Synel SY-7000 series User manual

SY-7000 SDK
Manual
SYnel Industries LTD.

Manual 6/21/07. Document no. SY-7000SDK-222-01 Catalogue no. 650770
This model is compatible with Processor firmware version:
Main Processor firmware version: V9.00x0
LCDg Processor firmware version: G22V001
All rights reserved. to Synel Industries Ltd. Reproduction or use, without express permission of
editorial or pictorial content, in any manner is prohibited. No patent liability is assumed with respect to the
use of the information contained herein. While every precaution has been taken in the preparation of this
manual, Synel Industries Ltd. assumes no responsibility for errors or omissions. Neither is any liability
assumed for damages resulting from the use of the information contained herein. Pictures in this manual
are for illustration purposes only. SY-7000 is a trademark of Synel Industries Ltd. All trade names
referenced herein are either trademarks or registered trademarks of their respective companies.

SY-7000 SDK Manual
3
Table of Contents
Chapter 1 - Introduction.....................................................................................5
1.1SY-7000 Capabilities ...................................................................................................... 5
1.1.1TA 7100, 7200 & 7500 Family Specification.......................................................... 5
1.1.1.1Memory............................................................................................................ 5
1.1.1.2Communications .............................................................................................. 5
1.1.1.3LCDs ................................................................................................................ 6
1.1.1.4Readers............................................................................................................. 6
1.1.1.5Rubber Keypad................................................................................................. 7
1.1.1.6 Power Requirements ...................................................................................... 7
1.1.2The Software Development Kit ............................................................................... 8
1.1.2.1Components ..................................................................................................... 8
1.1.3Developer Minimum Skill Set ................................................................................. 8
1.1.3.1Technical Specifications .................................................................................. 9
1.1.3.2Bottom connector panel ................................................................................. 10
Chapter 2 -Terminal Configuration Instructions........................................... 11
2.0.1Configuration Menu............................................................................................... 11
2.0.2Dates ..................................................................................................................... 12
2.0.2.1Set Date and Time ......................................................................................... 12
2.0.2.2Daylight Savings ........................................................................................... 12
2.0.3Communication ..................................................................................................... 12
2.0.3.1Wired ............................................................................................................. 12
2.0.3.2Wireless ......................................................................................................... 13
2.0.4Set Readers ........................................................................................................... 13
2.0.5Accessory Test ...................................................................................................... 13
2.0.6Clock Reset ........................................................................................................... 14
2.0.6.1Reset Clock ................................................................................................... 14
2.0.7Clock Info ............................................................................................................. 14
2.0.7.1Version .......................................................................................................... 14
2.0.7.2Wired Settings ............................................................................................... 14
2.0.8Configure Access .................................................................................................. 15
2.0.9Utilities .................................................................................................................. 15
2.0.9.1Telnet Utilities ............................................................................................... 15
Chapter 3 -Application Development Instructions ........................................16
3.1Toolchain Development Tools ...................................................................................... 16
3.1.1CygWin.................................................................................................................. 16
3.1.2Cross Compiler ...................................................................................................... 16
3.1.3FTP or TFTP Server .............................................................................................. 16
3.2Communication Between the Host and Terminal.......................................................... 16
3.2.1Setting up Communication by a Serial Port........................................................... 16
3.2.2Setting up Communication via Telnet ................................................................... 17

SY-7000 SDK Manual - DRAFT
4
Chapter 4 - Writing the SDK Application...................................................... 18
CLASS EVENTMANAGER .................................................................................. 19
virtual ~EventManager(); ....................................................................................19
void RegisterForEvent(Event eventId, EventCallback callback , void* userdata ); 19
void UnRegisterForEvent(Event eventId, EventCallback callback); ...................20
int InstallNetworkServer ( const unsigned int port , const char* ifc = "eth0" ); .. 21
int createLowResTimer (long timeoutSeconds); .................................................21
void killTimer (int timerId); ................................................................................ 21
static EventManager * GetInstance(); .................................................................. 21
CLASS LCDDISPLAY ...........................................................................................22
LCDDisplay (); .....................................................................................................22
virtual ~LCDDisplay (); ........................................................................................22
virtual void Write (int row, int col, const char * str); .......................................... 22
virtual void Clear (); .............................................................................................23
virtual void DisplayContrast (int contrast); .........................................................23
virtual void SetCursorState (CursorState state); ................................................... 23
CLASS SOUND ....................................................................................................... 24
void Sound (); ....................................................................................................... 24
virtual ~Sound(); ...................................................................................................24
void Beep(int milliseconds, int toneHz); .............................................................. 24
CLASS LED .............................................................................................................25
void LED (); ..........................................................................................................25
virtual ~LED(); ..................................................................................................... 25
void TurnOn(Light light); ..................................................................................... 25
CLASS RELAY ....................................................................................................... 26
void Relay (); ........................................................................................................26
virtual ~ Relay (); .................................................................................................. 26
void Set(int index, int state); ................................................................................. 26
4.1Demo Application.......................................................................................................... 27
Chapter 5 - Creating and Loading the Application File to the Terminal .... 34
5.1Creating a Binary File of the Application...................................................................... 34
5.2Loading the Application Binary file to the Terminal..................................................... 35
5.3Running The Application on Terminal Startup ............................................................. 36
Appendix A - Setting Up the PIK Environment ............................................ 38
Appendix B - Model Matrix............................................................................. 53

