Taiden TMX Series User manual

TMX Series Professional Matrix Switchers
TMX-0804HTK 8×4 High Definition Video Tracking Matrix Switcher
Installation and Operation Manual
V 1.2
Professional Matrix Switchers

I
Remark:
All rights reserved for translation, reprint or reproduction.
Contents may change without prior announcement.
All technical specifications are guideline data and not guaranteed features.
Taiden Co., Ltd. is not responsible for any damage caused by improper use of this manual.
The equipment must be connected to earth!
This product conforms to the rules of the European directive 2004/108/EC.
If any detailed information needed, please contact your local agent or TAIDEN service center in your region.
Any feedback, advice and suggestion about the products is appreciated.
TAIDEN is the registered trademark of TAIDEN Co., Ltd.

II
Important Safety Instruction
1. Read and keep these instructions.
2. Heed all warnings and follow all instructions.
3. The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
4. The MAINS plug serving as a disconnection device,
should be easy to operate.
5. The apparatus should be connected to the MAINS
socket-outlet with protective earth.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade and the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Do not place the equipment on any uneven or
unstable stand; original product package or
appropriate package should be used to avoid damage
caused by strong impacts during transportation.
16. Power supply cords:
AC 100 V-120 V 60 Hz or AC 220 V-240 V 50 Hz
17. The quantity of connected units in one system should
not exceed prescribed quantity. For service, please
contact the nearest TAIDEN Service Center.
18. Use ONLY specified connection cable to connect the
system equipment.
19. All TAIDEN products are guaranteed for definite time
(see the WARRANTY CARD for details) excluding the
following cases:
A. All damage or malfunction caused by human
negligence;
B. Damage or malfunction caused by improper
operating by operator;
C. Parts damage or loss caused by disassembling
the product by non-authorized personnel.
20. Upon receipt of the product, please fill out the
Warranty Card enclosed and post it to TAIDEN
Service Center nearby in your region.
The lightning flash with an arrowhead symbol, with
an equilateral triangle, is intended to alert the user
to the presence of uninsulated ‘dangerous voltage’
within the products enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
CAUTION: To reduce the risk of electric shock,
DO NOT open covers, no user serviceable parts
inside. Refer servicing to qualified service
personnel only.
CAUTION: DO NOT use alcohol, ammonia or
petroleum solvents or abrasive cleaners to
clean the devices.

III
Important Safety Instruction
The exclamation mark within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Attention: Installation should be performed by
qualified service personnel only in accordance
with the National Electrical or applicable local
codes.
Power Disconnect: Units with or without ON – OFF
switch have power supplied to the unit whenever
the power cord is inserted into the power source;
however, the unit is operational only when the ON
– OFF switch is in the ON position. The power cord
is the main power disconnect for all units
WARNING: The apparatus should be
connected to a mains socket outlet with a
protective earthing connection.
WARNING: To reduce the risk of fire or
electric shock, DO NOT expose units to rain
or moisture.

IV
Contents
Installation & User Guide........................................................................................................... V
Chapter 1. High Definition Video Tracking Matrix Switcher ........................................................1
1.1 Functions and indications .................................................................................................................................1
1.1.1 Front panel .................................................................................................................................................1
1.1.2 Rear panel..................................................................................................................................................3
1.2 Installation and connection ...............................................................................................................................4
1.2.1 Installation ..................................................................................................................................................4
1.2.2 Connection between Matrix Switchers and PC..........................................................................................4
1.2.3 Connection with input, output devices .......................................................................................................4
1.3 Setup and Operation.........................................................................................................................................6
1.3.1 Menu setup ................................................................................................................................................6
1.3.2 Switch operation.........................................................................................................................................9
Chapter 2. IR Remote Control..................................................................................................13
Chapter 3. Software .................................................................................................................14
3.1 Installation and Running .................................................................................................................................14
3.1.1 Running Environment...............................................................................................................................14
3.1.2 Installation ................................................................................................................................................14
3.1.3 Software Running.....................................................................................................................................14
3.2 Connect Mode.................................................................................................................................................15
3.2.1 TCP/IP Connection ..................................................................................................................................15
3.2.2 COM Connection......................................................................................................................................15
3.3 Primary Window Operation.............................................................................................................................16
3.3.1 Channel Setup .........................................................................................................................................18
3.3.2 Scene Management .................................................................................................................................19
3.4 Timing Switch..................................................................................................................................................20
3.4.1 Custom switch..........................................................................................................................................20
3.4.2 Auto switch...............................................................................................................................................21
3.4.3 Input to all.................................................................................................................................................21
3.5 User Group .....................................................................................................................................................22
3.6 Signal status ...................................................................................................................................................23
3.7 Parameter .......................................................................................................................................................23
3.8 System Status.................................................................................................................................................23
Chapter 4. Communication protocol and control code..............................................................24
Chapter 5. Technical data.........................................................................................................26

