Tascam US-144 User manual

US-144
USB Audio/MIDI Interface
D00927520E
OWNER'S MANUAL

2TASCAM US-144
IMPORTANT SAFETY INSTRUCTIONS
Declaration of Conformity
Model Number: US-144
Trade Name: TASCAM
Responsible party: TEAC AMERICA, INC.
Montebello, California, U.S.A.
Telephone number: 1-323-726-0303
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received,
including interference that cause undesired opera-
tion.
This appliance has a serial number
located on the rear panel. Please
record the model number and serial
number and retain them for your
records.
Model number
Serial number
TO THE USER
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio fre-
quency energy and, if not installed and used
in accordance with the instruction manual,
may cause harmful interference to radio com-
munications.
However, there is no guarantee that interfer-
ence will not occur in a particular installation.
If this equipment does cause harmful interfer-
ence to radio or television reception, which
can be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures.
a) Reorient or relocate the receiving anten-
na.
b) Increase the separation between the
equipment and receiver.
c) Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
d) Consult the dealer or an experienced
radio/TV technician for help.
CAUTION
Changes or modifications to this equip-
ment not expressly approved by TEAC
CORPORATION for compliance could void
the user's authority to operate this equip-
ment.
For U.S.A.

TASCAM US-144 3
IMPORTANT SAFETY PRECAUTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings.
Install in accordance with the manufac-
turer's instructions.
8 Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that pro-
duce heat.
9 Only use attachments/accessories speci-
fied by the manufacturer.
10 Use only with the cart, stand, tripod, brack-
et, or table specified by the manufacturer,
or sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
 • Do not expose this apparatus to drips or
splashes.
 • Do not placeanyobjects filled withliquids,
such as vases, on the apparatus.
 • Do not install this apparatus in a confined
space such as a book case or similar unit.
Microsoft, Windows, Windows XP, and*
Windows Vista are either registered
trademarks or trademarks of Microsoft
Corporation in the United States and/or
other countries.
Macintosh, Mac OS and Mac OS X are*
trademarks of Apple Inc., registered in
the U.S. and other countries.
Pentium is a trademark of Intel*
Corporation in the U.S. and other coun-
tries.
AMD Athlon is a trademark of*
Advanced Micro Devices, Inc.
Other company names and product*
names in this document are the trade-
marks or registered trademarks of their
respective owners.

4TASCAM US-144
IMPORTANT SAFETY INSTRUCTIONS
Contents
1 – Introduction................ 5
Overview ......................... 5
Features ........................... 5
A note about computer
opera tion.......................... 5
What is in the package ... 5
Conventions used in this
manual.................... 6
2 – Parts of the US-144..... 7
Top panel ......................... 7
Rear panel........................ 8
Front panel ...................... 9
3 – Installation.................10
System requirements .... 10
Windows ..........................10
Mac OS X ..........................10
Installing the drivers ..... 11
Installing the drivers for
Windows....................11
Installation procedure ...... 11
Installing the drivers for
Mac OS X....................12
Settings on your
computer........................ 12
4 – Control panel
settings ................13
Overview ....................... 13
Status section .................... 13
Driver settings ............... 13
Audio Performance .........13
Digital Output Format ....14
Sample Clock Source .......14
5 – Connections...............15
USB connections............ 15
Audio connections ........ 15
Mic ...................................... 15
Guitar.................................. 16
Keyboard & etc. (analog
connection) ................... 16
Sound module / MD / CD etc.
(digital connection) ...... 16
Analog record player ........ 16
Speakers/headphones ...... 17
MIDI connections .......... 17
6 – MIDI Implementation
Chart ....................18
7 – Specifications and
performance ........19
Audio specifications...... 19
Audio performance ....... 20
Other characteristics ..... 20
Physical characteristics. . 21
Dimensions .................... 22

