Synergy Global Technology R2002 User manual

Page 1 of 1
R2002(
(3 32 2 b bi it t 1 1- -2 2 R Ri is se er r C Ca ar rd d) )
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n G Gu ui id de e
A. Introduction:
R2002 is a Riser Card, which changes the PCI card insert direction from vertical to horizontal and
also expands PCI slot up to two. In order to install the R2002
on your system board (motherboard), you
need to configure the mini-jumpers on R2002 by following the procedures in the next section
(Installation Procedures). For your convince, a device num
ber scanning software is available as a tool for
setting up the mini-jumpers and once the installation is done, R2002
could be treated as a part of your
system board. Which means you don't have to re-install or re-configure the R2002 while you are
operating (power-on/power-off) the system board.
In our lab testing, R2002 with full loading (two Ethernet LAN
cards loaded in all slots) performs
very well and stable at maximum speed.
B. Installation Procedures:
1. Scanning the First Device Number
Step 1. Power-off system board. (Motherboard)
Step 2. Connect a PCI peripheral card into the first slot of R2002. The first slot is the one next to the R2002
card's golden finger. (See Fig. 1)
Step 3. Plug the above-prepared R2002 card into the system board.
Step 4. Power-on the system board and entering the DOS mode. Using a DOS system diskette in drive A
as the boot system is strongly recommended.
Step 5. In DOS prompt, execute the scanning software. The first slot's Device Number (DN#1) and other
PCI devices' DN# will be shown on screen. Keep these DN# for preceding the following steps.
Fig. 1. PCI
Mini-Jumper 2
. . . . . .
. . . . . .
. . . . . .
Slot 2
Slot 1

Page 2 of 2
2. Mapping the Second Device Numbers
Step 6. Power-off system board.
Step 7. Connect another PCI peripheral card into the second slot of R2002. The second slot (slot 2) is
the one next to the first slot. Note that the mini-jumper for slot 2 is mini-jumper 2. (See Fig. 1)
Step 8. Power-on system board again.
Should you find nothing appearing on screen after booting up your system in normal start up time,
it could be the DN conflicting. Please turn off the power and reset the mini-jumper 2 to the next
position, and then power-on again. Supposed the mini-jumper is set at position A, you could try to
reposition it at position B. If B doesn't work, try position C, and so forth until DOS prompt is
shown.
Step 9. Execute the scanning software again; the second DN (DN#2) will be listed on screen.
Suppose the mini-jumper is set at position A as the diagram shown bellow, and the DN#2 detected
by the scanning software is 2, which tells A=2. Because mini-jumpers are in the sequence as A, B,
C, D, E, F, G, H, I, J, K and L, so the mapping for all mini-jumpers are (Fig.2):
K=12 I=10 G=8 E=6 C=4 A=2
L=13 J=11 H=9 F=7 D=5 B=3
K I G E C A
L J H F D B
Fig 2. Mini-Jumper Diagram, preset at position A
3. Setting the Second Slot Mini-jumpers
Step 10. Power-off system board and unplug R2002 from system board.
Step 11. The rule for setting mini-jumper 2 is:
Supposed that DN#1 = X,
• DN#2 should be any number chosen of X-1, X-5, X-9, X+3, X+7, or X+11.
Please also note that DN#2 cannot set to those numbers already been occupied by other PCI
devices.
• Please place your mini-jumper at the proper position. The mini-jumper 2 is for DN#2.
• For example, say DN#1=9, and 0,7,8 are occupied, then DN#2 could be 3, 4, 11, or 12.
Step 12. Re-plug R2002 back to system board and done.
