TCL 32S330 User manual

Hi! Let’s get started.
3-Series
32S330/40S330

DO NOT RETURN TO STORE
TCL SUPPORT:
support.tclusa.com
1-877-300-9576
contact us first
with any questions
WE ARE
READY TO
HELP
TAKE CARE WHEN
REMOVING THE TV

1
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts
inside. Refer servicing to qualified service personnel.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that this product incorporates
double insulation between hazardous main voltage
and user accessible parts. When servicing, use only
identical replacement parts.
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
This product should not be exposed to dripping
or splashing. No objects filled with liquids, such
as vases, should be placed on the apparatus.
WARNING
The TV is unstable if it is not properly attached to
the base or mounted to the wall. Please follow the
base or wall mounting instructions provided in the
User’s Guide to ensure your safety.
Warning: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Model No.
Purchase Date
Serial No.
Dealer/Address/Phone
Important Information
Refer to the identification/rating label located on the back panel of your product for its proper operating
voltage.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National
Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper
grounding and, inparticular, specifies that the cableground should be connected to the grounding system
of the building as close to the point of cable entry as practical.
Important: This television is a table model and is designed to sit on a firm, flat surface. Don’t place
the TV on soft carpeting or similar surface because the ventilation slots on the bottom of the unit will
be blocked, resulting in reduced lifetime from overheating. To assure adequate ventilation for this
product, maintain a spacing of 1 inch from the top and side of the TV receiver and 2 inches from the
rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from
being accidentally tipped over, pushed o, or pulled o. This could cause personal injury and/or damage
to the TV. Refer to the Important Safety Instructions on the next page.
The Power buttonon this TVand your remote control puts the TV into a very low-power standby
mode but will not completely turn the power o. In order to completely shut the power o, you will
need to disconnect the power cord from the outlet. The mains plug/appliance coupler is used to
completely turn o the device. If you prefer to completely turn o the device, you should install
the TV in a manner that allows you to disconnect the power cord when desired.
Product Registration
Please register your TCL TV purchase on-line at www.tclusa.com. It will make it easier to contact you
should it ever be necessary. Registration is not required for warranty coverage.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here
and record the serial and model numbers in case you need them. These numbers are located on the
product.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Keep the apparatus at least 8
inches away from the human body.
For the best viewing experience, remove the energy guide label from the TV front panel or TV screen
before use.
Input Signal Compatibility
480i, 480p, 576i/p, 720p/60Hz, 1080i/p/50Hz, 1080i/60Hz, 1080p/60Hz
480i, 576i
480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)
HDMI
Composite Video
Antenna/Cable

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information
before installing or operating the apparatus.
11. WARNING:The mains plug is used as disconnect device, the disconnect device shall remain readily
operable.
12. When not in use and during movement, please take care of the power cordset, e.g. tie up the power
cordset with cable tie or something like that. It shall be free from sharp edges and the like that can
cause abrasion of the power cordset. When put into use again, please make sure the power cordset
being not damaged. If any damages found, please look for the service person to replace the power
cordset specified by the manufacturer or have the same characteristics as the original one.
13. No naked flame sources, such as lighted candles, should be placed on the apparatus.
14.
Unplug this apparatus during lightning storms or when unused for long periods of time.
15. Only use attachments/accessories specified by the manufacturer.
16. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
17. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
18. For safe operation of the apparatus, observe these installation requirements:
Keep at least 2 inches of ventilation space between the rear cover of the apparatus and the wall.
Keep at least 1 inch of ventilation space between the apparatus and all other surfaces. Do not allow
any of the apparatus’ ventilation openings to be blocked by objects that might obstruct them, such
as newspapers, curtains, table-cloths or any other objects. Do not expose the apparatus to any external
heat sources. Do not place any heat sources such as candles, lamps, etc. on the apparatus. Do not expose
the device to high levels of humidity or to any possible sources of moisture. When disposing of used
batteries
from the remote control, consult local regulations regarding proper disposal.
19. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code, ANSI/NFPA No. 70-2011 (Section 54 of Canadian Electrical Code,
Part 1) provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead in wire to an antenna-discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
See following example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PART H)