TASCAM US-144 5
1 – Introduction
Please read this owner’s manual carefully
before you begin using the US-144, and use
the product correctly as directed in order to
ensure long and trouble-free enjoyment of
all its functionality.
After you have read this manual, keep it
nearby for reference when required.
We can accept no responsibility for any
loss of the data you record using this prod-
uct onto other MIDI equipment in your
system or onto storage devices such as hard
disk.
Overview
The US-144 is a USB-based audio interface
designed for use with Digital Audio
Workstation (DAW) software. It provides a
four-input, four-output 24-bit 96 kHz audio
interface and a 16-channel MIDI interface.
Because the US-144 is USB-based, it is the
ideal companion to any desktop- or laptop-
based digital recording setup. And since
the US-144 operates using only USB
power, you can use it with a laptop com-
puter to create a very compact and portable
digital audio workstation system.
The US-144 is also an ideal way to capture
analog sources such as records or cassette
tapes into your computer and preserve
them as audio CDs.
Features
24-bit / 96 kHz audio interface.•
Analog input signals (L, R) and digital•
input signals (L, R) can be input at the
same time and recorded simultaneously
into your computer via USB.
Two XLR mic/line inputs (balanced) and•
two 1/4” phone mic/line inputs (bal-
anced/unbalanced) are provided. One of
the 1/4” phone inputs can be switched to
allow direct input of an electric guitar or
electric bass (R channel only).
Stereo digital input jack and stereo digi-•
tal output jack.
Unbalanced stereo line output (RCA•
connector) and headphone output.
MIDI IN/OUT.•
Direct Monitor function allows zero-•
latency monitoring of the input.
Power is supplied by the USB connector.•
A note about computer opera tion
If you are unsure about how to perform
basic computer operations appearing in
this manual, please refer to the owner’s
manual that came with your computer.
What is in the package
The US-144 package contains the follow-
ing items.
US-144 main unit•
USB cable•
Owner’s manual (this document)•
CD-ROM• ( containing drivers and manuals )
DVD-ROM (• Cubase LE4)
Cubase LE4 Quick Start Guide•

6TASCAM US-144
1 – Introduction
Conventions used in this manual
The following conventions are used in this
manual:
Front panel keys, knobs, and indicators,
and rear panel connectors are designated in
all-capital letters.
Example: LINE IN jacks
This typeface is used to designate messag-
es displayed by the software.
Example: Control Surface Protocol
This typeface is used to designate software
menu functions and on-screen controllers.
Example: ASIO Device

TASCAM US-144 7
2 – Parts of the US-144
Top panel
1LINE OUT level knob Controls the
output level of the LINE OUT jacks.
2PHONES LEVEL knob Controls the
output level of the PHONES jack.
3MIDI IN indicator Lights when MIDI
data is being received at the MIDI IN con-
nector.
NOTE
A device that transmits the MIDI Active
Sense message will cause this indicator
to blink constantly. To stop the blinking,
disable the use of MIDI Active Sense on
the sending device, if possible.
3MIDI OUT indicator Lights when
MIDI data is being transmitted from the
MIDI OUT connector.
4USB indicator Lights to indicate a
valid USB connection to the host computer.
5MON MIX balance knob Controls
the balance of the signal sources being out-
put from the LINE OUT jacks and the
PHONES jack. When this knob is turned to
the far left, the signal being input to the
US-144 (from the XLR jacks, or 1/4” phone
jacks) will be output. When this knob is
turned to the far right, the output signal
received from the computer via USB will
be output.
6MONO switch Turn this switch ON
if you want to monitor in monaural. This
switch affects only the analog input signal.

8TASCAM US-144
2 – Parts of the US-144
7INPUT knobs (L, R) Adjust the level
of the audio signal being input to the MIC
IN jacks and LINE IN jacks.
8SIG/OL indicators Light when sig-
nals are being input to the input channels
(L, R). They will light green to indicate a
signal is present, and will light red imme-
diately before distortion occurs. These
indicators apply only to the analog inputs.
NOTE
These indicators will light green when
the input signal level is in the range of
-30 dBFS to -2 dBFS. The indicators will
light red when the input signal level
exceeds -2 dBFS.
9MIC/LINE-GUITAR select switch Set
this switch as appropriate for the input
source you have connected to the LINE IN
jack R channel. Use the GUITAR position if
you have directly connected an electric
guitar or electric bass. Use the MIC/LINE
position if you have connected an electronic
musical instrument, audio device, or mic.
0PHANTOM switch Turns on the
+48V phantom power supplied to the MIC
IN jacks.
WARNING
Microphones should not be connected
to or disconnected from the US-144
with phantom power switched on.
Unbalanced dynamic microphones
should never be connected to phantom-
powered connectors.
NOTE
Turn this switch on only if you are using
condenser microphones that require
phantom power.
Please note that if you are operating
the unit with a battery-powered laptop
computer, the battery life of the com-
puter will be reduced if the PHANTOM
switch is on.
Rear panel
qUSB connector Use a USB cable to
connect this to the host computer’s USB
2.0 port. The US-144 obtains power from
the host computer via the USB cable. In
rare cases, a computer’s USB port may not
be able to supply enough power to operate
the US-144. If this occurs, consider pur-
chasing a USB 2.0 hub that comes with its
own external power supply.
NOTE
If the US-144 is operating with a USB 1.1
(Full Speed) connection, only two chan-

