Syncronorm SyncroADC User manual

SyncroADC
Operating Manual
www.syncronorm.com [e-mail]#liquidinspiration

[phone]
[phone]
www.syncronorm.com
[email protected]
Syncronorm GmbH
Graf-Gottfried-Strasse 122
59755 Arnsberg | Germany
ABOUT US
Syncronorm GmbH are highly motivated producers of high-end multimedia show design software,
which features a most unique real-time 3D visualizer. Our dynamic & experienced team thereby
operates on a world-wide scale, providing you with the best software & hardware solutions tting
to your dedicated project. From show-design, training-programs, instant support & consulting
to continuously soft- & hardware development, the team at Syncronorm is eager to realize your
visions. Syncronorm provide the most established & renowned products for the entertainment- &
water-show sectors within the industry and beyond.

Version: April 2021
SYNCROADC
The SyncroADC Multiplexer converts analog control signals (0...10V DC) into digital DMX control
signals. The SyncroADC accepts 12 analog Inputs. It is ideally suited to integrate operating Panels
or analog inputs into the Syncronorm Depence Network Structure. The unit may be congured for
linear Mode, to switching mode or to 1...10V Input sensitivity. Additionally, a second independent
DMX512 out may be activated by the input Signal.
0..10V to DMX Multiplexer

(C) 2021 Syncronorm GmbH
4
You made a great choice by purchasing Syncronorm‘s SyncroADC hardware unit. Prior to
commissioning the unit, please read the following instructions of use carefully and fully familiarise
yourself with the unit. Ensure that all work on and with this unit is only carried out in accordance to these
instructions. Adhere to the safety information for the correct and safe use of the unit. Keep these
instructions in a safe place! Please also hand over the instructions, when passing the unit on to a new
owner.
Preface
This document is a guideline for controlling the hardware of Syncronorm‘s fountain control systems. The
information contained in this manual will give you a sucient understanding of this product, helping you
to use the unit correctly and eectively. Adhere to all instructions contained in this manual, when
installing and operating this unit. Every person working with this equipment must read this manual
before installation and commissioning of the equipment/device. Every person working with this device/
equipment must read the manual before starting to work. Even personnel working with this device only
occasionally must read and understand this manual before beginning to work. This manual must always
be available at the site, where the device is located. Every user of this device must be aware of the
location of the manual.
Technical Data
WELCOME TO SYNCRONORM
Dimensions
Weight
Protection Class
Power Supply
Operation Temperature
Certification
Outputs
Inputs
Order Number
80x90x58 mm DIN RAIL 4U
0.20 kg
IP 20
24V DC
0.. 40° / 0.. 80% humidity
CE
DMX 512 (12 Channels)
12x 0..10V DC or 1..10V DC > 10kOhm input impedance
SN-STADC24
SyncroADC

(C) 2021 Syncronorm GmbH 5
Checking the Scope of Delivery
Please check that the scope of delivery is complete. Keep the packaging for later transport. If
components are damaged or missing, contact your Syncronorm supplier via [email protected].
Scope of delivery:
1x SyncroADC 0..10V to DMX Multiplexer
Please note that a programming adaptor (3000P) is not included with DIN rail mount devices. A
programming adaptor (required to set DMX start addresses and operating options) must be ordered
separately.
This unit requires the SyncroTools DMX address board (SN-STADRB) (not included).
Intended Use
The Syncronorm DMX Multiplexer 3112A-H will convert analog input voltages to digital DMX512 signals
according to USITT DMX512/1990 (United States Institute for Theatre Technology, www.usitt.org) , ANSI
E1-11 DMX512-A (www.ansi.org) or DIN56930-2 (www.din.de). All types of equipment labeled with „DMX-
512“ or „DMX-512/1990“ may be connected.
Safety Information
Danger to persons and assets may emanate from this unit, if it is used in an improper manner or not
in accordance with its intended use, or if the safety instructions are ignored. This unit must not be used
by children under the age of 18. Persons with impairments or lack of experience and knowledge may
use the unit, as long as they are supervised and instructed on how to use the unit safely and are able to
understand the potential risks. Do not allow children to play with this unit. Do not allow children to clean
or maintain the unit.
Correct electrical Installation
• Electrical installations must meet the national regulations and may only be carried out by a qualied
electrician.
• A person is regarded as a qualied electrician, if, due to his/her vocational education, knowledge and
experience, he or she is capable of and authorized to judge and carry out the work commissioned
to him/her. This also includes the recognition of possible dangers and the adherence to the pertinent
regional and national standards, rules and regulations.
• For your own safety, please consult a qualied electrician.
• The unit may only be connected when the electrical data of the unit and the power supply coincide.
The unit data is to be found on the unit type plate or on the packaging, or in this manual.
• Ensure that the unit is fused for a rated fault current of max. 3A on the mains side by means of a fault
current protection device.
SAFETY INSTRUCTIONS

