Systemline SM3160 User manual

SM3160
AirWay Multizone (4 Zone)
A multi zone audio distribution system designed
for use with a network connected music source
LOCALSYSTEMPOWER
ZAM40

Systemline AirWay Multizone is designed to be installed into your home so that you can
enjoy music from your mobile device wirelessly in any room of your choice. Each zone
amplier also has a local audio input allowing you to easily plug in the sound from a TV.
The following instructions assume that you are competent in general DIY skills. You will
need to locate and mount the central hub and power supply, and connect speakers and
Cat5 cable to the ampliers. If you are not condent in doing this then you should seek
professional assistance.
We strongly recommend that you connect the system together before installing it to
ensure that you are comfortable it will all work well in your home.
Introduction
Multi zone hub:
Dimensions: (WxHxD) 145mm x 132mm x 43mm
Weight: 1.1Kg
Inputs: stereo RCA
Power input: +24V DC (PSM120 required)
Output: balanced audio, power and data on 6 RJ45 sockets
Ampliers:
Dimensions: (WxHxD): 186mm x 40mm x 106mm
Weight: 0.6Kg
Inputs: 1 x RJ45 balanced line and power
1 x stereo 3.5mm jack,
1 x keypad RJ45
1 x IR 3.5mm
1 x direct power input
Outputs: 4 x screw t speaker terminals
1 x 3.5mm jack pre-amp output
Power supply:
Dimensions: (WxDxH) 68mm x 43mm x 115mm
Weight: 0.273Kg
Speakers:
Bass / mid driver: 140mm polypropylene cone
Tweeter driver: 25mm soft-dome multi-positional
Frequency response: 60Hz to 20kHz (±3dB)
Power handling: 30W rms
Sensitivity: 88dB/1W
Impedance: 8Ω nominal
Cutout: 195mm
Mounting depth: 75mm
Specications
Systemline, QED & uPlay Plus are registered trade marks ® of Armour Home Electronics Ltd. iPod, iPad, iPhone and iTunes are
registered trade marks ® of Apple Inc. All other product names are trademarks or registered trademarks of their respective owners.

Pack contents
B
H
CA
E FD
G
Zone amplier module
(ZAM) x 4
3m data patch cable x 8
Power supply x 1
UK mains cable x 1
I
Faceplate x 4
Hub and bracket x 1
Keypad x 4
1m data patch cable x 4 Jack to phono
audio cable x 1
J K
Plastic punch
down tool x 1
CLS2 ceiling
speakers x 4 pairs
LOCALSYSTEMPOWER
ZAM40

Repeat for up to 6 zones
* Source not supplied
Hard wired ethernet
Apple
Airport
or similar
device
Central location
*
System schematic
(Standard conguration)
LOCAL DC
POWER
REMOTE
POWER
LINE
INPUT
PRE-AMP
OUTPUT
IR-REC
INPUT
SPEAKERS
KEYPAD
INPUT
SYSTEM
INPUT
DC SUPPLY
+24 V
@ 4.1 A
L R
DESIGNED IN THE UK
Local input
Zone 1
*
* items not supplied
LOCAL DC
POWER
REMOTE
POWER
LINE
INPUT
PRE-AMP
OUTPUT
IR-REC
INPUT
SPEAKERS
KEYPAD
INPUT
SYSTEM
INPUT
DC SUPPLY
+24 V
@ 4.1 A
L R
DESIGNED IN THE UK
Local input
Zone 2
*

Determine Cat5 location in each zone. One cable from the hub (A) to each
amplier (B) is required.
Mount the hub bracket on the wall and t hub (A) in the central source location.
Plug in a ZAM (B) in each zone using the Cat5 cable and patch cables (F) and (G).
SYSTEM
INPUT
1.
2.
3.
B
A
A
FG
Max 50m Cat5
Max 50m Cat5
Zone 1
Zone 2
Main location
LOCALSYSTEMPOWER
ZAM40
ZONE
OUTPUT
Installation instructions

