T-Mobile MDA Touch Plus Operating instructions

Please Read Before Proceeding
1
Please Read Before Proceeding
The battery is not charged when you take it out of the box.
Do not remove the battery pack when the device is charging.
Your warranty is invalidated if you open or tamper with the device’s outer
casing.
Privacy Restrictions
Some countries require full disclosure of recorded telephone conversations,
and stipulate that you must inform the person with whom you are speaking
that the conversation is being recorded. Always obey the relevant laws and
regulations of your country when using the recording feature of your device.
Intellectual Property Right Information
Copyright © 2007 High Tech Computer Corp. All Rights Reserved.
, , , ExtUSB and TouchFLO are trademarks and/or
service marks of High Tech Computer Corp.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows
Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device
Center, Internet Explorer, Windows Live, MSN, Hotmail, Outlook, Excel,
PowerPoint, Word, and Windows Media are either registered trademarks
or trademarks of Microsoft Corporation in the United States and/or other
countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG,
Inc.
microSD is a trademark of SD Card Association.
Java, J2ME and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other
countries.

Please Read Before Proceeding
2
Copyright © 2007, Adobe Systems Incorporated.
Copyright © 2007, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader
are trademarks and/or registered trademarks of Macromedia Netherlands,
B.V. or Adobe Systems Incorporated.
Copyright © 2007, JATAAYU SOFTWARE (P) LTD. All Rights Reserved.
Copyright © 2007, Dilithium Networks, Inc. All Rights Reserved.
Copyright © 2007, Aplix Corporation. All Rights Reserved.
ArcSoft MMS Composer™ Copyright © 2003-2007, ArcSoft, Inc. and its
licensors. All Rights Reserved. ArcSoft and the ArcSoft logo are registered
trademarks of ArcSoft, Inc. in the United States and/or other countries.
Sprite Backup is a trademark or service mark of Sprite Software.
Licensed by QUALCOMM Incorporated under one or more of the following
patents:
4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,778,338
5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,710,784
5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,659,569
5,600,754 5,414,796 5,657,420 5,416,797
All other company, product and service names mentioned herein are
trademarks, registered trademarks or service marks of their respective
owners.
HTC shall not be liable for technical or editorial errors or omissions
contained herein, nor for incidental or consequential damages resulting
from furnishing this material. The information is provided “as is” without
warranty of any kind and is subject to change without notice. HTC also
reserves the right to revise the content of this document at any time without
prior notice.
No part of this document may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photocopying, recording

Please Read Before Proceeding
3
or storing in a retrieval system, or translated into any language in any form
without prior written permission of HTC.
Disclaimers
The weather information, data and documentation are provided “as
is” and without warranty or technical support of any kind from HTC. To
the maximum extent permitted by applicable law, HTC and its affiliates
expressly disclaim any and all representations and warranties, express or
implied, arising by law or otherwise, regarding the Weather Information,
Data, Documentation, or any other Products and services, including without
limitation any express or implied warranty of merchantability, express or
implied warranty of fitness for a particular purpose, non-infringement,
quality, accuracy, completeness, effectiveness, reliability, usefulness, that
the Weather Information, Data and/or Documentation will be error-free, or
implied warranties arising from course of dealing or course of performance.
Without limiting the foregoing, it is further understood that HTC and its
Providers are not responsible for Your use or misuse of the Weather
Information, Data and/or Documentation or the results from such use.
HTC and its Providers make no express or implied warranties, guarantees
or affirmations that weather information will occur or has occurred as the
reports, forecasts, data, or information state, represent or depict and it shall
have no responsibility or liability whatsoever to any person or entity, parties
and non-parties alike, for any inconsistency, inaccuracy, or omission for
weather or events predicted or depicted, reported, occurring or occurred.

