TAKACHI MSN Series User manual

239
■Available in 3 different colors and 176 different sizes.
■Stand handle can be shifted and locked at 30° intervals.
■Maximum load support of 25kg.
Components
No. Part name Pcs Material Color / Finish
1Front panel 1 Aluminium A1050P t=2.0 Silver • Black / Hairline brushed & Anodized
2Rear panel 1 Aluminium A1050P t=2.0 Silver • Black / Anodized
3Side frame 2 Extruded aluminium A6063S-T5 Gray • Black / Painted
4Front frame 2 Extruded aluminium A6063S-T5 Gray • Black / Painted
5Rear frame 2 Extruded aluminium A6063S-T5 Silver / Anodized
6Top • Bottom cover 1 each Steel SPCC t=1.0 Light gray • Black / Painted
7Corner block 2 Diecast aluminium ADC12 Gray • Black / Painted
8Rear feet 2 ABS UL94V-0 Gray • Black
9Rubber feet 4Polyurethane Black
10 Stand handle Bracket 2ABS UL94VHB Light gray • Black
11 Grip 1 Extruded aluminium A6063S-T5 Silver • Black
■Front • Rear panels comes with a protective sheet cover.
Included screws
M4-6 countersunk screw, trivalent chromate x 4 pcs
M4-8 pan head screw, trivalent chromate x 8 pcs
M4-10 binding head screw, black trivalent chromate x 4 pcs
MSN SERIES
DESKTOP ENCLOSURE with STAND HANDLE
6
5
7
1
4
10
12
2
8
3
6
13
11
9
Assembly drawings
English 2016_235_264.indd 239 16/10/19 11:40

240
Available range D-25
17.5
Available range (rear panel) W-30
3.5
Available range W-21
Available range (rear panel)
H-16.5
Available range (front panel)H-16
Available range H-5
H
W
D
12.5
6.1
※Note
30°
30°
30°
30°
30°
Available range (front panel) W-30
Rubber feet
※Note
Stand handle location can be freely afxed within denoted range.
Accessories (Optional parts)
12
Mounting plate
MSC series
See page 249
13
L-bracket
MSCL series
See page 249
Cable hook
CBF series
See page 251
■Top • Bottom cover of sizes 160x160, 160x230, 160x280, 210x160 do not have ventilation holes.
MSN dimensions ■DXF/DWG/PDF drawings available on our website.
● G
Panel Silver
Top • Bottom cover Light gray
Side frame Gray
Color Type ■Please suffix color code at the end of the product number.
●◓BS
Panel Silver
Top • Bottom cover Black
Side frame Black
● B
Panel Black
Top • Bottom cover Black
Side frame Black
English 2016_235_264.indd 240 16/10/19 11:40

241
Product no. H W D Weight (kg)
MSN 66-16-16 66 160 160 1.2
MSN 66-16-23 66 160 230 1.5
MSN 66-16-28 66 160 280 1.8
MSN 66-21-16 66 210 160 1.4
MSN 66-21-23 66 210 230 1.8
MSN 66-21-28 66 210 280 2.1
MSN 66-21-35 66 210 350 2.5
MSN 66-26-23 66 260 230 2.1
MSN 66-26-28 66 260 280 2.4
MSN 66-26-35 66 260 350 2.9
MSN 66-32-23 66 320 230 2.4
MSN 66-32-28 66 320 280 2.8
