TDT RZ2 User manual

System3Manual
Updated: 5/8/18

2System 3
Copyright
©2000-2018 Tucker-Davis Technologies, Inc. (TDT). All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording, for any
purpose without the express written permission of TDT.
Tucker-Davis Technologies
11930 Research Circle
Alachua, FL 32615 USA
Phone: [phone]
Fax: [phone]
Notices
The information contained in this document is provided “as is,” and is subject to
being changed, without notice. TDT shall not be liable for errors or damages in
connection with the furnishing, use, or performance of this document or of any
information contained herein.
The latest versions of TDT documents are always online at www.tdt.com/
support.htm.
A CAUTION informs users when failure to take or avoid a specified action could
result in damage to the product or loss of data.
A WARNING calls attention to an operating procedure or practice that, if not
correctly performed or adhered to, could result in personal injury or death. Do
not proceed beyond a WARNING notice until the indicated conditions are fully
understood and met.
Licenses and Trademarks
ZIF-Clip® is a registered trademark of Tucker-Davis Technologies.
Warranty
TDT System 3 hardware* carries a five-year warranty on parts and labor.
Contact TDT to obtain an RMA (return merchandise authorization) number
before returning any hardware.
* Custom hardware carries a one-year warranty on parts and labor. All
headstages, the ES1 and the EC1 carry a two year warranty.

3
System3ManualTableofContents
Part1:RZZ‐SeriesProcessors
RZ2BioAmpProcessor.....................................................................................................................................1‐3
RZ5DBioAmpProcessor............................................................................................................................... 1‐17
RZ5PFiberPhotometryProcessor ........................................................................................................... 1‐27
RZ6MultiI/OProcessor ............................................................................................................................... 1‐35
RZ5BioAmpProcessor.................................................................................................................................. 1‐51
RZ‐UDPCommunicationsInterface......................................................................................................... 1‐63
Part2:DataStreamers
RS4DataStreamer.............................................................................................................................................2‐3
PO8eStreamingInterfacefortheRZ ...................................................................................................... 2‐27
Part3:RXProcessors
RX8MultiI/OProcessor .................................................................................................................................. 3‐3
RX6MultifunctionProcessor ...................................................................................................................... 3‐13
RX5PentusaBaseStation ............................................................................................................................ 3‐25
RX7StimulatorBaseStation....................................................................................................................... 3‐35
Part4:RPProcessors
RP2.1Real‐TimeProcessor .............................................................................................................................4‐3
RA16BAMedusaBaseStation.......................................................................................................................4‐9
RV8BarracudaProcessor ............................................................................................................................ 4‐13
Part5:RMMobileProcessors
RM1/RM2MobileProcessors.........................................................................................................................5‐3
Part6:Preamplifiers
PZ5NeuroDigitizer............................................................................................................................................6‐3
PZ5MMedicallyIsolatedNeuroDigitizer .............................................................................................. 6‐31
PZ2PreAmp ....................................................................................................................................................... 6‐59
PZ3LowImpedanceAmplifier................................................................................................................... 6‐67
PZ4DigitalHeadstageManifold................................................................................................................ 6‐79
RA16PA/RA4PAMedusaPreAmps ........................................................................................................... 6‐83

