and transferring images
• A wide variety of models to meet your application needs — from
corded and cordless to hands-free and handheld
Performance you can count on
Every scanner is built using Symbol technology and offers the dynamic
combination of quality, reliability, ease of use and user comfort that have
made Motorola the global leader in the handheld scanning industry.
From the cash register and stockroom to patient bedside and more, this
comprehensive family of all-purpose scanners is designed to endure the
rigors of everyday all day use, with the durability you need to ensure
continuous business — and an outstanding low total cost of ownership.
And you can count on Motorola for outstanding investment protection.
Every scanner in this family offers:
• Durable and reliable construction designed for all day, everyday use
• Onboard support for multiple interfaces, delivering plug-and-play
simplicity for your technology environment today, as well as in
the future
Unique functionality from the inventor of the handheld scanner
With over 900 U.S. patents, including more than 300 for bar code
scanning, our technology delivers features and functionality unique to
Motorola. For example, some products offer unique scanning patterns that
eliminate the need for precise alignment and positioning of products. All
products offer internal electronics designed for durability, delivering reliable
performance even if dropped. And ergonomic designs reduce fatigue
and provide comfort, even in the most intensive scanning environments.
With over 30 years of firsts, from the creation of the first handheld laser
scanner to the development of the first wearable and rugged scanner,
Motorola continues to deliver innovation, raising the bar for excellence in
1
Whether you need a
feature-packed scanner
for high-volume scan
intensive environments
or a value-priced scanner
for your small business,
there is a general
purpose scanner from
Motorola designed to
meet your needs — and
your budget.

2
the scanning industry. Through the experience
gained from deploying over 15 million scanners
around the world in nearly every industry,
Motorola delivers well-developed designs that
meet the unique needs of your environment.
Whether you have clerks at the register ringing
up purchases or in the aisles performing price
checks, employees in the backroom taking
inventory or receiving shipments, or healthcare
workers at a patient bedside verifying patient
identity and medication orders, you can count
on Symbol’s general-purpose scanner family
from Motorola for the industry-leading technology,
ergonomics and scanning performance you
need to ensure maximum productivity — and
maximum return on investment.
Service and support with
comprehensive coverage
Motorola products are known for their durability
and reliability.Yet even the most durable products
need a maintenance plan and a support strategy.
After all, accidents happen — and when they
do, you’ll want to know the support you need
is right at your fingertips to keep your business
systems running at peak performance.
Advance Exchange Support is ideal for
mission-critical applications. Rather than waiting
for your device to be repaired, Motorola uses
an advance exchange process and overnight
shipping to get a replacement unit to you as
quickly as possible. Replacement units are pulled
from a Motorola-owned pool so you don’t have to
buy or manage your own spares, and Motorola
pays the shipping costs in both directions. Best
of all, this service includes Comprehensive
Coverage, which extends your investment
protection beyond normal wear and tear to cover
plastics, exit windows and other components
that are accidentally damaged during usage.
Service Center Support enhances warranty
coverage by providing a fast three-day turnaround
time for products needing repair. As with our
Advance Exchange Support offering, Service
Center Support includes telephone access
to the Motorola technical support team for
troubleshooting. In addition, it gives you the peace
of mind of knowing your equipment is expertly
repaired to its original factory specifications.
Both of these programs are available with
Service from the Start — a prepaid service
program that provides multiple years of
coverage at significant cost savings when
purchased alongside the hardware.
Ask your Motorola sales representative
which plan is best for you.