(C) 2021 Syncronorm GmbH
6
SAFETY INSTRUCTIONS
Save Operation
• Never operate the unit, if either the electrical cables or the housing are defective!
• Do not carry or pull the unit by its electrical cables.
• Route cords/hoses/lines in a way that they are protected against damage, and ensure that they do
not present a tripping obstacle.
• Only open the unit housing or its attendant components, when this is explicitly required in the ope-
rating instructions or approved/prescribed by Syncronorm‘s technical support service.
• Only execute work on the unit that is described in this manual. If problems cannot be overcome,
please contact an authorized customer service point or, when in doubt, the manufacturer.
• Only use original spare parts and accessories for the unit.
• Never carry out technical modications to the unit.
• Only operate the unit, if no persons are in the water!
• The unit, the connections and the plugs are not water-proof and must not be routed or installed in
water.
Qualications and Training of Employees
• Ensure that installation personnel have the required technical qualications.
• Also ensure that all operating personnel are suciently qualied.
• Ensure that maintenance work is only performed by personnel authorized for this purpose, e.g.
specialists of Syncronorm GmbH or personnel with suitable training.
Dangers resulting from non-adherence to the Safety Information
Please note that Syncronorm GmbH assumes no liability for damage, downtimes or malfunctions resul-
ting from non-adherence to this installation and operating manual. By ignoring or not adhering to all of
the safety information contained in this manual, you could endanger people, the environment and the
system of this unit. For example, non-adherence to the safety information contained in this manual can
lead to the following dangerous occurrences:
• A malfunction of important features of this unit
• Danger for persons due to electric shock
Safety-conscious Operation
As a user of this unit, ensure that you follow all safety information contained in this manual. Follow the
accident prevention regulations at all times. If the unit is used in a location where internal regulations,
operating and safety instructions apply, ensure that these regulations and instructions are also adhered
to.

(C) 2021 Syncronorm GmbH 7
Optional retrotting and Production of Spare Parts
Safety Information regarding Maintenance, Inspection and Installation Work
Changes or modications to the device are only permitted after consultation with the manufacturer.
Original spare parts and accessories approved by the manufacturer provide safety. We wish to stress that
all parts and accessories not supplied by Syncronorm GmbH have neither been tested nor approved
by Syncronorm GmbH. For this reason, the installation and/or use of such products can, under certain
circumstances, negatively aect the specications for the device. This could also lead to restrictions of the
active and/or passive safety of the device. Syncronorm GmbH assumes no liability for damage resulting
from the use of parts and accessories other than original Syncronorm GmbH parts.
In this case all guarantee expires.
It is the owner/user‘s responsibility to ensure that all maintenance, inspection and installation work is car-
ried out by authorized and qualied personnel, who have read and understood this manual.
Only carry out maintenance work on this unit, when the unit system is switched o. Ensure that no
pressure is applied to the unit and it is disconnected from the power supply (voltage-free) before carry-
ing out maintenance or repair work.
Ensure that small malfunctions are immediately rectied by authorized personnel to avoid possible future
damage, malfunctions and/or downtimes of the unit system. Certain maintenance work may require
safety barriers to be removed and/or deactivated. If this is the case, ensure that all safety and protective
devices/guards are re-installed and/or reactivated after completing the maintenance work.
Dangers encountered by the Combination of Water and Electricity
• The combination of water and electricity can lead to death or severe injuries from electrocution, if the
unit is incorrectly connected or misused.
• Prior to reaching into the water, always switch o the mains voltage to all units used in the water.
SAFETY INSTRUCTIONS