4System 3
RA8GAAdjustableGain PreAmp................................................................................................................ 6‐89
HeadstageConnectionGuide ...................................................................................................................... 6‐93
TB3232‐ChannelDigitizer.......................................................................................................................... 6‐97
PZ5‐BATExternalCharger ........................................................................................................................6‐101
PZ‐BATExternalBatteryPackforthePZAmplifiers .....................................................................6‐105
Part7:StimulusIsolator
IZ2/IZ2HStimulator..........................................................................................................................................7‐3
IZ2M/IZ2MHStimulator............................................................................................................................... 7‐21
MS4/MS16StimulusIsolator...................................................................................................................... 7‐33
Part8:VideoProcessor
RV2VideoProcessor..........................................................................................................................................8‐3
RVMapSoftwareforRV2.............................................................................................................................. 8‐21
Part9:MicroElectrodeArrayInterface
MZ60MicroElectrodeArrayInterface .......................................................................................................9‐3
Part10:HighImpedanceHeadstages
ZIF‐Clip®AnalogHeadstages .................................................................................................................... 10‐3
ZIF‐Clip®ZDDigitalHeadstages ...........................................................................................................10‐13
ZIF‐Clip®ZCDDigitalHeadstages.........................................................................................................10‐21
ZIF‐Clip®HeadstageHolders ...................................................................................................................10‐29
Acute(Non‐ZIF)Headstages.....................................................................................................................10‐33
Chronic(Non‐ZIF)Headstages.................................................................................................................10‐41
ECoGHeadstages............................................................................................................................................10‐45
SH16SwitchableHeadstages....................................................................................................................10‐47
Part11:LowImpedanceHeadstages
LowImpedanceHeadstages........................................................................................................................ 11‐3
Part12:AdaptersandConnectors
ZIF‐Clip®HeadstageAdapters.................................................................................................................. 12‐3
ProbeAdapters ...............................................................................................................................................12‐19
Splitters..............................................................................................................................................................12‐25
Connectors........................................................................................................................................................12‐31
PreamplifierAdapters .................................................................................................................................12‐33
Part13:MicrowireArrays
ZIF‐Clip®BasedMicrowireArrays ......................................................................................................... 13‐3
OmneticsBasedMicrowireArrays........................................................................................................... 13‐9
SuggestionsforMicrowireInsertion .....................................................................................................13‐11
zDriveMicrodriveswithZIF‐Clip®MicrowireArrays ..................................................................13‐15
ProcedureforzDriveImplantationandMaintenance...................................................................13‐17

System 3 5
Part14:Attenuator
PA5ProgrammableAttenuator................................................................................................................. 14‐3
Part15:Commutators
ACO32/ACO64MotorizedCommutators............................................................................................... 15‐3
Part16:TransducersandAmplifiers
MF1Multi‐FieldMagneticSpeakers........................................................................................................ 16‐3
EC1/ES1ElectrostaticSpeaker .................................................................................................................. 16‐9
ED1ElectrostaticSpeakerDriver ...........................................................................................................16‐15
HB7HeadphoneBuffer ...............................................................................................................................16‐17
MA3MicrophoneAmplifier.......................................................................................................................16‐21
MS2MonitorSpeaker ..................................................................................................................................16‐25
SA1StereoAmplifier ....................................................................................................................................16‐27
SA8EightChannelPowerAmplifier....................................................................................................16‐29
FLYSYSFlashLampSystem.......................................................................................................................16‐33
CF1/FF1MagneticSpeakers ....................................................................................................................16‐37
Part17:SubjectInterface
RBOXResponseBox ........................................................................................................................................ 17‐3
HTI3HeadTrackerInterface ..................................................................................................................... 17‐9
BBOXButtonBox ...........................................................................................................................................17‐17
BH32BehavioralCageController...........................................................................................................17‐25
Part18:SignalHandling
FB128NeuralSimulator .............................................................................................................................. 18‐3
PP24PatchPanel ............................................................................................................................................ 18‐9
PP16PatchPanel ..........................................................................................................................................18‐15
PM2RelayPowerMultiplexer....................................................................................................................18‐21
SM5SignalMixer...........................................................................................................................................18‐27
ETM1ExperimentTestModule ................................................................................................................18‐29
Part19:PCInterfaces
InterfaceTransferRates............................................................................................................................... 19‐3
PO5/PO5eOptibitInterface........................................................................................................................ 19‐5
UZ3USB3.0InterfaceforOptibit............................................................................................................. 19‐9
UZ2USB2.0Interface..................................................................................................................................19‐11
LO5ExpressCardtozBusInterface........................................................................................................19‐13
GigabitInterface............................................................................................................................................19‐15
Part20:ThezBusandPowerSupply
ZB1PS‐PoweredzBusDeviceChassis.................................................................................................... 20‐3
ZB1DeviceCaddieandPS25FPowerSupply....................................................................................... 20‐7

