SYR SefeTech Connect Installation guide

Operation and Maintenance
SafeTech Connect Leakage Detector
WE KEEP SMART THINGS SIMPLE.
Innovative solutions for smart people

Operation and Maintenance SafeTech Connect Leakage
Content
1. General....................................................................................................................... 3
1.1 Indications regarding the instructions for use............................................................................3
1.2 Symbols used..........................................................................................................................................3
1.3 Copyright / Standards / Warranty ....................................................................................................4
2. Safety ........................................................................................................................ 5
2.1 Intended use...........................................................................................................................................5
2.2 Fundamental hazards...........................................................................................................................5
2.3 Hazards due to electric energy.........................................................................................................5
2.4 Maintenance and repair work............................................................................................................6
3. Installation instructions............................................................................................. 6
4. Design and function.................................................................................................... 7
4.1 Scope of supply......................................................................................................................................7
4.2 Optional accessories ............................................................................................................................7
4.3 Design .......................................................................................................................................................8
4.4 Function....................................................................................................................................................8
5. Transport and storage................................................................................................ 9
5.1 Transport..................................................................................................................................................9
5.2 Storage .....................................................................................................................................................9
6. Installation and initial setup......................................................................................10
6.1 Safety instructions on installation and initial setup................................................................10
6.2 Installation ............................................................................................................................................. 11
7. Operation and settings..............................................................................................13
7.1 Operation and settings via the SYR App....................................................................................... 13
7.2 Displays and actions directly on the device ............................................................................... 16
7.3. Connection of several Connect devices ....................................................................................... 17
8. Emergency unlocking function...................................................................................18
9. Components and spare parts.................................................................................... 22
10. Maintenance............................................................................................................. 23
11. Faults ....................................................................................................................... 23
12. Specifications .......................................................................................................... 26
13. Dimensions............................................................................................................... 27

3
1.1 Indications regarding the instructions for use
The instructions for use are to help you handle your SYR SafeTech Connect Leakage Detector in a safe
and efficient manner. They form part of the scope of supply and have to be readily available at all times.
Due to technical developments, illustrations and descriptions in the present instructions for use may
slightly differ from the SafeTech Connect Leakage Detector actually supplied.
We do not assume any liability for damage due to any violations of the present instructions for use.
1.2 Symbols used
All safety instructions are signalled in the instructions for use by respective symbols. The symbolsat
the beginning of the safety instructions are an expression of the extent of the risk.
Danger!
The combination of the symbol and the signal word indicates direct danger and a
situation which, if not avoided, could result in death or severe injury.
Warning!
The combination of the symbol and the signal word indicates a potentially dange-
rous situation which, if not avoided, could result in death or severe injury.
Caution!
The combination of the symbol and the signal word indicates a potentially dange-
rous situation which, if not avoided, could result in minor injury.
Attention!
The combination of the symbol and the signal word represents important informa-
tion that helps prevent material or environmental damage.
1. General

Operation and Maintenance SafeTech Connect Leakage
1.3 Copyright / Standards / Warranty
The instructions for use and all the specifications supplied with the device remain intellectual property
of Hans Sasserath GmbH & Co. KG.
Their use in the framework of the use of the device is admissible and desired.
These documents must not be copied nor may they be made available to third parties, in particular
competitors, without the express consent of SYR.
Please note that the SYR SafeTech Connect Leakage Detector is patent protection.
The following European and national standards have been applied for the development and design of
the SafeTech Connect Leakage Detector:
•DIN EN 806
•DIN 1988
•DIN 3553
The manufacturer’s warranty is subject to the sales terms and conditions of delivery.
The warranty is invalid in case of:
•Damage due to improper operation,
•Repair or conversion work performed by unauthorised persons,
•Use of non-original SYR accessories or spare parts.
•Faulty parts that are not repaired immediately as to limit the extent of damage as soon as
possible and avoid a negative effect on the safety of the device (repair obligation).