V
Installation & User Guide
About this manual
This manual is a comprehensive guide to the
installation and operation of TAIDEN TMX-0804HTK
8×4 High Definition Video Tracking Matrix Switcher It
includes: operation and setup, installation and
connection, software and protocol, etc.
The manual is divided into the following chapters:
Chapter 1: High Definition Video Tracking Matrix
Switcher
Descriptions in detail of the functions and indications,
installation and connection, configuration and operation
of TMX-0804HTK 8×4 High Definition Video Tracking
Matrix Switcher
Chapter 2: IR Remote Control
Introduction into the operation of IR remote control.
Chapter 3: Software
Comprehensive and detailed user’s guide of the
application software for matrix switchers.
Chapter 4: Communication protocol and control
code
Detailed description of codes and their function.
Chapter 5: Technical data
Mechanical and electrical details of TMX-0804HTK 8×4
High Definition Video Tracking Matrix Switcher.
This manual is applicable to:
TMX-0804HTK 8×4 High Definition Video
Tracking Matrix Switcher

1
Chapter 1. High Definition Video Tracking Matrix Switcher
1.1 Functions and indications
1.1.1 Front panel
Figure 1.1 Front panel of TMX-0804HTK
Figure 1.1:
1. “POWER” indicator
2. “ACTIVE” indicator
Indicator will be turned on if Matrix Switcher
executes switch instructions.
3. “NETWORK” indicator
Indicator flashes if Matrix Switcher is
connected with PC software.
4. IR receiving window
Receives the IR signals from remote control;
make sure the remote control aims at the
window.
5. “RECALL” button
Recall the stored scene.
6. “SAVE” button
Save current channel status as appointed
scene.
7. “ALL” button
Switch one input channel to all output
channels.
8. “1, 2, 9…0” button
Number keys, used to select input or output
channel, save scene number, recall scene
number.
9. “AUDIO” button
Switch audio signal separately.
10. “VIDEO” button
Switch video signal separately.
11. “AV” button
Composite audio and video switch key.
12. “UNDO” button
Undo last switch operation.
13. “←” button
Backspace key, delete last input number or
command.
14. “CANCEL” button
Back to root directory, when in setup menu,
back to previous directory.
15. “/” button
Separator, displayed as “,” on LCD. Used to
space output channels if more than one
channel is operated.
16. “THROUGH” button
Audio or video switch through from input
channel to corresponding output channel.
17. “CLOSE” button
Close one or all output channels.

2
18. “STATUS” button
Query channel status.
19. “►” button
For right, forward and plus.
20. “◄” button
For left, backward and subtract.
21. “ENTER” button
Confirm or execute command.
22. “END” button
End for a switch command.
23. “DEMO” button
In DEMO status, channels are switched one
by one.
24. “GROUP” button
Maximum 5 groups and maximum 5 channels
per group can be configured.
25. “LOCK” button
Keyboard lock.