6System 3
Part21:System3Utilities
zBUSmonInterfaceTestingSoftware ..................................................................................................... 21‐3
CorpusSystem3HardwareEmulator ..................................................................................................21‐11
Part22:ComputerWorkstation
WS4/WS8HighPerformanceComputerWorkstation.................................................................... 22‐3

Part1:RZZ‐SeriesProcessors

1-2 System 3

1-3
RZ2 BioAmp Processor
RZ2BioAmpProcessor
RZ2Overview
The RZ2 BioAmp Processor has been designed for high channel count
neurophysiology recording and signal processing. The RZ2 features two (RZ2-2),
four (RZ2-4), or eight (RZ2-8) digital signal processors cards. Any card can be
either a single standard processor card (RZDSP) or a quad-core processor card
(QZDSP). Standard single processor cards use a single Sharc DSP; quad-core
processor cards use four Sharc DSPs Cores with the potential to more than double
the power of the RZ2. All cards are networked on a multiprocessor architecture that
features efficient onboard communication and memory access. The highly optimized
multi-bus architecture uses four dedicated data buses to eliminate data flow
bottlenecks—all transparent to the user. This architecture yields an extremely powerful
system capable of sophisticated real-time processing and simultaneous acquisition on
all channels.
The RZ2 is typically used with a Z-Series Amplifier (such as the PZ5). High
bandwidth data is streamed from the amplifier to the RZ2 over a lossless, fast, fiber
optic connection. Both single and quad-core processors cards may include an optical
interface for connection to devices such as the RS4 Data Streamer, an IZ2
Stimulator or a secondary PZ Amplifier. Each onboard optical connection can support
256 channels at sampling rates up to ~25 kHz and 128 channels at sampling rates
up to ~50 kHz. The RZ2 also features 16 channels of analog I/O, 24 bits of
digital I/O, two Legacy optical inputs for Medusa PreAmps, and an onboard LCD for
system status display.
PowerandCommunication
The RZ2's Optibit optical interface ensures fast and reliable data transfer from the
RZ2 to the PC and is integrated into the device. Connectors are provided on the
back panel and are color coded for correct wiring. The RZ2’s power supply is also
integrated into the device and is shipped from the factory configured for the desired
voltage setting (110 V or 220 V). If you need to change the voltage setting,
please contact TDT support at +1.386.462.9622 or email [email protected].

1-4 System 3
RZ2 BioAmp Processor
The RZ2 is UL compliant, see the RZ2 Operations Manual for power and safety
information.
SoftwareControl
TDT Synapse software controls the RZ2 and provides users a high level interface for
device configuration.
Device programming is implemented with circuit files developed using TDT's RP Visual
Design Studio (RPvdsEx). Circuits are loaded to the processor through TDT run-
time applications or custom applications. This manual includes device specific
information needed for designing circuits. For circuit design techniques and a complete
reference of the RPvdsEx circuit components, see the
RPvdsEx Manual .
RZ2TouchScreen
The touchscreen shows information about each DSP, the optical PC interface, a
connected PZ preamplifier, and system I/O.
Touch a section of the screen to display more detailed information.
Screen Element Information Displayed
DSPs A stacked histogram shows cycle usage for each DSP with the
bottom section (blue) showing the cycle usage taken up by
circuit operation and the top section (pink) showing the cycle
usage required for data transfer.
If the cycle usage surpasses 100%, a bar is drawn above the
100% line in the cycle use histogram and will persist until the
RZ2 is rebooted. For quad-core DSPs, the core with the highest
cycle usage is displayed.
Interface
I/O
Amplifier Status
DSP Information
RQDSP

