TAIYO YUDEN EYSMJCS User manual

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
1/40
TAIYO YUDEN
EYSMJCS
Bluetooth®Module
EYSMJCS (RF+Baseband (Class 2) USB)
User’s Manual
The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks
by TAIYO YUDEN CO., LTD. is under license.
In case you adopt this module and design some appliance, please
ask for the latest specifications from the local sales office.
We wish the customer to request the Specification Report when the
design for the mass production begins because the content of this
Data Report might change without a previous notice to the customer.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
2/40
TAIYO YUDEN
EYSMJCS
Document constituent list
Control name Control No. Document Page
General Items HD-AG-A071063 1/3 – 3/3
Absolute maximum ratings HD-AM-A071063 1/1
Electrical characteristics HD-AE-A071063 1/3- 3/3
Electrical characteristics HD-AE-B071063 1/2 - 2/2
Electrical characteristics HD-AE-C071063 1/13 - 13/13
Electrical characteristics HD-AE-D071063 1/10- 10/10
Circuit schematic HD-MC-A071063 1/1
Outline / Appearance HD-AD-A071063 1/1
Outline / Appearance HD-AD-B071063 1/1
Pin Layout HD-BA-A071063 1/1
Rev. record
24-Aug.-2007> Ver.0.1

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
3/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AG-A071063 (1/3)
Control name
General Items
Scope
This specification (“Specification”) applies to the hybrid IC “EYSMJCS” for use Bluetooth®module
(“Product”) manufacture by TAIYO YUDEN Co., Ltd. (“TAIYO YUDEN”)
1. User’s Code: EYSMJCS (USB I/F Support)
Type: EYSMJCS
2. Function: Radio frequency transfer Module (power class 2). Bluetooth®standard Ver 2.0+EDR conformity
3. Application: Laptop PC
4. Structure: Hybrid IC loaded with silicon monolithic semiconductor
5. Outline: FFC/FPC Connector Type
6. Marking: TBD
7. Features:
-Bluetooth®2.0+EDR conformity
-USB Interface
-Point-to-Multipoint (7 Slaves)
-Encryption
-Hold, Sniff and Park Mode
-Supported Link Type: ACL
-AFH
-EDR (Enhanced Data Rate)
8. Packing: TBD
9. Terminal: Data input-output (6pin Cable Connector)
RF input-output (Antenna)
10. Mount: TBD
11. Notes:
a. Any question arising from this Specification shall be solved through mutual discussion by the parties
hereof.
b. This Product is not designed for radiation durable and should not be used under the circumstance of
radiation.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
4/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AG-A071063 (2/3)
Control name
General Items
c. The operating conditions of this Product are as shown in this Specification. Please note that TAIYO
YUDEN shall not be liable for a failure and/or abnormality which is caused by use under the conditions
other than the operating conditions hereof.
d. This Product mentioned in this Specification is manufactured for use in Laptop PC. Before using this
Product in any special equipment (such as medical equipment, space equipment, air craft, disaster
prevention equipment), where higher safety and reliability are duly required, the applicability and
suitability of this Product must be fully evaluated by the customer at its sole risk to ensure correct and
safety operation of those special equipments. Also, evaluation of the safety function of this Product even
for use in general electronics equipment shall be thoroughly made and when necessary, a protective circuit
shall be added in design stage, all at the customer’s sole risk.
e. TAIYO YUDEN warrants only that this Product is in conformity with this Specification for one year after
purchase and shall in no event give any other warranty.
f. The warranty period shall be one year.
g. Communication between this Product and others might not be established nor maintained depending upon
radio environment or operating conditions of this Product and other Bluetooth®products.
h. This Product is designed for use in products which comply with Bluetooth®Specifications (Ver 2.0+EDR)
(“Bluetooth Specifications”). TAIYO YUDEN disclaims and is not responsible for any liability concerning
infringement by this Product under any intellectual property right owned by third party in case the
customer uses this Product in any product which does not comply with Bluetooth Specifications (the
“non-complying products”). Furthermore, TAIYO YUDEN warrants only that this Product complies with
this Specification and does not grant any other warranty including warranty for application of the
non-complying products.
i. TAIYO YUDEN dose not render updating or upgrading service for the firmware in the Module.
j. In order to take tests for getting the certification of each country’s Radio Law with a device incorporating
this module, it is necessary to make the software in Host to put the module into test condition. Please
contact TAIYO YUDEN for farther details.
k. Please evaluate adequately our module incorporated to your products before mass production.