Please Read Before Proceeding
4
Without limiting the generality of the foregoing, you acknoledge that
the weather information, data and/or documentation may include
inaccuracies and you will use common sense and follow standard safety
precautions in connection with the use of the weather information, data
or documentation.
Limitation of Damages
To the maximum extent permitted by applicable law, in no event shall
HTC or its providers be liable to user or any third party for any indirect,
special, consequential, incidental or punitive damags of any kind, in
contract or tort, including, but not limited to, injury, loss of revenue,
loss of goodwill, loss of business opportunity, loss of data, and/or loss
of profits arising out of, or related to, in any manner, or the delivery,
performance or nonperformance of obligations, or use of the weaher
information, data or documentation hereunder regardless of the
foreseeability thereof.
Important Health Information and Safety
Precautions
When using this product, the safety precautions below must be taken to
avoid possible legal liabilities and damages.
Retain and follow all product safety and operating instructions. Observe all
warnings in the operating instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage to the
equipment, observe the following precautions.
Electrical Safety
This product is intended for use when supplied with power from the
designated battery or power supply unit. Other usage may be dangerous
and will invalidate any approval given to this product.

Please Read Before Proceeding
5
Safety Precautions for Proper Grounding Installation
Caution: Connecting to an improperly grounded equipment can result in an
electric shock to your device.
This product is equipped with a USB cable for connecting the product to a
desktop or notebook computer. Be sure your computer is properly grounded
(earthed) before connecting the product to the computer. The power supply
cord of a desktop or notebook computer has an equipment-grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet which is properly installed and grounded in accordance
with all local codes and ordinances.
Safety Precautions for Power Supply Unit
Use the correct external power source
A product should be operated only from the type of power source
indicated on the electrical ratings label. If you are not sure of the type of
power source required, consult your authorised service provider or local
power company. For a product that operates from battery power or other
sources, refer to the operating instructions that are included with the
product.
Handle battery packs carefully
This product contains a Li-ion battery. There is a risk of fire and burns if
the battery pack is handled improperly. Do not attempt to open or service
the battery pack. Do not disassemble, crush, puncture, short external
contacts or circuits, dispose of in fire or water, or expose a battery pack to
temperatures higher than 60˚C (140˚F).

Please Read Before Proceeding
6
!
Warning: Danger of explosion if battery is incorrectly
replaced. To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external
contacts, expose to temperature above 60°C
(140°F), or dispose of in fire or water. Replace
only with specified batteries. Recycle or dispose of
used batteries according to the local regulations or
reference guide supplied with your product.
Take extra precautions
Keep the battery or device dry and away from water or any liquid as it
may cause a short circuit.
Keep metal objects away so they don’t come in contact with the battery
or its connectors as it may lead to short circuit during operation.
Do not use a battery that appears damaged, deformed, or discoloured, or
the one that has any rust on its casing, overheats, or emits a foul odor.
Always keep the battery out of the reach of babies and small children,
to avoid swallowing of the battery. Consult the doctor immediately if the
battery is swallowed.
If the battery leaks:
Do not allow the leaking fluid to come in contact with skin or clothing.
If already in contact, flush the affected area immediately with clean
water and seek medical advice.
Do not allow the leaking fluid to come in contact with eyes. If already
in contact, do not rub; rinse with clean water immediately and seek
medical advice.
Take extra precautions to keep a leaking battery away from fire as
there is a danger of ignition or explosion.
Communicate the appropriate steps immediately in case a hazard
occurs.

Please Read Before Proceeding
7
Safety Precautions for Direct Sunlight
Keep this product away from excessive moisture and extreme temperatures.
Do not leave the product or its battery inside a vehicle or in places where
the temperature may exceed 60°C (140°F), such as on a car dashboard,
window sill, or behind a glass that is exposed to direct sunlight or strong
ultraviolet light for extended periods of time. This may damage the product,
overheat the battery, or pose a risk to the vehicle.
Prevention of Hearing Loss
Caution: Permanent hearing loss may occur if
earphones or headphones are used at high volume
for prolonged periods of time.
Note: For France, mobile headphones or earphones (listed below) for
this device have been tested to comply with the Sound Pressure Level
requirement laid down in the applicable NF EN 50332-1:2000 and/or NF EN
50332-2:2003 standards as required by French Article L. 5232-1
Earphone, manufactured by HTC, Model HS S200
Safety in Aircraft
Due to the possible interference caused by this product to an aircraft’s
navigation system and its communications network, using this device’s
phone function on board an aeroplane is against the law in most countries. If
you want to use this device when on board an aircraft, remember to turn off
the phone by switching to Airplane Mode.