MSN 66-32-35 66 320 350 3.4
MSN 66-32-45 66 320 450 4.1
MSN 66-37-23 66 370 230 2.6
MSN 66-37-28 66 370 280 3.1
MSN 66-37-35 66 370 350 3.7
MSN 66-37-45 66 370 450 4.4
MSN 66-43-23 66 430 230 3.0
MSN 66-43-28 66 430 280 3.5
MSN 66-43-35 66 430 350 4.2
MSN 66-43-45 66 430 450 5.2
MSN 88-16-16 88 160 160 1.3
MSN 88-16-23 88 160 230 1.6
MSN 88-16-28 88 160 280 1.9
MSN 88-21-16 88 210 160 1.5
MSN 88-21-23 88 210 230 1.9
MSN 88-21-28 88 210 280 2.3
MSN 88-21-35 88 210 350 2.7
MSN 88-26-23 88 260 230 2.3
MSN 88-26-28 88 260 280 2.6
MSN 88-26-35 88 260 350 3.1
MSN 88-32-23 88 320 230 2.6
MSN 88-32-28 88 320 280 3.0
MSN 88-32-35 88 320 350 3.6
MSN 88-32-45 88 320 450 4.4
MSN 88-37-23 88 370 230 2.9
MSN 88-37-28 88 370 280 3.3
MSN 88-37-35 88 370 350 4.0
MSN 88-37-45 88 370 450 4.7
MSN 88-43-23 88 430 230 3.2
MSN 88-43-28 88 430 280 3.7
MSN 88-43-35 88 430 350 4.4
MSN 88-43-45 88 430 450 5.5
Product no. H W D Weight (kg)
MSN 99-16-16 99 160 160 1.3
MSN 99-16-23 99 160 230 1.7
MSN 99-16-28 99 160 280 2.0
MSN 99-21-16 99 210 160 1.6
MSN 99-21-23 99 210 230 2.0
MSN 99-21-28 99 210 280 2.3
MSN 99-21-35 99 210 350 2.8
MSN 99-26-23 99 260 230 2.3
MSN 99-26-28 99 260 280 2.7
MSN 99-26-35 99 260 350 3.2
MSN 99-32-23 99 320 230 2.6
MSN 99-32-28 99 320 280 3.1
MSN 99-32-35 99 320 350 3.7
MSN 99-32-45 99 320 450 4.5
MSN 99-37-23 99 370 230 2.9
MSN 99-37-28 99 370 280 3.4
MSN 99-37-35 99 370 350 4.1
MSN 99-37-45 99 370 450 4.8
MSN 99-43-23 99 430 230 3.3
MSN 99-43-28 99 430 280 3.8
MSN 99-43-35 99 430 350 4.5
MSN 99-43-45 99 430 450 5.6
MSN133-16-16 133 160 160 1.5
MSN133-16-23 133 160 230 1.9
MSN133-16-28 133 160 280 2.2
MSN133-21-16 133 210 160 1.8
MSN133-21-23 133 210 230 2.3
MSN133-21-28 133 210 280 2.6
MSN133-21-35 133 210 350 3.1
MSN133-26-23 133 260 230 2.6
MSN133-26-28 133 260 280 3.0
MSN133-26-35 133 260 350 3.5
MSN133-32-23 133 320 230 2.9
MSN133-32-28 133 320 280 3.4
MSN133-32-35 133 320 350 4.0
MSN133-32-45 133 320 450 4.9
MSN133-37-23 133 370 230 3.3
MSN133-37-28 133 370 280 3.8
MSN133-37-35 133 370 350 4.4
MSN133-37-45 133 370 450 5.2
MSN133-43-23 133 430 230 3.7
MSN133-43-28 133 430 280 4.2
MSN133-43-35 133 430 350 4.9
MSN133-43-45 133 430 450 6.0
Product no. / Dimensions
English 2016_235_264.indd 241 16/10/19 11:40

242
Product no. H W D Weight (kg)
MSN149-16-16 149 160 160 1.6
MSN149-16-23 149 160 230 2.0
MSN149-16-28 149 160 280 2.4
MSN149-21-16 149 210 160 1.8
MSN149-21-23 149 210 230 2.4
MSN149-21-28 149 210 280 2.7
MSN149-21-35 149 210 350 3.2
MSN149-26-23 149 260 230 2.7
MSN149-26-28 149 260 280 3.1
MSN149-26-35 149 260 350 3.6
MSN149-32-23 149 320 230 3.1
