TBI TRU-BILT TRU-LEVEL Operating instructions

TRU-LEVEL™
Edge of Dock Leveller
INSTALLATION & OWNERS MANUAL
PROJECT/CLIENT:
SO No:
PACKED BY:
DATE: / /
CHECKED BY:
DATE: / /
INSTALLED BY:
DATE: / /
COMMISIONED BY:
DATE: / /
(THIS MANUAL MUST REMAIN WITH LEVELLER FOR SERVICING AND MAINTENANCE AT ALL TIMES)

TRU-LEVEL™EDGE OF DOCK LEVELLER INSTALLATION & OWNERS MANUAL
2
•When receiving goods on site, please check all packages immediately for damage
or repackaged goods that may have been damaged during shipping.
•Any damage must be reported to TRU-BILT Industries Ltd within 24 hours of
receiving product.
Free Phone New Zealand: 0800 144 999
Free Phone Australia: 1800 144 888
Website: www.tru-bilt.co.nz

TRU-LEVEL™TL2515/TL3015 INSTALLATION & OWNERS MANUAL
3
Contents
Safety Warnings …………………………..…………….…………………………………………………….……….. 3
Installation Instructions .………………………..……..…………………..……..………………….....…… 4 - 7
Operating Instructions ....….………….…………..….…………………………………………….………... 8 - 9
General Maintenance ...….………………….………….……………………………….………….…………….. 10
Troubleshooting ……….....….……………………..…...…………………….…………………….…….……….. 10
Warranty …………………………………….…………………………………………..…………..……….………….. 11
Preface
•The installation of the TRU-LEVEL Edge of Dock Leveller is reasonably basic if you
follow the instructions in this manual carefully.
•All warnings and safety precautions must be followed at all times.
•A selection of hand and power tools and a welder will be required for installation.
•A forklift or Hiab will be needed to lift the leveller into place.
•TRU-BILT Industries Ltd reserves the right to change product design and
specifications without notice.
Safety Warning
•All necessary safety precautions must be carried out to ensure a safe working
environment for yourself and those around you.
•All electrical work must be carried out by a fully qualified electrician.
•Take extreme care when working under dock levellers.
WARNING! - Failure to follow precautions in this manual
may result in severe personal injury or death.

TRU-LEVEL™EDGE OF DOCK LEVELLER INSTALLATION & OWNERS MANUAL
4
Installation Instructions
Step 1 –Choice of two applications
The Edge of Dock Leveller can be installed in two ways:
a) Wall mounted directly against a loading dock (See Fig 1.1 and Fig 1.2).
For this purpose, the dock must be provided with a mounting edge at the front
consisting of an angled section measuring at least 100mm x 100mm with anchors
spaced at 150mm centres.
Fig 1.1

TRU-LEVEL™TL2515/TL3015 INSTALLATION & OWNERS MANUAL
5
Fig 1.2

TRU-LEVEL™EDGE OF DOCK LEVELLER INSTALLATION & OWNERS MANUAL
6
b) The leveller can be installed directly into a dock pit (see Fig 1.3). This pit must be
equipped with a protective edge consisting of a similar 100mm x 100mm angled
section with anchors at 150mm centre to centre.
Fig 1.3

TRU-LEVEL™TL2515/TL3015 INSTALLATION & OWNERS MANUAL
7
Step 2 –Installation
•Place anchors as specified in Fig 1.2.
•The Edge of Dock Leveller is supplied completely assembled.
•Remove the steel strips.
•Place the leveller on the pit edge by using a forklift and hoisting strap.
•Weld into place.
•Place the leveller in a vertical position and secure it in this position using the
operating hand lever (see Fig 2.1).
•Fit the rubber bumpers. If the dock is provided with a pit, then the bumpers are
fitted directly to the front by anchor bolts. If the dock face has a steel mounting
edge, the bumpers are provided with steel supports. Fit the supports to the front
of the dock with anchor bolts placed at the bottom and weld the supports to the
top of the dock edge.
•Brush all welds clean and apply a primer and finishing coat.
•Fasten the holder for the operating lever at an appropriate spot for operators.
Fig 2.1

