Samsung B2100V User manual

Samsung B2100
user manual

ii
using this
manual
This user manual has been specially designed to
guide you through the functions and features of your
mobile phone. To get started quickly,
refer to “introducing your mobile phone,”
“assembling and preparing your mobile phone,”
and “using basic functions.”
Instructional icons
Before you start, familiarise yourself with the icons
you will see in this manual:
Warning —situations that could cause
injury to yourself or others
Caution —situations that could cause
damage to your phone or other equipment
Note —notes, usage tips, or additional
information
 Refer to —pages with related information;
for example:  p. 12 (represents “see
page 12”)

using this manual
iii
Copyright information
Rights to all technologies and products that
comprise this device are the property of their
respective owners:
• Bluetooth®is a registered trademark of the
Bluetooth SIG, Inc. worldwide—Bluetooth QD
ID: B014857.
• Java™ is a trademark of Sun Microsystems, Inc.
• Windows Media Player® is registered trademark
of Microsoft Corporation.
→
Followed by —the order of options or
menus you must select to perform a step;
for example: In Menu mode, select
Messages → Create new message
(represents Messages, followed by
Create new message)
[ ] Square brackets —phone keys; for
example: [ ] (represents the Power/
Menu exit key)
< > Angled brackets —softkeys that control
different functions at each screen; for
example: <OK> (represents the OK
softkey)

iv
contents safety and usage information .................. 2
Safety warnings ..........................................2
Safety precautions ......................................4
Important usage information ....................... 7
introducing your mobile phone ............. 10
Unpack .....................................................10
Phone layout .............................................11
Keys .........................................................12
Display ......................................................14
Icons .........................................................14
assembling and preparing your mobile
phone ...................................................... 16
Install the SIM card and battery .................16
Charge the battery .................................... 18
Insert a memory card (optional) .................19
using basic functions ............................. 21
Turn your phone on and off ....................... 21

contents
v
Access menus .......................................... 22
Customise your phone .............................. 22
Use basic call functions ............................ 24
Send and view messages ......................... 25
Add and find contacts ............................... 27
Use basic camera functions ...................... 28
Listen to music ......................................... 29
Browse the web ........................................ 30
using advanced functions ..................... 32
Use advanced call functions ..................... 32
Use advanced Phonebook functions ......... 34
Use advanced messaging functions .......... 36
Use advanced music functions ................. 37
using tools and applications ................. 40
Use the Bluetooth wireless feature ............ 40
Activate and send an SOS message .........42
Activate the mobile tracker ........................ 43
Record and play voice memos .................. 43
Edit images ............................................... 44
Use Java-powered games and
applications .............................................. 47
View world clocks ..................................... 48
Set and use alarms ................................... 49
Use the calculator ..................................... 50
Convert currencies or measurements ....... 50
Set a countdown timer ............................. 50
Use the stopwatch .................................... 50
Create a new task ..................................... 51
Create a text memo .................................. 51
Manage your calendar .............................. 51
troubleshooting ........................................ a
index ......................................................... d

2
safety and
usage
information
Comply with the following precautions to avoid
dangerous or illegal situations and ensure peak
performance of your mobile phone.
Keep your phone away from small
children and pets
Keep your phone and all accessories out of the
reach of small children or animals. Small parts may
cause choking or serious injury if swallowed.
Protect your hearing
Safety warnings
Listening to a headset at high volumes
can damage your hearing. Use only the
minimum volume setting necessary to
hear your conversation or music.

