SERVICE MANUAL
CTF6870S
68CM CTV
APR03 SERVCTF6870

TEAC
SERVICE MANUAL
1. Caution……………………………………………………………2
2. Specification………………………………………………………6
3. BOM List …………………………………………………………13
4. Alignment Procedure………………………………………….…36
5. Block Diagram……………………………………………………42
6. Schematic Diagram………………………………………………43
7. PCB Layout………….……………………………………………44
8. Exploded View Diagram ……………………Temporary Absence
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product.
CT-F6870S

WARNING: TOREDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SER VICING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CAUTION
RISKRISK OFOF ELECTRIELECTRICC
SHOCKSHOCK DODO NOTNOT OPEN.OPEN.
2
dangerous

3
FOR YOUR PERSONAL SAFETY
1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance.Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Save these instructions for later use.Follow all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions- All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
IMPORTANT SAFETY INSTRUCTIONS

4
PROTECTION AND LOCATION OF YOUR SET
11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water.If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
PROTECTION AND LOCATION OF YOUR SET
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits.When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s

OPERATION OF YOUR SET
18. This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
IF THE SET DOES NOT OPERATE PROPERLY
21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off.If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
FOR SERVICE AND MODIFICATION
24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.
25.When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
5
off

6
PRODUCT SPECIFICATION
MODEL：
：：
：CT-F6870S
AMBIENT CONDITIONS：
：：
：
AMBIENT TEMPERATURE：
：：
：
OPERATING ：
：：
：-10°
°°
°C ~ +40°
°°
°C
STORAGE：
：：
：-15°
°°
°C ~ +45°
°°
°C
HUMIDITY
OPERATING：＜
：＜：＜
：＜80%
STORAGE: ＜
＜＜
＜90%
AIR PRESSURE: 86kpa ~ 106kpa
PREPAREDBY: DATE:
APPROVEDBY: DATE:

7
A: GENERAL SPECIFICATION :
1: CRT
14”20”
21”25”
X
X 29”34”OTHER
2: CHASSIS:
DIGITAL NICAMSTEREO
X
X ANALOG
SURROUND SOUND TELETEXT
X
X GERMAN STEREO
X
X
S.VHS
X
X
OTHER COMB-F ,VM, INTERNAL WOOFER BOX
3: CPU:
TSB M5C01 TSB M5C03 TSB M5ENG TSB M6/M6A TSB M7/M7A
TSB M8A TSB M8B TSB CTS-654A TSB M2A SS M4F
PHIL.CTV 222S MIT.(2911) SIE SDA 5352
X
X 其他(OTHERS) M13
4: TV BROADCASTING SYSTEM AND COUNTRY
PAL-I
X
X PAL-BG PAL-DK PAL-DK.1
PAL-DK.BG SECAM-BG SECAM-L SECAM-DK.BG
PAL-N NTSC-M
X
X NTSC3.579/4.43 AV MODE 21 MULTI SYSTEM
UK HK GERMAN RUSSIA
CHINA USA E.EUROPE VIETNAM
CANADA DUBAI INDONESIA S.AFRICA
MALAYSIA MID. AMERICA SINGAPORE
ISRAEL
X
X AUSTRALIA & NEW ZEALAND TAIWAN MOROCCO
PHILIPPINES OTHER
5：RECEIVING CHANNELS
CH21--CH69 CH2--CH12（CCIR）
CHFA-CHS20（FRANCE BAND）CH2--CHS41（HYPER BAND）
CH21--CH69 CH21--CH69
CH2--CHS20（CABLE BAND）CH2--CH13（USA BAND）