TASCAM US-144 9
2 – Parts of the US-144
nels of recording/playback will be avail-
able, and the sample rate choices will be
limited to 44.1 kHz and 48 kHz. Use the
control panel to select whether the ana-
log or digital inputs will be used.
wMIDI OUT connector Transmits
MIDI messages.
eMIDI IN connector Receives MIDI
messages.
rLINE OUT L/R jacks (RCA connector,
unbalanced) These are analog stereo out-
put jacks.
tDIGITAL IN jack This is an RCA con-
nector that inputs a stereo S/PDIF digital
signal.
yDIGITAL OUT jack This is an RCA
connector that outputs a stereo S/PDIF dig-
ital signal.
NOTE
The US-144's DIGITAL IN/OUT jacks
allow simultaneous input and output at
24-bit/96 kHz.
Front panel
uMIC IN (L, R) jacks (XLR balanced)
These are analog mic input jacks. The wir-
ing is as follows: pin 1 = ground, pin 2 =
hot, pin 3 = cold.
iLINE IN (L, R) jacks (TRS 1/4” phone
jacks) These are balanced line input jacks.
The Rchannel also accommodates guitar
input. If the top panel MIC/LINE-GUITAR
select switch is in the GUITAR position, the
Rjack operates as an unbalanced input jack
for guitar.
If the MIC/LINE-GUITAR select switch is in
the MIC/LINE position, the Rjack operates
as a balanced input jack. (Sleeve = ground,
tip = hot, ring = cold)
oPHONES jack (stereo 1/4” phone)
This is a headphone output jack.

10 TASCAM US-144
3 – Installation
System requirements
Windows
Supported operating system:
32-bit Windows XP SP2 and 32-bit
Windows Vista
Recommended system: Pentium or AMD
Athlon 1 GHz or faster (or equivalent pro-
cessor), 512 MB or more memory, USB 2.0
port
These requirements are for when using
Cubase LE4. If you are using other appli-
cation software, you will need to consult
the operating requirements for the software
you are using.
NOTE
The number of usable audio tracks will
depend on the speed of your hard disk.
The faster your hard disk, the better
your results will be.
If the US-144 is operating with a USB 1.1
(Full Speed) connection, only two chan-
nels of recording/playback will be avail-
able.
We recommend that you have at least
512 MB of memory, but when using dig-
ital audio application software, the
more memory you have the happier you
will be.
Although this product has been checked
for use with typical computers that meet
the above operating requirements, we
cannot guarantee that it will operate
with all computers that meet these
requirements. Please be aware that even
under the same conditions, processing
capability may vary depending on differ-
ences of the design and system.
Mac OS X
Macintosh computer with a USB 2.0•
connector
Mac OS X 10.3.9 & higher on PowerPC•
Mac systems
For Macintosh as well, the more memory
you have and the faster your hard disk, the
happier you will be when using digital
audio application software

