Introduction
© 2023 System Q Ltd
3
DoorKnox.com
Introduction
The VDP304 has a stylish brushed aluminium & gloss black finish. The quality build
the DoorKnox is ideal for domestic, retail and commercial projects.
The menu interface has an updated modern design, showing coloured icons, for
easy use of the menu.*
Our touch button monitor provides control of the door entry camera and is available in
a 4" size.
Two door cameras and two door locks can be connected to the main monitor.
*The menu structure in the VDP304 does not match the latest VDP207 and VDP210 monitors, but
they can be used in conjunction with each other.
DoorKnox Monitors from serial numbers VDP207 (HCA01001) & VDP210 (HCB00401) can be used
along side the VDP304.
1.1 Key Features
·
Up to 4 monitors on a system. 1 Main Monitor plus 3 Auxiliary Monitors.
·
Camera to Monitor Intercom
·
Monitor to Monitor Intercom
·
12 built ringtones
·
Customise ringtone MP3
·
Motion detection
·
Ring at camera
·
Automated Message & Video Mail Recording
·
Local Unlock
·
Standby Screen Saver Customisation
·
Media Player - Music, Video & Pictures
09/06/2023
VDP304
4DoorKnox.com
User Information
·
Do not expose to moisture or high humidity conditions. This product is rated for
internal use only.
·
Take care when transporting, storing and installing the monitor
·
Always use and conform to current standards to install and use these. The signal
cables should be kept way from high voltage equipment. Damage to units by
lightning or mains voltage surges is not covered under the product warranty.(BS EN
62676-1-1) (BS EN 62676-4) (BS8418)
·
There are no user serviceable parts in the monitor and opening or attempting to
repair the product will void the warranty.
·
Do not touch the connections with wet hands.
·
Wipe dirt away with a damp micro-fibrecloth.
·
Do not install or use the monitor if the cables, casing, or the power supply is
damaged.
09/06/2023
VDP304
6DoorKnox.com
3.1 Cameras
All of the DoorKnox cameras have connection cables terminated into the same 7
colour coordinated wires. 4 wires are used to connect to the monitor and then 2 of
the 3 remaining wires are used to connect to an electronic door lock.
The common (COM) wire is always used along with either the normally open (NO) or
normally closed (NC) wire depending on the lock type, power for the lock is separate
as the Door Lock relay does not provide power output.
Connections and Wiring
© 2023 System Q Ltd
7
DoorKnox.com
3.2 Monitors
Every monitor is supplied with 5x 4 wire y-leads, 1x 2 wire y-lead and 1x 3 wire y-
lead.
The 4 wire y-leads are terminated into 4 pin plugs which are simply inserted into the
sockets on the rear of the monitor. These are used for connecting door cameras,
auxiliary cameras and auxiliary monitors, the 4 wires are colour co-ordinated to
match the 4 wires from the door camera.
The 2 wire y-lead is terminated with a 2 pin plug and is used as the TV out for
connecting the door monitor to a TV monitor or DVR.
The 3 wire y-lead is terminated for the local relay plug and is used to unlock a local
relay like a door release local to the monitor.
09/06/2023
VDP304
8DoorKnox.com
3.3 Powering Cameras
Door cameras and auxiliary cameras can be powered in two ways, either locally or
via the main monitor.
The DoorKnox monitors can supply a 12V DC output to any of the four cameras but
can only supply a maximum of 400mA across all outputs.
To power a camera locally connect the Audio (white) and Video (yellow) to the door
monitor, the GND (black) to the PSU and the door monitor and then the 12V DC (red)
to the PSU only.
3.4 Powering Monitors
Door monitors are supplied with a 12V DC 2A plug-in PSU that terminates into a 2
pin plug which slots into the rear of the monitor.
Connections and Wiring
© 2023 System Q Ltd
9
DoorKnox.com
3.5 Cable Runs
The maximum achievable cable run is limited by the voltage drop in the chosen cable
and also the quality of the video cable which can cause signal loss and interference.
Resistance differs depending on the cable used and the higher the resistance the
more the voltage drops hence the shorter cable run achievable.
It is recommended to use one of three types of cable, PTZ combo cable sometimes
known as RG59+4, CAT5+2 cable or 4 core cable with 0.3mm2 cores.