8
CH21--CH69 CH14--CH83
CHR1--CHR12（OIRT）CH1--CH12/CH13-CH57（CHINA BAND）
X
X OTHER CATV 470MHz
6：SCANNING LINES AND FREQUENCIES
625 LINES 15.625kHz 50Hz
525 LINES 15.75kHz 60Hz
X
X 525/625 LINES 15.625kHz /15.75kHz 50/60Hz
7：COLOUR SUB-CARRIER
X
X
4.433MHz
X
X
3.579MHz 3.58MHz
8：INTERMEDIATE FREQUENCIES
PICTURE 39.5MHz SOUND 6.0MHz
X
X PICTURE 38.9MHz
X
X SOUND5.5MHz
PICTURE 38.0MHz SOUND 6.5MHz
PICTURE 45.75MHz SOUND 4.5MHz
OTHER AM SOUND 6.5MHz
9：POWER CONSUMPTION ：
65W 70W 75W 80W 110W 120W
X
X
130W 140W 180W 190W OTHER
10：POWER SOURCE ：
AC 120V 60Hz±10％
AC 200V 50Hz±10％
AC 220V 50Hz±10％
AC 220V 50Hz+10％~25％
X
X AC 240V 50Hz±10％
AC 110V-240V 50/60Hz±10％
OTHER
11：AUDIO OUTPUT POWER (7％THD)

9
13”&14”---1W
20”& 21”---2W
20”& 21”---2W + 2W (R + L)
25”---4W + 4W (R + L)
X
X 29”>=6W + 6W (R + L)
34”---8W + 8W(R + L)
OTHER
12：AERIAL INPUT IMPEDANCE
X
X 75 ΩUNBALANCED DIN JACK ANT.INPUT75
75ΩUNBALANCED F TYPE ANT.INPUT FOR NTSC
300 ΩBALANCED（TWO TERMINALS ANT.INPUT）
OTHER
13：PRODUCT SAFETY REQUIREMENT
BS APPROVAL
VDE APPROVAL
UL APPROVAL
CHINA APPROVAL
X
X CB APPORVAL
X
X OTHER SAA EMC
14：PRODUCT EMC/EMI REQUIREMENT
FTZ APPOVAL
FCC APPROVAL
X
X CHINA APPOVAL
OTHER
B：BASIC FEATURES OF CONTROLLER
1：CHANNEL TUNING METHOD
X
X VOLTAGE SYNTHESIZER (V.S.)

10
PLL FREQUENCY SYNTHESIZER (F.S.)
2：PRESETTABLE PROGRAM
50 PROGRAMS 0-99 PROGRAMS
X
X 100 PROGRAMS 181 PROGRAMS
OTHER
3：TUNING FOR VHF AND UHF BANDS
X
X AUTO SEARCH）
X
X MANUAL TUNING）
X
X
FINE TUNING
4：PICTURE AND SOUND ADJUSTMENT
X
X BRIGHT，CONTRAST，COLOUR AND VOLUME CONTROL
X
X TINT CONTROL(NTSC)
TREBLE，BASS，BALANCE CONTROL
X
X SHARPNESS CONTROL
X 4D FAULT SOUND STETTING, FIVE-BAND EQUALIZER
5：TELETEXT
SIMPLETEXT TOP(TABLE OF PAGES)
FLOF(FASTEXT) LIST
6：ON SCREEN DISPLAY
X
X
GENERAL FEATURES∗STEREO DUAL LAN.
FOUR S.EFFECT INDICATOR GERMAN STEREO INDICATOR
注： ∗REMARK：OSD-GENERAL FEATURES OF CPU：
VOLUME，BRIGHTNESS，CONTRAST，COLOUR，PROGRAM，BAND，
AUTOSEARCH，MANUAL，TUNE，MUTING，AV AND SLEEP TIMER．
7：SLEEP TIMER
X
X 10-120 MINUTES WITH 10M.INCREMENT
8：AUTO OFF WHEN NO BROADCASTING SIGNAL
10 min
X
X 15min 20 min