3
1.1.2 Rear panel
Figure 1.2 Rear panel of TMX-0804HTK
Figure 1.2:
1. Video inputs
2. Video outputs
3. Grounding point
6. RS-232 communication interface COM2
5. RJ45 interface
6. RS-232 communication interface COM1
7. Power cable interface

4
1.2 Installation and connection
1.2.1 Installation
TMX-0804HTK Matrix Switchers can be fixed in an
exactly fitting standard cabinet.
A couple of mounting brackets ①are attached to the
product package. First release the screws ②from the
lateral sides of the matrix. Bolt on the brackets to the
housing by using the screws previously released. Now
put the unit into the cabinet, and fix it by screws. As
figure 1.3.
Figure 1.3 Installation
1.2.2 Connection between Matrix Switchers and
PC
TMX-0804HTK Matrix Switchers can be controlled and
setup by computer via RS-232 interface COM2. And it
also can be controlled by Central Control System via
RS-232 interface COM1, this interface is also used for
software upgrade (Figure 1.4).
1.2.3 Connection with input, output devices
TMX-0804HTK Matrix Switchers support various AV and
VGA signal sources. AV signal source equipment should
have RGB or YC joints, VGA signal source equipment
should have RGB joints. If VGA equipment does not
have RGB joints, VGA-RGB converters or drivers
provided by TAIDEN can be used.
Please use good quality 3-core RGB cable to connect
input and output device.
Input connection example for PC, chosen INPUT =
No.1: connect RGB cores 1 to 3 from PC to the
corresponding RGB BNC INPUT joints 1 to 3, in each
case marked No. 1 on the RGB Matrix Switchers (Figure
1.4).
Output connection example to Projector, chosen
OUTPUT= No. 4: connect RGB cores 1 to 3 from
Projector, to the corresponding RGB BNC OUTPUT
joints 1 to 3, marked No. 4 on the TMX-0804HTK Matrix
Switchers (Figure 1.4).
Control Interface:
Control
Video Track Off
COM (RS-232) 9 pin female D connector
COM1 Baud rate: 9600, data: 8 bits,
stop: 1 bit, no parity check bit
COM2 Variable baud rate, data: 8 bits,
stop: 1 bit, no parity check bit
Video Track On
COM (RS-232) 9 pin female D connector
COM1
Baud rate: 19200, To
conference main unit TO VIDEO
SWITCHER, 1=A(RX+),
4=B(RX-), 5=GND
COM2 -
RJ45
Baud rate: 9600, 1=TX+, 2=TX-,
3=RX+, 6=RX-, RS422/RS485
To doom camera
Note:
)Take care that both ends of a cable are
correctly connected on both sides to the
ports bearing the same name e.g. R to R, G
to G etc. Otherwise there will be
pseudocolors even if there is no signal
output.
)If connected with camera by RS232 protocol,
the matrix switcher and the camera must be
common ground.

5
Figure 1.4 Connection example for input and output devices to TMX-0804HTK Matrix Switchers

6
1.3 Setup and Operation
1.3.1 Menu setup
TMX-0804HTK main interface:
Press “0” for 5 seconds to enter setup menu, including:
1. Ring
2. COM2 Baud rate
3. Demo Switch Delay
4. COM1 protocol
5. Sync Switch Delay
6. Test button
* Tested button is working if character changes when
button is pressed.
7. Input password
8. Video Track
9. Video Track Type
10. Video Track Delay
Menu 1 to menu 10 are explained explicitly:
1. Ring
Buzzer ring on-off of this unit. If buzzer ring is setup
“on”, the buzzer will ring when front panel operation,
PC software executing switch and receiving command
from central control system. The buzzer ring can be
setup “off”.
ON: open;
OFF: close.
2. COM2 Baud rate
When Video Tracking Off, if PC connect mode RS-232
is selected, available COM2 baud rates are: 9600,
14400, 19200, 28800, 38400 and 57600.
COM1 is invariable and fixed to 9600 bit/s.
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►” until ”Ring”
prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/►” to select parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Ring
OFF
Ring
▋
OFF
Ring
ON
Ring
▋
ON
TMX-0804HTK
Version: 2.00
Note:
)RJ45 is just working as RS422/RS485 port
to control doom camera and have no
TCP/IP function.
)When Video Tracking Off, COM1 port can
be connected to central control system and
COM2 port can be connected to PC
software; Video Track Type menu is not
accessible.
)When Video Tracking On, COM1 port can
only be connected to TO VIDEO
SWITCHER interface of congress main unit
and COM2 port is not accessible; Camera
protocol can be selected from Video Track
Type menu.
)The connection type between main unit and
PC software is fixed as RS232 and have no
other choice.