safety and usage information
3
Install mobile phones and equipment
with caution
Ensure that any mobile phones or related equipment
installed in your vehicle are securely mounted. Avoid
placing your phone and accessories near or in an air
bag deployment area. Improperly installed wireless
equipment can cause serious injury when air bags
inflate rapidly.
Handle and dispose of batteries and
chargers with care
• Use only Samsung-approved batteries and
chargers specifically designed for your phone.
Incompatible batteries and chargers can cause
serious injuries or damage to your phone.
• Never dispose of batteries or phones in a fire.
Follow all local regulations when disposing used
batteries or phones.
• Never place batteries or phones on or in heating
devices, such as microwave ovens, stoves, or
radiators. Batteries may explode when
overheated.
• Never crush or puncture the battery. Avoid
exposing the battery to high external pressure,
which can lead to an internal short circuit and
overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between
mobile phones and pacemakers to avoid potential
interference, as recommended by manufacturers
and the independent research group, Wireless
Technology Research. If you have any reason to
suspect that your phone is interfering with a
pacemaker or other medical device, turn off the
phone immediately and contact the manufacturer of
the pacemaker or medical device for guidance.

4
safety and usage information
Turn off the phone in potentially
explosive environments
Do not use your phone at refuelling points (service
stations) or near fuels or chemicals. Turn off your
phone whenever directed by warning signs or
instructions. Your phone could cause explosions or
fire in and around fuel or chemical storage and
transfer areas or blasting areas. Do not store or carry
flammable liquids, gases, or explosive materials in
the same compartment as the phone, its parts, or
accessories.
Reduce the risk of repetitive motion
injuries
When sending text messages or playing games on
your phone, hold the phone with a relaxed grip,
press the keys lightly, use special features that
reduce the number of keys you have to press (such
as templates and predictive text), and take frequent
breaks.
Drive safely at all times
Avoid using your phone while driving and obey all
regulations that restrict the use of mobile phones
while driving. Use hands-free accessories to
increase your safety when possible.
Follow all safety warnings and
regulations
Comply with any regulations that restrict the use of a
mobile phone in a certain area.
Use only Samsung-approved
accessories
Using incompatible accessories may damage your
phone or cause injury.
Safety precautions

safety and usage information
5
Turn off the phone near medical
equipment
Your phone can interfere with medical equipment in
hospitals or health care facilities. Follow all
regulations, posted warnings, and directions from
medical personnel.
Turn off the phone or disable the
wireless functions when in an aircraft
Your phone can cause interference with aircraft
equipment. Follow all airline regulations and turn off
your phone or switch to a mode that disables the
wireless functions when directed by airline
personnel.
Protect batteries and chargers from
damage
• Avoid exposing batteries to very cold or very hot
temperatures (below 0° C/32° F or above 45° C/
113° F). Extreme temperatures can reduce the
charging capacity and life of your batteries.
• Prevent batteries from contacting metal objects,
as this can create a connection between the +
and - terminals of your batteries and lead to
temporary or permanent battery damage.
• Never use a damaged charger or battery.
Handle your phone carefully and
sensibly
• Your phone has been tested in a controlled
environment and shown to be dust and
water resistant in certain circumstances
(meets requirements of classification IP57 as
described by the international standard IEC
60529 - Degrees of Protection provided by
Enclosures [IP Code]; test conditions:
15~35° C, 86~106kPa, 1meter, for
30minutes). Despite this classification, your
phone is not impervious to water damage in
any situation.

6
safety and usage information
• Improperly sealed covers, extended immersion in
water, and/or excessive pressure may cause
leaks and allow water to enter the phone. Do not
intensionally immerse the phone in water, allow
the phone to come in contact with water, or
expose it to humidity.
• Improper sealing of covers, eccessive exposure
to dust and/or excessive pressure may cause
dust penetration. Do not expose to dust and/or
sand for extended periods of time.
• Your phone is a complex electronic device.
Protect it from impact and rough handling to avoid
serious damage. Damage to the phone’s exterior
may reduce its protection against water damage.
Do not insert sharp objects into the speaker
holes, microphone holes, or receiver holes, as
this may puncture the protective surface and
allow water and dust to enter.
• Do not paint your phone, as paint can clog
moving parts and prevent proper operation.
• Avoid using the phone’s camera flash or light
close to the eyes of children or animals.
• Your phone and memory cards may be damaged
by exposure to magnetic fields. Do not use
carrying cases or accessories with magnetic
closures or allow your phone to come in contact
with magnetic fields for extended periods of time.
Avoid interference with other electronic
devices
Your phone emits radio frequency (RF) signals that
may interfere with unshielded or improperly shielded
electronic equipment, such as pacemakers, hearing
aids, medical devices, and other electronic devices
in homes or vehicles. Consult the manufacturers of
your electronic devices to solve any interference
problems you experience.