(C) 2021 Syncronorm GmbH
8
CONNECTION
Connectors
The Syncro ADC Encoder 12x features these connectors:
CN1 POWER SUPPLY 2-pin Connector
1 blue 0V AC (N)
2 black 230V AC (L)
CN2 DMX IN 3-pin connector
1 grey GND,Shield
2 blue DMX -
3 orange DMX +
CN3 DMX OUT 3-pin connector
1 grey GND, Shield
2 blue DMX -
3 orange DMX +
CN4 ANALOG IN 20-pin connector
1 Analog input 1
2 Analog input 2
3 Analog input 3
4 Analog input 4
5 Analog input 5
6 Analog input 6
7 Analog input 7
8 Analog input 8
9 Analog input 9
10 Analog input 10
11 Analog input 11
12 Analog input 12
13 nc
14 nc
15 nc
16 nc
17 Shield, 0V, GND
18 Shield, 0V, GND
19 +5V stab out
20 +10V DC stabilized out
CN5 START ADDRESS 10-pin connector
Connector to connact a start address board 3000P or 3003P for start address and device properties pro-
gramming. Unit may be used with or without start address board attached.

(C) 2021 Syncronorm GmbH 9
CONNECTION
Signal Indicators
The Multiplexer 3112A-H consists of two signalling LEDs:
red: Error blinking: no valid DMX input signal present
green: unit is active, at least one input signal is present.
blinking: no valid start address set
Important Notice
All decoders intended for DIN rail mount may need a DMX start address board to set the desired start
address. DMX start address boards cat no. 3000P (switches) or 3003P (display) may be used. Since one
start adress board can be used to program any DIN rail unit this is NOT contained with this product and
must be ordered separately.
0-10V / 1-10V
The multiplexer can be used for signal input voltages from 0..10V or 1...10V,respectively. (to change the
input range see chapter „DIP SWITCHES“). If inputs are required to comply with unpowered 1-10V driving
gear, use an additional 1mA current source to supply the required bias current.
24V DC POWERDAISY CHAIN
START-ADR
MODULE
DMX-OUT ANALOG INPUT
11 0
11 20
1-12 - Signal
17-18 - GND
19 - +5V DC
20 - +10V DC

(C) 2021 Syncronorm GmbH
10
SETTINGS & SETUP
Signaling
Upon connection of power (230V AC) to connector CN2 (see page 2) the multiplexer is ready to work.
The red LED will light. As soon as DMX512 is applid on the input terminal, or any analog signal input (1-
12) is driven from an input voltage of more than 100mV the green LED will come up to indicate activity.
Switch Settings
To program the multiplexer conguration the DMX start address board may be connected to CN5. The
multiplexer may be used with or without start address board connected; if the board is diconeccted the
last valid settings will be retained in nonvolatile memory.
Note: It may take about 2 secs until data are saved. The input DMX signal is fed to the DMX512 output,
and is superimposed with the analog input data. The DMX start address denotes the data slot number
starting with analog input #1, followed by inputs #2 thru #12. All other data slots are not aected.
DIP-Switches
The DIP switches are used to congure the multiplexer.
DIP-SWITCH 1 DMX HOLD
OFF: Normal
ON: DMX HOLD „retain last look“
DIP-SWITCH 2 INPUT VOLTAGE RANGE
OFF: Linear Mode
ON: Switch Mode, OFF<2,5V, ON>7,5V
DIP-SWITCH 3 SWITCHING MODE
OFF: input voltage 0...+10V DC
ON: input voltage 1...+10V DC
DIP-SWITCH 4 MERGE MODE
OFF: Normal, DMX data merged HTP with analog data
ON: Prevail, DMX data replaced with analog data