SY-7000 SDK Manual Introduction
5
Chapter 1 - Introduction
The SY-7000 series data collection terminal is introduced by Synel as a top of the line hardware terminal.
The terminal has almost unlimited capabilities when partnered with Synel’s additional time and attendance
software and hardware products. By using one or more of several different input methods, the SY-7000
series terminal records the time, date, employee number, and other collected data to be processed by a host
computer. The SY-7000 series data terminal has the capability to accommodate auxiliary inputs and
outputs used to control a wide variety of systems ranging from door access control to bells and alarms.
Each SY-7000 series terminal model type includes slightly different features. This guide is a compatible
and reliable installation guide for each type of terminal, regardless of the model type.
SY-7000 is an Open architecture terminal which enables the user to create their own settings and uses for
the terminal. The unit user defined capabilities are user-created using the Linux open source platform.
This SDK manual provides you with the information needed to create your own user defined system to
collect and manage Time and Attendance data.
1.1 SY-7000 Capabilities
In an effort to broaden availability and functionality of customer use, Synel offers several different model
types of the SY-7000 series data terminals. Each model type (7100, 7200, and 7500) differs slightly in
features ranging from wireless communications capabilities to LCD interactive touch screen menus. Please
refer to the Model matrix at the end of the book and the sales spec sheet for individual attributes.
1.1.1 TA 7100, 7200 & 7500 Family Specification
1.1.1.1Memory
TA 7100 & 7200
•8MBSDRAM
• 16 MB Flash
TA 7500
•64MBSDRAM
• 16 MB Flash
1.1.1.2Communications
•Ethernet
•Standard
• Support for 10/100 Mb networks
• Poe - Power for the unit enters from the same cable as your Ethernet
• Wireless
•RS-232
•RS-485
•Modem
• 1200 Kb – 28.8 Kb

IntroductionSY-7000 SDK Manual
6
•2USBports
• –Host and Device
• –Bar-code wands
• –Printers
• –Keyboards
• 2 PCMICA Slots
• –Additional memory
•–Wireless
•802.11b
–WEP
–eap-leap wireless security
1.1.1.3LCDs
TA 7100 & TA 7200
• Large Character 4x20 backlit text display (6.5”)
TA 7500
• 8.0” Graphical color LCD touch screen
1.1.1.4Readers
• FPU- Finger Print Unit
• FPU-S (Capacitance) sensor
• Template size 384 Bytes (reducible to 256 bytes)
• Template capacity 9,000 at 4MB flash
• Encryption 256 bit AES (fingerprint data protection)
• Resolution 500 (dpi)
• Image size 280 x 320 (pixel)
• Bar Code and Key Entry
• Can have both bar code and magnetic on one reader

SY-7000 SDK Manual Introduction
7
• Supports the following bar code formats: Code 39, Code 128, Interleaved 2 of 5, Industrial 2 of 5,
Codabar, UPC-A, UPC-E, EAN-13, EAN-8, UPC/EAN 2 & 5 digit AddOn, Code 11, Code 93, MSI/
Plessey, Code 4, Code 5 and BC412
• Internal Proximity Reader
The Proximity reader receives input via a two wire Wiegand type logic level interface consisting of a
pair of data lines Data0 and Data1. Data input via this interface is typically a small stream of from 26 to
36 bits representing a binary ID number that is broken into two or more fields in the software. Some
custom adaptations of this interface use longer bit streams of up to 60 plus bits.
1.1.1.5Rubber Keypad
• Numeric + 12 function keys + directional arrows
• Customizable overlay
1.1.1.6 Power Requirements
DC Power Input (@ J15):
15 VDC nominal; -1% - +7% (1)
0.25 - 1.5 A @ 15 VDC (2)
3.75 - 22.5 Watts (2)
AC Power Module(3) Input:

IntroductionSY-7000 SDK Manual
8
90 - 264 VAC
47 - 63 Hz, single phase
0.5 A max. @ 90 VAC
5 - 23 Watts (2)
Power-over-Ethernet Input (via J4):
IEEE 802.3af compliant power sources only (4)
4 - 12.5 Watts (2)
• A wider DC input range is permissible depending on model and options configured; consult the factory
for details.
• Actual input power and current vary depending on model and options configured.
• Based on use of either of the following approved external AC to DC power modules:
Ault PW118RA1503F01
Sunny SYS1089-1515-W3
• Recommended stand-alone PoE power injector module:
Ault PW130RB4800F01
Note: PW130RA modules are not 802.3af compliant.
You can view the SY-7000 series matrix in “Model Matrix” on page 44.
1.1.2 The Software Development Kit
1.1.2.1Components
The following components are included in the SY-7000 SDK kit.
• The SY-7000 Terminal
(contains standard application named SY-7000)
• SY-7000 SDK disk (includes readme.txt file)
• Cross Compiler – GCC Version 3.3.3
•Cables
• Crossover Cable
• DB9 Cable (In Cables)
• SDK manual
• Terminal installation manual
1.1.3 Developer Minimum Skill Set
In order to assure the most efficient use of time and resources during while building the project, it is
important for developers to be proficient in at least the following minimum skill sets:
•CorC++
• Familiar with Linux
• Familiar with embedded systems

SY-7000 SDK Manual Introduction
9
1.1.3.1Technical Specifications
The heart of the Terminal is based on a MPC885 from Freescale Semiconductor.
It is specifically designed to enable working with for several communication types and is powerful enough
to meet several future demands.
Operating System - standard open source embedded Linux Version 2.4.26.

IntroductionSY-7000 SDK Manual
10
1.1.3.2Bottom connector panel