l. This Product operates in the unlicensed ISM band at 2.4GHz. In case this Product is used around the other
wireless devices which operate in same frequency band of this Product, there is a possibility that
interference occurs between this Product and such other devices. If such interference occurs, please stop
the operation of other devices or relocate this Product before using this Product or do not use this Product
around the other wireless devices.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
5/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AG-A071063 (3/3)
Control name
General Items
m. Containment of hazardous substance in this Product
*Pb(Lead) :Nonuse
*Additional RoHS regulation substance (Cd.Hg.Cr+6.PBB.PBDE) :Non use
n. In addition when this Product is used under environmental conditions such as over voltage which
are not guaranteed ,it may be destroyed in short mode. To ensure the security of customer’s product,
please add an extra fuse or/and a protection circuit for over voltage.
p. In some cases, TAIYO YUDEN may use replacements as component parts of Products. Such
replacement shall apply only to component part of Products, which TAIYO YUDEN deems it
possible to replace or substitute according to (i) Scope provided in this Specification (e.g.
Official Standard (Type Approvals, Bluetooth LOGO etc.)) and (ii) Quality of Products. TAIYO
YUDEN also ensures traceability of such replacement on production lot basis.
r. Do not alter Hardware and/or Software of this Product.
Please note that TAIYO YUDEN shall not be liable for any problem if it is caused by customer's
alteration of Hardware or/and Software without Taiyo Yuden's prior approvals.
This module is still under development, thus specifications do not guarantee both the quality and
reliability at the time of shipment. Since the specifications and mass production of the module are not
confirmed either, the contents of the technical notes are subject to change without any prior notice.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
6/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AM-A 071063 (1/1)
Control name
Absolute maximum ratings
Absolute maximum ratings
Rating
Item Symbol
Min. Typ. Max. Unit Remark
Supply voltage VDD -0.3 3.6 V
Ta=25 degrees C,
GND reference
Input voltage Vin -0.3 VDD+0.3 V I/O terminals except
USB interface
Recommendation operating range
Rating
Item Symbol
Min. Typ. Max. Unit Remark
Supply voltage VDD 3.15 3.3 3.45 V
Supply voltage ripple
and spike noise VDD_rn (30) mVp-p Note 1
Operation temperature
range Topr 0 25 70 Degrees C
Humidity=40%RH
Note 2
Storage temperature
range Tstg -30 25 85 Degrees C
Humidity=40%RH
Note 3
Notes:
1. To fill the standard of “Supply voltage ripple and spike noise”, the capacitor, which has the capacity of
2.2uF or more, should be put in the terminal VDD outside as a bypass capacitor .
2. Operating temperature range is set to satisfy products electrical characteristics in the short term.
In terms of product life cycle when it is used in condition of varying from TYP standard in the long term,
please refer to the reliability condition.
3. Storage temperature range is the condition for transportation and storage in temporary.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
7/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-A071063 (1/3)
Control name
Electrical characteristics
Electrical characteristic
DC Specifications
The Specification applies for Topr.= 25 degrees C, VDD=3.3V
No. Parameter Condition Symbol Min. Typ. Max. Unit Remark
1 Normal supply voltage VDD 3.15 3.3 3.45 V
2 Input Low Voltage 1 /RESET, PIOX VIL1 -0.3 0.8 V
3 Input Low Voltage 2 USB_D+, USB_D- VIL2 - 0.8 V
4 Input High Voltage 1 /RESET, PIOX VIH1 0.7xVDD VDD+0.3 V
5 Input High Voltage 2 USB_D+, USB_D- VIH2 2.0 - V
6 Output Low Voltage 1 PIOX VOL1 - 0.4 V IOL=4mA
7 Output Low Voltage 2 USB_D+, USB_D- VOL2 - 0.3 V
8 Output High voltage 1 PIOX VOH1 VDD-0.4 - V IOH=-4mA
9 Output High voltage 2 USB_D+, USB_D- VOH2 2.8 - V
10 Peak current Continuous Rx Iccp1 (42) (120) mA Notes 3, 4
11 Average current1 Sniff mode (Slave only) Icca1 (10) - mA Notes 1, 3, 4
12 Average current2 Standby mode Icca2 (9) - mA Notes 3, 4
13 Average current3 Send DM1packet (Master) Icca3 (36) - mA Notes 3, 4
14 Average current4 Receive DM1packet (Slave) Icca4 (37) - mA Notes 3, 4
15 Average current5 Hold mode (Slave only) Icca5 (9) - mA Notes 3, 4
16 Average current6 Park mode (Slave only) Icca6 (9) - mA Notes 2, 3, 4
Notes:
1. Sniff mode parameter. Max interval 0050h
Min interval 0010h
Attempt 0005h
Timeout 0005h
2. Park mode parameter. Max interval 0100h
Mininterval 0010h
3. The consumption current might fluctuate with the condition of radio communication, host performance
and test circuit.