Below shows the maximum recommended cable run for each cable type. Cable runs
exceeding the stated maximum run are at risk of issues caused by voltage drop and
non performance of equipment.
Camera to Main Monitor
Cable Type
Max Cable Run
PTZ Combo Cable (RG59+4)
Up To 150m
CAT5+2 Up To 100m
4 Core Cable (0.3mm2
Up To 100m
4 Core Cable (0.3mm2)
Up To 50m
Main Monitor to Auxiliary Monitors
Cable Type
Max Cable Run
PTZ Combo Cable (RG59+4)
Up To 30m (Per Monitor)
Controls and Features
© 2023 System Q Ltd
11
DoorKnox.com
Controls and Features
1. Power Indicator
2. Indicator shows which camera is being displayed
3. Transfer - Send call to other monitor(s) / Intercom
4. Monitoring - Switch between camera inputs
5. Unlock - Sends command to unlock
6. Answer Intercom - Answer / End call / Return
7. Microphone
8. Settings - Enter / Up and down
9. Volume Control
10. Micro SD card slot
Basic Monitor Settings
© 2023 System Q Ltd
13
DoorKnox.com
Basic Monitor Settings
If only using 1 door camera and 1 monitor then skip setting monitor ID and camera
switch.
7.1 Setting Monitor ID
Up to 4 DoorKnox monitors can be used; 1 main monitor and up to 3 auxiliary
monitors.
The main monitor ID must be set to 1, and the auxiliary monitors ID from 2 up.
1. Press the Setting button on the side of the monitor to access the menu.
2. Using the Setting button flick up / down to navigate to "Mode" in the menu, then
press the Setting button.
3. Navigate to "Device ID" then press Setting button, flick up / down to change the
ID.
See the Full Manual for more information on settings in the monitor.
7.2 Camera Switch
Coming soon
Using the Door Entry System
Coming soon
8.1 Visitor Calls
Coming soon
Monitor Features
Coming soon
Troubleshooting
Coming soon
09/06/2023
VDP304
14 DoorKnox.com
General Maintenance
·
Ensure that nothing is obscuring the field of view, position the camera to ensure the
subject is in field of view and can be seen clearly.
·
Ensure that the Microphone is clear and not obscured at all.
·
Routinely clean the monitor to prevent dust build up as this can effect the
performance. We recommend a damp non-abrasive microfibre cloth.
·
Routinely check the connections for power and data to ensure the connections are
secure and solid.
·
Check that the monitor is firmly attached to the wall mounting bracket.
·
Check playback in the monitor to ensure it is recording & triggering properly on the
SD Card
Extra Resources
Coming soon
Specifications
© 2023 System Q Ltd
15
DoorKnox.com
Specifications
Screen Size
4”
Video Input
CVBS / AHD (2MP) Ready
Screen Resolution
320 (H) x 240 (V)
Camera Input
2x Door Cameras / 2x Auxiliary Cameras
Door Monitor Inputs
1
Door Monitor Outputs
1 (3 Auxiliary, 4 Total – Daisy chained)
TV Monitor Outputs
1 (720 x 576)
SD Card
Micro SD / 2GB – 128GB Class 10 Min (Not Supplied)
Power / Consumption
12V DC / 1200mA (2A PSU Supplied)
Build
Plastic (Silver)
Operating Temperature
-10°C +60°C
Installation
Internal Use Surface Mount
Intercom Duration
120s
Dimensions
(H) 165 x (W) 245 x (D) 23mm
09/06/2023
VDP304
16 DoorKnox.com
Conditions
All specifications are approximate. System Q Ltd reserves the right to change any
product specifications or features without notice. Whilst every effort is made to
ensure that these instructions are complete and accurate, System Q Ltd cannot be
held responsible in any way for any losses, no matter how they arise, from errors or
omissions in these instructions, or the performance or non-performance of the
equipment that these instructions refer to.
This symbol on the products and/or accompanying documents means that used
electronic equipment must not be mixed with general household waste. For
treatment, recovery and recycling please return this unit to your trade supplier or local
designated WEE/CG0783SS collection point as defined by your local council.
© Copyright 2020
DoorKnox is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40
2WB