5
2.1 Intended use
The SYR SafeTech Connect is used as an effective leakage protection system according to DIN 3553 for
apartments and single family homes.
Due to the nature of the system, there cannot be a 100% guarantee that no water damage will occur.
The SYR SafeTech Connect Leakage Detector is intended for use in cold water systems. Any other use or
use beyond the intended use is considered unintended use.
The respect of these instructions for use also falls under the scope of intended use.
2.2 Fundamental hazards
In general, danger can occur when handling electrically powered devices. Therefore, please follow safe-
ty and health regulations (VSG), other generally accepted safety and occupational health rules as well
as health and safety regulations of the German trade associations (BGV).
Do not modify the SafeTech Connect
Leakage Detector. The manufacturer
does not assume any liability for da-
mage due to improper alterations.
2.3 Hazards due to electric energy
In general, danger can occur when handling electrically powered devices. Therefore, please follow safe-
ty and health regulations (VSG), other generally accepted safety and occupational health rules as well
as health and safety regulations of the German trade associations (BGV).
Do not modify the SYR SafeTech Connect Leakage Detector. The manufacturer does not assume any
liability for damage due to improper alterations.
2. Safety
Please pay attantion to the technical regulations for
safety-related systems, e.g. fire-fighting pipelines,
emergency showers etc.!

Operation and Maintenance SafeTech Connect Leakage
Please observe the prescribed values for voltage and power (see specifications).
Work on electrical installations or controls must be made by qualified electricians only.
Disconnect the mains adapter and remove the batteries prior to working on the installation.
Regularly check the mains adapter and have it removed by a qualified electrician in case it is damaged.
2.4 Maintenance and repair work
Maintenance and repair work must be done by qualified and authorised specialists only. They are con-
sidered authorised specialists because of their vocational training, instruction or experience to do the
required intervention, detect and prevent potential risks from occurring in pursuing their activities.
They must be able to provide evidence about their knowledge of the relevant safety standards, safety
regulations and the health and safety regulations of the German trade associations (BGV) and they
must have read the instructions for use.
The SYR SafeTech Connect Leakage Detector operates on an ISM band of 2.4 GHz. Please make sure that
the installation is not next to devices with the same channel assignment (e.g. wireless LAN devices, HF
components etc.).
In unfavourable ambient conditions, in buildings or rooms with walls made of reinforced concrete, steel
or iron frames or near metal barriers (e.g. pieces of furniture), radio reception may be impaired or inter-
rupted. Possibly, a wireless repeater will have to be installed to increase the range of the radio signal.
The SafeTech Connect Leakage Detector must be installed in frost-proof, non-condensing rooms. The
SafeTech Connect must not be installed in inaccessible ducts.
To guarantee smooth operations, the SafeTech Connect, the smartphone or tablet and possibly the
computer must be connected to the Internet. A wireless LAN-enabled router is also required.
3. Installation instructions

7
➊
➋ ➌ ➍
➎
➏
➐
Legend
➊ Electronic unit
➋ 9V battery
➌ Emergency unlocking key
➍ Mains adapter
➎ Screw connections (2x)
➏ Smart start instructions
➐ Operation and maintenance
4.1 Scope of supply
4.2 Optional accessories
The system’s functionalities can be extended with the following accessories:
•SYR SafeFloor Connect radio-controlled floor sensor (2422.00.200)
4. Design and function

Operation and Maintenance SafeTech Connect Leakage
➎
➍
➌
➏
➊ ➋
4.3 Design
4.4 Function
The SYR SafeTech Connect Leakage Detector is an efficient leakage protection system according to DIN
3553. Thanks to permanent monitoring, any leak is detected at an early stage and the risk of extensive
water damage is reduced because the water supply is cut off automatically.
The SafeTech Connect Leakage Detector features an electronic water metering device (by means of a
turbine), an electrically-driven shut-off valve, a pressure sensor to monitor the smallest leakage volu-
mes and a multifunctional display. In addition, the device determines water hardness and indicates it
in three stages.
The SYR SafeTech Connect Leakage Detector can connect to the SYR App via its AccessPoint. In case
of an active Internet connection, the SafeTech Connect transmits the measured values from the drin-
king water installation, e.g. volume flow, flow rate per time, duration of volume flow, pressure drop and
temperature via a secure connection.
Even if the Internet connection is down, the parameters will continue to be monitored. However, during
that period, there is no communication with the server and no notification in case of derogations from
set parameters. Of course, the system can also operate without Internet connection.
The mains adapter is used for power supply. The scope of delivery includes a battery for the short-term
protection in case of power failure.
Legend
➊ LCD Display
➋ Touch switch
➌ Battery compartment
➍ Battery
➎ Emergency unlocking key
➏ Cover of battery compartment
with product-specific QR code

