Takstar ELV-182 User manual

9TLV181S1A
音箱说明书
ELV-182
适用于大型演出扩声系统或DISC酒吧、大型KTV等扩声场合的低频补偿
额定功率：4Ω/2400W(AES) 8Ω/1200W(AES)*2
额定阻抗：8Ω和4Ω（根据接线方式可转换）
频率响应：30Hz-500Hz(±3dB)
灵敏度：102dB
覆盖角度：无指向性
最大声压级：133dB
接线方式：2×NL4speakon，连接1+、1-和2+、2-均可，不建议两
只音箱并联使用
箱壳：18厘夹板
表面处理：黑色催化聚亚安酯漆
低频：18″×2(100芯)，220磁钢
规格（mm）：1206×650×551（W×D×H）
净重：90Kg
音箱箱体采用了18厘夹板制作，音箱前板采用25厘夹板，板材加表
面油漆具有良好的抗潮性能，且内阻尼良好，抗共振能力强。
箱体底部装有五只橡胶脚垫，防止大动态时音箱震动位移。
扬声器元器件采用磁路对称设计，既能保证磁回路有较高的的磁束
密度，又能保证较小的失真。耐高温音圈能承受较大的功率，并且
在承受大功率或长时间工作时，音圈温度上升后性能依然稳定、不
易烧毁，折环和布边的合理选用，使扬声器振动系统有着收放自如
的弹力，即能降低失真又能令扬声器有着良好的瞬态响应 。
1. 确保功率放大器和音箱的功率、阻抗相匹配，失衡搭配可导致设备损
坏或音质效果不佳。
2. 音箱工作时的振幅较大，请不要在箱体上放置物品。
3. 音箱的安装需由专业工程人员进行，应固定牢靠，并选择安装在不易
碰触的位置。
4. 搬运音箱时，请小心轻放，保护好音箱不受损坏。
注：以上数据由得胜实验室测试得到，并拥有最终解释权！
为避免电击、高温、着火、辐射、爆炸、机械危险以及使用不当等可能
造成的人身伤害或财产损失，使用本产品，请仔细阅读并遵守以下事项:
1. 使用产品时请确认所连接设备与本产品功率是否匹配以及合理调整音量
大 小，不要在超过产品功率及大音量下长时间使用，以免造成产品异常
和听力损伤；
2. 使用中若发现有异常（如冒烟、异味等），请立即关闭电源开关并拔掉
电源插头，然后将产品送经销商检修；
3. 本产品及附件都应放置在室内干燥通风处，勿长期存放在潮湿、灰尘多
的环境，使用中避免靠近火源、雨淋、进水、过度碰撞、抛掷、振动本
机及覆盖通风孔，以免损坏其功能；
4. 若产品需要固定于墙壁或天花板上时，请确保固定到位，防止因固定强
度不足导致产品发生跌落危险；
5. 使用该产品时需遵守相关安全规定，法律法规明确禁止使用场合请勿使
用本机，以免导致意外事故；
6. 请不要自行拆机改装或维修，以防止出现人身伤害，如有问题或服务需
求请联系当地经销商跟进处理。
产品特性
欢迎使用ELV系列高品质专业音箱。此款超低音音箱在单元配置方面，
采用了两只18寸220磁钢100芯音圈的高品质低音扬声器，该扬声器单元元
器件选用耐高温音圈和刚性优良的纸盆，箱体外型美观，音箱灵敏度高，
低频厚实并且爆发力强劲震憾。使用前请您仔细阅读说明书，以便能正确
的操作使用。
若存在有疑问或者您有宝贵的建议，可通过拨打得
胜官方服务热线400 6828 333 或微信扫描二维码关注
得胜官方公众号与我们联系。
标准配置
适用场合
技术参数
安全警示
注意事项
ELV-182音箱
说明书
接线方式
8Ω/1200W(AES)*2
两芯2.0平方音箱线缆
(+1,-1)
(+1,-1)
4Ω/2400W（AES）
两芯2.0平方音箱线缆 (+1,-1)
(+2,-2)
(+1,-1)
(+1,-1)

Subwoofer User Manual
ELV-182
Large-scale performances, DISCO bars, KTVs
Rated Power: 4Ω/2400W (AES) 8Ω/1200W (AES)*2
Rated Impedance: 8Ω and 4Ω (switchable based on the wiring)
Frequency Response: 30Hz-500Hz (±3dB)
Sensitivity: 102dB
Coverage: no directivity
Max SPL: 133dB
Connection: 2×NL4speakon, connecting 1+, 1- or 2+, 2- for
operation, no parallel use of two speakers
Enclosure: 18mm plywood
Finish: black painting
LF Unit: 18"×2 (100mm), 220 magnet
Dimensions (mm): 1206×650×551 (W×D×H)
Net Weight: 90Kg
The enclosure of ELV-182 uses 18mm plywood and its baffle uses
25mm plywood. Plywood and paint finish provide good anti-
moisture performance. ELV-182 features good internal damping
and strong anti-resonance ability.
