T.BONE 516619 User manual

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 516619_516620_15.04.2021
Safety instructions
Intended use
This device is intended to be used for the wireless transmission of audio signals especially
for mobile applications. Any other use or use under other operating conditions is conside-
red to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard! Ensure that child-
ren do not detach any small parts from the product. They could swallow the
pieces and choke! Never let children unattended use electrical devices.
Where to use the product
Never use the product
• in conditions of extreme temperature or humidity
• in extremely dusty or dirty areas
• at locations where the unit can become wet
General handling
• To prevent damage, never use force when handling the product.
• Never immerse the product in water. Just wipe it with a clean dry cloth. Do not use
liquid cleaners such as benzene, thinners or ammable cleaning agents.
Quick Start Guide
This quick start guide contains important information on the safe operation of the
product. Read and follow the safety advice and instructions given. Retain the quick
start guide for future reference. If you pass the product on to others please include
this quick start guide.
Incorrect handling of lithium batteries can result in injury
• In the event of a short circuit, overheating or mechanical damage, lithium batteries can
cause severe injuries.
• When handled correctly and appropriately lithium batteries pose no risk.
• Store lithium batteries in a cool, dry place, ideally in the original packaging.
• Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batte-
ries are hermetically sealed. Never attempt to open a lithium battery.
• If the battery housing is damaged small amounts of the electrolyte may leak out. If this
should happen, seal the lithium battery in airtight packaging and wipe up the traces of
electrolyte using absorbent paper towels. You must wear protective rubber gloves when
doing so. Clean your hands and the aected surface thoroughly with cold water.
• Never attempt to recharge non-rechargeable lithium batteries. When charging lithium
batteries you must use a suitable charging device intended for the purpose.
• Before disposing of the device remove the lithium batteries. Protect used lithium batte-
ries against potential short circuits, e.g. by covering the poles with adhesive tape.
• Only use powder extinguishers or other suitable extinguishing agents to extinguish a
burning lithium battery.
Possible damage to lithium-ion batteries through incorrect storage
By deep discharge, lithium-ion batteries can be permanently damaged or lose some of their
capacity. Before long breaks, charge the batteries to around 50% of their capacity and then
switch o the device. Store the device at room temperature or cooler in an environment as
dry as possible. If the batteries are stored for a longer period, recharge them to 50% every
three months. Fully charge the batteries only shortly before use at room temperature.
Features
• professional digital 2.4 GHz wireless system with transmitter and receiver
• ideal for mobile applications as interviews, micro video recordings, vlogging
• transmitter with built-in microphone or external Lavalier microphone
• distorsion-free signal transmission
• switchable low-cut lter
• auto-pairing
• TRS headset output for real-time monitoring
• TRS recording output
• TRS microphone input
• Built-in lithium-ion battery
• Clip for installation on belt or clothes, also for installation on hot shoe
• Colour: black
EN
Sync 1 and 2
Scope of delivery
1×receiver 1×transmitter (item no. 516619)
2×transmitter (item no. 516620)
1×Tragetasche
1×fur-windscreen (item no. 516619)
2×fur-windscreen (item no. 516620)
1×3.5 mm TRS on TRS camera spiral cable
1×3.5 mm TRS on TRRS phone cable
1×external Lavalier microphone (item no. 516619)
2×external Lavalier microphone (item no. 516620)
1×charging cable 1×USB A to 2×USB C (item no. 516619)
1×charging cable 1×USB A to 3×USB C (item no. 516620)
Connections and operating elements Transmitter
#ö &' ()*% +$ öBack clip
#Connection for external microphone
$USB C charging port
%Main switch, keep pressed for 2 seconds for switching on/o
&Blue indicator LED for pairing
slow ashing: switching on
fast ashing: pairing
lighting up: successfully paired
2×fast flashing, then
turning off, in cycle: lowpass function enabled
'Green charge status indicator
slow ashing: battery charging status less than 10 %
lighting up: charging
turning o: battery fully charged
(Button for forced shut-o
)Lowpass button
*Pairing button
+Built-in microphone
left front right top

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 516619_516620_15.04.2021
Technical specications
Transmitter
Frequency of operation 2400 - 2483.5 MHz
Max. transmission power 10 mW
Max. input level 1 V (0 dBV)
Latency 12.5 ms
Range in free eld 50 m
not in free eld 30 m
Power supply USB port
Battery type built-in lithium-ion battery
capacity 400 mAh
operating time 5 h
charging time 1.5 h
Dimensions (W×H×D) 52 mm×42 mm×16mm
Weight (w/o external microphone) 35g
Ambient conditions
temperature range 0 °C…40 °C
relative humidity 20 %…80 % (non-condensing)
Microphones
Sound eld mono
Polar pattern omnidirectional
Frequency range 50 Hz - 20 kHz
Sensitivity –40 dB (±3 dB, re 1 V / Pa @ 1 kHz)
Max. sound pressure level (@ 1 kHz) 135 dB
EN
For the transport and protective packaging, environmentally friendly materials have
been chosen that can be supplied to normal recycling. Ensure that plastic bags,
packaging, etc. are properly disposed of. Do not just dispose of these materials with
your normal household waste, but make sure that they are collected for recycling.