9
5.1 Transport
The device is completely pre-mounted when delivered.
It weighs approximately 1,275 g.
5.2 Storage
Store the device under the following ambient conditions only:
Temperature: +4 to +60 °C, relative air humidity: max. 80 %.
Attention!
Improper transport may damage the device!
The packaging serves as protection during transport.
•Do not install the device if the packaging is severely damaged.
•When submitted to hard shocks or impacts, replace the synthetic part
concerned (even if it presents no visible damage).
Attention!
Improper storage may damage the device!
•Protect the valve and the electronic system against frost.
5. Transport and storage

Operation and Maintenance SafeTech Connect Leakage
6.1 Safety instructions for installation and initial setup
Only authorized, qualified and specially trained personnel with the corresponding know-how shall
install and commission the SYR SafeTech Connect Leakage Detector.
Observe the general safety instructions for drinking water installations, such as the following:
•TRWI - DIN 1988, DIN EN 806, DIN EN 1717
•Rules and regulations of the local water company
Attention!
Improper installation of the drinking water device may cause damage!
•Follow the instructions for use to mount the SafeTech Connect.
Check that the connection is leaktight
•
Avoid strong water hammers, caused e.g. by downstream solenoid valves.
Attention!
Drinking water pollution may cause corrosion and malfunctions of the valves.
•We recommend the use of a filter (e.g. DRUFI+ DFR) to protect the installa-
tion downstream!
Attention!
The device may be damaged if the electric installation is not made properly!
•Use only the supplied mains adapter to connect the device to the power
supply.
6. Installation and initial setup

11
6.2 Installation
•Turn off the water supply prior to starting the installation work.
Mount the device only in drinking
water installations according to DIN
1988, directly downstream of the
water metering device. Do not apply
stresses.
Flush the pipes before installation.
To be safe in case of a defect, you should install a drinking water filter according to DIN 1988 (e.g. SYR
DRUFI+) downstream of the SafeTech Connect Leakage Detector.
Drinking water filter
Point of entry installation
SafeTech Connect
Please observe the direction of flow marked by an
arrow on the body!
In case of continued draw-off operations (e.g. filling-up a swimming pool) and in com-
bination with safety-related valves (e.g. thermal safety valve 3065), there must be a
separate outlet upstream of the SafeTech Connect Leakage Detector!
•Re-open the water supply.
•Check that the valve connections are leaktight!
•Open the battery compartment and insert the 9V block battery.
Be sure to observe the polarity!

Operation and Maintenance SafeTech Connect Leakage
•Insert the battery.
•Plug in the mains adapter to ensure power supply.
The device is now ready to use!

13
7. Operation and settings
7.1. Operation and settings via the SYR App
It’s easy to set your SYR SafeTech Connect Leakage Detector via the SYR App on your smartphone or
tablet.
Simply install the current SYR App on your smartphone or tablet. You can also use your computer
(http://syrconnect.de) and follow the user instructions.
You will fi nd exact instructions for the initial setup of your device in the appended instructions.
The SafeTech Connect can also be used without an Internet connection. In this case,
functions like notification by text messages or e-mail are not available though. The
SafeTech Connect cannot be connected to other devices in this case either, like e.g. the
radio-controlled floor sensor SafeFloor Connect.

Operation and Maintenance SafeTech Connect Leakage
Explanation and setting options factory settings
User profile
Individual setting of the device, adjusted to the user profi le. A maximum of eight
user profi les are possible.
Example:
Usually, the two daughters are present at weekends. The two girls like to take
long, extensive showers. To make sure that the parents have sufficient water,
too, they create a new profile with the corresponding parameters.
SYR tip: Refer to the smart self-learning phase of the SafeTech Connect to
determine the optimum safety levels for your new profile.
Volume-based leakage
Present
(active)
Absent
Maximum amount of water drawn after opening a draw-off point. The setting for
volume-based leakage ranges from10 to 9,000 litres. Volume-based leakage may
be switched off.
Example:
The draw-off point with the highest draw-off amount is a bathtub with a capa-
city of approximately 120 litres. Set the value of leakage in the presence-mo-
de to 200 litres so that the bathtub can be filled up without any problem and
you can still draw water.
Time-based leakage
300 l
If a draw-off is registered that takes longer than the time set for a specifi c volume,
the device will isolate the system. Time-based leakage can be set to 30 minute
intervals, ranging between 0.5 and 25 hours. This setting can also be switched off.
Example:
In addition to the amount of water set for volume-based leakage, a period of
time can be determined when water may be drawn without interruption. If, for
example, the time-based leakage is set to 60 minutes, the SafeTech Connect
will isolate the system once this time has elapsed, even if the set volume has
not yet been reached.
60 minutes
7.1.1. Settings range
Please find below the most important terms for the settings range of the SafeTech Connect Leakage
Detector in the SYR App. Examples are given for illustration.

