SynQuaNon Hex I/O Expander User manual


Hex I/O Expander User Manual
Page of 1 3
Hex I/O Expander
Module front panel overview
➊
➊I/O"DC-coupled inputs or outputs 1 - 6; accept +/- 12V signals. ""
"Wired to both SynQuaNon Audio and CV Bus connectors on rear.#
Introduction
Congratulations on your purchase of this SynQuaNon product! It is our belief that our
products will enable you to find new and interesting ways to create custom sounds
with your synthesizer and other SynQuaNon modules. Check out our full line at
www.synquanon.com.


Hex I/O Expander User Manual
Page of 2 3
Module rear panel overview
➊
➋#
➊Audio Bus"" Pins 1,3,5,7,9,11 are connected to jacks 1-6 on the front. "
" " All other pins are grounded.#
➋CV Bus "Pins 1-6 are connected to jacks 1-6 on the front. Pins 7,8 "
"are grounded.#
Overview
The Hex I/O Expander module adapts six audio or CV signals connected to the front
panel to SynQuaNon Audio and/or CV Bus connections on the rear. The module is
entirely passive. Conversion can be from 3.5mm jacks to SynQuaNon Bus or the
reverse. This facilitates interfacing SynQuaNon modules with other brands, as well as
adding six additional inputs and/or outputs to SynQuaNon modules.#
Ideal for guitar or bass single-string processing.


Hex I/O Expander User Manual
Page of 3 3
Features
•Allows for connection of other brand modules to SynQuaNon Audio and/or CV
Bus connections on rear of SynQuaNon modules.#
•Can be used to add six more audio/CV inputs and/or outputs to SynQuaNon
modules.#
•Minimizes front panel patch cable lengths if placed close to other brand
modules while using appropriate length SynQuaNon Bus cable inside case.#
•Passive design.#
Support
In case of difficulty:#
1. Check patch cables for continuity or shorts.#
For additional information please feel free to contact us at [email protected]
Technical Specifications + Downloads
Width
3 HP
Depth
17 mm
Power
Module does not draw
power