Please Read Before Proceeding
8
Environment Restrictions
Do not use this product in gas stations, fuel depots, chemical plants or
where blasting operations are in progress, or in potentially explosive
atmospheres such as fuelling areas, fuel storehouses, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the
air contains chemicals or particles, such as grain, dust, or metal powders.
Please be aware that sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Explosive Atmospheres
When in any area with a potentially explosive atmosphere or where
flammable materials exist, the product should be turned off and the user
should obey all signs and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death. Users are advised
not to use the equipment at refueling points such as service or gas stations,
and are reminded of the need to observe restrictions on the use of radio
equipment in fuel depots, chemical plants, or where blasting operations
are in progress. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. These include fueling areas, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or metal powders.
Road Safety
Vehicle drivers in motion are not permitted to use telephony services with
handheld devices, except in the case of emergency. In some countries,
using hands-free devices as an alternative is allowed.
Safety Precautions for RF Exposure
Avoid using your device near metal structures (for example, the steel
frame of a building).
Avoid using your device near strong electromagnetic sources, such as
microwave ovens, sound speakers, TV and radio.

Please Read Before Proceeding
9
Use only original manufacturer-approved accessories, or accessories
that do not contain any metal.
Use of non-original manufacturer-approved accessories may violate your
local RF exposure guidelines and should be avoided.
Interference with Medical Equipment Functions
This product may cause medical equipment to malfunction. The use of this
device is forbidden in most hospitals and medical clinics.
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining this information.
Turn the phone off in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to external RF energy.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your service provider, or
call the customer service line to discuss alternatives.
Nonionising Radiation
Your device has an internal antenna. This product should be operated in its
normal-use position to ensure the radiative performance and safety of the
interference. As with other mobile radio transmitting equipment, users are
advised that for satisfactory operation of the equipment and for the safety of
personnel, it is recommended that no part of the human body be allowed to
come too close to the antenna during operation of the equipment.
Use only the supplied integral antenna. Use of unauthorised or modified
antennas may impair call quality and damage the phone, causing loss of
performance and SAR levels exceeding the recommended limits as well as
result in non-compliance with local regulatory requirements in your country.

Please Read Before Proceeding
10
Internal antenna
location
To assure optimal phone performance and
ensure human exposure to RF energy is
within the guidelines set forth in the relevant
standards, always use your device only in
its normal-use position. Do not touch or
hold the antenna area unnecessarily when
placing or receiving a phone call. Contact
with the antenna area may impair call quality
and cause your device to operate at a higher
power level than needed. Avoiding contact
with the antenna area when the phone is in
use optimises the antenna performance and
the battery life.
General Precautions
Heed service markings
Except as explained elsewhere in the Operating or Service documentation,
do not service any product yourself. Service needed on components
inside the device should be done by an authorised service technician or
provider.
Damage requiring service
Unplug the product from the electrical outlet and refer servicing to an
authorised service technician or provider under the following conditions:
Liquid has been spilled or an object has fallen into the product.
The product has been exposed to rain or water.
The product has been dropped or damaged.
There are noticeable signs of overheating.
The product does not operate normally when you follow the operating
instructions.

