TC Electronic Teleport GLT User manual

TELEPORT GLT/GLR
High-Performance Active Guitar Signal Transmitter/
Receiver for Long Cable Run Systems
Connection
Getting Started
1. Connect the included power adaptor to the GLT power socket.
2. Connect your guitar to the GLT ¼" input via standard instrument cable.
3. Connect a balanced XLR cable from the GLT output to the GLR input.
4. With the amplier turned o or in standby mode, connect a standard instrument cable from the GLR output to your amp’s input.
5. Power on your amplier.
6. Move the ground switch on the GLR to the LIFT position if grounding noise is audible.
7. Adjust the DRAG control to simulate the loading that occurs when you connect directly into an amp at close distance. More drag will simulate a longer cable.
GLT
Guitar
GLR
XLR female
XLR male
Guitar amp

GLR GLT
Input
Connector XLR female, balanced ¼" TS, unbalanced
Impedance 180 kΩ Adjustable 22 kΩ to >1 MΩ
Max. input level — +10 dBu @ 1 kHz
Output
Connector ¼" TRS, unbalanced XLR male, balanced
Impedance 200 kΩ 2 kΩ
Max. output level — +10 dBu @ 1 kHz
System
Frequency response 10 Hz to 35 kHz (±3 dB) 10 Hz to 26 kHz (± 3 dB)
THD + N (distortion) 0.0015% @ 1 kHz, 0 dBu 0.05% @ 1 kHz, 0 dBu
Signal-to-noise ratio 110 dB @ 1 kHz, 0 dBu 90 dB @ 1 kHz, 0 dBu
CMRR 62 dB typical —
Power requirement Passive 12 V DC, 150 mA
Physical
Dimensions (H x W x D) 64 x 118 x 112 mm (2.5 x 4.6 x 4.4")
Weight 0.43 kg (0.9 lbs) 0.5 kg (1.1 lbs)
Specications