MSN149-32-28 149 320 280 3.5
MSN149-32-35 149 320 350 4.2
MSN149-32-45 149 320 450 5.1
MSN149-37-23 149 370 230 3.4
MSN149-37-28 149 370 280 3.9
MSN149-37-35 149 370 350 4.6
MSN149-37-45 149 370 450 5.4
MSN149-43-23 149 430 230 3.8
MSN149-43-28 149 430 280 4.4
MSN149-43-35 149 430 350 5.1
MSN149-43-45 149 430 450 6.3
MSN177-16-16 177 160 160 1.9
MSN177-16-23 177 160 230 2.4
MSN177-16-28 177 160 280 2.8
MSN177-21-16 177 210 160 2.2
MSN177-21-23 177 210 230 2.8
MSN177-21-28 177 210 280 3.2
MSN177-21-35 177 210 350 3.8
MSN177-26-23 177 260 230 3.2
MSN177-26-28 177 260 280 3.6
MSN177-26-35 177 260 350 4.2
MSN177-32-23 177 320 230 3.5
MSN177-32-28 177 320 280 4.0
MSN177-32-35 177 320 350 4.8
MSN177-32-45 177 320 450 5.8
MSN177-37-23 177 370 230 3.9
MSN177-37-28 177 370 280 4.4
MSN177-37-35 177 370 350 5.2
MSN177-37-45 177 370 450 6.1
MSN177-43-23 177 430 230 4.3
MSN177-43-28 177 430 280 4.9
MSN177-43-35 177 430 350 5.7
MSN177-43-45 177 430 450 7.0
Product no. H W D Weight (kg)
MSN199-16-16 199 160 160 2.0
MSN199-16-23 199 160 230 2.6
MSN199-16-28 199 160 280 2.9
MSN199-21-16 199 210 160 2.3
MSN199-21-23 199 210 230 2.9
MSN199-21-28 199 210 280 3.3
MSN199-21-35 199 210 350 3.9
MSN199-26-23 199 260 230 3.3
MSN199-26-28 199 260 280 3.7
MSN199-26-35 199 260 350 4.4
MSN199-32-23 199 320 230 3.7
MSN199-32-28 199 320 280 4.2
MSN199-32-35 199 320 350 4.9
MSN199-32-45 199 320 450 5.9
MSN199-37-23 199 370 230 4.0
MSN199-37-28 199 370 280 4.6
MSN199-37-35 199 370 350 5.4
MSN199-37-45 199 370 450 6.3
MSN199-43-23 199 430 230 4.5
MSN199-43-28 199 430 280 5.1
MSN199-43-35 199 430 350 5.9
MSN199-43-45 199 430 450 7.2
MSN222-16-16 222 160 160 2.2
MSN222-16-23 222 160 230 2.7
MSN222-16-28 222 160 280 3.0
MSN222-21-16 222 210 160 2.5
MSN222-21-23 222 210 230 3.0
MSN222-21-28 222 210 280 3.4
MSN222-21-35 222 210 350 4.1
MSN222-26-23 222 260 230 3.4
MSN222-26-28 222 260 280 3.8
MSN222-26-35 222 260 350 4.5
MSN222-32-23 222 320 230 3.8
MSN222-32-28 222 320 280 4.3
MSN222-32-35 222 320 350 5.1
MSN222-32-45 222 320 450 6.2
MSN222-37-23 222 370 230 4.2
MSN222-37-28 222 370 280 4.8
MSN222-37-35 222 370 350 5.6
MSN222-37-45 222 370 450 6.6
MSN222-43-23 222 430 230 4.7
MSN222-43-28 222 430 280 5.2
MSN222-43-35 222 430 350 6.1
MSN222-43-45 222 430 450 7.5
Product no. / Dimensions
English 2016_235_264.indd 242 16/10/19 11:40

249
2
5.5mm
Mounting plate
Bottom cover L-bracket
2
13.1mm
Mounting plate
Bottom cover L-bracket
44
7.3
10.6
6
14.5
5
12
14.5
12
4-R2
w12.5
8.5
22 22
d2 d1
1.6
2
13.5mm to rear panel25mm to front panel
4-R3
■1 set = Mounting plate + L-bracket Mounting example
