TCSM CS Series User manual

1
CHEN SHIN (TCSM)
MC CO.,LTD.
CS Series
PRODUCT MANUAL

Oil mist collector CS series
2
Table of Contents
Page
0. General information ……………………………….3
0-1 Description of the machine…………………….3
0-2 Obsolescence information……………………..3
1. Open Box ................................................................. 4
1-1 Assembly Tools Prepare .................................... 4
1-2Install Accessories (I.A.)................................. 4
1-3Direct I.A. .................................................. 5
1-4 Indirect I.A.............................................. 5
1-5Optional Accessories ............................ 6
2. Installation instructions
2-1 Installation outfit................................................ 7
2-2.Overall Dimensions ....................................... 8
2-3Well installed sample ................................... 9
2-4Electrical connection............................... 10
2-5Optional Accessories…………………..12
3. Maintenance ........................................................... 14
3-1 Regular Check.................................................. 15
3-2 Maintenance……………………………….. 16
3-3Filter Maintenance ………………………..18
3-4 Maintenance list………………………. 19
3-5 Troubleshooting……………………..19
4. Exploded view……………………………………..20
5. Machine Type List & Technical Data……………..21
6. Sign instruction……………………………………22
7. Product Warranty…………………………………..23
8. Product Approval…………………………………..24

Oil mist collector CS series
..
3
User information
0 General information
For a safe and trouble-free operation of machine, all safety information and regulations must be
understood. It contains the most important information for the safe installation and operation of the
machine. Furthermore, compliance with the rules and regulations on accident prevention and industrial
hygiene applicable to the place of installation is essential.
The user information belongs to the machine and must be always kept accessible to professionally
trained and operating personnel.
When handing over the machine to someone else, also include this user information.
0-1 Description of the machine:
TCSM oil mist collector is for machine tools to filter oil mist and recycle oil or coolant.
Each type of CS series have the characteristic to recycle oil. Patented cyclone design allows 90% oil
mist to be solidified as oil drop through physical dash theory for first cutting liquid recycle. Then the
small oil drops will be brought upward to the filter kit for filtration and second recycle to ensure the
maximum recycle ability.
Patented cyclone create huge wind flow, and centrifuge filtration reduce the saturated rate of
filter kit.
High density filter kit, each cubic millimeter is crisscross by 100 small holes
Beside above design, CS series have high efficiency motor to use energy more efficiency.
Multiple balance calibrate, separate the filter kit from fan, to ensure the balance of fan after a
long term usage.
And the last Flexible Installation, installing position depends on the factory layout and do not
interfere the working flow.
0-2 Obsolescence information:
If oil mist machine is no longer useable. Please follow local law or instruction to recycle or
abandon each oil mist collector parts.

Oil mist collector CS series
..
4
1. Open Box:
Put box on plane place
with box word on right
direction.
Put something to cover on flow, prevent
bottom screw scratch flow.
Then open box and pull out oil mist
collector from the top side. Place oil mist
collector on flow carefully.
Make sure the oil mist collector
outfit is ok and oil pipe is well
installed.

Oil mist collector CS series
..
5
1-1 Assembly Tools Prepare
Assembly Tools
Tools
Purpose
Suggest size
Qty.
Substitute Tool
Electric drill
Drilling a pilot hole
1
Hydraulic
drill
Open an oil mist outlet hole
on cover
φ125mm
1
Any other tools which could
open same hole.
screwdriver
1
silicone
Epoxy glues
Sealing connect place
Cable tie
Holding oil pipe
1-2 Install Accessories (I.A.)
Install Accessories (I.A.)
1-3 Direct I.A.
Accessories
Purpose
Type
Specification
Qty.
Note
O
il return pipe Let oil return to machine tool.
MKI 、 MKII
OD=28；ID=25
MK PLUS
OD=35
；
ID=32
MKIII
OD=42
；
ID=38
Electromagne
tic switch
Main power switch All Types
220V 1/2HP
1
Base on supply
voltage
380V 1/2HP
Hose clamp
Hold return pipe
MKI 、 MKII
1-1/4"
1
MK PLUS 、 MKIII
1-1/2"
Hold outlet pipe
All Types
5-1/2"
2
Upholstery
foam
Hold outlet pipe All Types 5-1/2" 2
F
or direct install
1-4 Indirect I.A.
Accessories
Purpose
Type
Specification
Qty.
Note
O
il return pipe Let oil return to machine tool
or
collect barrel
MKI 、 MKII OD=28；ID=25
Length depend on
case
MK PLUS
OD=35；ID=32
MKIII
OD=42；ID=38
Electromagne
tic switch
Main power switch All Types
220V 1/2HP
1
Base on supply
voltage
380V 1/2HP
Hose clamp
Hold return pipe
MKI
、
MKII
1-1/4"
1
MK PLUS
、
MKIII
1-1/2"
Hold outlet pipe
All Types
5-1/2"
2
5
"outlet pipe
Connect oil mist outlet hole and
machine tool.
All Types φ125mm 1 For indirect install
S
upport kit Hold oil mist collector All Types
Standard square
kit
1
For indirect install
Length depend on
case
L type s upport kit