11
9：FULL FUNCTION INFRARED REMOTE CONTROL
P/N OF REMOTE CONTROL INLAY) : 58-HS46F2-MUI
10：REMOTE EFFECTIVE DISTANCE 8 m
C：CONSTRUCTION OF FRONT PANEL
X
X MAINPOWERSWITCH FUNCTION SELECT
X
X REMOTESENSOR
X
X MENU SELECT
SYSTEMFUNCTION S.VHS INPUT
MICROPHONE INPUT
X
X TV/AV SELECT
X
X STANDBY INDICATOR
X
X PROGRAM VOLUME UP/DOMN
BAND SELECT
X
X RCA SOCKET (SIDE)
EARPHONE INPUT OTHER
AUTO SEARCH AND MANUAL TUNING SELECT
D：CONSTRUCTION OF REAR PANEL
X
X 75ΩAERIAL TERMINAL
300ΩAERIAL TERMINAL
RCA SOCKET(AV INPUT ONLY
RCA SOCKET--AV IN/OUT
X
X
RCA SOCKET --A-R+L IN/OUT，V- IN/OUT
RCA SOCKET --A-R+L /V INPUT X 2，
SCART SOCKET
X
X S.VHS INPUT
EXT/INT SPEAKER SELECT
EXT.SPEAKERS（R+L）TERMINALS
EXT.SPEAKERS（R+L）RCA SOCKET
SUPER WOOFER TERMINAL
X
X
OTHER YUV
E：AUDIO AND VIDEO INPUT/OUTPUT

12
X
X RCA SOCKET
SCART SOCKET(AV)
S SCART SOCKET(FULL)
SPECIFICATION SCART RCA
VIDEO INPUT 75ΩS 1VP-P 1VP-P
AUDIO INPUT 10kΩ(R+L) 0.5VrmS 0.5VrmS
VIDEO OUTPUT 75Ω1VP-P 1VP-P
AUDIO OUTPUT 1kΩ(R+L) 0.5VrmS 0.5VrmS
RGB INTPUT 75Ω0.7VP-P
AUDIO LINE OUTPUT 1kΩ1VP-P
F：OTHERS INFORMATION
1. FLYBACK ：37-BS2901-58BOX
2. TUNER ：07-389VI5-NX4
3. SAW FILTER ：45-SAWK33-50K
4. POWER CORD ：
5. FUSE ：
6. COLOUR TEMP ：
7. MAGNETIC FIELD ：
8. IC EEPROM ：13-00M24C-08P
9. IR RECEIVER ：11-IRR001-1X0
10. CIRCUIT DIAGRAM ：01-29704T-MA5
11. MAIN BOARD ：40-2916MT-MAH

