Thank you for purchasing this Tamron lens. Before using your new lens, please read the contents of this Owner’s manual to properly
use the lens. Also, it will be important to read the manual of the camera to which you will attach the lens.
After reading, store this Owner’s manual in a safe place.
Please read also the document “Precautions for Safe Use of Tamron Lenses” supplied with the lens for the detailed safety precautions
to observe when using Tamron lenses.
•Explains precautions that help to prevent problems.
•Explains things you should know in addition to basic operations.
PART NAMES (Refer to Fig. 1)
①Lens hood ②Hood attaching alignment mark
③Hood locking mark ④Filter ring
⑤Hood release mark ⑥Zoom ring
⑦Focal length scale ⑧Focal length mark
⑨Focus ring* ⑩Tripod mount
⑪Tripod mount mark ⑫Tripod mount locking screw
⑬Screw hole for safety lock screw ⑭Safety lock screw (×2)
⑮Hexagonal wrench ⑯Strap hole
⑰Lens attachment mark
⑱AF/MF switch (For Sony E / Nikon Z) / MF SPEED switch (For FUJIFILM X)
⑲VC (Vibration Compensation) switch (For Sony E / FUJIFILM X) / LINEAR/NON-LINEAR switch (For Nikon Z)
⑳VC mode switch (For Sony E / FUJIFILM X) 󰼼Focus limiter switch
󰽇Lens-camera interface contacts 󰽈Wide-end zoom lock switch
󰽉Connector port (For Nikon Z)
* Corresponds to the control ring on Nikon Z mounts.
•Before using the lens, make sure to remove the tape on lens surface.
MAIN SPECIFICATIONS
Model A057
Focal Length 150 - 500 mm
Maximum Aperture F/5 - 6.7
Angle of View (diagonal) 16°25' - 4°57' / 10°59' - 3°18' (APS-C)
Optical Construction 16/25
Minimum Object Distance (MOD) 0.6 m (23.6") (Wide) / 1.8 m (70.9") (Tele)
Maximum Magnification Ratio 1:3.1 (Wide MOD) /1:3.7 (Tele MOD)
Filter Size ø 82 mm
Length 209.6 mm (8.3") / Sony E, 209.9 mm (8.3") / FUJIFILM X, 212.3 mm (8.3") / Nikon Z
Maximum Diameter ø 93 mm
Weight 1,725 g (60.8 oz) / Sony E, 1,710 g (60.3 oz) / FUJIFILM X,
1,720 g (60.7 oz) / Nikon Z (without tripod mount), Tripod mount 155 g (5.5 oz)
Lens Hood HA057
Connector Type (For Nikon Z) USB Type-C
•Length : From front end of the lens to mount surface.
•Specifications, appearance, functionality, etc., are subject to change without prior notice.
ATTACHING AND REMOVING THE LENS
Remove the rear cap of the lens. Align the lens attachment mark ⑰and mounting mark on the camera, and then insert the lens.
Turn the lens clockwise for Sony E / FUJIFILM X mounts or counterclockwise for Nikon Z mounts until it locks.
To remove the lens, turn the lens in the opposite direction while pressing the lens release button on the camera.
•Turn off the power of the camera before attaching or removing the lens.
•For details, please read the instruction manual of your camera.
SWITCHING FOCUS MODE (Ref. Figs. 1, 2, 2
’
)
For Sony E: AF/MF Switching (Ref. Figs. 1, 2)
To shoot using autofocus (AF), set both the camera and the AF/MF switch ⑱on the lens to “AF”. (Ref. Fig. 2) (If the lens is set at
“MF”, it will not autofocus.)
To shoot using manual focus (MF), set the camera and/or the lens AF/MF switch ⑱to “MF”. For manual focus, turn the focus ring
⑨to acquire the focus. (Ref. Figs. 1, 2)
For FUJIFILM X: MF SPEED Switching (Ref. Figs. 1, 2)
When you choose “MANUAL FOCUS” on the camera body, you may select the focus response speed by the selector switch ⑱on
the lens.
MODE 1 For normal focusing, average response speed
MODE 2 For precise focusing, slower response speed
For Nikon Z: LINEAR/NON-LINIER Switching (Ref.Figs. 1, 2 ’ )
Under the MF mode setting, the focusing method of the focus ring ⑨can be changed using the LINEAR/NON-LINEAR switch ⑲.
NON-LINEAR The rotation speed of the focus ring ⑨changes the amount of focus movement.