ELECTRONICS RECYCLING INFORMATION FOR CONSUMERS
TCL strives to provide a high level of service to our customers and in the communities we serve, and
recommends that consumers always look for a recycling or reuse alternative to throwing away televisions and
other electronics. We encourage customers to recycle end-of-life electronic devices using one of the many
convenient methods available today. In many states TCL has programs in place to enable consumers to
drop-o and recycle televisions free of charge. For information on electronics recycling in all 50 states, including
drop-o locations, please visit the “Electronics Recycling” area of the TCL USA website at www.tclusa.com.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and
the double-D symbol are trademarks of Dolby Laboratories.
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
3-series, include models (32S330/40S330)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Supplier Name: TTE Technology, Inc. (dba TCL North America)
Supplier Address: 1860 Compton Ave, Corona, CA 92881, USA
Supplier phone number and internet contact information: 1-877-300-9576 support.tclusa.com
FCC Radiation Exposure Statement:
The equipment complies with FCC Radiation exposure limits set forth for uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
Battery Caution & Disposal Information
1. For best results, use alkaline type batteries.
2. Install only new batteries of the same type in your product.
3.
Failure to insert batteries in the correct polarity, as indicated in the battery compartment, may shorten
the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not use Rechargeable (Nickel Cadmium or Nickel Metal Hydride) batteries.
6. Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium or Nickel Metal Hydride)
batteries.
7.
8. Batteries should be recycled or disposed of as per state and local guidelines.
Do not dispose of batteries in fire.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
3

4
What’s in the box
TV stands AV Input cable adapter
2 x AAA batteries
for remote
TV remote
What you need
Phillips head
screwdriver
For additional support, please visit support.tclusa.com
Key things to know:
A paid subscription or other payments may be required for some streaming channels and apps.
Streaming channels and apps availability are subject to change and vary by country.
Make the most of your TV
Router + Internet Connection
(needed for streaming)
TCL TV
4 x Stand screws
ST4X25mm
Power cable

5
Step 1 Set up your TV
Ready for the step-by-step? You’re only minutes away from TV bliss!
the TV. Secure the stands to the TV with four (4) screws.
Put the column of the stands into the TV, align the stands with the screw holes located on
Remove your TV from the box
To prevent damage to the screen, carefully place your TV on a soft, cushioned surface.
A
B
To use the stand
Warning:
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
- Using cabinets or stands recommended by the manufacturer of the television set.
- Only using furniture that can safely support the television set.
- Ensuring the television set is not overhanging the edge of the supporting furniture.
-
Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
-
Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
-
Educating children about the dangers of climbing on furniture to reach the television set
or its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 100X100 refers to the fact that the mounting measurements are 100mm horizontally
and 100mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
To mount on a wall
Purchasea VESA 100x100 (4 M4x10mm screws)
If you are mounting your TV to the wall, don’t attach the stands.
To mount your TV to the wall, purchase a VESA wall mount
Screws
(ST4X25mm)
Stand
B
A
Models of 32”
Models of 40”Purchasea VESA 100x100 (4 M6x12mm screws)

Step 2
6
Power up
Grab your remote Step 3
In this step, we’ll make sure all systems are GO!
Power your TV remote by inserting the included
batteries.
Plug the power cable of your TV into the wall
outlet.
and descriptions on the next page.
Connect other devices by referencing port label
Power Tip! Always replace depleted batteries with two
same brand-new batteries from the same manufacturer.
Never use damaged batteries.
If your remote gets warm/hot during use, discontinue
use and contact customer support immediately at
support.tclusa.com.
The TV remote should feel right at home in your hand. We designed it to
be
incredibly intuitive for watching TV and navigating on-screen menus.
A
C
E
G
J
K
I
D
F
H
L
Insert batteries in the correct polarity as
indicated in the battery compartment.
POWER Turn TV on and o
SETTINGS Display the TV settings menu
HOME Return to home screen
OPTIONS Open the Option menu
BACK Return to previous screen
SOURCE Open input source shortcut
A
B
D
C
E
F
GOOGLE ASSISTANT Awake Google Assistant (Only
available when the network is connected)
G
CHANNEL Change channels
H
VOLUME Raise and lower volume
Press and hold the button for about 3 seconds to
mute the sound.
I
VIRTUAL KEYBOARD Open virtual keyboard on screen
J
NETFLIX Open Netflix
K
YouTube Open YouTube
LTip! Follow the on-screen guide
to pair the remote control with
the TV when pressing the
button for the first time.
B