safety and usage information
7
Use your phone in the normal position
Avoid contact with your phone’s internal antenna.
Allow only qualified personnel to service
your phone
Allowing unqualified personnel to service your phone
may result in damage to your phone and will void
your warranty.
Ensure maximum battery and charger
life
• Avoid charging batteries for more than a week, as
overcharging may shorten battery life.
• Over time, unused batteries will discharge and
must be recharged before use.
• Disconnect chargers from power sources when
not in use.
• Use batteries only for their intended purpose.
Handle SIM cards and memory cards
with care
• Do not remove a card while the phone is
transferring or accessing information, as this
could result in loss of data and/or damage to the
card or phone.
• Protect cards from strong shocks, static
electricity, and electrical noise from other devices.
• Frequent writing and erasing will shorten the life
span of memory cards.
• Do not touch gold-coloured contacts or terminals
with your fingers or metal objects. If dirty, wipe the
card with a soft cloth.
Important usage information

8
safety and usage information
Ensure access to emergency services
Emergency calls from your phone may not be
possible in some areas or circumstances. Before
travelling in remote or undeveloped areas, plan an
alternate method of contacting emergency services
personnel.
Specific Absorption Rate (SAR)
certification information
Your phone conforms to European Union (EU)
standards that limit human exposure to radio
frequency (RF) energy emitted by radio and
telecommunications equipment. These standards
prevent the sale of mobile phones that exceed a
maximum exposure level (known as the Specific
Absorption Rate, or SAR) of 2.0 watts per kilogram
of body tissue.
During testing, the maximum SAR recorded for this
model was 0.716 watts per kilogram. In normal use,
the actual SAR is likely to be much lower, as the
phone has been designed to emit only the RF
energy necessary to transmit a signal to the nearest
base station. By automatically emitting lower levels
when possible, your phone reduces your overall
exposure to RF energy.
The Declaration of Conformity at the back of this
manual demonstrates your phones compliance with
the European Radio & Terminal Telecommunications
Equipment (R&TTE) directive. For more information
about the SAR and related EU standards, visit the
Samsung mobile phone website.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and
other European countries with separate
collection systems)

safety and usage information
9
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle
it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government office, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and
check the terms and conditions of the purchase
contract. This product should not be mixed with
other commercial wastes for disposal.
Correct disposal of batteries in this
product
(Applicable in the European Union and other
European countries with separate battery
return systems)
This marking on the battery, manual or
packaging indicates that the batteries in this product
should not be disposed of with other household waste
at the end of their working life.
Where marked, the chemical symbols Hg, Cd or Pb
indicate that the battery contains mercury, cadmium or
lead above the reference levels in EC Directive 2006/66.
If batteries are not properly disposed of, these
substances can cause harm to human health or the
environment.
To protect natural resources and to promote material
reuse, please separate batteries from other types of
waste and recycle them through your local, free battery
return system.
This EEE is compliant with RoHS.