LINEAR The rotation angle of the focus ring ⑨changes the amount of focus movement.
•Under AF mode, there may be difficulty for autofocus to work depending on the subject.
•For Sony E mount lens, if your camera features an AF/MF control button, it is possible to temporarily switch to MF from AF by
pressing the AF/MF control button. When the lens set to “AF” and the camera set to “MF”, by pressing the AF/MF control button
you may temporarily switch the focus to AF.
•For Nikon Z, under the AF mode setting, the focus ring ⑨will act as “Control Ring” and can apply functions from the camera.
•For details, please read the instruction manual of your camera.
ENGLISH

CONNECTOR PORT (Ref. Fig. 1) *For Nikon Z only
Lenses with the connector port 󰽉can be connected to a computer using the TAMRON connection cable (sold separately). Then, using
the dedicated “TAMRON Lens Utility
TM
” application, you will be able to update the firmware.
See the online help of “TAMRON Lens Utility” using the link below for more details.
https://www.tamron.com/jp/consumer/support/help/lensutility/en/
•Do not use the TAMRON connection cable (sold separately) for any purpose other than connecting the TAMRON lens equipped
with a connector port to a computer.
•Tamron will not bear any responsibility for any loss or damage of data in use of the TAMRON connection cable (sold separately).
VIBRATION COMPENSATION (Ref. Figs. 1, 5, 6)
For Sony E / FUJIFILM X
To compensate for the vibrations, set the VC (Vibration Compensation) switch ⑲to ON. (Ref. Fig. 5)
Switching the modes (Ref. Fig. 6)
You can switch the modes by using the VC mode switch ⑳.
MODE 1 Basic vibration compensation mode
MODE 2 Panning mode
MODE 3 Mode that prioritizes framing. Makes it easier to maintain subjects moving quickly within the frame.
* MODE 1 and MODE 3 do not support panning.
For Nikon Z
For vibration compensation, the lens do not have a switch for vibration compensation, please activate the function from the camera
body.
zVibration compensation is effective under the following conditions
•Dimly lit locations
•Locations where flash photography is prohibited
•Locations where tripod cannot be used
zVibrations may not be compensated sufficiently under the following conditions
•When a photograph is taken from a vehicle that is shaking greatly
•Shooting during excessive movement of the camera
•When shooting while using a tripod
•Set the VC switch ⑲to OFF when taking pictures with bulb photography (long exposures). Otherwise, vibration compensation may
cause a malfunction. (For Nikon Z, the lens do not have a switch for vibration compensation, please activate the function from the
camera body)
•When MODE 1 or MODE 2 is set (For Sony E / FUJIFILM X), the viewfinder image may become blurred immediately after
the shutter button is pressed halfway. This is due to the principles of the vibration compensation mechanism and not a
malfunction. (For Sony E / FUJIFILM X / Nikon Z)
•When MODE 3 is set, the viewfinder image may become blurred even without touching the shutter button in the case the
camera is turned on with the VC switch ⑲set to ON. This is due to the principles of the vibration compensation mechanism and
not a malfunction. (For Sony E / FUJIFILM X)
•Set the VC switch ⑲to OFF when you are shooting while the camera is secured by something other than your hand (such as
a tripod). (For Nikon Z, the lens do not have a switch for vibration compensation, please activate the function from the camera
body)
•You may feel the lens rattle when the camera is turned off or when the lens is removed from the camera. This is not a
malfunction.
•For details, please read the instruction manual of your camera.
FOCUS LIMITER (Ref. Figs. 1, 7- 9for Sony E / 7’ - 9’ for FUJIFILM X / Nikon Z)
When autofocus is set, switching the focus limiter switch 󰼼can speed up focusing by limiting the focus range.
For Sony E mount lens
To limit the autofocus range to subjects from infinity to 3 m (Ref. Fig. 7)
Set the focus limiter switch 󰼼to “∞-3m”.
To limit the autofocus range to subjects from infinity to 15 m (Ref. Fig. 8)
Set the focus limiter switch 󰼼to “∞-15m”.
To use the full focus range (Ref. Fig. 9)
Set the focus limiter switch 󰼼to “FULL”.
For FUJIFILM X / Nikon Z mount lens
To limit the autofocus range to subjects from MOD* to 10 m (Ref. Fig. 7’ )
Set the focus limiter switch 󰼼to “MOD-10m”.
