TCW Technologies IBBS-24v-CHARGER-LiFe User manual

725.0046 REV 1.1 © 2019 TCW Technologies, LLC.
1
Integrated Back-up Battery System
ground based AC plug-in charger
Model: IBBS-24v-CHARGER-LiFe
The IBBS-24v-CHARGER is a line voltage supplied charger intended to
be used with the IBBS-24v-3ah battery back-up system.
The IBBS-24v-CHARGER provides a simple means to keep an IBBS
system fully charged during long term product storage. Additionally, the
charger can provide full power to the IBBS system for fast charging after doing
continued airworthiness inspections.
The IBBS-24v-CHARGER is connected to standard line voltage power
from 100-240 VAC, 50/60 Hz. The unit is provided with the mating CPC
connector that matches up to the IBBS product. The charger also has an LED
indicator to show the battery charge state.
The IBBS-24v-CHARGER is intended only to be used for charging a TCW
Technologies, LLC. IBBS-24v-3ah back-up battery system, no other uses are
permitted. The charger is an indoor type product and not intended to be
exposed to rain, snow, damp environments or high humidity or utilized
outdoors.
The IBBS-24v-CHARGER will only charge the IBBS battery pack, it will
not provide pass through power to any other equipment.

725.0046 REV 1.1 © 2019 TCW Technologies, LLC.
2
Operation and Use:
1) Disconnect the IBBS unit from the aircraft wiring harness.
2) Connect the IBBS-24v-CHARGER to the D-sub connector on an IBBS
Integrated Back-up Battery System.
2) Plug the line cord into a suitable source of power (100-240 Vac).
The IBBS-24v-CHARGER provides full charge capability of an IBBS unit. If an
IBBS unit is to be stored for a long period of time (9 months or greater), it is
recommended that it be connected to the IBBS-24v-CHARGER and left
plugged into AC power for a period of 2 hours. The IBBS-24v-CHARGER
may be left connected to the IBBS unit for as long as desired.
When using the IBBS-24v-CHARGER to fast charge an IBBS unit, leave the
system connected for at least 2 hours.
The indicator on the charger shows that power is available, the IBBS unit
determines and controls the charge profile of the battery.
For service or if you have questions, please contact us.
610-928-3420
www.tcwtech.com
email: [email protected]
TCW Technologies, LLC.
2955 Main Road East
Emmaus, PA 18049