Please follow the notes and markings on the packaging.
Dispose lithium batteries only in discharged condition. Remove replaceable lithium
batteries from the device before disposal. Protect used lithium batteries from short
circuits, for example by covering the poles with adhesive tape. Permanently installed
lithium batteries must be disposed of together with the device. Please inquire about
a suitable acceptance point.
This product is subject to the European Waste Electrical and Electronic Equipment
Directive (WEEE) in its currently valid version. Do not dispose of your old device with
your normal household waste. Dispose of this product through an approved waste
disposal rm or through your local waste facility. Comply with the rules and regula-
tions that apply in your country. If in doubt, consult your local waste disposal facility.
Sync 1 and 2
Receiver
Frequency of operation 2400 - 2483.5 MHz
Sensitivity –81 dBm
Output level Line Out 1 V
Monitoring 25 - 30 mW
Audio channels item no. 516619 1×mono
item no. 516620 2×mono or 1×stereo
Latency 12.5 ms
Range in free eld 50 m
not in free eld 30 m
Power supply USB port
Gain steps 0 - 4 switchable (0 - 8 dB)
Battery type built-in lithium-ion battery
capacity 400 mAh
operating time 5 h
charging time 1.5 h
Dimensions (W×H×D) 52 mm×42 mm×16mm
Weight (w/o external microphone) 35g
Ambient conditions
temperature range 0 °C…40 °C
relative humidity 20 %…80 % (non-condensing)
Operating
Connections and operating elements Receiver
#ö %& '() * +$
öBack clip
#USB C charging port
$Main switch, keep pressed for 2 seconds for switching on/o
additional for item no. 516620: Switching mono/stereo
%Blue indicator LED for pairing
slow ashing: switching on
fast ashing: pairing
lighting up: successfully paired
2×fast flashing, then
turning off, in cycle: lowpass function enabled
&Green charge status indicator
slow ashing: battery charging status less than 10 %
lighting up: charging
turning o: battery fully charged
'Button for forced shut-o
(Gain setting (item no. 516619)
Gain setting channel A (item no. 516620)
)Pairing button (item no. 516619)
Gain setting channel B (item no. 516620)
*3.5 mm connection for monitoring (headset output)
+3.5 mm connection for audio output (line out)
Pairing
The pairing automatically starts after switching on. If you like to pair the devices manually,
keep pressed the pairing button (8) (item no. 516619) or the buttons (7) and (8) (item no.
516620) on the receiver and the pairing button (9) on the transmitter for 3 seconds. The
pairing starts automatically.
Connection
The receiver outputs the audio signal via the 3 5 mm TRRS phone cable or the 3.5 mm
TRS camera spiral cable to the recording device. Please use the cable which is suitable for
your device.
Installation
Install the transmitter or the external microphone on the clothes of the speaker. Install the
receiver with the back clip on the hot shoe of the camera.
Gain setting
The initial gain value is the original volume of the microphone. Press the gain button
once to increase the gain by one step. There are 4 steps in total switchable. When the gain
reaches the highest step, press the button again to return to the initial value.
M/S
#ö %& '() * +$
Item no. 516619
Item no. 516620
left front right top
left front right top
