Tala ALM-SPHR-IV-SAP-TBL-01-EU User manual

BEFORE STARTING
Please read instructions thoroughly before installation
and keep them for future reference. Please take
extreme care when dealing with electrical equipment.
IMPORTANT
Bulb must be installed in fixture before turning on.
WARNING
Incorrect assembly may result in risk of fire or electric
shock.
CARE AND CLEANING
We recommend cleaning with a so dry cloth. Do not
use abrasive materials as these will damage the finish
of the product.
AFTERCARE
Please note, the flexible cable attached to this luminaire
cannot be replaced; if the cable is damaged, recycle the
luminaire and seek a replacement.
Thoughul lighting, responsibly designed in London.
Thank you for making the switch to Tala.
Discover the full Tala family at tala.co.uk.
Scan me for more
technical help
INSTALLATION GUIDE
ALUMINA TABLE LAMP
SKU  ALMSPHRIVBLSTBL01EU
SKU  ALMSPHRIVCHKTBL01EU
SKU  ALMSPHRIVCHRTBL01EU
SKU  ALMSPHRIVSAPTBL01EU
SKU  ALMSPHRIVSGETBL01EU
FOR INDOOR USE ONLY
UKEU
IP20 220 - 240V~

STEP 1
Insert your bulb into the top of the lamp,
rotating clockwise until tight. Take
care not to tighten too much to avoid
breakage.
STEP 2  FOR UK ONLY
Insert the EU plug into the UK Adapter,
making sure it clicks-in and does not
come loose.
STEP 4
Switch the power on and rotate the dial
on your dimmer until the bulb lights up.
Adjust the dimmer for your desired light
output.
Table Configuration
STEP 3
Insert the lamp plug into your chosen
wall socket, making sure the power is
switched o.

STEP 1
Remove your bulb from the lamp, rotating
counter clockwise and set aside.
STEP 2
Remove the small lock screw from
the side of the lamp with the hex key
provided.
STEP 3
Slide the lamp towards the cable to
disconnect it from the base.
Li the lamp and set it aside.
Wall Configuration

STEP 4
Attach the base to your wall in the
orientation shown below.
Always choose screws and plugs that are
appropriate for the wall.
STEP 5 OPTIONAL
Customers who wish to hard wire the
product into the household mains.
Please consult a qualified electrician to
peorm this modification.
Junction boxes are not provided.
STEP 6
Move the cable from the top to the
bottom opening .
Wall Conguration

STEP 7
Align the lamp above the base and slide
down to lock in place .
STEP 8
Insert your bulb into the front of the
lamp, rotating clockwise until tight. Take
care not to tighten too much to avoid
breakage.
STEP 9
Re-attach the lock screw using the hex
tool provided.
Tighten until flush with the outside
suace of the lamp . Over-tightening
may result in the screw becoming lost
inside the lamp.
Wall Configuration

STEP 12
Switch the power on and rotate the dial on your
dimmer until the bulb lights up.
Adjust the dimmer for your desired light output.
Wall Configuration
WARRANTY AND AFTERCARE
This product has a two-year warranty. If there appears to be a functional defect with
the product during this time, please contact our team at [e-mail].
STEP 11
Insert the lamp plug into your chosen
wall socket, making sure the power is
switched o.
STEP 10  FOR UK ONLY
Insert the EU plug into the UK Adapter,
making sure it clicks-in and does not
come loose.