Sheet1
03-29704T-AA5 Effective Date : 2002-7-23
Parent Item Parent Item Description Item No. Item Description Item Type Quantity
Requirement Designator
08-29704T-MAN ASS'Y - MAIN BD 27-MBC104-J0X CAP. M.P.E.0.1 UF 50V +/-5% C 6 C102, C211, C212, C213, C242,
C252
08-29704T-MAN ASS'Y - MAIN BD 27-PBC222-J0X CAP. P.E. 2200 PF 50V +/-5% C 2 C207, C221
08-29704T-MAN ASS'Y - MAIN BD 27-PBC223-J0X CAP. P.E. 0.022UF 50V +/-5% C 2 C611, C612
08-29704T-MAN ASS'Y - MAIN BD 27-PBC273-J0X CAP. P.E 0.027UF 50V +/-5% C 2 C653, C659
08-29704T-MAN ASS'Y - MAIN BD 27-PBC333-J0X CAP. P.E 0.033UF 50V +/-5% C 1 C302
08-29704T-MAN ASS'Y - MAIN BD 27-PBC393-J0X CAP. P.E 0.039UF 50V +/-5% C 1 C308
08-29704T-MAN ASS'Y - MAIN BD 27-PBC472-J0X CAP. P.E. 4700PF 50V +/-5% C 1 C244
08-29704T-MAN ASS'Y - MAIN BD 27-PBC563-J0X CAP. P.E 0.056 UF 50V +/-5% C 1 C304
08-29704T-MAN ASS'Y - MAIN BD 27-PBC822-J0X CAP. P.E. 8200 PF 50V +/-5% C 2 C652, C656
08-29704T-MAN ASS'Y - MAIN BD 27-RHQ563-J0X CAP. PP 0.056 UF 400V +/-5% C 1 C451
08-29704T-MAN ASS'Y - MAIN BD 34-R120J2-0EX COIL PL - 12 UH +/-5% C 1 L256
08-29704T-MAN ASS'Y - MAIN BD 13-TCLM13-V1P IC TCLM13V1 3CD4 (CPU) H 1 IC001
08-29704T-MAN ASS'Y - MAIN BD 18-CD0392-JNX RES. C.F. 3.9K OHM 1/4W +/-5% C 2 R312, R725
08-29704T-MAN ASS'Y - MAIN BD 18-CE0229-JNX RES. C.F. 2.2 OHM 1/2W +/-5% C 1 R305
08-29704T-MAN ASS'Y - MAIN BD 18-FG0479-JHX RES. M.O. 4.7 OHM 2W +/-5% C 1 R303
08-29704T-MAN ASS'Y - MAIN BD 27-RHQ223-J0X CAP. PP 0.022 UF 400V +/-5% C 1 C416
08-29704T-MAN ASS'Y - MAIN BD 36-WID601-XX1 COIL CHOKE 600 UH C 1 L414
08-29704T-MAN ASS'Y - MAIN BD 70-271510-00A SERVICE CARD C 1 FOR PRODUCTION USE
08-29704T-MAN ASS'Y - MAIN BD 62-2970TB-0UN TERMINAL BD BRACKE
T
C1
08-29704T-MAN ASS'Y - MAIN BD 27-ALQ272-J0X CAP. M.PP 0.0027UF 1.6KV +/-5% C 1 C413
08-29704T-MAN ASS'Y - MAIN BD 27-ALQ432-J0X CAP. M.PP 4300 PF 1.6KV +/-5% C 1 C414
08-29704T-MAN ASS'Y - MAIN BD 27-ALR822-J0X CAP. M.PP 8200 PF 1.6KV +/-5% C 1 C415
08-29704T-MAN ASS'Y - MAIN BD 36-LIN240-XX1 COIL LINEARITY 24 UH C 1 L413
08-29704T-MAN ASS'Y - MAIN BD 18-GM0302-KT
X
RES. CEMENT 3K OHM 7W +/-10% C 1 R404
08-29704T-MAN ASS'Y - MAIN BD 37-SC2901-58B0X FLYBACK BSC29-0158B C 1 T461
08-29704T-MAN ASS'Y - MAIN BD 18-CD0681-JNX RES. C.F. 680 OHM 1/4W +/-5% C 1 R724
08-29704T-MAN ASS'Y - MAIN BD 27-PBC103-J0X CAP. P.E. 0.01UF 50V +/-5% C 1 C052
08-29704T-MAN ASS'Y - MAIN BD 18-CB0622-JNX RES. C.F. 6.2K OHM 1/6W +/-5% C 1 R231
08-29704T-MAN ASS'Y - MAIN BD 18-CB0393-JNX RES. C.F. 39K OHM 1/6W +/-5% C 1 R314
08-29704T-MAN ASS'Y - MAIN BD 27-AGQ514-JSX CAP. M.PP 0.51 UF 250V +/-5% C 1 C418
08-29704T-MAN ASS'Y - MAIN BD 62-2970MB-0UN MAIN BD BRACKE
T
C1
08-29704T-MAN ASS'Y - MAIN BD 63-W30100-AB4 S/T SCREW W 3 X 10 AB C 2 MTG TERM. BKT & M.BD BK
T
08-29704T-MAN ASS'Y - MAIN BD 18-FG0100-JHX RES. M.O. 10 OHM 2W +/-5% C 1 J211
08-29704T-MAN ASS'Y - MAIN BD 27-MBC473-J0X CAP. M.P.E. 0.047 UF 50V +/-5% C 2 C603, C604
08-29704T-MAN ASS'Y - MAIN BD 46-32282H-02X HS 2P22 300 F/W SCN2Y/SM2R WH C 1 P621A FOR REAR CAB.
08-29704T-MAN ASS'Y - MAIN BD 18-CB0133-JNX RES. C.F. 13K OHM 1/6W +/-5% C 1 R452
08-29704T-MAN ASS'Y - MAIN BD 18-CD0182-JNX RES. C.F. 1.8K OHM 1/4W +/-5% C 1 R313
08-29704T-MAN ASS'Y - MAIN BD 18-EG0689-JHX RES. FUSE 6.8 OHM 2W +/-5% C 1 R461
13