Step 4
7
Get to know your TV
G
K
H
2 HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
ETHERNET Connect an Ethernet cable to your
home
Internet router or switch.
E
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT)
Connect an optical
cable to an external digital audio system.
Use the supplied adapter to connect to older devices
that use analog audio/video outputs. The supplied
adapter connects to the RCA cable (video - yellow
and audio - white and red) that you normally use to
connect to that device.
AV IN adapter AV Input (analog audio/video).
J
USB PORT Connect a USB device to access photos,
music and movies.
I
F
HEADPHONE OUT Connect headphones or other
external speakers.
TV FRONT
TV SIDE
I
D
H
J
K
F
D/E
G
HDMI ARC PORT Connect HDMI ARC (audio return
D
channel) capable audio devices like sound bars or
AV receivers.
ETHERNET
CABLE/ANT
AV IN
AUDIO OUT
IR RECEIVER Receives signal from
the TV remote.
STATUS LIGHT
Glows when the
TV is in standby.
A
POWER PORT Connect your TV
C
to the power source with the
included power cable.
POWER and OPTIONS BUTTON
B
Press once to open the menu.
Press and hold to turn o the TV.
TV BACK
C
A
B

Step 5 Complete guided setup
It’s the final stretch-hurray!
Let’s Connect
Once select your language, you can quickly set up the TV using an Android phone with app
“Google”.
Or you can follow the easy on-screen instructions to setup your TV. If you aren’t ready to
connect your TV to a wireless network, you can still use it as a regular TV.
And setup is done…congratulations!
Continue using the remote to personalize your Home screen, streaming channels and apps line-up,
stream movies, and so much more.
TCL SUPPORT:
support.tclusa.com
1-877-300-9576
contact us first withany questions
WE ARE READY TO HELP
8
TV interface may vary and subject to change.

9
TCL North America Limited Warranty
All LCD/LED Models.
What your warranty covers: Defects inmaterials or workmanship to the original owner of this TCL
product when purchased as new from an Authorized Dealer of TCL brand products in the United States and
packaged withthis warranty statement.
New LCD/LED Televisions (Non-Commercial Use)
For how long after your purchase:
One (1) year from date of purchase for parts and labor for non-commercial use.
New LCD/LED Televisions (Commercial Use)
For how long after your purchase:
Six (6) months from date of purchase for parts and labor for commercial use.
Commercial use includes, but is not limited to, the use of this product in a commercial or business environment,
the use of this product in an institution or for institutional purposes, or other commercial purposes including
rental purposes.
What we will do:
At TCL North America’s discretion, (1) pay an Authorized TCL Service Centerforboth labor charges and parts to
repair yourtelevision, or(2) replaceyour television with anew or refurbished /remanufactured equivalent value
product. The decision to repair or replace will bemade solely by TCL North America. See “How toget service”.
How to get service:
Call 1-877-300-9576.
Please have your original purchase receipt or proof of purchase (bill of sale or receipted invoice), the unit’s
date of purchase, place of purchase and model/serial number ready. The model/serial number information
can befound onthe back of your unit.
A representative will troubleshoot your problem over the telephone. If it is determined that your unit
requires service, the service location will be at the sole discretion of TCL North America based upon the
TCL North America Limited Warranty Statement.
At the sole discretion of TCL North America, television screen sizes 43”and smaller will either be repaired at an
Authorized TCL Service Centre or directly exchanged for a new or refurbished/remanufactured unit. At the sole
discretion of TCL North America, television screen sizes 44”through 55”or larger will either be repaired at an
Authorized TCL Service Center or repaired in-home.
If repaired at an Authorized TCL Service Center, a pre-paid shipping label will be provided and TCL North
America will pay for return shipping.
Proof of purchase in the form of a bill of sale or receipted invoice from an Authorized Dealer which is
evidence that the product is within the warranty period must be presented to obtain warranty service.
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE (1) SENDING ANY PRODUCT TO AN AUTHORIZED
TCL SERVICE CENTER, OR (2) OBTAINING ANY IN-HOME REPAIR/REPLACEMENT/RENTAL SERVICES.
What your warranty does not cover:
Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your Authorized Dealer).
Installation and related adjustments, or damage resulting from installation.
Damage resulting from non-approved installation methods.
Signal reception problems not caused by your unit.
Damage from misuse, abuse, neglect, normal wear and tear, cosmetic damage, mishandling, faulty installation,
or power line surges.
Markings or images on the television’s panel resulting from viewing fixed images (including but not limited
to certain 4:3 images on wide screen televisions, or data or images in fixed screen locations from banners,
video games, or certain broadcast networks).
A television that has been modified or incorporated into other products.
A unit purchased or serviced outsidethe USA.
A unit sold in “As-Is”, “Factory Reconditioned”, “Factory Re-Certified”, or “Refurbished” condition or with
faults.
Acts of nature or God, such as but not limited toearthquake or lightning damage.
Special, incidental or consequential damages.
Product Registration:
Please register your TCL TV purchase on-line at www.tclusa.com. It will make it easier to contact you should
it ever be necessary. Registration is not required for warranty coverage.