4. The value may fluctuate several (mA) depending on Firmware version.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
8/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-A071063 (2/3)
Control name
Electrical characteristics
AC Specifications
The Specification applies for Topr.= 25 degrees C, VDD=3.3V
No. Parameter Condition Symbol Min Typ Max Unit Remark
1 VDD Rise Time from 0V to 3.15V t1 0 2 ms Note 1
2 VDD= 3.15V to /RESET High t2 10 ms Note 2
3 /RESET High to Module Ready t3 (100) 3000 ms Notes 3, 4
4 /RESET Pulse Width t4 6 ms
5 DETACH High to USB I/F High-Z t5 130 ms
6 DETACH Low to USB I/F Active t6 0 10 ms
7 /RESET High to /RESET Low t7 3000 ms Note 5
8 /RESET Low to USB_I/F High-Z t8 0 10 ms
9 Module Active to /RESET Low t9 0 ms Note 5
10 /RESET Low to VDD_3.3V Off t10 0 ms
Notes:
1. This module has an internal flash memory and a function to erase/sort unnecessary data if certain HCI commands
are issued and consume more than a certain level of free space in the flash memory. This operation occurs at every
module initialization (power-on).
If supply voltage becomes non-defined states during initialization or writing in flash memory, data in flash memory
might be destroyed. If the data in flash memory is destroyed, module will not work correctly. Therefore please be
sure to stabilize power source before /RESET release.
In addition please design module peripheral circuits to avoid temporary blackout of power source during operation.
Please refer HD-AE-C 071063 for HCI command which rewrites flash memory data.
2. Input /RESET signal of 10ms and more in condition of VDD_3.3V at over 3.15V.
3. When the module is ready to accept the command, its module outputs the “0F 04 00 01 00 00” (Hex) USB to the
Data Line. After that, please access to the module.
4. The Typ. is a reference value. The value may change depending on the firmware version and conditions of use.
5. You don’t need to wait t6 if you confirm that this module has output “0F 04 00 01 00 00” (Hex).

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
9/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-A071063 (3/3)
Control name
Electrical characteristics
USB_DETACH
VDD
/RESET
USB_I/F
(Note 1)
Timing Diagram for Power Up Sequence
t1
t2
t4
t7
t3
Active
t9 t8
Active Active
t5 t6
Timing Diagram for Power Down Sequence
VDD_3.3V
/RESET
(Note 1)
USB_I/F
USB_DETACH
Active
t10

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
10/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-B071063 (1/2)
Control name
Electrical characteristics
RF Specifications at Basic Rate
The Specification applies for Ta=25 degrees C, VDD=3.3V
No. Parameter Condition Symbol Min Typ Max Unit Remark
1 Frequency band FREQ 2400 2483.5 MHz
2 Tx power PO -6 0 +4 dBm
3 Modulation
characteristics 1 dF1: F0(11110000) M1 140 175 kHz
4 Modulation
characteristics 2 dF2: AA(10101010) M4 115 kHz
5 Modulation
characteristics 3 dF2/dF1 MC 0.8