3
Handheld Scanners
Symbol LS4208 Laser / Corded / Handheld
The Symbol LS4208 scanner is Motorola’s premiere general purpose laser scanner,
offering a unique array of features that deliver superb scanning performance with
minimal user effort. With an innovative multi-line rastering scan pattern, superior motion
tolerance and a wide working range, the Symbol LS4208 delivers robust scanning that
eliminates the need to precisely aim and position the device, or pause between scans.
And even the smallest, stacked, damaged and poorly printed bar codes are quickly and
accurately captured on the first scan, resulting in maximum productivity. Combined with
a patented single board construction that eliminates one of the most common points
of failure, the Symbol LS4208 delivers reliable day-to-day performance — and a low
total cost of ownership. Available in 1D only and PDF/Composite Code configurations.
Symbol LS4278 Laser / Cordless / Handheld
The Symbol LS4278 offers the same superb scanning performance and unique features
as the Symbol LS4208 along with cordless Bluetooth™freedom and the security
features needed to help ensure protection of your wirelessly transmitted data. The
ability to move throughout the workspace enables cashiers to step out from behind the
register to scan items, allows healthcare workers to scan patient wristbands to verify
medication orders and more. Productivity is improved and revenue is enhanced. As
for durability, the Symbol LS4278 offers a patented single board construction, a cradle
with industrial charging contacts that ensure reliable performance through hundreds of
thousands of insertions and drain points to protect sensitive electronics in the event of
spills. (Workspace size: within a 30 to 50 foot/9.1 to 15.2 m radius)
Symbol P460 Laser / Corded / Handheld
The Symbol P460 1D scanner offers the flexibility of real-time corded and batch
mode cordless scanning to meet the needs of a wide variety of applications. Corded
real-time scanning enables cashiers to quickly, easily and accurately ring purchases.
Cordless offline batch mode enables employees to perform inventory counts and price
verifications on the retail floor, and allows customers to scan products to create an
on-the-fly ‘wish list’ for gift registries. With a convenient display window and keypad,
users can easily view, enter and delete scanned records, enabling instant correction of an
erroneous scan. Designed for easy and rapid deployment, the Symbol P460 is pre-loaded
with inventory software and enables seamless integration of scanned data into your
existing applications. And with support for MCL-Designer, you can develop custom
applications quickly and easily — without technical programming knowledge.
Symbol P470 Laser / Corded / Handheld
The Symbol P470 1D cordless scanner provides your employees with wireless freedom
to move throughout the workspace to scan heavy items or check carts for ‘forgotten’
items, take inventory in the stock room and verify shelf pricing. In addition to extending
the workspace to over 100 ft./30 m, advanced, long range functionality enables accurate
scanning of bar codes as far away as 30 ft./9.1 m. Cables are eliminated, reducing tripping
hazards and helping to minimize accidents. A convenient display window and keypad
enables users to easily view, enter and delete scanned records to instantly correct an
erroneous scan. Up and running right out of the box with pre-loaded inventory software,
the Symbol P470 can be rapidly integrated into your environment, thanks to its ability
to easily port scanned data right into your existing applications. And support for MCL-
Designer enables even non-technical staff to easily develop custom applications.
PREMIUM

4
Symbol DS6700 Digital Imager / Corded / Handheld
Enjoy extraordinary application flexibility with the versatile Symbol DS6700 Series
digital imager scanner from Motorola. The handheld Symbol DS6700 offers 1D/2D
bar code and direct part mark (DPM) scanning and a 1.3 megapixel digital camera for
image and document scanning — all in a single cost-effective device. Fast and accurate
data capture functionality streamlines business processes in the retail store, post
office, pharmacy or manufacturing floor, maximizing employee productivity. Capital and
operational expenses are reduced by eliminating the need to purchase separate devices
to capture images and read different bar code symbologies. And remote management
further reduces the total cost of ownership. Available models: The Symbol DS6707
offers 1D and 2D bar code scanning. The DS6707 offers 1D and 2D bar code scanning
as well as the 1.3 megapixel camera and Motorola’s text enhancement technology for
superior document clarity — even on fine print — ideal for capturing prescriptions and
more. The Symbol DS6707-DP enables the capture of virtually all 1D and 2D bar codes
and direct part marks, including the most difficult mark, dot peen. And the DS6707-DL
enables enterprises to capture and utilize the information in 2D PDF417 bar codes on
the back of government-issued ID cards such as driver’s licences, streamlining and
error-proofing age verification and over-the-counter medication tracking as well as the
completion of credit and loyalty card applications, returns processing and more.
Symbol LS2208 Laser / Corded / Handheld
The Symbol LS2208 is a small, lightweight affordable scanner designed to increase
productivity from the checkout line to the back room. The Symbol LS2208’s single circuit
board design eliminates common points of failure, and its ability to withstand multiple
5 ft./1.5 m drops to concrete provides the durability and reliability needed to withstand
all day every day heavy usage. And multiple onboard interfaces enable connectivity to
virtually any host, providing future proofing and investment protection.
MID LEVEL
DS6700
DS6707-DP