The bottom of the enclosure is equipped with five rubber feet to
prevent the vibration and displacement of the speaker due to the
high dynamic range.
Symmetrical magnetic circuit design is adopted to guarantee
higher magnetic flux density and less distortion. The heat-resistant
voice coil can withstand high power, and when it is under high
power or working for a long time, its performance is still stable
after the temperature rises, and it is not easy to burn. The
reasonable selection of surround and cloth edge provides the
speaker's vibration system with good elasticity, which can reduce
distortion and allow the speaker to have a good transient response.
1. Ensure that the power and impedance of the power amplifier match
with those of the speaker. Unbalanced matching can cause damage
to the equipment or poor sound quality.
2. The amplitude of the speaker is large when it is working. Please do
not place objects on the cabinet.
3. The installation of the speaker should be carried out by engineering
professionals. It should be firmly fixed and installed in a location
that is not easy to access.
4. When transporting the speaker, please handle it carefully to protect
it from damage.
Note: The data is tested by Takstar Laboratory, and Takstar has the final
interpretation right!
To avoid possible personal injury or property damage caused by
electric shock, high temperature, fire, radiation, explosion,
mechanical hazards, and improper use, please read and observe the
following items before using the product.
1. When using the product, please confirm whether the power of the
connected device matches the power of the product, and adjust the
volume of the device. Do not use it for a long time when the power
of the product is exceeded or at a high volume to avoid product
failure and hearing damage.
2. If there is any abnormality (such as smoke, odor, etc.) during use,
please turn off the power switch and unplug the power plug
immediately, and then send the product to the dealer for
maintenance.
3. The product and accessories should be placed indoors in a dry and
ventilated place. Do not store them in a humid and dusty
environment for a long time. Avoid getting close to fire, rain, water,
excessive collision, throwing, vibrating the machine and covering
the ventilation holes during use, so as not to damage its function.
4. If the product needs to be fixed on the wall or ceiling, please make
sure to fix it in place to prevent it from falling.
5. When using the product, you must abide by the relevant safety
regulations. Please do not use the product in the occasions that are
clearly prohibited by laws and regulations to avoid accidents.
6. Please do not disassemble, refit or repair the product by yourself to
prevent personal injury. If you have any questions or service needs,
please contact the local dealer.
Features
Welcome to use ELV-182 high-quality professional subwoofer. It
has two 18-inch high-quality woofers with 220mm magnet and
100mm voice coil. The voice coils are heat-resistant, and the paper
cones are of good rigidity. ELV-182 features elegant contour, high
sensitivity, and rich, powerful bass. Please read the user manual
carefully before use and keep it for future reference.
If you have any questions or suggestions, please contact our local
dealer.
Product Content
Applications
Specifications
Safety Instructions
Cautions
ELV-182 subwoofer
User manual
Wiring
8Ω/1200W(AES)*2
(+1,-1)
(+1,-1)
2.0mm² 2 core speaker cable
4Ω/2400W（AES）
(+1,-1)
(+2,-2)
(+1,-1)
(+1,-1)