6 In-
b
and spurious
emission 2 2MHz(|M-N|=2) ISE1 -20 dBm
7 In-
b
and spurious
emission 3
3MHz or greater
(|M-N|>=3) ISE2 -40 dBm
8 Initial Carrier
Frequency ICF -75 +75 kHz
9 Frequency Drift 1 DH1 FD1 -25 +25 kHz
10 Frequency Drift 2 DH3,DH5 FD2 -40 +40 kHz
11 Drift rate DH1,DH3,DH5 DR 400 Hz/us
12 C/I co-channel CIC 11 dB -60dBm
13 C/I 1MHz CI1 0 dB -60dBm
14 C/I 2MHz CI2 -30 dB -60dBm
15 C/I >= 3MHz CI3 -40 dB -67dBm
16 C/I Image CI4 -9 dB
-3MHz
offset
-67dBm
17 C/I Image +/- 1MHz CI5 -20 dB -67dBm
18 Out-of-Band
Blocking 1
30MHz to 2000MHz
f=2460MHz OBB1 -10 dBm
BER<=0.1
%
19 Out-of-Band
Blocking 2
2000 to 2399MHz
f=2460MHz OBB2 -27 dBm
BER<=0.1
%
20 Out-of-Band
Blocking 3
2484 to 3000MHz
f=2460MHz OBB3 -27 dBm
BER<=0.1
%
21 Out-of-Band
Blocking 4
3000MHz to
12.75GHz
f=2460MHz
OBB4 -10 dBm
BER<=0.1
%
22 Maximum Input
Level MAXP -20 dBm
BER<=0.1
%
23 20dB Bandwidth B20 1 MHz
24 Sensitivity-single DH1 SEN1 -70 dBm BER<=0.1
%
25 Sensitivity-multi DH3,DH5 SEN2 -70 dBm BER<=0.1
%

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
11/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-B071063 (2/2)
Control name
Electrical characteristics
RF Specifications at EDR
The Specification applies for Ta=25 degrees C, VDD =3.3V
No. Parameter Condition Symbol Min Typ Max Unit Remark
1 RMS DEVM 1 Pai/4DQPSK RDE1 0.20
2 RMS DEVM 2 8DPSK RDE2 0.13
3 Peak DEVM 1 Pai/4DQPSK PDE1 0.35
4 Peak DEVM 2 8DPSK PDE2 0.25
5 99% DEVM 1 Pai/4DQPSK D991 0.30
6 99% DEVM 2 8DPSK D992 0.20
7 EDR In-band spurious
emission 1 |M-N|=1 EISE1 26 dB
8 EDR In-band spurious
emission 2 |M-N|=2 EISE2 -20 dBm
9 EDR In-band spurious
emission 3 |M-N|=3 EISE3 -40 dBm
10 EDR Initial Carrier
Frequency EICF -75 +75 kHz
11 EDR Drift ED -10 +10 kHz
12 Relative transmit
power PDPSK RTP
PGFSK
-4 PGFSK
+1 dB
13 Actual Sensitivity
Level
2-DH5(3-DH5)
16000000bit ESEN -70 dBm BER= 10-4
14 BER Floor
Performance
2-DH5(3-DH5)
160000000bit FSEN -60 dBm BER= 10-5
15 C/I co-channel 2-DH5 2CIC 13 dB -60dBm
16 C/I 1MHz 2-DH5 2CI1 0 dB -60dBm
17 C/I 2MHz 2-DH5 2CI2 -30 dB -60dBm
18 C/I >= 3MHz 2-DH5 2CI3 -40 dB -67dBm
19 C/I Image 2-DH5 2CI4 -7 dB
-67dBm
-3MHz
offset
20 C/I Image +/- 1MHz 2-DH5 2CI5 -20 dB -67dBm
21 C/I co-channel 3-DH5 3CIC 21 dB -60dBm
22 C/I 1MHz 3-DH5 3CI1 5 dB -60dBm
23 C/I 2MHz 3-DH5 3CI2 -25 dB -60dBm
24 C/I >= 3MHz 3-DH5 3CI3 -33 dB -67dBm
25 C/I Image 3-DH5 3CI4 0 dB
-67dBm
-3MHz
offset
26 C/I Image +/- 1MHz 3-DH5 3CI5 -13 dB -67dBm
27 Maximum Input Level 2-DH5(3-DH5) EMAX
P -20 dBm
Note:
Bluetooth®standard Ver 2.0+EDR conformity

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
12/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (1/13)
Control name
Electrical characteristics
Supported HCI Commands / HCI Events
The Bluetooth®functions of this module is as written in the attached PICS. Depending on
firmware version Upgrade, the Bluetooth®functions are subject to change without notice.