TASCAM US-144 11
3 – Installation
Installing the drivers
In order to use the US-144, you must install
the appropriate drivers into your computer.
As described below, this is an easy process
using the CD-ROM included with the
US-144.
Drivers are updated from time to time. You
can download the most recent version of
the drivers from the TASCAM website
<http://www.tascam.com/>.
Do not connect the US-144 to your com put-
er before you have installed the drivers.
CAUTION
Handle the enclosed CD-ROM with care.
If the disc becomes scratched or dirty,
your computer may be unable to read it
and the software cannot be installed. If
the disc becomes unreadable, a fee will
be charged for its replacement.
WARNING
Never attempt to play the enclosed
CD-ROM in a conventional audio CD
player, as the resulting noise may dam-
age your speakers or your hearing.
Installing the drivers for Windows
The US-144’s drivers are provided on the
CD-ROM as an executable installer enti-
tled US-122L & US-144 driver x_yy.exe
(x_yy is the version number.) Installation
of the drivers requires that you run this
installer before plugging in your US-144
for the first time. If you do happen to plug
in your US-144 before running the install-
er, the Add New Hardware wizard will
appear. In this case, simply unplug the
US-144, cancel all the Add New Hardware
wizard windows, and run TASCAM’s driv-
er installer.
Installation procedure
Make sure that the US-144 is not con-1
nected to your computer.
Double-click the executable installa-2
tion file US-122L & US-144 driver x_
yy.exe. The installer will start up.
Select the desired language from the3
menu and click the OK button. A dia-
log box will appear.
Click the4 Install the Driver button and
follow the instructions on the screen.
The drivers will be installed.
NOTE
During driver installation, a warning
that this software ... has not passed
Windows Logo testing will appear. If this
message appears, click Continue to pro-
ceed with the installation.

12 TASCAM US-144
3 – Installation
Installing the drivers for Mac OS X
The US-144’s drivers are provided on the
CD-ROM as a package file entitled
US-122L& US-144 driver x_yy.mpkg. (x_
yy is the version number.) Simply double-
click on this package file’s icon to launch it
and follow the directions that appear on
your screen.
Settings on your computer
Here are a few basic points to help you set
up your computer for best performance
with audio applications.
Do not run other applications. You will•
probably use your computer for applica-
tions other than audio, but we recom-
mend that you avoid running other appli-
cations at the same time you are running
audio programs. Processing digital audio
places a considerable load on your com-
puter.
This means that if you are running other
applications (especially graphics or
Internet tools) at the same time as your
audio application, the processing may
not happen fast enough.
Certain devices such as network cards or•
WinModems can cause conflicts with
USB processing. If you experience such
a conflict, you can use the Device
Manager to temporarily disable the
offending device.
If your computer has an IDE hard disk,•
enabling Direct Memory Addressing
(DMA) will improve performance. In
Windows XP and Windows Vista, this is
enabled by default.

TASCAM US-144 13
IMPORTANT SAFETY PRECAUTIONS
Overview
4 – Control panel settings
The Control Panel lets you make vari ous
settings for the US-144’s functionality.
On Windows XP and Windows Vista, the
US-122L & US-144 Control Panel shortcut
can be found in the Windows Start menu in
the Windows control panel and also under
All Programs\TASCAM\US-122L &
US-144.
On Mac OS X, the US-122L & US-144
Control Panel is located in the
Applications folder. Other useful audio and
MIDI settings for Mac OS X can be found
in Applications/Utilities/Audio MIDI
Setup.
The Control Panel is divided into the fol-
lowing two sections.
Status section
This shows the current status of the driver
and the connected hardware.
You cannot edit the settings from this sec-
tion.
Setting section
You can edit the various settings of the
driver.
Driver settings
Audio Performance
The US-144 driver temporarily stores input
and output audio samples in buffers. The
size of these buffers can be adjusted.
A smaller buffer size will reduce the delay
when monitoring the audio signal, but will
require your computer to perform the pro-
cessing faster. If the processing does not
occur in time (e.g., if other system opera-
tions are occurring), you may hear clicks,
pops, or dropouts in the audio signal.
A larger buffer size provides more safety
against such problems caused by other sys-
tem activities, but will produce greater
delay when monitoring the audio signal.
You select the buffer size that works best
for your system.
On the Windows version of the US-144
Control Panel, the Audio Performance set-
ting permits you adjust the buffer size that
will be used by all audio applications. The
Lowest Latency setting is the minimum
buffer size, and the Highest Latency set-
ting is the maximum buffer size.
On Mac OS X, the buffer size is deter-
mined by each audio application.
Consequently, there is no Audio
Performance setting on the Mac OS X ver-
sion of the US-144 Control Panel. Some
applications select the buffer size automati-
cally while others permit the user to select
the buffer size. Please consult your audio
application’s documentation for details.