System 3 1-5
RZ2 BioAmp Processor
Touch to Display:
Optical Config is the peripheral device supported by the DSP,
if any.
Data memory (DM) is the amount of DM used for filter delay
line and short delays.
External Memory (XM) is the amount of XM used for long
delays and buffers.
Program Memory (PM) is the amount of PM used to hold filter
coefficients.
Tabs are enabled for quad-core DSPs, with one Core per tab.
Interface Virtual Status lights display status of the interface (Status),
zTrig-A, and zTrig-B. A stacked histogram shows data transfer
rate in mb/s.
Touch to Display:
Firmware version, MB data received/sent and transfer errors.
Amp Touch to Display:
Amp model, number of channels and firmware version of
connected PZ series amplifier.
DSP #1 Details
Firmware Version:
Model:
DSP Type:
Sample Rate:
Time Slice:
Component Usage:
Core Cycle Use:
Optical Config:
Memory Usage:
XM => 0 of 65536 kBytes
DM => 0 of 32768 Bytes
PM => 0 of 28672 Bytes
Data Pipe Source:
Pipe[A] => Inactive
Pipe[B] => Inactive
Quad Core DSP
12 kHz (24414.0625 Hz)
RZ2 Bioamp Processor
None
0%
0 of 768 Max
10
84
Core-A Core-B Core-C Core-D
zBus Interface Detail
Firmware Version: 1.2
MBytes Received: 8.628
MBytes Sent: 384.397
Errors: 32584

1-6 System 3
RZ2 BioAmp Processor
I/O Virtual indicator lights.
[A], [B], and [C]: Digital I/O
LED will light for an input bit or it will show the logic level for
an output bit.
[D] and [E]: Analog I/O
16 lights indicate the signal level, green when a signal is
present and red to warn that the signal is approaching the
maximum voltage (at which point clipping would occur).
Legacy Optical: Amp Light For The Legacy Preamplifier Sync
Flashes yellow when no amp is connected and will be light
green when the amplifier is correctly connected.
Note: Older versions of the RZ2 have a selection knob that allows the user to highlight a
section of the screen. To display more detailed information, rotate the knob to select
a system component and then push the knob to show the information view.
RZ2Architecture
The RZ2 processor utilizes a highly optimized multi-bus architecture and offers four
dedicated, data buses for fast, efficient data handling. While the operation of the
system architecture is largely transparent to the user, a general understanding is
important when developing circuits in RPvdsEx.
Amplifier Model: No amplifier connected
Firmware Version: 0
Channels: 0
Amplifier Details

System 3 1-7
RZ2 BioAmp Processor
RZ2Multi‐DSPArchitectureFunctionalDiagram
As shown in the diagram above, the RZ2 architecture consists of three
functional blocks:
The DSPs Each DSP in the DSP Block is connected to a local
interface to the four data buses: two buses that connect
each DSP to the other functional blocks and two that handle
data transfer between the DSPs (as described further in
Distributing Data Across DSPs below). Each standard DSP
is connected to 64 MB SDRAM and each core in a QZDSP
is connected to 256 MB DDR2. This architecture facilitates
fast DSP-to-off-chip data handling.
Because each DSP has its own associated memory, access
is very fast and efficient. However, large and complex
circuits should be designed to balance memory needs (such

1-8 System 3
RZ2 BioAmp Processor
as data buffers and filter coefficients) across processors.
Memory use can be monitored on the RZ2 front panel
display.
When designing circuits also note that the maximum number
of components for each RZ2 standard RZDSP is 768 and
1000 for each QZDSP.
The zBus Interface The zBus interface provides a connection to the PC. Data
and host PC control commands are transferred to and from
the DSP Block through the zBus Interface Bus, allowing for
large high-speed data reads and writes without interfering
with other system processing.
The I/O Interface The I/O interface serves as a connection to outside signal
sources or output devices. It is used primarily to input data
from a PZ amplifier via the high speed optical port, but also
serves the Legacy amplifier inputs and digital and analog
channels. The I/O Interface Bus provides a direct connection
to each DSP and the Data Pipe Bus.
DistributingDataAcrossDSPs
For the best performance, processing tasks must be efficiently distributed across the
available DSPs. That means transferring data across DSPs. The RZ2 architecture
provides three data buses for this type of data handling.
TheDataPipeBus
The Data Pipe bus is optimized for handling high count multi-channel data streams
and efficiently transfers up to 256 channels of data between DSPs. The Data Pipe
bus also interconnects to the I/O Interface bus allowing direct access to data from
the PZ amplifiers.
In RPvdsEx data can be transferred across the Data Pipe bus using Data Pipe
components.
PipeSource and MCPipeIn components are used to select a data source (another
DSP or the PZ amplifier) and feed data to a DSP circuit.
MCPipeOut feeds data off the DSP to the Data Pipe Bus.