Oil mist collector CS series
..
6
1-5 Optional Accessories
Accessories
Purpose
Type
Specification
Qty.
Note
Independent
support kit
Hold oil mist collector
All Types
Height
：
1700mm
1
If space on
machine tool is not
enough for
oil mist
collector
or cannot
install directly, it
suggest using this
support kit.
Outlet Cover
Out Let pipe
All Types
1
Outlet Filter
Filter the smaller particle
All Types
1

Oil mist collector CS series
.
7
2-1Installation outfit
We have two ways to installed oil mist collector. First is “Direct Install”. It is the way with best efficiency. Install
oil mist collector direct on machine tools. Since the oil mist flow did not through any pipe, it got best discharge. Direct
Install like Pic.1 showing. This way should make sure the space on machine tool is enough for oil mist collector.
Pic.1 “Direct Install”
Second is “Indirect Install”, if space on machine tool is not enough for oil mist collector or cannot install on machine
tools clamshell, it should install in this way. Because through outlet pipe, the flow will decrease. In this case we suggest
customer use short length of pipe. (Pic.2)
Pic.2 “Indirect Install”

Oil mist collector CS series
.
8
2-2 Overall Dimensions (Direct Install)
A
B
C
D
E
F
G
CS900-MKI
3800mm
150 mm
9 mm
35 mm
100 mm
200 mm
>1000 mm
CS900-MKII
3800 mm
150 mm
9 mm
35 mm
100 mm
200 mm
>1000 mm
CS900-PLUS
3800 mm
150 mm
9 mm
39 mm
100 mm
200 mm
>1000 mm
CS1200-MKIII
4200 mm
150 mm
9 mm
45 mm
100 mm
200 mm
>1000 mm
CS2000-MKIV
5000 mm
160 mm
9 mm
45 mm
100 mm
200 mm
>1000 mm
CS3000-MKV
CS3000-MKV
5300 mm
200 mm
9 mm
45 mm
160 mm
320 mm
>1000 mm

Oil mist collector CS series
.
9
2-2 Overall Dimensions (Indirect Install)
A
B
C
D
E
F
G
H
I
J
K
CS900-
MKI
3800mm 125mm 9mm 125mm 6mm 35mm 100mm 200mm <1000mm >1000mm 72.5mm
CS900-
MKII
3800mm 125mm 9mm 125mm 6mm 35mm 100mm 200mm <1000mm >1000mm 72.5mm
CS900-PLUS
3800mm
125mm
9mm
125mm
6mm
39mm
100mm
200mm
<1000mm
>1000mm
72.5mm
CS1200-
MKIII
4200mm 125mm 9mm 125mm 6mm 45mm 100mm 200 <1000mm >1000mm 72.5mm
CS2000-
MKIV
5000mm 150mm 9mm 150mm 6mm 45mm 100mm 200mm <1000mm >1000mm 72.5mm
CS-3000-MKV
CS3000-
MKV
5300mm 2000mm 9mm 2000mm 6mm 45mm 160mm 320mm <1000mm >1000mm 100mm

Oil mist collector CS series
.
10
2-3Well installed sample
Black Support kit Black Support kit side install
(With customization intake hole )
White L type support kit Customization Support kit
Direct Install Indirect Install

Oil mist collector CS series
.
11
2-4 Electrical connection
1. Three phase Motor
2. Electromagnetic switch(Contactor & Thermal overload relay)
3. Main switch