14 TASCAM US-144
4 – Control panel settings
Sample Clock Source
You can set the clock source to Automatic
or Internal.
Automatic (default): If a signal is being
input to the DIGITAL IN jack, its clock will
be used. If no signal is being input to the
DIGITAL IN jack, the US-144’s internal
clock will be used.
Internal: The US-144’s internal clock will
always be used.
This lets you choose either AES/EBU or
S/PDIF as the digital output format.
Many professional devices use an XLR
connector for AES/EBU. Special adapters
may be purchased to convert between a
digital audio RCA connector and digital
audio XLR connector.
USB 1.1 Mode Input Selection
This item is shown only if the US-144 is
connected to a USB 1.1 port on the host
computer or to a USB 1.1 hub. In this case,
the US-144 functions as a 2-in / 2-out
audio device, rather than the usual 4-in /
4-out. You can choose either Analog or
Digital as the input source.
Digital Output Format

TASCAM US-144 15
5 – Connections
USB connections
Using the included cable, connect the
US-144 to your computer as shown in the
illustration.
NOTE
Some USB devices access the USB bus
frequently. To avoid dropouts and clicks
in the audio signal, we strongly recom-
mend that you do not connect other
USB devices to the USB bus used by the
US-144.
USB keyboards and mice are exceptions
to this, and will probably not cause
problems.
USB
Computer
Audio connections
Connect the output signal of your mic, gui-
tar, keyboard, or other audio device to the
US-144, where it will be converted into
digital audio and sent via USB to your
computer. Connect the output of the
US-144 to your speakers (via an amp) or
headphones, so you will be able to monitor
the audio signals coming into the US-144
or being produced by your computer.
NOTE
The US-144 has two input channels (L,
R), with a MIC IN jack (XLR) , LINE IN
and LINE/GUITAR IN jack (1/4” phone
jack) provided for each channel. Do not
connect signals to both of these analog
input jacks at the same time. If both are
connected, the signal will not be cor-
rectly input to the US-144.
Mic
Connect your mics to the MIC IN (L, R)
jacks (XLR). If you are using a condenser
mic that requires phantom power, turn on
the phantom power.
If you're using a
condenser mic

16 TASCAM US-144
5 – Connections
Guitar
Connect your guitar to the R-channel LINE/
GUITAR IN jack (1/4” phone jack) and set
the MIC/LINE-GUITAR switch to GUITAR.
Keyboard / drum machine /
sound module / cassette
deck / MD / CD etc. (analog
connection)
Connect the analog audio output of these
devices to the LINE IN L or LINE/GUITAR
IN Rjacks (1/4” phone jack). If you use the
R-channel, set the MIC/LINE-GUITAR
switch to MIC/LINE.
Sound module / MD / CD etc.
(digital connection)
Connect the digital audio output of these
devices to the DIGITAL IN jack.
NOTE
The US-144’s digital input jack is an RCA
connector.
Analog record player
The output of an analog record player can-
not be connected directly to the US-144.
You must connect a phono amp between
your analog record player and the US-144.
(Alternatively, you can connect it via an
audio amp that has PHONO inputs.)
Guitar
Keyboard /
drum machine /
sound module /
cassette deck /
MD / CD or similar device
OUT
DIGITAL OUT
DIGITAL IN
Sound module /
MD / CD or similar device
Analog record
player
OUT
Phono amp or
amp with PHONO input

TASCAM US-144 17
5 – Connections
Speakers/headphones
Headphones Powered speakers,
or amp and speakers
MIDI connections
Connect your sound module, keyboard/
synthesizer, drum machine, or other MIDI
device to the US-144 as shown below.
You can use the MIDI IN/MIDI OUT con-
nectors to transmit and receive MTC
(MIDI Time Code). This allows the MTC-
compatible DAW (Digital Audio
Workstation) computer application to syn-
chronize with your MIDI equipment.
USB
Computer
MIDI OUT
MIDI IN
Sound module etc.
Keyboard /
synthesizer etc.
USB
MIDI OU
T
MIDI IN
Computer
Sequencer /
drum machine etc.