System 3 1-9
RZ2 BioAmp Processor
The RZ2_Input_MC macro also transfers inputs from the I/O interface to the Data
Pipe bus and DSPs.
ThezHopBus
The zHop bus is useful for transferring single or low channel count signals, such as
timing and control signals.
In RPvdsEx data is transferred across the zHop Bus using paired zHop components,
including zHopIn, zHopOut, MCzHopIn, MCzHopOut, and MCzHopPick. These
components can be used on any DSP or DSP-core. Up to 126 pairs can be used
in a single RPvdsEx circuit.
The zHopBus is less efficient than the Data Pipe bus, so it is not recommended for
multi-channel signals.
BusRelatedDelays
A standard two sample delay is associated with the zHop, and Data Pipe. However,
these delays are taken care of for the user in Synapse and when Timing and Data
Saving macros are used in OpenEx.
50kHzSamplingRateAcquisitionwiththePZAmplifier
The RZ2 and PZ amplifier support sample rates from ~6 kHz to ~50 kHz.
When sampling at a rate of ~50 kHz, there are several important considerations:
•Only the first 128 PZ amplifier channels will be available.
•All Data Pipes will have a max of 128 channels instead of 256.
•Both halves (A and B) of the PipeSource component must be selecting the
desired source. For example, when acquiring data from a PZ amplifier,
Pipe[A] and Pipe[B] both need to be set to Amp. Chan[1...128].
DataTransferRate
As with other devices, your expected sustained RZ-to-Host PC data rate should not
exceed 1/2 to 2/3 of the rated data transfer speed. For the RZ2 device this is 160
Mbits/second (Mbps) so your designs should have a sustained data rate of no

1-10 System 3
RZ2 BioAmp Processor
more than ~100 Mbps. When the RZ2 is processing, the current data transfer rate
(Mbps) is displayed in the top right corner of the LCD Screen. This maximum rate
may be further limited by your PC’s ability to store the data to disk.
This equates to streaming a maximum of 160 channels at a sampling rate of ~25
kHz or 90 channels at a sampling rate of ~50 kHz. See “Calculating Data Transfer
Rates” in the
OpenEx Manual for more information.
RZ2Features
AmplifierandOnboardAnalogI/O
The RZ2 is equipped with both optical port amplifier input and onboard analog I/O
capabilities. The high speed fiber optic ports (located on the RZ2 back panel) and
Legacy fiber optic ports allow a direct connection to Z-Series or Medusa
preamplifiers. Physiological signals are digitized on the preamplifier and transferred
across noiseless fiber optics.
The RZ2 also includes onboard D/A for stimulus generation and experiment control,
and A/D for input of signals from a variety of other analog sources.
The RZ2_Input_MC macro provides a universal solution for analog input via the RZ2,
automatically selecting the correct components, applying any scale factors or channel
offsets, and performing data type conversion needed based on information the user
provides about the input source.
The table below provides a quick overview of these I/O features and how they must
be accessed during circuit design. When the RZ2_Input_MC macro is not used,
reference the table and be sure to use the appropriate component, channel offset,
Analog I/OLegacy PreAmp Input