Components
No. Part name Pcs Material Color / Finish
1Mounting plate 1 Aluminium A1050P t=2.0 Unfinished
2L-bracket 2 Steel SPCC Trivalent chromate
Included screws: M4-6 pan head, trivalent chromate x8
Product no. / Dimensions
Product no. w d1d2Enclosure W×D Weight (g)
MSC16-16 130 96.5 91.5 160 × 160 120
MSC16-23 130 166.5 161.5 160 × 230 210
MSC16-28 130 216.5 211.5 160 × 280 270
MSC21-16 180 96.5 91.5 210 × 160 150
MSC21-23 180 166.5 161.5 210 × 230 250
MSC21-28 180 216.5 211.5 210 × 280 330
MSC21-35 180 286.5 281.5 210 × 350 430
MSC26-23 230 166.5 161.5 260 × 230 300
MSC26-28 230 216.5 211.5 260 × 280 390
MSC26-35 230 286.5 281.5 260 × 350 510
MSC32-23 290 166.5 161.5 320 × 230 360
Product no. w d1d2Enclosure W×D Weight (g)
MSC32-28 290 216.5 211.5 320 × 280 460
MSC32-35 290 286.5 281.5 320 × 350 600
MSC32-45 290 386.5 381.5 320 × 450 810
MSC37-23 340 166.5 161.5 370 × 230 410
MSC37-28 340 216.5 211.5 370 × 280 520
MSC37-35 340 286.5 281.5 370 × 350 680
MSC37-45 340 386.5 381.5 370 × 450 910
MSC43-23 400 166.5 161.5 430 × 230 460
MSC43-28 400 216.5 211.5 430 × 280 590
MSC43-35 400 286.5 281.5 430 × 350 770
MSC43-45 400 386.5 381.5 430 × 450 1,040
Product no. / Dimensions
Product no. L a b Sales unit
MSCL-16 91.5 33.75 5 1 set (2 pcs)
MSCL-23 161.5 27.5 81 set (2 pcs)
MSCL-28 211.5 37.5 81 set (2 pcs)
MSCL-35 281.5 51.5 81 set (2 pcs)
MSCL-45 381.5 71.5 81 set (2 pcs)
■ Use with your original mounting plate or PCB.
■1 pair of L-bracket are included with each MSC mounting plate.
Components
Part name Material Color / Finish
L-bracket Steel SPCC Trivalent chromate
22 22 1.6
10.6 12.5
6 8.544.6
b-M4
MSCL-16
12 12a a a
L
a a
MSCL-23
MSCL-28
MSCL-35
MSCL-45
4-R2
12 a a 12
L
1 2
MSC SERIES MOUNTING PLATE for MS • MSN • MSY
MSCL SERIES L-BRACKET for MS • MSN • MSY
■DXF/DWG/PDF drawings available on our website.
Accessories (Optional parts)
English 2016_235_264.indd 249 16/10/19 11:40

252
129.5
197.5
144.5
191.5
Φ3
M4-14 Screw
25
27
11.51.5
Components
No. Part name Pcs Material Color / Finish
1Holder 2PC + ABS Gray • Black
2Blind cap 2 PP + Elastomer Gray • Black
3Grip 1 PP + Elastomer Gray • Black
−Screw 2 Steel Trivalent chromate
−Slide nut 2 Brass : PE Nickel plated : Black
Product no. / Dimensions
Product no. Max load
Gray Black
MY-197G MY-197B 20kgf
■Not suitable for MS series if D = 160mm.
1 2 3
MSN • MSY SERIES INSTALLATION METHOD
Insert the slide nut into the side frame. Adjust the slide nut to the required position.
MSN series installation. MSY series installation.
MY SERIES CARRYING HANDLE
Accessories (Optional parts)
