Synergy 21 SR-1006 Series User manual

Programmable RGB Remote Led Controller
Programmable
Control 4 zones
Model:SR-2810 with SR-1006 Series
Parameter
Wiring diagram
Product Size
Brief introduction of buttons
RGB Remote control
SR-1006TA 12-36VDC Constant voltage
3x(36-108)W
3x3A
SR-1006FA 12-36VDC Constant voltage
3x(60-180)W3x5A
Remote
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
Operation
Frequency
SR-2810 4.5VDC 55x120x17
434MHz/868MHz
Receiver
SR-1006FA3 12-36VDC Constant current
3x(4.2-12.6)W
3x350mA
Remarks
load 3pcs 7 AAA (1.5V)
batteries
Note:
One receiver can work with 1-8pcs SR-2810
One SR-2810 control multiple receivers
The power supply chosen must be 20% higher than the actual load
Indicator: indicate the state of
remote control
ON/OFF button
1)Receiver Connection Diagram for Single Unit
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
LN
110V-230VAC
Power Supply
12-36VDC
LN
110V-230VAC
Color wheel
55.0
17.0
120.0
SR-1006FA7 12-36VDC Constant current
3x(8.4-25.2)W3x700mA
SR-1006EA 12-36VDC Constant voltage
3x(96-288)W3x8A
Programmable button
1-4 zones
Short press: choose zone
Long press:switch on/off
Mode
Brightness down
Brightness up
Primary color
Speed down S-
M
B B+
S+ Speed up
Saturation color temperature
change to white
SR-1006FA
SR-1006FA
SR-1006FA
SR-1006FA
Part No. Input Voltage Remarks
Output Current Output Power

Operation
1. Learning receivers ID to remote
a. Press learning button on the receiver (the indicator will be on)
b. Choose a zone number on the remote
c. Touch the color wheel
Note:
The remote must be on before learning ID
Enable to assign multiple receivers to the same zone number, those receivers will be controlled
synchronously.
Long press the learning button over 5 seconds until the indicator off, the learned ID will be deleted.
2.How to Program?
a.Press “P”
b.Touch color wheel to choose a period of color or several colors you want
C. Press “P”again to save the color you choose
c.Choose the zone number on remote
d.Touch “M” to play the colors
Note:
The remote must be on, when program
Enable not only to program each zone separately, but also to program multiple zones together at one time by
press multiple zone numbers.
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