7
3. Demo Switch Delay
The interval between two switching operations can
range from 2 seconds to 60 seconds by step of 2 s.
4. COM1 protocol
Central control system can be selected from Taiden/
Extron or Other, Please add correct protocol according
to user request.
5. Sync Switch Delay
When switching from one video input source to another,
a brief time delay is required to adjust to sync data of
the new source before a new undisturbed RGB signal
is sent. Range: 0 to 5000 ms with pace of 50 ms.
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►” until
“DemoSwitchDelay” prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/ ►” to select parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
DemoSwitchDelay:
4 S
DemoSwitchDelay:
▋
4 *S
DemoSwitchDelay:
6 S
DemoSwitchDelay:
▋
6 *S
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►” until
“SyncSwitchDelay” prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/►” to adjust parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
SyncSwitchDelay:
50 *ms
SyncSwitchDelay:
▋
0550 *ms
SyncSwitchDelay:
100 *ms
SyncSwitchDelay:
▋
100 *ms
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►”until”COM1
protocol” prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/►” to select parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►” until ”COM2
Baudrate” prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/►” to select parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
COM2 Baudrate:
38400
COM2 Baudrate:
▋
9600
COM2 Baudrate:
14400
COM2 Baudrate:
▋
14400
COM1 protocol:
Tai d en
COM1 protocol:
▋
Taiden
COM1 protocol：
▋
Extron
COM1 protocol:
Extron

8
6. Test button
Tested button is working if character changes when
button is pressed.
7. Input password
Set unlock password, password must be 5 bits. Original
password is 11111.
8. Video Track
Select the function of video track on or off.
9. Vidoe Track Type
When Video Track On, camera protocol can be
selected from HCS-3316RS-232/ HCS-3316RS-485/
HCS-3313C/ Sony D70/ Sony D100/ Sony BRC-Z300/
Sony BRC300/ Sony BRC700/ Sony HD1/ Pelco D/
Pelco DC/ Pelco P1/ Pelco P2/ Panasonic CS950/
SAMSUNG C6407P. Please select correct protocol
according to actual device type.
10. Video Track Delay
The interval ranges from 0 second to 8000 seconds by
steps of 500 seconds.
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►” until
“VideoTrackDelay” prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/ ►” to select parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
VidoTrackDelay:
4000 ms
VidoTrackDelay:
▋
4000 *ms
VidoTrackDelay:
6000 ms
VidoTrackDelay:
▋
6000 *ms
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►”until “Video Track
Type” prompts;
；
2. Press “ENTER” to enter setup;
3. Press “◄/►” to adjust parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Video Track Type
PELCO P2
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►”until “Video Track”
prompts;
2. Press “ENTER” to enter setup;
3. Press “◄/►” to adjust parameter;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Video Track
OFF
Video Track
▋
OFF
Video Track
▋
ON
Video Track
ON
1. Press “0” for 5 seconds to enter setup
menu and press “◄/►”until “Input
password” prompts;
2. Press “ENTER” to enter setup;
3. Input password;
4. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Input password:
Input password:
▋
Input password:
****
▋
Input password:
Video Track Type
▋
PELCO P2
Video Track Type
▋
HCS-3313C
Video Track Type
HCS-3313C
Note：
)The function of video track on will be enabled
after rebooting the matrix switcher.

