T.B.D. HEATOR SRE 804 TC - User manual

SRE 80x-TC
Portable heaters
Laser
T.B.D.
SRE 80x-TC (BD Type A)
LC-V397-NB(BD)
grey (dull)
8713508741161
Burner type
Capacity kW 1.05-3.60
Suitable space
m214 - 42
m335 - 105
Fuel consumption ltr/hr 0.109 - 0.375
g/hr 87 - 300
Tank capacity ltr 5.4
Burning time tank hr 14.4 - 49.5
Mains V/Hz 220-230 / 50
Power consumption preheat W320
Power consumption burning W24
Noise level (low-high) dB(A) 21 - 36
Dimensions (w x d x h) * mm 516 x 315 x 450
Weight kg 11.0
Guarantee ** years 2
*including base plate
Transportation cap
Instructions for use
Description Model EAN Code
Burner mat C 8713508131504
Removable fuel tank E 8713508401805
Fuel tank cap high A 8713508400600
Fuel filter high A 8713508401003
Burner mat adhesive 8713508403403
Mica window 8713508135007
Transportation cap 8713508402505
Model name
Toyotomi model name
Colour
EAN code
Product data sheet 2007
Product range
Product line
Brand name
Technical specifications
Electronic Injection Burning System (BI)
** except burner mat and manual fuel pump
3254>1
Accessories
Most important spare parts
20 ft = 400
40 ft = 816
HQ =980
WxDxH=
425 x 325 x 488 mm
Gross =
10.5 kg
HEATER

SRE 80x-TC HEATER
Features
Additional high burning mode: This feature is also known as booster. It
provides 10% extra heating capacity for 5 minutes, in addition to the heat output
in the maximum burning mode during a cold start (room temperature below 10oC
and set temperature above 15o C).
Automatic cleaning mode: When the heater has been burning for two hours
consecutively at its maximum burning mode it will automatically clean the burner
chamber for a period of 5 minutes.
Semi-automatic operation: This heater is equipped with a 24-hour
programmable timer and integrated thermostatic control to maintain the desired
room temperature.
Wickless design: Provides clean and economical heating without wick
maintenance or replacement.
Information display: Helps to keep track of all the important heater functions.
Safety devices: This heater is equipped with two flame-rod sensors, an over-
heat protector, a tip-over switch and a burner thermistor for safe heating.
Safety system: This heater is fitted with a safety system that automatically
switches off the heater after 48 hours of continuous operation.
Childproof lock: When this button is pressed, the operation of buttons will be
blocked, except the on/off button.
Automatic airflow control: The speed of the built-in fan is self-regulatory,
depending on the burning mode of the heater.
Made in Japan: This heater has been produced according to the ISO 9000:2000
Quality Control Standard.
LCD display
Laser burner
Fuel filter
Transportation cap