10
introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, display, and icons.
Unpack
Check your product box for the following items:
• Mobile phone
• Battery
• Travel adapter (charger)
•Usermanual
The items supplied with your phone may vary
depending on the software and accessories
available in your region or offered by your
service provider.
You can obtain additional accessories from
your local Samsung dealer.

introducing your mobile phone
11
Phone layout
The front of your phone includes the following keys
and features:
The rear of your phone includes the following keys
and features:
Power/Menu
exit key
Mouthpiece
Volume key
Dial key
Left softkey
Right softkey
Earpiece
Display
Alphanumeric keys
Confirm key
Special
function keys
4-way
navigation key
Flash key
Flashbulb
You can lock the keys to prevent any unwanted
phone operations. To lock the keys, press and
hold [ ]. To unlock these keys, press and hold
[].
When the auto keypad lock is on, the keys will be
locked automatically after the display turns off.
Camera lens
Battery cover
Internal antenna
Multifunction
jack
Speaker

12
introducing your mobile phone
Maintain your water and dust resistant
feature
Your phone offers limited protection against
accidental exposure to water in some conditions,
but you should never intensionally immerse the
phone in water.
Keys
• Do not expose your phone to high
water pressures or any other
liquids, such as salt water, ionized
water or dirty water.
• If the phone gets wet, dry it
thoroughly with a clean soft cloth.
• Ensure that all covers are properly
aligned and tightly closed.
• Always keep the multifunction jack
cover clean and be careful to
avoid damaging it.
• Any service performed on the phone may reduce
the water and dust protection. Avoid exposing the
phone to dust and water if any service has been
performed on it.
• Exposing the phone to extreme temperatures
may reduce the water and dust protection. Avoid
exposing the phone to temperatures below 0° C/
32° F or above 45° C/113° F.
Key Function
Softkeys Perform actions indicated at the
bottom of the display

introducing your mobile phone
13
4-way
navigation
In Idle mode, access user-defined
menus (depending on your service
provider, pre-defined menus may
differ); In Menu mode, scroll through
menu options
Confirm
In Idle mode, launch the web
browser or access Menu mode; In
Menu mode, select the highlighted
menu option or confirm an input
Dial
Make or answer a call; In Idle mode,
retrieve recently dialled, missed, or
received numbers
Power/
Menu exit
Turn the phone on and off (press
and hold); End a call; In Menu
mode, cancel input and return to
Idle mode
Key Function
Alpha-
numeric
Enter numbers, letters and special
characters; In Idle mode, press and
hold [1] to access voice mails and
[0] to enter an international call prefix
Special
function
Enter special characters or perform
special functions; In Idle mode,
press and hold [ ] for Silent profile;
In Idle mode, press and hold [ ] to
lock the keys; Press and hold [ ] to
enter a pause between numbers
Flash Turn the flash on or off (press and
hold)
Volume Adjust the phone’s volume
Key Function

14
introducing your mobile phone
Display
Your phone’s display consists of three areas:
Icons
Learn about the icons that appear on your display.
Icon line
Displays various icons
Text and graphic area
Displays messages,
instructions, and
information you enter
Softkey line
Displays the current actions
assigned to each softkey
Select Back
Icon Definition
Signal strength
GPRS network status
• Blue: GPRS network connected
• Red: Transferring data via GPRS network
EDGE network status
• Blue: EDGE network connected
• Red: Transferring data via EDGE network
Voice call in progress
Call diverting active
SOS message feature activated
Alarm activated
Connecting to secured web page

introducing your mobile phone
15
Roaming (outside of normal service area)
Bluetooth activated
Bluetooth hands-free car kit or headset
connected
Syncronised with PC
New text message (SMS)
New multimedia message (MMS)
New email message
New voice mail message
Music playback in progress
Music playback paused
FM radio on
Memory card inserted
Icon Definition
Normal profile activated
Silent profile activated
Battery power level
Current time
Icon Definition

16
assembling and
preparing your
mobile phone
Get started by assembling and setting up
your mobile phone for its first use.
Install the SIM card and battery
When you subscribe to a cellular service, you will
receive a Subscriber Identity Module, or SIM card,
with subscription details, such as your personal
identification number (PIN) and optional services.
To install the SIM card and battery,
1. Unscrew the lock and remove the battery cover.
Do not use your fingernails to unscrew. Use a
coin or screw driver, instead.
If the phone is on, press and hold [ ] to turn
it off.