9
1.3.2 Switch operation
1. VIDEO
Switch video signal separately, switch one input video
signal to any output channel.
Example: Switch video signal of input channel 7 to all
output channels synchronously.
2. THROUGH
Video signals switch through from input channel to
corresponding output channel.
Example 1: Switch video signals from input channel 1,
2, 3 to corresponding output channel 1, 2,
3 respectively.
6. Press “/”;
1. Press number key ”7”;
2. Press “VIDEO”;
3. Press “ALL” to execute switch.
TMX-0804HTK
Version: 2.00
Switch
7
Switch
7 V
Switch OK!
7 V ALL
1. Press “THROUGH”;
2. Press “VIDEO”;
3. Press number key ”1”;
4. Press “/”;
5. Press number key ”2”;
Switch through
V
Switch through
V1
Switch through
V1
，
2
Switch through
V1
，
Switch through
TMX-0804HTK
Version: 2.00
7. Press number key ”3”;
8. Press “ENTER” to execute switch.
Switch through
V1
，
2
，
3
Switch OK!
Note:
)The functions of buttons in this section have
been introduced in section 1.1; “V” stands
for video.
)“Input channel” and “output channel”
number must be less than matrix type.
)If any menu item is edited, except setup
menu, a key must be pressed within 15
seconds otherwise the system will return to
main menu item automatically and erase
the previous channel setup.
)To return to main menu press any key if
currently editing user interface is switch
finish interface, display input, output status
interface or DEMO interface. To return to
main menu if editing other user interface
press “CANCEL” or “←”.
)If new input source signal is switched,
please wait until previous source is
switched off. Wait according to Sync switch
Delay (refer to section 1.3.1).
Switch through
V1
，
2
，
Note:
)If there are more than one output channels,
use “/” key to separate them, and it will be
shown as “,” on LCD.

10
Example 2: Switch video signal from all input channels
to all corresponding output channels
respectively, i.e. 1→1，2→2，3→3，4→4…
3. CLOSE
Close one output channel or all output channels.
Example: Close video of output channel 4.
4. UNDO
Undo last completely terminated and validated switch
operation, and come back to the status before
executing the last switch.
5. GROUP
Group key: to compose not more than 5 groups, each
group with not more than 5 output channels.
Example 1: take output channel 1, 2, 3 as group 1.
5. Press number key “2”;
1. Press “THROUGH”;
2. Press “VIDEO”;
3. Press “ALL” to execute switch.
TMX-0804HTK
Version: 2.00
Switch through
V
Switch OK!
V ALL
Switch through
1. Press “CLOSE”;
2. Press “VIDEO”;
3. Press number key “4”;
4. Press “ENTER” to execute switch.
TMX-0804HTK
Version: 2.00
Close
Close
V
Switch OK!
Close
V 4
1. Press “GROUP”;
2. Press number key “1”;
3. Press number key “1”;
4. Press “/”;
TMX-0804HTK
Version: 2.00
Group Define
Group Define 1:
Group Define 1:
1
，
Group Define 1:
1
6. Press “/”;
7. Press number key “3”;
8. Press “ENTER” to confirm.
Group Define 1:
1
，
2
，
Group Define 1:
1
，
2
，
3
TMX-0804HTK
Version: 2.00
Group Define 1:
1
，
2
Press “UNDO” to execute.
Switch OK!
TMX-0804HTK
Version: 2.00
Note:
)If “ALL” is pressed instead of “4”, all output
channels are closed in this case.

11
Example 2: switch video signal of input channel 2 to all
output channels of group 1.
6. SAVE
Save current video signal to appointed scene. 10
scenes can be saved at most, each scene has a
number, from 0 to 9.
Example: Save current input and output channel
status in scene 1
7. RECALL
Recall AV signal from selected scene.
Example: Recall scene 3 and execute it.
8. LOCK
Keyboard lock: if “LOCK” is hold for 3 seconds, keyboard
will be locked. Thereafter password is needed to unlock
keyboard. Ethernet and RS-232 control are not locked.
Original password is: 11111.
1. Press number key “2”;
2. Press “VIDEO”;
3. Press “GROUP”;
4. Press number key “1”;
5. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Switch
2
Switch
2 V
Switch
2 V Grou
p
1
Switch
2 V Grou
p
1. Press “SAVE”;
2. Press number key “1” to execute.
TMX-0804HTK
Version: 2.00
Save scene:
Save scene OK!
Save scene: 1
1. Press “RECALL”;
2. Press number key “3” to execute.
TMX-0804HTK
Version: 2.00
Recall scene:
Switch OK!
Recall scene: 3
1. Hold “LOCK” for 3 seconds, keyboard will
be locked, Then password is needed to
unlock keyboard;
2. Input password;
3. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Enter password:
▋
Enter password:
****
▋
Switch OK!
Switch OK!
2 V Grou
p
1