Please Read Before Proceeding
11
Avoid hot areas
The product should be placed away from heat sources such as radiators,
heat registers, stoves, or other products (including amplifiers) that produce
heat.
Avoid wet areas
Never use the product in a wet location.
Avoid using your phone after a dramatic change in temperature
When you move your device between environments with very different
temperature and/or humidity ranges, condensation may form on or within
the device. To avoid damaging the device, allow sufficient time for the
moisture to evaporate before using the device.
Notice: When taking the device from low-temperature conditions into a
warmer environment or from high-temperature conditions into a cooler
environment, allow the device to acclimate to room temperature before
turning on power.
Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other openings in the
product. Slots and openings are provided for ventilation. These openings
must not be blocked or covered.
Mounting Accessories
Do not use the product on an unstable table, cart, stand, tripod, or
bracket. Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recommended by the
manufacturer.
Avoid unstable mountin
Do not place the product with an unstable base.
Use product with approved equipment
This product should be used only with personal computers and
options identified as suitable for use with your equipment.

Adjust the volume
Turn down the volume before using headphones or other audio
devices.
Cleaning
Unplug the product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but
never use water to clean the LCD screen.
Please Read Before Proceeding
12

1313
Contents
Chapter 1 Getting Started ................................................................ 19
1.1 Getting to Know Your MDA Touch Plusand Accessories........................19
1.2 Installing the SIM Card, Battery, and Storage Card..................................25
1.3 Starting Up......................................................................................................29
1.4 The Today Screen .........................................................................................32
1.5 The Start Menu...............................................................................................33
1.6 X-Button Quick Menu....................................................................................34
1.7 QuickTasks.....................................................................................................35
1.8 HTC Home™...................................................................................................36
1.9 TouchFLO™....................................................................................................41
1.10 Status Icons..................................................................................................49
1.11 Programs ......................................................................................................51
1.12 Settings .........................................................................................................54
Chapter 2 Entering and Searching Information................................. 59
2.1 Entering Information......................................................................................59
2.2 Using the Hardware Keypad ........................................................................61
2.3 Using the Onscreen Keyboard.....................................................................63
2.4 Using Touch Keyboard .................................................................................63
2.5 Using Touch Keypad.....................................................................................64
2.6 Using Symbol Pad .........................................................................................65
2.7 Using Letter Recognizer...............................................................................66
2.8 Using Block Recognizer ...............................................................................67
2.9 Using Transcriber ..........................................................................................67
2.10 Searching Information ................................................................................69

14
Chapter 3 Using Phone Features...................................................... 71
3.1 Using the Phone.............................................................................................71
3.2 Making a Call..................................................................................................74
3.3 Receiving a Call .............................................................................................77
3.5 Receiving a Video Call..................................................................................84
3.6 Smart Dial........................................................................................................85
3.7 Additional Dialing Information.....................................................................87
3.8 Setting Up Bluetooth SIM Access for Car Kit Phones..............................87
Chapter 4 Setting Up Your MDA Touch Plus ..................................... 89
4.1 Basic Settings.................................................................................................89
4.2 Personalising the Today Screen..................................................................93
4.3 Protecting Your MDA Touch Plus ...............................................................96
Chapter 5 Synchronising Information With Your Computer ............... 99
5.1 About Synchronisation..................................................................................99
5.2 Setting Up Windows Mobile® Device Center on Windows Vista® .... 100
5.3 Setting Up ActiveSync® on Windows XP ............................................... 103
5.4 Synchronising With Your Computer ........................................................ 104
5.5 Synchronising via Bluetooth ..................................................................... 106
5.6 Synchronising Music and Video............................................................... 107
Chapter 6 Organising Contacts, Appointments, Tasks,
and Other Information.................................................... 109
6.1 Contacts....................................................................................................... 109
6.2 SIM Manager ............................................................................................... 114
6.3 Calendar....................................................................................................... 117
6.4 Tasks ............................................................................................................ 120
6.5 Notes............................................................................................................. 122
6.6 Voice Recorder ........................................................................................... 125