* MOD: Minimum Object Distance
To limit the autofocus range to subjects from 10 m to infinity (Ref. Fig. 8’ )
Set the focus limiter switch 󰼼to “10m-∞”.
To use the full focus range (Ref. Fig. 9’ )
Set the focus limiter switch 󰼼to “FULL”.
ZOOMING (Ref. Fig. 1)
Turn the zoom ring ⑥to adjust the focal length (Zoom position) to a desired position.
WIDE-END ZOOM LOCK (Ref. Figs. 1, 3, 4)
You can lock the zoom ring ⑥at a focal length of 150 mm to keep it from rotating.
Setting the zoom lock (Ref. Fig. 3)
Align 150 mm on the focal length scale ⑦with the focal length mark ⑧.
Set the wide-end zoom lock switch 󰽈to the zoom ring side.
Releasing the zoom lock (Ref. Fig. 4)
Set the wide-end zoom lock switch 󰽈to the camera side.
•To zoom, release the lock, and then rotate the zoom ring ⑥.

FLEX-ZOOM LOCK (Ref. Figs. 1, 󱯠, 󱧂)
This mechanism is intended to stop the lens from zooming inadvertently at any position.
Rotate the zoom ring ⑥to the desired zoom position, and then apply the lock after you have determined the position.
Setting the zoom lock (Ref. Fig. 󱧁)
Move the zoom ring ⑥to the subject side until the white mark is visible.
Releasing the zoom lock (Ref. Fig. 󱧁)
Move the zoom ring ⑥to the camera side.
•During activities such as carrying the product, use the wide-end zoom lock to prevent zooming due to its own weight. (Ref.
Figs. 1, 3)
•To zoom, release the flex-zoom lock, and then rotate the zoom ring ⑥.
•Take care not to get your fingers caught while you switch the flex-zoom lock.
•If the camera will not be used for an extended period, release the flex-zoom lock before storage.
LENS HOOD (Ref. Figs. 1, 󱧃, 󱧄)
A bayonet-type lens hood ①is provided as standard equipment.
We recommend shooting with the hood properly attached because the lens hood eliminates stray light that may affect the picture.
Using the lens hood (Ref. Fig. 󱧃)
Align the hood attaching alignment mark ②of the hood with the hood release mark ⑤of the lens.
Rotate the hood ①in the direction of the arrow until the hood locking mark ③meets the hood release mark ⑤.
Stowing the lens hood (Ref. Fig. 󱧄)
You can stow the lens hood ①by attaching it in reverse.
Align the hood locking mark ③of the hood with the hood release mark ⑤of the lens.
Rotate the hood ①in the direction of the arrow until the hood attaching alignment mark ②meets the hood release mark ⑤.
•Be aware that the periphery of the photographed image may be darkened if the hood ①is not attached properly.
TRIPOD MOUNT (Ref. Figs. 1, 󱧅- 󱧇)
The A057 model comes with a tripod mount ⑩. When you use a tripod, lock the lens firmly to the tripod using the tripod mount ⑩.
Attaching and removing the tripod mount (Ref. Figs. 󱧅, 󱧇)
You can attach and remove the tripod mount by loosening tripod mount locking screw ⑫and then lift the portion with the screw, to
open the ring.
When attaching the tripod mount, make sure that the protruding part on the inner side of the tripod mount ⑩is inserted into the
groove on the lens, and then tightly secure the tripod mount locking screw ⑫.
If this protruding part is not inserted into the groove on the lens correctly when attaching the tripod mount ⑩, the lens may be
damaged or fall off.
Changing the directional position of the camera (Ref. Fig. 󱧆)
When you change the directional position of the camera, you can rotate the lens by loosening the tripod mount locking screw ⑫.
Align the tripod mount mark on the lens ⑪with the mark on the tripod mount ⑩.
After determining the shooting position, tightly secure the tripod mount locking screw ⑫to fix the position.
Strap hole (Ref. Fig. 1)
You may pass a strap through these holes to prevent the lens from falling.
When using the strap holes ⑯of the tripod mount ⑩, first check that the tripod mount locking screw ⑫is firmly tightened, and
then attach the strap securely. Note that the lens may fall if the tripod mount ⑩or the strap detaches from the lens.
•The A057 tripod mount ⑩can be attached to an ARCA-SWISS camera platform.