HCI COMMAND LIST Firmware Version 21e (Build3164)
Command Description OpCode
Group
(Hex)
Command
(Hex) Parameters Returns Status Notes
LINK CONTROL
Inquiry
LAP
Inquiry Length
HCI _Inquiry 0x0401 1 1
Num Responses
Yes
HCI _ Inquiry_ Cancel 0x0402 1 2 Status Yes
Max Period Length
Min Period Length
LAP
Inquiry Length
HCI_ Periodic_ Inquiry _Mode 0x0403 1 3
Num Responses
Status Yes
HCI _Exit _Periodic _Inquiry _Mode 0x0404 1 4 Status Yes
Connection Management
BD ADDR
Packet Type
Page Scan Repetition Mode
Page Scan Mode
Clock Offset
HCI _Create_ Connection 0x0405 1 5
Allow Role Switch
Yes a,b
Connection Handle
HCI _Disconnect 0x0406 1 6 Reason Yes b
SCO Handle
HCI _Add _SCO _Connection 0x0407 1 7 Packet Type Yes
b,c,
d,j,p
Status
HCI _Create _Connection _Cancel 0x0408 1 8 BD ADDR BD_ADDR Ye s l
BD ADDR
HCI _Accept _Connection _Request 0x0409 1 9 Role Ye s
HCI _Reject _Connection _Request 0x040A 1 A BD ADDR Yes
Connection HandleHCI _Change _Connection _Packet
_Type 0x040F 1 F Packet Type Yes
Connection_Handle
Transmit_Bandwidth
Receive_Bandwidth
Max_Latency
Voice_Setting
Retransmission_Effort
HCI _Setup _Synchronous
_Connection 0x0428 1 28
Packet_Type
Yes
l,m,
o,p
BD ADDR
Transmit_Bandwidth
Receive_Bandwidth
Max_Latency
Content Format
Retransmission_Effort
HCI _Accept _Synchronous
_Connection _Request 0x0429 1 29
Packet_Type
Yes l, m, o
BD ADDRHCI _Reject _Synchronous
_Connection _Request 0x042A 1 2A Reason Yes l ,m,o

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
13/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (2/13)
Control name
Electrical characteristics
Authentication / Pairing
BD ADDR Status
HCI _Link _Key _Request _Reply 0x040B 1 B Link Key BD ADDR Ye s
StatusHCI _Link _Key _Request
_Negative _Reply 0x040C 1 C BD ADDR BD ADDR Ye s
BD ADDR Status
PIN Code Length BD ADDR
HCI _PIN _Code _Request _Reply 0x040D 1 D
PIN Code
Yes
StatusHCI _PIN _Code _Request
_Negative _Reply 0x040E 1 E BD ADDR BD ADDR Ye s
HCI _Authentication _Requested 0x0411 1 11 Connection Handle Yes
HCI _Change _Connection _Link
_Key 0x0415 1 15 Connection Handle Yes
Encryption
Connection Handle
HCI _Set _Connection _Encryption 0x0413 1 13 Encryption Enable Yes
HCI _Master _Link _Key 0x0417 1 17 Key Flag Yes
Remote Information
BD ADDR
Page Scan Repetition Mode
Page Scan Mode
HCI _Remote _Name_ Request 0x0419 1 19
Clock Offset
Yes
StatusHCI _Remote _Name _Request
_Cancel 0x041A 1 1A BD_ADDR BD_ADDR Yes l
HCI _Read _Remote _Supported
_Features 0x041B 1 1B Connection Handle Yes
Connection HandleHCI _Read _Remote _Extended
_Features 0x041C 1 1C Page_Number Yes l
HCI _Read _Remote _Version
_Information 0x041D 1 1D Connection Handle Yes
HCI _Read _Clock _Offset 0x041F 1 1F Connection Handle Yes
Status
Connection Handle
LMP_Handle
HCI _Read _LMP _Handle 0x0420 1 20 Connection Handle
Reseved
Yes l

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
14/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (3/13)
Control name
Electrical characteristics
LINK POLICY
Connection Handle
Hold Mode Max Interval
HCI _Hold _Mode 0x0801 2 1
Hold Mode Min Internal
Yes
Connection Handle
Sniff Mode Max Interval
Sniff Mode Min Interval
Sniff Attempt
HCI _Sniff _Mode 0x0803 2 3
Sniff Timeout
Yes
HCI _Exit _Sniff _Mode 0x0804 2 4 Connection Handle Yes
Connection Handle
Beacon Max Interval
HCI _Park _State 0x0805 2 5
Beacon Min Interval
Yes k
HCI _Exit _Park _State 0x0806 2 6 Connection Handle Yes k
Connection Handle
Flags
Service Type
Token Rate
Peak Bandwidth
Latency
HIC _QoS _Setup 0x0807 2 7
Delay Variation
Yes e, m
Status
Connection Handle
HCI _Role _Discovery 0x0809 2 9 Connection Handle
Current Role
Yes
BD ADDR
HCI _Switch _Role 0x080B 2 B Role Yes
States
Connection Handle
HCI _Read _Link _Policy _Settings 0x080C 2 C Connection Handle
Link Policy Settings
Yes
Connection Handle States
HCI _Write _Link _Policy _Settings 0x080D 2 D Link Policy settings Connection Handle Ye s