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 C 5 FOR T461
08-29704T-MAN ASS'Y - MAIN BD 41-BF0100-3BB WIRE UL 1007 #24 100MM ORG C 1 FOR P1 - P1
08-29704T-MAN ASS'Y - MAIN BD 13-000040-52P IC 4052 H 2 IC961, IC962
08-29704T-MAN ASS'Y - MAIN BD 13-0TDA26-16S IC TDA2616 (AUDIO O/P) H 1 IC601
08-29704T-MAN ASS'Y - MAIN BD 13-TA1216-ANP IC TA1216AN H 1 IC651
08-29704T-MAN ASS'Y - MAIN BD 13-TB1240-ANP IC TB1240AN H 1 IC201
08-29704T-MAN ASS'Y - MAIN BD 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% C 13
R053, R056, R205, R206, R917,
R918, R919, R926, R927, R928,
R929, R973, R983
08-29704T-MAN ASS'Y - MAIN BD 18-CB0106-JNX RES. C.F. 10M OHM 1/6W +/-5% C 1 R116
08-29704T-MAN ASS'Y - MAIN BD 18-CB0123-JNX RES. C.F. 12K OHM 1/6W +/-5% C 2 R244, R951
08-29704T-MAN ASS'Y - MAIN BD 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% C 4 R127, R934, R935, R994
08-29704T-MAN ASS'Y - MAIN BD 18-CB0152-JNX RES. C.F. 1.5K OHM 1/6W +/-5% C 5 R063, R204, R212, R213, R214
08-29704T-MAN ASS'Y - MAIN BD 18-CB0181-JNX RES. C.F. 180 OHM 1/6W +/-5% C 1 R123
08-29704T-MAN ASS'Y - MAIN BD 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% C 1 R715
08-29704T-MAN ASS'Y - MAIN BD 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% C 8 R012, R203, R215, R216, R217, R255, R261, R401
08-29704T-MAN ASS'Y - MAIN BD 18-CB0224-JNX RES. C.F. 220K OHM 1/6W +/-5% C 1 R251
08-29704T-MAN ASS'Y - MAIN BD 18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% C 1 R711
08-29704T-MAN ASS'Y - MAIN BD 18-CB0272-JNX RES. C.F. 2.7K OHM 1/6W +/-5% C 1 R227
08-29704T-MAN ASS'Y - MAIN BD 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% C 4 R222, R223, R229, R259
08-29704T-MAN ASS'Y - MAIN BD 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% C 4 R125, R252, R931, R932
08-29704T-MAN ASS'Y - MAIN BD 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% C 5 R052, R115, R262, R263, R284
08-29704T-MAN ASS'Y - MAIN BD 18-CB0560-JNX RES. C.F. 56 OHM 1/6W +/-5% C 1 R122
08-29704T-MAN ASS'Y - MAIN BD 18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% C 1 R228
08-29704T-MAN ASS'Y - MAIN BD 18-CB0750-JNX RES. C.F. 75 OHM 1/6W +/-5% C 1 R933
08-29704T-MAN ASS'Y - MAIN BD 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% C 4 R913, R923, R971, R981
08-29704T-MAN ASS'Y - MAIN BD 18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% C 3 R022, R232, R286
08-29704T-MAN ASS'Y - MAIN BD 18-CD0181-JNX RES. C.F. 180 OHM 1/4W +/-5% C 1 R226
08-29704T-MAN ASS'Y - MAIN BD 18-CD0222-JNX RES. C.F. 2.2K OHM 1/4W +/-5% C 1 R723
08-29704T-MAN ASS'Y - MAIN BD 18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% C 2 R607, R608
08-29704T-MAN ASS'Y - MAIN BD 18-CE0121-JNX RES. C.F. 120 OHM 1/2W +/-5% C 1 R731
08-29704T-MAN ASS'Y - MAIN BD 18-FF0103-JGX RES. M.O. 10K OHM 1W +/-5% C 1 R421
08-29704T-MAN ASS'Y - MAIN BD 18-FF0221-JGX RES. M.O. 220 OHM 1W +/-5% C 1 R307
08-29704T-MAN ASS'Y - MAIN BD 18-FF0242-JGX RES. M.O. 2.4K OHM 1W +/-5% C 1 R402
08-29704T-MAN ASS'Y - MAIN BD 18-FF0681-JGX RES. M.O. 680 OHM 1W +/-5% C 1 R411
08-29704T-MAN ASS'Y - MAIN BD 18-FG0399-JHX RES. M.O. 3.9 OHM 2W +/-5% C 1 R726
08-29704T-MAN ASS'Y - MAIN BD 18-GF0109-JGX RES WIRE ROUND 1 OHM 1W +/-5% C 1 R311
08-29704T-MAN ASS'Y - MAIN BD 18-GG0109-JHX RES WIRE ROUND 1 OHM 2W +/-5% C 1 R422
08-29704T-MAN ASS'Y - MAIN BD 25-264610-M1X CAP. ELEC 4.7UF 50V +/-20% NP C 1 C417
08-29704T-MAN ASS'Y - MAIN BD 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B C 2 C431, C441
08-29704T-MAN ASS'Y - MAIN BD 26-AIC332-KBX CAP. CER 3300 PF 500V +/-10% B C 1 C402
14