SAFETY LOCK SCREW (Accessory for the tripod mount) (Ref. Figs. 1, 󱧈)
We recommend attaching the lock screws in accordance with the camera platform type when you use an ARCA-SWISS-standard
compatible camera platform or clamp.
How to use safety lock screws (Ref. Fig. 󱧈)
The safety lock screws ⑭prevent the lens/camera from falling from the camera platform when a tripod mount ⑩is attached to an
ARCA-SWISS-standard compatible camera platform or clamp.
As shown on the figure, use the hexagonal wrench ⑮to tighten the safety lock screws ⑭to the two screw holes ⑬.
•After attaching the safety lock screws ⑭, the screw heads protrude from the tripod mount ⑩bottom surface to prevent the lens/camera
from falling. For this reason, if you are using a camera platform or a clamp other than ARCA- SWISS-standard compatible, you do not
need to have them attached.
USAGE PRECAUTIONS
•An internal focusing (IF) system is employed to reduce the minimum focus distance. The angle of view may be wider than that of
lenses with other focusing systems when shooting at a distance less than infinity.
•The lens hood or the lens barrel may block the light from the flash. It is recommended to perform trial shooting in advance.
•Differences in the display systems of cameras may cause to show values different from the maximum and minimum aperture values
from the specifications. This is not an indication of an error.
•Do not touch the lens-camera interface contacts 󰽇with your fingers. Otherwise, it may cause a malfunction.
•If the temperature changes suddenly, condensation may form and cause malfunctions.
•The front lens is covered with stain-proof coating. After removing the dust on the lens surface with a blower or another means, wipe it
with a dry cloth.
•Never use benzene, thinner, or other organic solvents to clean the lens.
•Store the lens in a clean and well-ventilated place.
•For more details on the lens cleaning and storage, the compatibility with cameras, and other support information see our website.
https://www.tamron.com/global/consumer/support/

Disposal of Electrical and Electronic Equipment in Private Households. Disposal of used Electrical &
Electronic Equipment (Applicable in the European Union and other European countries with separate
collection systems)
This symbol indicates that this product shall not be treated as household waste.
Instead it shall be collected separately for the recycling of electrical and electronic equipment.
If the new products are purchased, this product might be handed over to the distributor or the collection system
of waste electrical and electronic equipment eventually.
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product or components of this product.
If this product is disposed illegally, it might cause a possibility of penalties. For more detailed information about recycling of this product,
please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

For safe operation be sure to carefully read this "Precautions for Safe Use of Tamron Lenses" and the
manual before using the product.
After reading them, store them in a place where they can easily be reviewed whenever needed.
Caution instructions are divided into the following two categories according to the degree of danger
involved.
•Do not view the sun or other strong light source directly through the lens or through a camera
while using this lens.
Doing so could cause loss of vision, damage to the lens and/or the camera, and possibly cause
the lens and/or camera to ignite.
•Do not dissemble, repair, or modify the lens.
This could damage the lens or camera.
•Keep the lens out of the reach of small children.
There is a risk of injury if the lens is dropped or falls down.
TPL- EN -L e ns -T-2301
This indicates instructions which if not followed or if performed
incorrectly could lead to death or serious injury.
Precautions for Safe Use of Tamron Lenses
ENGLISH
WARNING
•Do not place lens in direct sunlight or leave it in an extremely hot place such as inside a car. Doing
such could damage the internal parts of the lens or cause a fire.
•Always attach the lens cap whenever the lens is not in use.
•When attaching the lens to the camera, ensure that the lens has been properly attached to the
camera and firmly locked.
If the lens is not attached properly, it could be difficult to remove or it could fall off causing damage
or injury.
•Do not use this lens for any application other than photography.
•Do not carry around the lens while it is still attached to a tripod.
•Regarding the lens equipped with a connector port
1) Place the lens in a stable location when customizing the lens using the dedicated application
(TAMRON Lens Utility TM). Make sure not to let it fall or impact the lens.
2) When connecting the lens to a computer, use a Tamron connection cable (sold separately).
3) Do not touch the connector port with your fingers or a metal object. Also, prevent dust or water
from adhering to the connector port. If the connector port is dirty, it may cause connection
problems.
•Tamron will not be responsible for damages caused by a failure, a fire, or other accidents that may
occur when using an accessory other than Tamron accessories. Note that in case of such damage,
repair of the Tamron lens will be charged since it is not covered by the warranty.
This indicates instructions which if not heeded or if performed
incorrectly could lead to bodily injury or physical damage
CAUTION