Status
HCI _Read _Default _Link _Policy
_Settings 0x080E 2 E Default Link Policy
Settings
Yes l
HCI _Write _Default _Link _Policy
_Settings 0x080F 2 F Default Link Policy
Settings Status Yes l
Connection Handle
Flags
Flow direction
Service Type
Token Rate
Token Bucket Size
Peak Bandwidth
HCI _Flow _Specification 0x0810 2 10
Access Latency
No l,m

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
15/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (4/13)
Control name
Electrical characteristics
HOST CONTROLLER & BASEBAND
HCI _Set _Event _Mask 0x0C01 3 1 Event Mask States Yes
HCI _Reset 0x0C03 3 3 States Yes
Filter Type
Filter Condition Type
HCI _Set _Event _Filter 0x0C05 3 5
Condition
States Yes
States
HCI _Flush 0x0C08 3 8 Connection Handle Connection Handle Yes
States
HCI _Read _PIN _Type 0x0C09 3 9 PIN Type Yes
HCI _Write _PIN _Type 0x0C0A 3 A PIN Type States Yes
HCI _Create _New _Unit _Key 0x0C0B 3 B States Yes
BD ADDR States
Max Num Keys
HCI _Read _Stored _Link _Key 0x0C0D 3 D Read All Flag Num Keys Read Yes
Num Keys To Write States
BD ADDR [I]
HCI _Write _Stored _Link _Key 0x0C11 3 11
Link Key [I] Num Keys Written Ye s n
BD ADDR States
HCI _Delete _Stored _Link _Key 0x0C12 3 12 Delete All Flag Num Keys Deleted Yes n
HCI _Write _Local _Name 0x0C13 3 13 Local Name States Yes f,k
States
HCI _Read _Local _Name 0x0C14 3 14 Local Name Yes
StatesHCI _Read _Connection _Accept
_Timeout 0x0C15 3 15 Conn Accept Timeout Ye s
HCI _Write _Connection _Accept
_Timeout 0x0C16 3 16 Conn Accept Timeout States Yes
States
HCI _Read _Page _Timeout 0x0C17 3 17 Page Timeout Yes
HCI _Write _Page _Timeout 0x0C18 3 18 Page Timeout States Yes
States
HCI _Read _Scan _Enable 0x0C19 3 19 Scan Enable Yes
HCI _Write _Scan _Enable 0x0C1A 3 1A Scan Enable States Yes
States
Page Scan Interval
HCI _Read _Page _Scan _Activity 0x0C1B 3 1B
Page Scan Window
Yes
Page Scan Interval
HCI _Write _Page _Scan _Activity 0x0C1C 3 1C Page Scan Window States Yes
States
Inquiry Scan Interval
HCI _Read _Inquiry _Scan _Activity 0x0C1D 3 1D
Inquiry Scan Window
Yes
Inquiry Scan Interval
HCI _Write _Inquiry _Scan _Activity 0x0C1E 3 1E Inquiry Scan Window States Yes
States
HCI _Read _Authentication _Enable 0x0C1F 3 1F Authentication Enable Yes
HCI _Write _Authentication _Enable 0x0C20 3 20 Authentication Enable States Yes
States
HCI _Read _Encryption _Mode 0x0C21 3 21 Encryption Mode Yes
HCI _Write _Encryption _Mode 0x0C22 3 22 Encryption Mode States Yes
States
HCI _Read _Class _of _Device 0x0C23 3 23 Class of Device Ye s
HCI _Write _Class _of _Device 0x0C24 3 24 Class of Device States Yes
States
HCI _Read _Voice _Setting 0x0C25 3 25 Voice Setting Yes
HCI _Write _Voice _Setting 0x0C26 3 26 Voice Channel setting States Yes

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
16/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (5/13)
Control name
Electrical characteristics
States
Connection Handle
HCI _Read _Automatic _Flush
_Timeout 0x0C27 3 27 Connection Handle
Flush Timeout
Yes
Connection Handle States
HCI _Write _Automatic _Flush_
Timeout 0x0C28 3 28 Flash Timeout Connection Handle Ye s
HCI _Read _Num _Broadcast_
Retransmission 0x0C29 3 29 States Yes
HCI _Write _Num _Broadcast_
Retransmission 0x0C2A 3 2A Num Broadcast
Retransmission States Yes
States
HCI _Read _Hold _Mode _Activity 0x0C2B 3 2B Hold Mode Activity Ye s
HCI _Write _Hold _Mode _Activity 0x0C2C 3 2C Hold Mode Activity States Yes
Connection Handle States
Connection Handle
HCI _Read _Transmit _Power
_Level 0x0C2D 3 2D Type Power Level
Yes
States
HCI _Read _Synchronous _Flow
_Control _Enable 0x0C2E 3 2E Synchronous Flow
Control Enable
No c,d,k
HCI _Write _ Synchronous _Flow
_Control _Enable 0x0C2F 3 2F Synchronous Flow
Control Enable States No c,d,k
HCI _Set _Controller _To _Host
_Flow _Control 0x0C31 3 31 Flow Control Enable States Yes k
Host ACL Data Packet
Length