System 3 1-11
RZ2 BioAmp Processor
scale factor and so forth. Further detail can be found below the table. Also, see the
RPvdsEx Manual for more information.
OnboardAnalogI/O
The RZ2 is equipped with eight channels of 16-bit PCM D/A and eight channels of
16-bit PCM A/D. All 16 channels can be accessed via front panel BNCs marked
Port D and Port E or via a 25-pin analog I/O connector. See “RZ2 Technical
Specifications” on page 1-14, for the DB25 pinout.
PZAmplifierFiberOpticPort
The RZ2's primary amplifier input, a high-speed fiber optic port is located on the
back panel. The connectors on the fiber optic pair used for PZ amplifier
communication are color coded for correct wiring. When designing circuits in
RPvdsEx, the PZ amplifier input channels are accessed using the Pipe components.
When the Data Pipe is used to feed signals from the amplifier an MCInt2Float or
Int2Float must be used with a scale factor of 1e-9.
The amplifier inputs can also be accessed using the RPvdsEx MCAIn component
starting at channel 1; however, this access method is less efficient and not
recommended for high channel count applications. Unlike the Legacy Port, this high
speed port can input up to 256 channels at a maximum sampling rate of 25 kHz or
128 channels at a maximum sampling rate of 50 kHz.
LegacyFiberOpticPorts
The base station can also acquire digitized signals from the Medusa preamplifier,
RA8GA, or other legacy enabled device over a fiber optic cable using the Legacy
ports. Two Legacy fiber optic ports labeled -A- and -B- are provided to support
simultaneous acquisition from up to two Medusa preamplifiers. Each port can input up
Analog I/O Description Components Chan. Notes
Port D Analog
Input
AdcIn 1-8 Standard Configuration (may vary)
Accessed through Port D BNCs or
Analog I/O labeled DB25
Port E Analog
Output
DacOut 9-16 Standard Configuration (may vary)
Accessed through Port E BNCs or
Analog I/O labeled DB25
High Speed
Fiber Optic
Port
Z-Series
BioAmp
Input
(located on
RZ back
panel)
MCPipeIn
PipeIn
recommended
1-256 When the RZ2_Input_MC is
NOT USED, use MCInt2Float
or Int2Float
with a scale factor of 1e-9
MCAdcIn 1-256 No scale required
Legacy
Amp-A
Medusa
PreAmp
Input
AdcIn 17-32 When the RZ2_Input_MC is NOT
USED, apply a scale factor of
.000833
Legacy
Amp-B
Medusa
PreAmp
Input
AdcIn 33-48 When the RZ2_Input_MC is NOT
USED, apply a scale factor of
.000833

1-12 System 3
RZ2 BioAmp Processor
to 16 channels at a maximum sampling rate of 25 kHz. The Legacy fiber optic ports
can be used with any of the Medusa preamplifiers including, the RA16PA, the
RA4PA, or the RA8GA. The channel numbers for each port begin at a fixed offset
regardless of the number of channels available on the connected device.
DigitalI/O
The digital I/O ports include 24 bits of programmable I/O. The digital I/O is divided
into three ports (A, B, and C) as described in the chart below. All digital I/O lines
are accessed via the 25-pin connector on the front of the RZ2 and ports A and C
are available through BNC connectors on the front panel.
See “RZ2 Technical Specifications” on page 1-14, for the DB25 pinout and BNC
channel mapping.
See the “Digital I/O Circuit Design” section of the
RPvdsEx Manual for more
information on programming the digital I/O.
The data direction for the Digital I/O is configured using the RZ2_Control macro in
RPvdsEx.
Double-click the macro to access the settings on the Digital I/O tab. The
RZ2_Control macro also offers a Direction Control Mode parameter that enables the
macro inputs and allows the user to control data direction dynamically. For more
information on using the RZ2_Control macro see the help provided in the macro's
properties dialog box.
Digital I/O Description DB25 BNCs Notes
Port A bits 0 - 7 Yes Yes byte addressable
Port B bits 0 - 7 Yes No byte addressable
Port C bits 0 - 7 Yes Yes bit addressable
Digital I/O

