T2 MS-34 User manual

MULTISWITCH
OWNER’S MANUAL
MS-34
T0213-MS-34OM.qxp 9/16/03 09:59 AM Page 1

Features::
The MS-34 is a three input, four output mu tiswitch. It
is bui t to accept a signa from a dua LNB sate ite dish,
p us a signa from either an off-air antenna or cab e TV.
The MS-34 then routes their combined signa to four
independent receivers.
• Rugged, a -a uminum construction and sea ed case
means operabi ity in any insta ation environment.
• Structured enc osure modu arity ensures fast,
custom, professiona insta ations.
• F at, ow oss RF circuitry ensures c ean, crisp
pictures on a te evision sets.
• Ergonomica y positioned F-connectors ensure
the easiest possib e insta ation.
2
Introdu tion::
Thank you for purchasing this T2 mu tiswitch. T2 is the
brainchi d of some of the most experienced professiona s
in the custom insta ation and home entertainment indus-
tries. P ease read through this owner’s manua so that you
wi know how to operate your MS-34 proper y. A ways
keep this manua in a safe p ace for future reference.
1
T0213-MS-34OM.qxp 9/16/03 09:59 AM Page 2

Other Mounting Options::
To mount your mu tiswitch on a f at wa or surface, simp y
remove the hook and ock pieces by pu ing outward. Your
mu tiswitch can then be mounted using screws. See fig. 4.
4
Fig. 4
Lo king System::
3
Mounting & Using the T2 Lo king System::
Your mu tiswitch comes with the removab e proprietary T2
ocking system attached, and is designed to be mounted in
a structured cab e enc osure.
Locate the product in the
enc osure as shown in fig. 1.
Rotate the ock 180 degrees
to secure the unit as shown
in fig. 2 & fig. 3. (Use a
3/16" hex key or a f at head
screwdriver.)
Fig. 3Fig. 2
Fig. 1
open
lo ked
180˚
T0213-MS-34OM.qxp 9/16/03 09:59 AM Page 4

Installation Guidelines::
DC Blo k::
A DC b ock has been inc uded with your MS-34. The DC
b ock shou d be used when your system is uti izing a cab e
TV feed or non-powered antenna. It shou d be insta ed
between the antenna and the antenna/CATV port
on the MS-34. See fig. 5.
5
Conne ting and Using::
Hooking up your MS-34 is easy. There are two eve s of
F-connectors. The three connectors on the upper eve are
the inputs, and the four connectors on the ower eve are
the outputs. See fig. 6.
The inputs are c ear y abe ed on the top eve , and
indicate which connectors shou d be used for sate ite
feeds (13V and 18V) and which shou d be used for the
antenna/CATV feed. See fig. 6a.
The outputs are c ear y marked “receiver 1” through
“receiver 4,” with each output transmitting exact y the
same signa . See fig. 6b.
6
receiver 1 receiver 2
sat. 13V antenna/CATV sat. 18V
receiver 3 receiver 4
Fig. 6
a
b
MS-34
ANTENNA/
CATV SATELLITE
DC BLOCK
OUT TO RECEIVERS
Fig. 5
T0213-MS-34OM.qxp 9/16/03 09:59 AM Page 6

Warranty::
T2 Signa Management (T2) warrants this product to be free from defects in materia s and
workmanship for a period of three (3) years from the date of purchase or T2 wi repair, or at
its option, rep ace the defective product (with a new or factory reconditioned product, as T2
may determine). To obtain warranty service under this warranty, ca T2 for a return materia
authorization (RMA) number and return the defective product together with a copy of the
sa es receipt or other satisfactory proof of purchase to T2 Signa Management, 63 Ma Drive,
Commack, NY 11725, Attention: Customer Service. P ease put the RMA number on the
outside of the carton. Ship a cartons freight prepaid.
This warranty does not cover damage resu ting from (1) use or insta ation other than in strict
accordance with manufacturer’s written instructions, (2) disassemb y or repair by someone
other than the manufacturer, (3) misuse, misapp ication or abuse, (4) a teration,
(5) ack of reasonab e care, (6) wind, ice, snow, rain, ightning, or any other extreme weather
conditions, acts of nature, fire or any other cause not within the reasonab e contro of T2.
ANY IMPLIED WARRANTY ARISING FROM THE SALE OF THE PRODUCT, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS, FOR PURPOSE, ARE LIMITED TO THE
WARRANTY STATED ABOVE. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION OF WARRANTY SET FORTH ABOVE. THIS PRODUCT IS SOLD AS IS.
T2 sha in no event, and under no circumstances, be iab e or responsib e for any consequentia ,
indirect, incidenta , punitive, direct or specia damages based upon breach or warranty,
breach of contract, neg igence, strict tort iabi ity or otherwise or any other ega theory,
arising direct y or indirect y from the sa e, use, insta ation or fai ure of any product acquired
from T2. Buyer’s remedy is strict y imited to return of the goods and repayment of the price
or repair or rep acement of the non-conforming goods or parts, whichever T2 chooses.
F r m re inf rmati n, visit www.t2signal.c m.
F r technical supp rt, call 1.800.827.5540. 89P004A
TERK and T2 are registered trademarks. The T2 ogo is a trademark of TERK Techno ogies Corp.