Host SCO Data Packet
Length
Host Total Num ACL Data
Packets
HCI _Host _Buffer _Size 0x0C33 3 33
Host Total Num SCO Data
Packets
States Yes
Number of Handles
Connection handle [I]
HCI _Host _Number _Of
_Completed _Packets 0x0C35 3 35 Host Num of Completed
Packets [I]
Yes
States
Connection Handle
HCI _Read _Link _Supervision
_Timeout 0x0C36 3 36 Connection Handle Link Supervision
Timeout
Yes
Connection Handle States
HCI _Write _Link _Supervision
_Timeout 0x0C37 3 37 Link Supervision Timeout Connection Handle Yes
States
HCI _Read _Number _Of _Support
_IAC 0x0C38 3 38 Num Support IAC Yes
States
Num Current IAC
HCI _Read _Current _IAC _LAP 0x0C39 3 39
IAC LAP [I]
Yes
Num Current IAC
HCI _Write _Current _IAC _LAP 0x0C3A 3 3A IAC LAP [I] States Yes
StatesHCI _Read _Page _Scan _Period
_Mode 0x0C3B 3 3B Page Scan Period Mode Ye s
HCI _Write _Page _Scan _Period
_Mode 0x0C3C 3 3C Page Scan Period Mode States Yes
States
HCI _Read _Page _Scan _Mode 0x0C3D 3 3D Page Scan Mode Yes j
HCI _Write _Page _Scan _Mode 0x0C3E 3 3E Page Scan Mode States Yes h,j
HCI _Set _AFH _Host _Channel
_Classification 0x0C3F 3 3F AH Host Channel
Classification Status Yes l

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
17/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (6/13)
Control name
Electrical characteristics
Status
HCI _Read _Inquiry _Scan _Type 0x0C42 3 42
Inquiry Scan Type Yes l
HCI _Write _Inquiry _Scan _Type 0x0C43 3 43 Inquiry Scan Type Status Yes l
Status
HCI _Read _Inquiry _Mode 0x0C44 3 44 Inquiry Mode Ye s l
HCI _Write _Inquiry _Mode 0x0C45 3 45 Inquiry Mode Status Yes l
Status
HCI _Read _Page _Scan _Type 0x0C46 3 46 Page Scan Type Yes l
HCI _Write _Page _Scan _Type 0x0C47 3 47 Page Scan Type Status Yes l
Status
HCI _Read _AFH _Channel
_Assessment _Mode 0x0C48 3 48 AFH Channel
Assessment Mode
Yes l
HCI _Write _AFH _Channel
_Assessment _Mode 0x0C49 3 49 AFH Channel
Assessment Mode Status Yes l
INFORMATIONAL PARAMETERS
Status
HCI Version
HCI Revision
LMP Version
Manufacturer Name
HCI _Read _Local _Version _
Information 0x1001 4 1
LMP Subversion
Yes
Status
HCI _Read _Local _Supported
_Commands 0x1002 4 2 Supported Commands Yes l
StatusHCI _Read _Local _Supported
_Features 0x1003 4 3 LMP_Features Ye s
Status
Page number
Maximum Page Number
HCI _Read _Local _Extended
_Features 0x1004 4 4 Page number
Extended LMP Features
Yes l
Status
HC ACL Data Packet
Length
HC Synchronous Data
Packet Length
HC Total Num ACL
Data Packet
HCI _Read _Buffer _Size 0x1005 4 5
HC Total Num
Synchronous Data Packe
Yes
Status
HCI _Read _Country _Code 0x1007 4 7 Country Code Ye s j
Status
HCI _Read _BD _ADDR 0x1009 4 9 BD ADDR Yes

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
18/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (7/13)
Control name
Electrical characteristics
STAUS PARAMETERS
Status
Connection handle
HCI _Read _Failed _Contact
_Counter 0x1401 5 1 Connection Handle
Failed Contact Counter
Yes
StatusHCI _Reset _Failed _Contact
_Counter 0x1402 5 2 Connection Handle Connection handle Ye s
Status
Connection Handle
HCI _Read _Link _Quality 0x1403 5 3 Connection Handle
Link Quality
Yes k
Status
Connection Handle
HCI _Read _RSSI 0x1405 5 5 Connection Handle
RSSI
Yes
Status
Connection Handle
AFH Mode
HCI _Read _AFH _Channel _Map 0x1406 5 6 Connection Handle
AFH Channel Map
Yes l
Status
Which Clock Connection Handle
AFH Mode
HCI _Read _Clock 0x1407 5 7
Connection Handle AFH Channel Map
Yes l
TESTING
States
HCI _Read _Loopback _Mode 0x1801 6 1 Loopback Mode Yes
HCI _Write _Loopback _Mode 0x1802 6 2 Loopback Mode States Yes g,i
HCI _Enable _Device _Under _Test
_Mode 0x1803 6 3 States Yes

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
19/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (8/13)
Control name
Electrical characteristics
Notes:
a) Up to seven connections: a slave of up to two masters, and/or a master of up to seven slave.