12
9. END
End for a switch command.
Example: Switch video signal of input channel 3 to
output channel 4, and switch video signal of
input channel 2 to output channel 1
synchronously.
10. DEMO
Switches one by one all possible combinations from
1→1, 1→2, …, 1→4, 2→1, 2→2, …, 2→4, …, 8→1,
8→2, …to 8→4. The interval can be setup via setup
menu (Refer to section 1.3.1).
11. STATUS
Query channel status, used to query corresponding
state of input and output channels.
Example：Query channel 8 status.
1. Press number key “3”;
2. Press “VIDEO”;
3. Press number key “4”;
4. Press “END”;
5. Press number key “2”;
6. Press “VIDEO”;
7. Press number key “1”;
8. Press “ENTER” to confirm.
TMX-0804HTK
Version: 2.00
Switch
3
Switch
3 V
Switch
Switch
3 V 4
Switch
2
Switch
2 V
Switch
2 V 1
Switch OK！
1. Press number key “8”;
2. Press “STATUS” to execute.
TMX-0804HTK
Version: 2.00
Switch
8
Video: 8 ---> :4
Press “DEMO” key, switch circularly.
TMX-0804HTK
Version: 2.00
Demo switch:
1 ---> : 1
Note:
)Pressing “STATUS” key permanently will
display all channel status one by one.
)Pressing
“◄/►”key permanently will display
previous/next channel status one by one.

13
Chapter 2. IR Remote Control
1. Basic function
Users can use remote control to operate matrixes, the function of
remote control key is the same as matrix front panel key (Please refer
to chapter 1 for detailed instructions).
Please refer to sections of menu operation for detailed operation
method of remote control key.
2. Camera function
For the matrix with and has opened the video tracking function, users
can use remote control to operate the cameras which connected to the
matrix. The functions of camera operate as below:
1) Camera control
a. press the yellow button to enter the menu:
Camera Control
0
b. select a camera ID (1 to 8 buttons);
c. use the following buttons to adjust the camera;
Button Function Button Function Button Function
◄Left STATUS Up Green Magnify
►Right CLOSE Down Red Lessen
d. press the “CANCEL” button to exit.
2) Camera scan
a. press the blue button to enter the menu:
Camera Scan
0
b. select a camera ID (1 to 8 buttons);
c. use the following buttons to control the direction of the camera;
Button Function Button Function
1 Frame scan
(between preset 30 and 31) 2 Auto cruise
3 scan 300°4 scan 180°
d. press the “CANCEL” button to exit.
The remote control can be used for all TAIDEN matrix main units with
IR receipt function.

14
Chapter 3. Software
This chapter is a comprehensive and detailed user’s
guide of the application software of Matrix Switchers. It
consists of several sectors such as:
■Installation and Running;
■Operation: Through All, Close All, Scene Manage,
Switch, All, Undo;
■Sub module: Connect Mode, Channel Check, User
Group, Input signal, Parameter, System Status.
3.1 Installation and Running
3.1.1 Running Environment
■Windows2000/XP/Vista
■Memory: 256M or higher
■Cross-pair (TCP/IP communication)
■COM port (COM communication)
3.1.2 Installation
■CD content:
Matrix-switch matrix control system software.
■Installation guide:
Double click and run “Install.exe” on CD.
3.1.3 Software Running
Once installation is completed, a shortcut icon named
“Matrix switch” will appear on Windows desktop.
Double click it to run application, and the primary
window of matrix switch software shows as figure 3.1.
Figure 3.1 Primary window of Matrix Switchers
■Operation: Through All, Close All, Scene Manage,
Switch, All, Undo.
■Sub modules: Connect Mode, Timing Switch, User
Group, Signal Status, Parameter, System Status.