15
Chapter 7 Exchanging Messages................................................... 127
7.1 Messaging ................................................................................................... 127
7.2 Text Messages ............................................................................................ 129
7.3 Picture Message ......................................................................................... 131
7.4 Types of E-mail Accounts .......................................................................... 136
7.5 E-mail Setup Wizard ................................................................................... 137
7.6 Using E-mail................................................................................................. 142
Chapter 8 Working With Company E-mails and Meeting
Appointments................................................................ 149
8.1 Synchronising Your MDA Touch Plus with the Exchange Server ....... 149
8.2 Working With Company E-mails............................................................... 151
8.3 Managing Meeting Requests.................................................................... 156
8.4 Finding Contacts in the Company Directory........................................... 158
Chapter 9 Working With Documents and Files................................ 161
9.1 Microsoft® Office Word Mobile................................................................ 161
9.2 Microsoft® Office Excel® Mobile ............................................................ 162
9.3 Microsoft® Office PowerPoint Mobile..................................................... 164
9.4 Adobe® Reader® LE................................................................................. 165
9.5 Copying and Managing Files.................................................................... 166
9.6 ZIP................................................................................................................. 168
9.7 Backing Up Data......................................................................................... 169
9.8 Using Anti-Virus to Scan Viruses .............................................................. 172

16
Chapter 10 Getting Connected ........................................................ 175
10.1 Comm Manager........................................................................................ 175
10.2 Ways of Connecting to the Internet ....................................................... 176
10.3 GPRS/3G................................................................................................... 176
10.4 Dial-up........................................................................................................ 178
10.5 Starting a Data Connection..................................................................... 178
10.6 web’n’walk................................................................................................. 179
10.7 Using Your MDA Touch Plus as a Modem (Internet Sharing)............ 181
10.8 Bluetooth ................................................................................................... 184
10.9 Using Spb GPRS Monitor........................................................................ 191
Chapter 11 Experiencing Multimedia ............................................... 195
11.1 Camera....................................................................................................... 195
11.2 Camera Album.......................................................................................... 208
11.3 Pictures & Videos...................................................................................... 213
11.4 Windows Media® Player Mobile............................................................ 215
11.5 Streaming Media ...................................................................................... 220
11.6 Audio Manager ......................................................................................... 222
11.7 Audio Booster ........................................................................................... 228
Chapter 12 Managing Your MDA Touch Plus.................................... 231
12.1 Adding and Removing Programs........................................................... 231
12.2 Using X-Button .......................................................................................... 231
12.3 Resetting Your MDA Touch Plus............................................................ 234
12.4 Managing Memory ................................................................................... 236
12.5 Windows Update ...................................................................................... 237
12.6 Battery Saving Tips .................................................................................. 239

17
Chapter 13 Using Other Applications ............................................... 241
13.1 Voice Speed Dial ...................................................................................... 241
13.2 JBlend......................................................................................................... 243
13.3 Spb GPRS Monitor................................................................................... 245
Appendix ..................................................................................... 249
A.1 Specifications.............................................................................................. 249
A.2 Regulatory Notices..................................................................................... 253
Index ..................................................................................... 261

18

Getting Started
19
1.1 Getting to Know Your MDA Touch Plus
and Accessories
Top panel
POWER
Press to turn off the display temporarily. To turn off the power, press and hold
for about 5 seconds. For more information, see “Starting Up” in this
chapter.
Lanyard/Strap holder
Bottom panel
Microphone
Chapter 1
Getting Started

Getting Sarted
20
Volume Buttons
Press the top or bottom
to adjust the speaker
volume.
During a call, press the
top or bottom to adjust
the earpiece volume.
RESET
Remove the back cover to
see the Reset button. With
the stylus, press the RESET
button to soft-reset your
device.
Sync Connector/Earphone
Jack/AC adapter connector
Connect the supplied
USB cable to synchronise
information or plug in the
AC adapter to recharge
the battery. You can also
connect the supplied USB
stereo headset for hands-free
conversation or for listening
to audio media.
microSD Slot
See "Installing a
Storage Card" for
details.
Left panel