Some operations restricted or non-functional in a scatternet.
b) Chip resource limits constrain the rate at which ACL and SCO connections can be made and broken to approximately
20 per 15 seconds. The time limit can be configured.
b) Up to three SCO links. Each SCO link can be routed over the chip’s PCM interface or over HCI/BCSP.
Preliminary Support for SCO over USB or H4 is in place, but testing has been light.
d) No HCI SCO Host Controller to Host flow control support.
No HCI SCO Host to Host Controller flow control support.
e) Limited support for “best effort” and “guaranteed” Qos only.
f) Initial device name taken from PS Keys, and so is maintained through a reset/reboot.
g) HCI Reset does not work if the device is in local loopback mode.
h) Optional Paging schemes are not supported.
i) Remote ACL loopback sometimes deadlocks when the device’s flow control mechanisms assert to each other.
j) Bluetooth v1.1 specification command, deprecated in the v1.2 specification,or later; support retained for backwards co
mpatibility.
k) Bluetooth v1.1 specification command, renamed in the v1.2 specification,or later.
Park Mode ---> Park State
Exit Park Mode ---> Exit Park State
Set Host Controller To Host Flow Control ---> Set Controller To Host Flow Control
Change Local Name ---> Write Local Name
Read SCO Flow Control Enable ---> Read Synchronous Flow Control Enable
Write SCO Flow Control Enable ---> Write Synchronous Flow Control Enable
Get Link Quality ---> Read Link Quality
l) Command not in the Bluetooth v1.1 specification.
m) Underlying Flow_Specification functionality the same as for QoS_Setup.
n) Command which rewrites FROM in module
p) CVSD not available with 3EV3 or 3EV5 EDR packets.
q) HCI Setup Synchronous Connection command does not support HV1,HV2 and HV3 Packet Type. If you want to use those
Packet Types, please use HCI Add SCO connection command.

24-Aug.-2007 Ver.0.1
TAIYO YUDEN Confidential
& Tentative
20/40
TAIYO YUDEN
EYSMJCS
Control No.
HD-AE-C071063 (9/13)
Control name
Electrical characteristics
HCIEVENTLIST
Event Description OpCode Parameters Status Notes
Inquiry
Inquiry _Complete 0x01 Status Yes
Num Responses
BD ADDR [I]
Page Scan Repetition Mode [I]
Page Scan Period Mode [I]
Page Scan Mode [I]
Class of Device [I]
Inquiry _Result 0x02
Clock Offset [I]
Yes
Num Responses
BD ADDR [I]
Page Scan Repetition Mode [I]
Page Scan Period Mode [I]
Page Scan Mode [I]
Class of Device [I]
Clock Offset [I]
Inquiry _Result _with _RSSI 0x22
RSSI [I]
Yes b
Connection Management
Status
Connection Handle
BD ADDR
Link Type
Connection _Complete 0x03
Encryption Mode
Yes
BD ADDR
Class of Device
Connection _Request 0x04
Link Type
Yes
Status
Connection Handle
Disconnection _Complete 0x05
Reason
Yes
Status
Connection Handle
BD ADDR
Link Type
Transmission Interval
Retransmission Window
Rx Packet Length
Tx Packet Length
Synchronous _Connection _Complete 0x2C
Air Mode
Yes b
Status
Connection Handle
Transmission Interval
Retransmission Window
Rx Packet Length
Synchronous _Connection _Changed 0x2D
Tx Packet Length
Yes b