10
TCL North America Limited Warranty
THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO
VERBAL OR WRITTEN INFORMATIONGIVENBY TCL NORTHAMERICA, ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER. TCL NORTH AMERICA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF
CALIFORNIA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO
THE APPLICABLE WARRANTY AND WARRANTY PERIOD SET FORTH ABOVE. THIS WARRANTY IS
SUBJECT TO CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCLUSA.COM TO VIEW THE MOST
CURRENT VERSION.
LIMITATION OF WARRANTY
How State Law relates to this warranty:
Broadcasting &Operating Environment
Broadcasting system US System NTSC-M
ATSC standard (8VSB),QAM
Receiving Channels VHF2-13
UHF14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85(AAA)-(ZZZ)
86-94 (86)-(94)95-99 (A-5)-(A-1)
100-135(100)-(135)
01 (4A)
Tuner type Frequency synthesized
Operating Temperature 5°C to35°C (41°F to95°F)
Operating Humidity 20% to80%, non-condensing
Storage Temperature-15°C to45°C (5°F to113°F)
Storage Humidity 10% to90%, non-condensing
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you alsomay have other rights that vary from state to
state.
If you purchased your unit outside the United States or seek warranty coverage
outside the United States:
This warranty does not apply.Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not
covered by this warranty. Costs of such service calls are the sole responsibility
of the purchaser.

11
Troubleshooting
Cannot connect to wireless network (Wi-Fi)
• Select the correct wireless network name and verify the password entered (case sensitive).
• Relocate the router from objects that interfere with performance (cordless phones, baby monitors, etc.).
• Reboot the router by disconnecting the power for more than 2 minutes and reconnect.
What is the remote code for programming my Universal or Cable box remote control?
• Please visit https://support.tclusa.com/tv-remote-codes
Problems connecting my cable box orantenna through acoaxcable
• For best performance, use the HDMI connection. If not available, then:
•
Make sure the cable connections to the TV and your device are securely fastened.
•
Select cable or antenna input.
Access parental control
• The initial personal password for your TV is 1234.
•
You can change the personal password anytime.
•
If you forget your personal password, you can use 0423 to reset.
• Select the channel scan menu and follow the on-screen instructions to perform a full channel scan.
Having trouble completing the guided setup? Don’t worry, it’s usually an easy fix.
1-877-300-9576
Need more help?
support.tclusa.com

ALTO 7 / 7+
ALTO 5 / 5+
Complete your Home Theater Experience
with a TCL Sound Bar!
STUNNING SOUND. MADE SIMPLE.
TCL’s Alto Sound Bar Lineup
Offering a truly immersive home theater experience, TCL Alto Sound
Bars are simple to setup and easy to use. With specialized sound modes,
available wireless subwoofers, and everything you need to connect to
your TCL TV, Alto Sound Bars provide stunning sound, made easy.
To learn more visit TCLUSA.com or your favorite retailer.
Part No.: 70-F6RT51-QSG1C
Android TV is a trademark of Google LLC. TCL and the TCL
Logo are owned by TCL Corporation and under license to
TCL North America. Other brand and product names are the
trademarks or registered trademarks of their respective
owners.
TTE Technology, Inc. (dba TCL North America)
1860 Compton Ave, Corona, CA 92881, USA