15
If the SafeTech Connect detects unusual fl ow rates within short periods of time,
the device will consider this as leakage. Flow-based leakage can be set up to a
volume of 5,000 l/h, yet this setting can also be switched off completely.
Example:
The factory setting of a maximum flow of 3,000 l/h continues for at least
one minute — mostly in case of pipe bursts: the SafeTech Connect Leakage
Detector will immediately shut off the pipe system.
SYR tip: Install an additional radio-controlled floor sensor SafeFloor in cri-
tical places. This will determine local water leaks, regardless of the selected
settings. The SafeFloor can be connected to the SafeTech Connect so that
the latter can immediately isolate the system.
3.000 l/h
Return to “present” mode
The user can determine the time when a selected profi le shall be active. Once
the set time is over, the SafeTech Connect will return to the “present” mode. The
options for the settings range between one hour and 28 days. Times will be given
in hours.
Example:
You will be away from home for four days and therefore you select a mode
with low water consumption. If you select your return time to “present” to be
four days, the SafeTech Connect will automatically switch back to this mode
after the selected time and you do not have to worry about anything.
Microleakage test
Time indica-
tion
The device will check at regular intervals for the smallest of leaks. The microlea-
kage test can be switched on or off.
Warning sound
Warning
The warning sound can be switched on or off.
Self-learning phase
On
During the self-learning phase, the SafeTech Connect Leakage Detector analy-
ses water consumption and the usual household usage. The measured values can
then be used for your own, selected profi le. The duration of the self-learning pha-
se can range between one and 28 days.
Off
Flow-based leakage

Operation and Maintenance SafeTech Connect Leakage
7.2. Displays and actions directly on the device
The user interface of the SafeTech Connect Leakage Detector includes a 4-line LCD display, one LED for
the status indicator and one touch switch.
LED-display Green Red
LED lights up Active leakage protection General fault
LED flashes Motor opens, closes,
active fl ow
Suspected leak
7.1.1. LED displays
LED
LCD-display
Touch switch
Condition of device Action Function
Shut-off valve open Touch-switch
1 x for 3s Shut-off valve closes
Shut-off valve closed Touch switch
1 x for 3s Shut-off valve opens
Fault (“red” LED on)
Shut-off valve closed
Touch switch
1 x for 3s Reset of fault, shut-off valve opens
AccessPoint (de-)activated Touch switch
1 x for 10s (De-)activates AccessPoint
7.1.2. Action

17
7.3. Connection of several Connect devices
To make sure that the external radio-controlled floor sensor SafeFloor Connect notifies a water leak or
suspicious humidity levels, it has to be connected to a SafeTech Connect Leakage Detector.
To connect the devices, they have to be registered
via SYR CONNECT and be online.
➊ Select the SafeTech Connect Leakage Detector and click
on “Connected devices”.
➋Then click on “+ Connect device”.
➌Follow the instructions and activate the AccessPoint of the
SafeFloor Connect.
➍ Once the SafeFloor has been successfully connected,
it will be indicated by a green dot on the list.
➊
The SafeTech Connect Leakage Detector acts as
the master, i.e. the SafeTech Connect activates the
connection to the radio-controlled floor sensor Sa-
feFloor Connect, not vice versa.
➋
➌
➍

Operation and Maintenance SafeTech Connect Leakage
8.1 Emergency unlocking function
Thanks to the emergency unlocking function, the SafeTech Connect Leakage Detector can be manually
unlocked, for instance in case of power failure or a missing or low battery.
The access to the emergency unlocking function is underneath the control unit.
8. Emergency unlocking function
No cables have to be
removed!
•One by one, remove the battery compartment and the shell of the SafeTech Connect
Leakage Detector.

19
•Remove the emergency unlocking key, the battery and the battery compartment.
•Pull the casing upwards and tip it sideways.

Operation and Maintenance SafeTech Connect Leakage
•
Insert the emergency unlocking key from the top and turn it until water starts to fl ow.
•Remove the clamp that connects the body of the SafeTech Connect Leakage Detector with
the motor unit and place the motor unit next to it, sideways (without removing the cables),
thus opening access to the shut-off valve.