TRU-LEVEL™EDGE OF DOCK LEVELLER INSTALLATION & OWNERS MANUAL
8
Operating Instructions
•PLEASE NOTE: The leveller should only be used for the purposes for which it is
intended, i.e. the loading and unloading of trucks with the aid of forklifts or pallet
trucks. The leveller shall not be operated above its rated load and permitted
gradient. Never operate the leveller when persons or goods are on it or in front of
it. Do not use the leveller before it has been fully extended and the lip is sufficiently
supported by the floor of the truck. Do not use the leveller if the truck floor is too
low or too high for sufficient support. Ensure the truck is secured before loading or
unloading, to prevent premature departure.
Procedure
•Align the truck correctly with the leveller and open the doors (Fig 3.1).
•If the truck is full and there is no place to accommodate the lip, remove the items
at the rear while the lip is still in stored position (Fig.3.2)
•Take the operating lever from the holder on the leveller and place it in the hole in
the top plate (Fig 3.3).
•Securely hold the lever with both hands and move it towards the floor until the lip-
lifter engages (Fig 3.4).
•Bring the operating lever up again and the top plate is lowered (Fig 3.5). The lip
extends and will rest on the truck floor (Fig 3.6).
•Take the operating lever out of hole and place it in the holder.
•After loading or unloading the truck, place the operating lever in the hole again and
move it towards the floor until the lip slides up and away from the truck floor (Fig
3.7).
•The leveller can now be lowered to its stored position (Fig 3.8).
•Store the operating lever in the holder.
•The truck can now depart.

TRU-LEVEL™TL2515/TL3015 INSTALLATION & OWNERS MANUAL
9
General Maintenance
Your TRU-LEVEL dock leveller has been designed for heavy duty use with a minimum of
maintenance needed.
However it can be damaged if used carelessly so we recommend that you inspect your
TRU-LEVEL every 3 months for damage. If repair is needed, it is important to get it done
as soon as possible. If it is left it will only cost your company more in the long run.
Should a problem arise, refer to the “Trouble Shooting” section on next page and call a
technician. We do not recommend that you try to fix it yourself.

TRU-LEVEL™EDGE OF DOCK LEVELLER INSTALLATION & OWNERS MANUAL
10
General Maintenance
To guarantee safe operation, check the Edge of Dock Leveller regularly for correct
operation or damage.
For repairs and maintenance advice contact Tru-Bilt Industries Ltd.
Trouble Shooting
PROBLEM
CORRECTION
Lip remains
extended during
upward movement
of leveller
Check for obstructions or damage.
Lip lifter does not
function properly
Check operation of lip lifter. Check lubrication.
Lip does not extend
during downward
movement of
leveller
Check for obstructions or damage.
Lip extends during
the backward
movement of
operation
Check for obstructions or damage.
Leveller does not
operate smoothly
and the lip drops
too fast
Check for obstructions or damage. The gas spring may be worn
out or defective –check and replace if necessary.

TRU-LEVEL™TL2515/TL3015 INSTALLATION & OWNERS MANUAL
11
Free Phone New Zealand: 0800 144 999
Free Phone Australia: 1800 144 888
Website: www.tru-bilt.co.nz
September 2018
Warranty
TRU-BILT Industries Ltd warrants that your TRU-LEVEL™Edge of Dock Leveller will be
free from defects in materials and workmanship under normal use for a period of two
years, provided the purchaser installs, maintains and operates the Edge of Dock Leveller
in accordance with this owner’s manual. If a warranty issue should arise, a Warranty
Claim Form is available from TRU-BILT and must be completed. Photos are also required
to support the claim. Travelling costs and labour are not claimable.
When a warranty claim is accepted, TRU-BILT will repair or replace parts, or complete
products, whichever TRU-BILT Industries Ltd deems suitable. TRU-BILT Industries Ltd
retains the right to reject any warranty claim for failure or damage caused by improper
use or abuse.
Contact TRU-BILT for your signed official warranty document: [email protected]