When you choose a Symbol scanner from Motorola, you get patented features and
functionality no other manufacturer can offer — from unique scanning patterns
and ergonomics to internal electronics.
5
Symbol LS1203 Laser / Corded / Handheld
The Symbol LS1203 handheld scanner is designed to meet the needs and budgets
of small retailers, delivering high quality laser scanning, user-friendly ergonomics and
durability at an economical price. For small independent retailers, Symbol LS1203
delivers the features, functionality and reliability needed to improve operational
efficiencies from the checkout line to the back room — day in and day out. Manual
keying is minimized, customers are charged the correct amount and paper-based
inventory processes are automated. The result is faster checkout, increased customer
satisfaction, increased employee productivity — and a rapid return on investment.
VALUE
Hands-free Scanners
Symbol LS7708 Laser / Corded / Presentation
The Symbol LS7708 is ideal for medium to high-volume scanning environments, such as
grocery, drug and convenience stores. This flexible on-counter scanner enables
both presentation and swipe scanning to keep the register lines moving, even in the
busiest retail environments. Robust scanning technology, including a dense rastering
omni-directional scan pattern, delivers higher first-pass read rates without requiring
cashiers to precisely position bar codes. And the ‘smart’ scanner moves into sleep
mode when not in use, automatically ‘waking up’ when a bar code is passed over
the scan window, reducing power demands and extending the life of your scanner.
Symbol M2000 Laser / Corded / Handheld and Hands-free
This combination hands-free/handheld scanner enables scanning of any size item,
providing maximum flexibility. Four user-selectable scan patterns deliver outstanding
scanning performance, enabling the fast and accurate capture of 1D and PDF-417 bar
codes, including those that are truncated, damaged and poorly printed. The intuitive
and easy-to-use Symbol M2000 automatically shifts from hands-free to handheld mode
when lifted and adjusts the scan pattern as needed.
Symbol LS7808 Laser / Corded / Presentation
The Symbol LS7808 horizontal slot scanner from Motorola provides the exceptional
scanning performance that enables your cashiers to deliver faster and more personalized
service at the point of sale. With its large omni-directional scan window and advanced
software algorithms, this flush-mounted, in-counter scanner delivers first time reading
on even poorly printed and damaged bar codes — regardless of scan angle. Integrated
EAS functionality, onboard support for most POS hosts, support for Reduced Space
Symbology and a three (3) year warranty maximize your investment and ensure
compatibility with your environment — now and in the future.
PREMIUM

When you choose a Symbol scanner from Motorola, you get patented features and
functionality no other manufacturer can offer — from unique scanning patterns
and ergonomics to internal electronics.
6
Symbol LS9208i Laser / Corded / Handheld and Hands-Free
This hands-free scanner offers a high-performance processor and an innovative
100-line rastering omni-directional scan pattern that enables rapid bar code scanning
regardless of the orientation of the product. It also offers the flexibility to switch quickly
and easily between hands-free and handheld mode, reducing the need to lift heavy
objects and the risk of injury. Combined with a small footprint that fits easily into
the tightest environments and the ability to easily switch to single line mode to read
pick lists and bar code menus, the Symbol LS9208i keeps checkout lines moving and
customers satisfied.
MID LEVEL
Symbol LS9203i Laser / Corded / Handheld and Hands-Free
The Symbol LS9203i is an affordable omni-directional scanner that can be used in either
hands-free or handheld mode, eliminating the need to lift heavy items – effectively
reducing the risk of injury. The intuitive Symbol LS9203i requires no training — simply
plug in the device and users are up and running in minutes, automatically capturing
the data you need to improve sales tracking and inventory management, as well as
reduce pricing mistakes, out of stocks and shrinkage. The small footprint is ideal for the
tightest checkout environments where counter space is reserved for ‘impulse purchase’
displays. And in keeping with the Motorola tradition of quality, this economically priced
scanner is built to handle every day accidental drops and tumbles.
VALUE
For more information about Symbol scanners from Motorola, visit
www.motorola.com/barcodescanners/generalpurpose.
To access our global contact directory, please go to
www.motorola.com/enterprise/contactus

motorola.com
Part number BR-GPSCNAGG. Printed in USA 04/09. MOTOROLA and the Stylized M Logo and SYMBOL and the SYMBOL Logo are registered in the US Patent & Trademark
Office. All other product or service names are the property of their respective owners. ©2009 Motorola, Inc. All rights reserved. For system, product or services availability and
specific information within your country, please contact your local Motorola office or Business Partner. Specifications are subject to change without notice.