System 3 1-13
RZ2 BioAmp Processor
Note: For more information on addressing and Digital I/O see the RPvdsEx Manual .
The RZ digital I/O ports have different voltage outputs and logic thresholds
depending on the type. The table below depicts the different voltage outputs and
thresholds for both types.
UDPEthernetInterface
The RZ UDP Ethernet interface is designed to transfer data to or from a PC. RZ
devices equipped with a UDP interface contain an additional port located on the back
panel. See “RZ-UDP Communications Interface” on page 1-63, for more
information.
Note: If the RZ2 has 4 optical DSP cards (see below) installed, the UDP Serial port is
not available.
SpecializedDSP/OpticalInterfaceBoards(Optional)
The RZ standard DSP boards can be replaced with specialized DSP boards which
include an optical interface for communication and control of RZ compatible devices,
such as the IZ2 Stimulator and RS4 Data Streamer. RZ devices equipped with one
or more specialized DSP boards include an optical port for each card. The ports are
located on the back panel and labeled for easy identification.
RZDSP-I This board supports the IZ2 Stimulator, allowing the RZ device
to function as a controller or base station. See “Software
Control” on page 7-10, for more information on using and
designing circuits for the stimulator.
RZDSP-S This board supports the RS4 Data Streamer, allowing the RZ
device to stream data directly to the RS4’s storage arrays. See
“RS4 Data Streamer” on page 2-3, for more information on
using and designing circuits for the streamer.
RZDSP-U This board supports the PO8e interface card, allowing the RZ
device to stream data directly to storage arrays on a PC or
other device. See “PO8e Streaming Interface for the RZ” on
page 2-27, for more information.
RZDSP-P This board supports PZ amplifier input, providing an alternate
method for acquiring data from a PZ amplifier. It can be used to
expand the number of channels that can be acquired on any RZ
processor. Access to this input can be enabled in the PZ control
macro.
RZDSP-V This board supports the RV2 Video Tracking System, allowing
the RZ device to function as a controller or base station. See
“RV2 Video Processor” on page 8-3, for more information on
using and designing circuits for the RV2.
Digital I/O Type
Voltage Output Voltage Input
logic high logic low logic high logic low
byte addressable 5 V 0 V ≥2.5 V 0 - 2.45 V
bit addressable 3.3 V 0 V ≥1.5 V 0 - 1.4 V

1-14 System 3
RZ2 BioAmp Processor
QZDSP_OPT This version of the QZDSP quad-core processor includes an
optical interface that can be programmed for use with any of the
RZ compatible devices, such as a secondary PZ Amp, the IZ2
Stimulator, and RS4 Data Streamer. Core-A is always used for
control of the peripheral device.
RZ2TechnicalSpecifications
Note: Technical specifications for amplifier A/D converters are found under the preamplifier's
technical specifications.
DSP
Up to eight standard DSPs and/or quad-core (QZDSP)
DSP: 400 MHz DSPs, 2.4 GFLOPS peak per DSP
QZDSP: Four 400 MHz DSPs, 2.4 GFLOPS per core
Memory 64 MB SDRAM per standard DSP
256 MB DDR2 RAM per core, four cores per QZDSP
D/A 8 channels, 16-bit PCM
Sample Rate Up to 48828.125 Hz
Frequency Response DC - 0.44*Fs (Fs = sample rate)
Voltage Out +/- 10.0 Volts, 175 mA max load
S/N (typical) 82 dB (20 Hz - 20 kHz at 9.9 V)
Output Impedance 10 Ohms
A/D 8 channels, 16-bit PCM
Sample Rate Up to 48828.125 Hz
Frequency Response DC - 7.5 kHz (3 dB corner, 2nd order, 12 dB per
octave)
Voltage In +/- 10.0 Volts
S/N (typical) 82 dB (20 Hz - 20 kHz at 9.9 V)
Input Impedance 10 kOhms
Fiber Optic Ports
Z-Series
One 256-channel input
The maximum sample rate is 48828.125 Hz when recording
up to 128 channels or 24414.0625 Hz when recording 129
- 256 channels).
Legacy (Medusa) Two 16-channel inputs
Add-on Specialty (Optional) Up to four, one per QZDSP_Opt or Specialty DSP card
upgrade.
Digital I/O 8 programmable bits: 3.3 V, 25 mA max load
2 programmable bytes (16 bits): 5.0 V, 35 mA max load
