6-Port Gigabit Compact Ethernet
Switch Manual
ShenZhen Comark Technology Co.,Ltd.

More Reliable Connection, More Intelligent Life More Reliable Connection, More Intelligent Life
-3- -4-
【Summary】
6-Port Gigabit Compact Industrial Ethernet Switch is designed with IP40 metal housing and
high level EMC protection, supports Auto-Negotiation speed, power input with wide range
voltage, 1~4*10/100/1000BaseT(X) RJ45 ports and 0~2* 1000M SFP ports(1000Base-X or
1000Base-T optional), and DIN35 rail or wall mounting for the different industrial
circumstances. It can work in harsh -40~75℃environment to provide the reliability and
flexibility for your industrial Ethernet solution.
【Features】
Support IEEE802.3/802.3u/802.3ab/802.3z, store-and-forward switching
1~4* 10/100/1000Base-T(X) RJ45 ports, support Auto-Negotiation speed
(10M/100M/1000M ), auto Full Duplex/ Half Duplex mode, auto MDI/MDI-X
connection
0~2* 1000M SFP ports (1000Base-X or 1000Base-T optional) Metal housing with
IP40 and high level EMC protection
Support wide range voltage 12~48V DC power input and over-current protection
function
Work in -40~75℃wide temperature
【Specifications】
Technical Standard
Protocol:IEEE802.3、IEEE802.3u、IEEE 802.3ab、IEEE 802.3z
Interface
RJ45 port: 10/100/1000BaseT(X) speed Auto-Negotiation, Full/Half Duplex mode,
MDI/MDI-X connection
SFP port: 1000Base-X or 1000Base-T optional, support for twisted pair cable
transmission
Switching Characteristic
10M Frame Forward Rate:14881pps
100M Frame Forward Rate:148810pps
1000M Frame Forward Rate:1488096pps
Forward Mode:store-and-forward
Switching Bandwidth:12Gbps
Cache Size:1Mbits
MAC Address Table:1K
Power Supply
Input: DC power input 12~48V(12V/24V/48V typical) with 7.62mm industrial
terminal
No-load Consumption :<0.48W (@24VDC)
Full-load Consumption:<4.8W (@24VDC)
Physical Characteristic
【Precautions】
Please use DC 12~48V standard industrial power supply, typical voltage are
12V/24V/48V.
Cover the unused fiber optic ports with caps to prevent it from contaminating.
Do not stare the fiber optic output ports directly, the laser should injure you eye.
Connect the device to ground properly, there is specified GND screw on the side-board,
connect it with specified Ground Wire.
【Models】
Model
Description
Ck1211
6-Port Gigabit Compact Ethernet Switch, 1*10/100/1000Base-T(X)
RJ45 ports, 1*1000 SFP ports(1000Base-X or 1000Base-T optional),
-40℃~75℃.
Ck1240
6-Port Gigabit Compact Ethernet Switch, 4*10/100/1000Base-T(X)
RJ45 ports, -40℃~75℃.
Ck1241
6-Port Gigabit Compact Ethernet Switch, 4*10/100/1000Base-T(X)
RJ45 ports, 1*1000 SFP ports(1000Base-X or 1000Base-T optional),
-40℃~75℃.
Ck1242
6-Port Gigabit Compact Ethernet Switch, 4*10/100/1000Base-T(X)
RJ45 ports, 2*1000 SFP ports(1000Base-X or 1000Base-T optional),
-40℃~75℃.
Dimensions(W×H×D):40mm×128mm×102mm
Weight:300g
Housing: Metal, IP40 protection
Installation: Wall mounting or DIN rail mounting
Environment Limits
Work Temp:-40℃~75℃
Storage Temp:-40℃~85℃
Relative Humidity:5%~95%(non-condensing)
Warranty
Warranty Period: 5 years
【Certifications】
IEC61000-4-2(ESD):±6KV Contact, ±8KV Air
IEC61000-4-3(RS):10V/M(80-1000MHZ)
IEC61000-4-4(EFT):Power ±4KV, Data Cable ±2KV

More Reliable Connection, More Intelligent Life More Reliable Connection, More Intelligent Life
-3- -4-
IEC61000-4-5(Surge):Power ±2KV CM/ ±1KV DM, Data Cable±4KV
IEC61000-4-6(CS):3V (10KHZ-150KHZ), 10V (150KHZ-80MHZ)
IEC61000-4-16(MS):30V COUNT 300V, 1S
IEC60068-2-6(Vibration)
IEC60068-2-27(Shock)
IEC60068-2-32(Free Fall)
IEC61000-6-2(General Industrial Standard)
【Dimensions】
Ck1211 Ck1240 Ck1241 Ck1242
【LED Indicator】
LED
Status
Description
PWR
Off
No power supply or failure
On
Power is on
G1~2
Off
No connection or failure on the RX fiber port
On
Fiber link is connected
Blinking
Fiber link is connected and data is being transmitted
2 LED indicators per RJ45 port, Gigabit use only green,10/100M use yellow and
green.
Yellow
Off
No valid link at the RJ45 port
On
10/100BaseT-(X) work mode
Blinking
10/100BaseT-(X) work mode and data is being
transmitted
Green
Off
No valid link at the RJ45 port
On
10/100/1000BaseT-(X) work mode
Blinking
10/100/1000BaseT-(X) work mode and data is being
transmitted
【Grounding and Power Supply】
Ground Connection: There is a ground (GND) screw on side-panel of the device,
connect the screw to ground terminal of the work place with ground wire. The ground
wire is required at least 2.5mm2and less than 5Ω resistance.
Power Input: The power input support voltage range DC 12~48V, you should use the
copper power wire above 0.75mm2.
【DIN Rail Mounting】
Follow these steps to install the device to DIN-Rail:
Step 1:Check the DIN-Rail Clip is fixed on the back panel of the device;
Step 2:Check DIN-Rail is stable and there is enough room to install the device;
Step 3:Insert the button edge of DIN rail into the clip slot just upside the stiff metal spring;
push the device forward slightly and the DIN-Rail Clip will snap into place as
shown in the following illustration.
Step 4:Check to make sure the device is installed to DIN Rail firmly.

More Reliable Connection, More Intelligent Life More Reliable Connection, More Intelligent Life
-3- -4-
【Package List】
When you take the device out of box, please check if any items are missing or damaged.
The device is shipped with following items:
6-Port gigabit Compact Ethernet Switch with industrial power terminal
Product Manual
Product Warranty