Oil mist collector CS series
.
12
2-5Optional Accessories
Accessories
Outlook
Type
Note
Outlet Cover
CS-900、CS1200 series
Installed on the top cover
of the oil mist collector,
and can be locked
together with the 4 knobs
on the top cover. The
exhaust port is a 6-inch
(150mm) electrostatic
machine.
Outlet Filter
CS-900、CS1200 series
Installed above the
circular upper cover of
the oil mist collector. This
is a consumable. It have
two type: 600mm high &
300mm high according to
the height of the
customers case .
Intake Oil block kit
CS-900、CS1200、
CS2000 series
Installed under the oil
mist collector, can be
locked with nuts with 4
anti-vibration feet below
the oil mist machine
Thermal sensor
CS series
It is additionally installed
on the machine, using the
sensor to sense the
temperature in the
processing room of the
machine tool. If the
temperature is too high, it
will buzz to inform the
user
Independent support kit
All type
It is used when the oil
mist collector cannot be
installed on the machine.

Oil mist collector CS series
.
13
Outlet Electrostatic filter
CS-900、CS1200 series
The product that replaces
the Outlet Filter.
It is installed above the oil
mist collector.
No consumables, only
needs to clean the filter
element.

Oil mist collector CS series
.
14
CS Series
Maintenance

Oil mist collector CS series
.
15
Cable outlet
3-1 Regular Check
1. Visual inspection for oil leakage / air leakage, please check all holes and joints
2. Whether the filter cotton or filter element is damaged
Filter cottons for
CS-900/2000/3000 series
have three filter cottons .
CS-1200 series have one filter cotton and filter
element.

Oil mist collector CS series
.
16
3-2Maintenance
Replacing or cleaning the filter:
Step 1.Unscrew the safety screw , The safety screw can be fixed on the buckle.. Take off upper cover after open the
buckle.
It should look like the picture on the left after open the locker..
＊Make sure the oil mist collector is turned off before open the locker.

Oil mist collector CS series
.
17
Place the cover on the table upside down.，take
off filter cotton follow arrow direction left pic.
Showing.
Pick up the cover

Oil mist collector CS series
.
18
3-3 Filter Maintenance
Step 1:
Bleach dilute with water at a ratio of 1: 3, and soak the filter
cotton in it about 30-40 minutes.
＊Do not use acid bleach
Step 2:
Rinse bleach the salad with water, then dry the filter with
your hands.
＊Do not remove the water by twisting. The filter cotton will be
damaged by improper force.
Step 3:
Hang in a cool place and air dry for about 1.5 days
＊Do not expose to the sun
※In order to achieve better cleaning results, it is
recommended to repeat step 1& step 2
※If there is deoiler in the factory,
It is recommended to use de-oiler instead of step 2 to
shorten the drying time.
(The 1200 series filter element should not be used in de-oiler)

Oil mist collector CS series
.
19
3-4Maintenance list
Time
Type
Each 300H Each 600H 6000H
CS900-MKI
Filter cotton set
Clean
Replace
Oil tray
Clean
CS900-MKII
Filter cotton set
Clean
Replace
Oil tray
Clean
CS900-PLUS
Filter cotton set
Clean
Replace
Oil tray
Clean
CS1200-MKIII
Filter cotton set
Clean
Oil tray
Clean
CS2000-MKIV
Filter cotton set
Clean
Oil tray
Clean
CS3000-MKV
Filter cotton set
Clean
Oil tray
Clean
Optional Accessories
All type
Outlet Filter
Replace
The maintenance time is recommended. The actual situation will be slightly changed due to the cutting/milling
condition of the client. The client can judge to reduce / extend the maintenance time according to the suction flow.
3-5 Troubleshooting
Error
Possible Causes
Solution
Motor do not work
Power is not connect
Check if the power wiring is well
connect
Defective switch / phase
loss
Use a three-use meter to measure
whether there is a phase loss. If the
phase is loss, replace the switch. If
necessary, contact service.
Vibration, strange sound,
odor
Motor wind wheel
abnormal
Check the condition of the motor and
wind wheel, contact service if
necessary
Filter cotton blocked or
damaged
Clean or replace the filter
New product suction is
abnormal
Motor reverse
Reverse power phase connection
Poor piping
The pipe is recommended to be
installed in a straight line with less
twists。
Oil leakage at the exhaust
pipe
Incorrect filter installed
Install filter correctly
Filter cotton damaged
Replace the filter
Exhaust air flow
significant reduce
（With Outlet Filter）
Filter blocked Replace the outlet Filter

Oil mist collector CS series
.
20
Exhaust air flow
significant reduce
（Without Outlet Filter）
Filter blocked Clean or replace the filter
※If you have other questions, please contact service dept..