B
B
Plug TV sound into the ZAM.
(Standard conguration only)
7.
LOCALSYSTEMPOWER
ZAM40
LINE OUT /
HEADPHONES
LINE
INPUT
H
C
A
A
4.
6.
Plug audio source into the hub
using audio cable (H).
Plug power supply (C) into the hub.
5.
D
* Source not supplied
Plug speakers (K) into the ZAM in each zone using the screw connectors.
IMO plugs included
with ZAM kit
LOCAL DC
POWER
REMOTE
POWER
LINE
INPUT
PRE-AMP
OUTPUT
IR-REC
INPUT
SPEAKERS
KEYPAD
INPUT
SYSTEM
INPUT
DC SUPPLY
+24 V
@ 4.1 A
L R
DESIGNED IN THE UK
K K
* Audio cable not supplied

Connect a keypad (E) in each zone:
Select a 3 metre data patch cable (F) and cut o the plug at one end only. Peel back
the cut end and terminate the brown, white/brown, blue and white/blue wires to the
connector as shown below. Note: do not strip o the conductor sleeving. The other four
green and orange wires are not used.
Use the supplied punch down tool to push each cable down rmly. Note: make sure
that the largest tooth of the tool is on the side of the terminal block with the coloured
sticker as shown above (right).
8.
Plug keypads into the ZAM in each zone.
9.
B
LOCALSYSTEMPOWER
ZAM40
KEYPAD
Cat5 cable
ZAM40
ZAM40
ZAM40
E
E
J
E

Make sure your audio source is playing music rst.
Power LED lights up red when in standby.
The ZAM shows a blue LED indicating that the zone is on.
Press the power button on the keypad to turn the
zone on. Use the volume up and volume down
buttons to increase or decrease the volume. Pressing
the power button again switches to local source (see
below) and a third press goes back to standby.
The ZAM shows a green LED when playing from a local
source.
Note: The local input can be disabled on the keypad by pressing the volume up button
and the power button simultaneously. Repeat this procedure to re-enable the local input.
LOCALSYSTEMPOWER
LOCALSYSTEMPOWER
LOCALSYSTEMPOWER
Operating instructions

LOCAL DC
POWER
REMOTE
POWER
LINE
INPUT
PRE-AMP
OUTPUT
IR-REC
INPUT
SPEAKERS
KEYPAD
INPUT
SYSTEM
INPUT
DC SUPPLY
+24 V
@ 4.1 A
L R
DESIGNED IN THE UK
Repeat for up to 6 zones
* Source not supplied
Hard wired ethernet
Apple
Airport
or similar
device
Central location
Alternative conguration
Zone 1
LOCAL DC
POWER
REMOTE
POWER
LINE
INPUT
PRE-AMP
OUTPUT
IR-REC
INPUT
SPEAKERS
KEYPAD
INPUT
SYSTEM
INPUT
DC SUPPLY
+24 V
@ 4.1 A
L R
DESIGNED IN THE UK
Zone 2

The following are available as additional accessories.
4.
SM0405 White
M-ZAM40 - Zone amplier module
QE2940 - QED uPlay Stream
M-RM1 - Infrared remote control
ZCAB504 - 1m data patch cable
ZCAB507- 3m data patch cable
SM0406 Black
Expand the number of zones up to 6
by adding more ZAM units. Just add
speakers and plug them in.
Plug extra ZAM units in using these cables.
Additional ZAM units
1. Additional patch cables
Additional keypads
2.
Additional remote controls
3.
6. Additional speakers
Network music player
5.
LOCALSYSTEMPOWER
ZAM40
VOL
Accessory products
R-CLS2 - Ceiling speakers (pair)

ZINS102
Stortford Hall Industrial Park
Dunmow Road
Bishops Stortford
Hertfordshire
CM23 5GZ
www.armourhome.co.uk
©2013 Armour Home Electronics, All rights reserved.
Our policy is one of continuous product improvement, we reserve
All information is given in good faith. The manufacturer accepts no
responsibility for errors, omissions or incorrect assumptions. Q14758-IS_r1