18 TASCAM US-144
IMPORTANT SAFETY INSTRUCTIONS
Function Transmitted Received Remarks
Basic Channel At power ON
Changed
X
X
X
X
Through
Mode At power ON
Messages
Altered
X
X
*************
X
X
Through
Note
Number Range
X
*************
XThrough
Velocity Note ON
Note OFF
X
X
X
X
Through
After Touch Polyphonic
Channel
X
X
X
X
Through
Pitch Bender X X Through
Control Change X X Through
Program Change
Range #
X
*************
XThrough
System Exclusive X X Through
System Common :Song Pos
:Song Sel
:Tu n e
X
X
X
X
X
X
Through
System
Real Time
:Clock
:Commands
X
X
X
X
Through
Other :Local on/off
:All note off
:Active sensing
:Reset
X
X
X
X
X
X
X
X
Through
Notes
Mode 1: Omni on, Poly Mode 2: Omni on, Mono O:Yes
Mode 3: Omni off, Poly Mode 4: Omni off, Mono X:No
6 – MIDI Implementation Chart

TASCAM US-144 19
7 – Specifications and performance
Audio specifications
Nominal input levels
MIC IN L and R (XLR balanced) –58 dBu ( TRIM =max) to –14 dBu
( TRIM =min)
LINE IN L and LINE/GUITAR IN R in
MIC/LINE position (1/4” jack, balanced)
–40 dBu ( TRIM =max) to +4 dBu
( TRIM =min)
LINE/GUITAR IN R in GUITAR
position (1/4” jack, unbalanced)
–51 dBu ( TRIM =max) to –7 dBu
( TRIM =min)
Maximum input levels
MIC L and R (XLR balanced) +2 dBu ( TRIM =min)
LINE IN L and LINE/GUITAR IN R in
MIC/LINE position (1/4” jack, balanced)
+20 dBu ( TRIM =min)
LINE/GUITAR IN R in GUITAR
position (1/4” jack, unbalanced)
+9 dBu ( TRIM =min)
Input impedance
MIC IN L and R (XLR balanced) 2.4 kΩ
LINE IN L and LINE/GUITAR IN R in
MIC/LINE position (1/4” jack, balanced)
10 kΩ
LINE/GUITAR IN R in GUITAR
position (1/4” jack, unbalanced)
1 MΩ
Nominal output level
LINE OUT (RCA unbalanced) –10 dBV
Maximum output level
LINE OUT (RCA unbalanced) +6 dBV
Output impedance
LINE OUT (RCA unbalanced) 100 Ω
Maximum output power
PHONES (1/4” stereo jack) 14 mW + 14 mW (32 Ω)

20 TASCAM US-144
7 – Specifications and performance
Audio performance
Signal-to-noise ratio
LINE IN (through ADC and DAC) to LINE
OUT
> 96 dB (A-weighted, TRIM =min., input
impedance at 40 Ω)
LINE IN (through direct monitor) to LINE
OUT
> 100 dB (A-weighted, TRIM =min., input
impedance 40 Ω)
Total harmonic distortion (THD+N, 22 Hz to 22 kHz)
LINE IN (through ADC and DAC) to LINE
OUT
< 0.006% (1 kHz sine +20 dBu input,
TRIM =min.)
LINE IN (through direct monitor) to LINE
OUT
< 0.004% (1 kHz sine +20 dBu input,
TRIM =min.)
Other characteristics
Digital audio
A/D Conversion (AK5381) 24-bit/96 kHz
D/A Conversion (AK4384) 24-bit/96 kHz
Digital IN
Connector RCA pin jack
Signal format IEC60958 Consumer (S/PDIF)
Level 0.5Vpp/75Ω
Digital OUT * The digital output is not used with Windows Media player
Connector RCA pin jack
Signal format Selectable in the Control Panel between IEC60958
Consumer (S/PDIF) and IEC958 Professional (AES/EBU)
Level 0.5Vpp/75Ω
MIDI
MIDI IN and MIDI OUT ports (DIN 5-pin) Conform to MIDI standards
