Product code: ABM050
AMBIENT
Slim LED Illuminated Mirror
Installation & Aftercare Instructions
Retain for future reference AO|02.19|V1
© Tavistock Bathrooms. 2019
Tavistock Bathrooms, Brassmill Lane Trading Estate, Bath, BA1 3JF
TEL: [phone] | [email protected]
www.tavistock.co.uk
Product code: ABM060

PAGE 2 PAGE 7
Page 2 Page 7
DO NOT connect
to a plug & socket outlet.
WIRING DIAGRAM - MAINS SUPPLY
COLOUR CODING:
L - Live = Brown
N - Neutral = Blue
- Earth = Green & Yellow
22
2
OUTSIDE
ZONES
2
ZONE
1
0.75m
2.25m
3.0m
0.6m
0.6m
0.75m
IEE Bathroom Zones Diagram
Distances from a bath tub or shower tray
Bathroom fittings are subject to the appropriate zones in accordance with IEE
Regulations. This product is only suitable for permanent indoor installation in Zone 2
and outside zones. (See above) This product is not suitable for installation in Zone 0
or 1, saunas, steam rooms or shower cubicles. Do not connect to a trailing plug and
socket. Do not install onto surfaces that are either damp or electrically conductive.
Bathroom Zones
Electrical Safety
Suitable for UK Installations only.
All fittings must be installed by a competent person, in accordance with current IEE
wiring regulations. If in doubt consult a qualified electrician.
Important: Always switch off the electrical supply at the mains before installation and
maintenance. It is recommended that the fuse is withdrawn or the circuit breaker is
switched off for the necessary circuit before installation commences.
This product is manufactured to class I category and must have an earth connection.

PAGE 3PAGE 6
Page 6 Page 3
Cleaning your product
When cleaning the mirror or any mirrored surfaces it is recommended to use a soft,
dry, non abrasive cloth with the mirror turned off. Do not use cleaning agents or
abrasive materials.
DO NOT allow moisture to come into contact with any electrical components.
Troubleshooting & After care service
For any further assistance, please contact our tech support team at:
[email protected].
10 Year Guarantee
We have complete confidence in this Tavistock bathroom mirror and as such it is
offered with a 10-year guarantee against defects in manufacture.
The guarantee requires that this product be used in the manner for which it was
intended and that it is installed and maintained in accordance with the fitting
instructions.
The guarantee covers products in domestic use only and is not transferable.
In the unlikely event that this product should fail during the guarantee period we will
either replace the faulty part or the complete unit as appropriate.
Compliance
This product complies with all relevant British and European safety standards.
After care service Installation Procedure
Important: Before starting the installation process, make sure the electrical supply
is switched off. It is recommended that the fuse is withdrawn or the circuit breaker
is switched off for the necessary circuit.
Important: Before starting the installation process, ensure the wall construction is
suitable and can support the weight of the mirror.
Note: The wall plugs supplied are suitable for solid stone / brick walls. For any
other wall material use specialist wall plugs.
1) Measure the distance (X) between the keyhole slots on the back of the mirror.
2) Mark out the fixing screw positions on the wall using a pencil to the desired
height, ensuring they are spaced at distance (X).
3) Drill the marked out positions and fit the wall plugs accordingly. Fix the screw into
position, leaving a small amount of the screw head proud of the wall for hanging.
4) Make the electrical connection from the mirror to the mains supply. Use the
connection wire found at the rear of the mirror to make the necessary connections in
accordance with the current IEE regulations. A second person will need to hold the
mirror in place whilst electrical connections are made.
5) The mirror should easily slide onto the fixing screws and secure into place.
NOTE: To secure the mirror further, a small amount of silicone sealant can be applied
to the side of the extrusions to prevent the mirror being accidently pulled away from
the wall.
To remove the mirror, the mirror should first be lifted and then pulled away from the
wall.
Landscape (X)
Portrait (X)

PAGE 4
Page 4 Page 5
PAGE 5
The Ambient mirror comes with LED lighting, which is controlled via a fixed touch
sensor located on the front face of the product. The lighting can be controlled using
the button functions detailed below:
Turn Mirror ON/OFF
To turn the product on/off, short
press the touch sensor.
Operating Instructions
Installation Procedure
Important: Before starting the installation process, make sure the electrical supply
is switched off. It is recommended that the fuse is withdrawn or the circuit breaker
is switched off for the necessary circuit.
Important: Before starting the installation process, ensure the wall construction is
suitable and can support the weight of the mirror.
Note: The wall plugs supplied are suitable for solid stone / brick walls. For any
other wall material use specialist wall plugs.
1) Measure the distance (X) between the keyhole slots on the back of the mirror.
2) Mark out the fixing screw positions on the wall using a pencil to the desired
height, ensuring they are spaced at distance (X).
3
Mains Supply
Distance X
2
5
Wall Screws
Wall plugs
4
3) Drill the marked out positions and fit the wall plugs accordingly. Fix the screw into
position, leaving a small amount of the screw head proud of the wall for hanging.
4) Make the electrical connection from the mirror to the mains supply. Use the
connection wire found at the rear of the mirror to make the necessary connections in
accordance with the current IEE regulations. A second person will need to hold the
mirror in place whilst electrical connections are made.
5) The mirror should easily slide onto the fixing screws and secure into place.
NOTE: To secure the mirror further, a small amount of silicone sealant can be applied
to the side of the extrusions to prevent the mirror being accidently pulled away from
the wall.
To remove the mirror, the mirror should first be lifted and then pulled away from the
wall.