(C) 2021 Syncronorm GmbH 11
The device requires regular maintenance.
Carry out maintenance in accordance with the maintenance schedule:
- If necessary, update your software version.
- Check, if all external cables are working properly.
Important information!
Maintenance must be carried out by qualied personnel only!
CE Conformity
This DMX decoder is microprocessor controlled and uses high frequency (8 MHz quartz). The interface
has been tested in our EMC lab to comply with EN5022B and IEC65/144. To ensure the best perfor-
mance regarding radiated and conducted emissions, please make sure that shielded data cable is used
and the shield is connected properly to the GND terminal. Shield must never make contact to any other
signal lines.
Protecting the environment
For the transport and Protective packaging, environmentally friendly
materials have been choosen that can be supplied normaly recycling.
Do not just dispose of these materials with your normal household waste,
but make sure that they are collected for recycling
This product is subject to the European Waste Electrical and Electronic
Equipment Directive (WEEE).
FCC Statement
This product has been tested and complies with the specications for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used according to the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which is found by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or devices
• Connect the equipment to an outlet other than the receiver‘s
• Consult a dealer or an experienced radio/TV technician for assistance
FCC Caution: Any change or modication to the product not expressly approved by SLH could void the
user’s authority to operate the device.
Maintenance and Cleaning
MAINTANANCE & DISPOSAL

(C) 2021 Syncronorm GmbH
12
Syncronorm GmbH assures a 12 month manufacturer ‘s guarantee for this specic Syncronorm unit, pur-
chased by you. This guarantee only exists in accordance to the specic guarantee conditions lad down
as follows:
The guarantee period starts with the purchase from a Syncronorm GmbH specialist dealer. In the event
of a resale, the guarantee period will not start again.
If services by Syncronorm GmbH are provided under the terms of this guarantee, this does not lead to
extension or renewal of the guarantee period. Your legal rights as a purchaser, especially those ensuing
from the warranty, persist. They are not restricted by this guarantee.
Syncronorm warranties are limited to our product only and do not extend to any
direct, indirect or subsequential loss under any circumstances.
Misusage of the device leads to a loss of guarantee!
Guarantee Conditions
SYNCRONORM GmbH guarantees impeccable, purpose-related properties and workmanship,
expert assembly and proper functionality. Subject to our discretion, the guarantee refers to
free-of-charge repair or free-of-charge supply of spare parts or of a replacement unit respectively.
Should the unit type concerned no longer be manufactured, we reserve the right, at our discretion, to
supply a replacement unit from our range that is closest to the type subject to complaint. Claims, the
origin of which can be traced back to installation and operating faults as well as lack of care, e.g. the use
of unsuitable cleaning materials or negligent maintenance, use other than that intended, damage due
to accidents, falls, impact, eect of frost, cutting plugs, shortening cables, calcium deposits or improper
attempts to repair the unit, are not covered by our guarantee. We hereby refer to the proper use as spe-
cied in the instructions of use that form an integral part of the guarantee. Wearing parts such as bulbs
etc. are exempted from the guarantee.
The refund of costs for removal and installation, checks, claims for lost prot and damages are exemp-
ted from the guarantee together with further reaching claims for damages and loss of whatever nature
caused by the unit or its use. The guarantee is only valid in the country in which the unit was purchased
from a Syncronorm GmbH dealer. This guarantee is governed by German law under the exclusion of the
agreement of the United Nations covering contracts, governing the international sale of goods (CISG)
regulations. Guarantee claims can only be brought forward by presenting the sales receipt to
Syncronorm GmbH
Graf-Gottfried-Strasse 122
59755 Arnsberg | Germany
by returning the unit or part of the unit‘s subject of complaint to us, freight free, at your own risk, ac-
companied by a copy of the original purchase receipt from the Syncronorm GmbH specialist dealer, this
guarantee document and written information of the fault encountered.
GUARANTEE
