Tabs TBGW100-915 User manual

Reference Manual
Hub
TBGW100-915
TBGW100-868

1
© 2017 TrackNet Inc, USA and Trackio GmbH, Switzerland. All rights reserved.
Table of Contents
1. Description ................................................1
2. Technical Specifications.........................2
2.1 LoRaWAN ...........................................2
2.2 Wi-Fi...................................................2
2.3 Wired Network.................................2
2.4 Routing ..............................................2
2.5 User Interface...................................2
2.6 Power.................................................2
2.7 Mechanical........................................2
3. Setup and Usage.....................................3
3.1 Ports....................................................3
3.2 Icons...................................................3
3.3 Status Lights .....................................3
3.4 WPS Button.......................................3
1. Description
The Tabs Hub is a complete LoRaWAN
compliant gateway combined with a high
performance 802.11ac dual band Wi-Fi Router.
The combination of long range, low power
connectivity with LoRa and availability of Wi-Fi
infrastructure creates the most eective and
economical way to deploy LPWAN networks
and guarantee indoor coverage. The gateway
is designed for high volume indoor usage in
homes and buildings. The Wi-Fi router can be
configured as a standard Wi-Fi access point or
as a Wi-Fi extender to expand existing Wi-Fi
network coverage.
Due to the high level of integration, no
expensive external antennas, cables, or com-
ponents are required, simplifying end-cus-
tomer installation. The gateways can easily
be configured to connect to dierent network
server cores and are available in 915MHz
and 868MHz versions. The gateway is fully
certified for Wi-Fi and LoRaWAN usage in
North America and Europe.

2
© 2017 TrackNet Inc, USA and Trackio GmbH, Switzerland. All rights reserved.
2. Technical Specifications
2.1 LorRaWAN
Chipset SX1308
Channels 8 multi-data rate and 1 high
speed
Receive Sensitivity -140dBm (EU) and -135dBm (US)
Transmit Power Up to +27dBm
2.2 Wi-Fi
Modes IEEE 802.11 a, b, g, n, ac
Frequency Bands 2.4 GHz and 5 GHz concur-
rently
Antenna
Configuration 2x2
Receive Sensitivity -94dBm
Transmit Power Up to 19dBm
Max Data Rate 867 Mbps
Security WPA and WPA2 personal
2.4 Routing
Network Security Firewall and Content Filtering
Network Integration Wi-Fi extender
LoRaWAN Track Central Station Packet
Forwarder
Ancillary functions NTP Server, DHCP Server
2.5 User Interface
Activity Indicators Wi-Fi, Ethernet, and
LoRaWAN
Push Buttons WPS and Reset buttons
USB Ports USB 2.0 capable of 500mA
Configuration Web Interface, iOS, and
Android
2.6 Power
Voltage 12vdc +/- 10%
Power 6 Watts maximum
Power Supply External wall mount 100/240
Vac 50/60 Hz
2.3 Wired Network
WAN Port 100 baseT, 10 BaseT
LAN Port 2 x 100b aseT, 10 BaseT
Cabling MDI/MDIX
2.7 Mechanical
Dimensions 145mm x 56mm x 171mm
Weight 347g
Temperature 0°C to 40°C
Enclosure Type Ventilated Plastic

3
© 2017 TrackNet Inc, USA and Trackio GmbH, Switzerland. All rights reserved.
3.1 Ports
Wired Network
Indicates the state of the WAN and
LAN ports
Wi-Fi
Indicates the state of the Wi-Fi network
Tabs Network
Indicates the state of the Tabs network
Power
Indicates that the Hub is functioning
normally
Solid Green
Feature is operating correctly.
Solid Orange
Feature is not operating correctly.
The large, round button on top of your hub
enables Wi-Fi Protected Setup (WPS).
3.2 Icons
USB
The USB 2.1 Type A port can be used
for recharging Tabs devices.
WAN
This ethernet port is used to connect
your broadband Internet modem
provided by an ISP.
LAN
There are two ethernet ports for
adding other devices to your Local
Area Network.
Power
Connects to the supplied 12V power
supply
Reset Button
Pressing for six seconds resets the Hub.
3. Setup and Usage
The Hub may be installed into an existing WLAN network as a repeater or
create a new WLAN network while acting as a WiFi Access Point. In both
scenarios the Hub is configure via TrackNet’s Tab Application available for
both iOS and Android. As a WiFi Access Point an ethernet connection is
required to provide internet access. The two ethernet LAN ports provide
bridging into the network in Repeater or Access Point mode.
Once an internet connection is made available the Hub will establish con-
nections for both LoRaWAN trac and management via the internet to
TrackNet’s TrackCentral services.
The four LEDs on the top of the Hub provide a easy to read summary of the
status of the Hub.
3.3 Status Lights
3.4 WPS Button