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B C 1 C403
08-29704T-MAN ASS'Y - MAIN BD 34-A608K6-1BX COIL CHOKE 0.6 UH +/-10% C 1 L412
08-29704T-MAN ASS'Y - MAIN BD 34-R100J2-0EX COIL PL - 10 UH +/-5% C 1 L252
08-29704T-MAN ASS'Y - MAIN BD 34-R101J2-0EX COIL PL - 100 UH +/-5% C 3 L201, L211, L271
08-29704T-MAN ASS'Y - MAIN BD 34-R220J2-0EX COIL PL - 22 UH +/-5% C 3 L051, L081, L251
08-29704T-MAN ASS'Y - MAIN BD 34-R229J2-0EX COIL PL - 2.2 UH +/-5% C 1 L053
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0070-B00 WIRE BARE JUMPER 7MM C 7 J023, J426, J513, J671, J672, J726, J741
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0080-B00 WIRE BARE JUMPER 8 MM C 4 J201, J425, J443, J453
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0095-B00 WIRE BARE JUMPER 9.5MM C 4 J226, J343, J344, J713
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0105-B00 WIRE BARE JUMPER 10.5MM C 4 J311, J333, J442, J622
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM C 6 J052, J246, J342, J522, J627, J628
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0120-B00 WIRE BARE JUMPER 12MM C 6 J051, J250, J253, J254, J434, J711
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0140-B00 WIRE BARE JUMPER 14MM C 5 J321, J335, J336, J337, J742
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM C 3 J221, J234, J314
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0180-B00 WIRE BARE JUMPER 18MM C 2 J214, J623
08-29704T-MAN ASS'Y - MAIN BD 54-128700-0X0 FIBRE WASHER 3.3 X 10 X 0.8 C 2 MTG M.BD & FB
T
08-29704T-MAN ASS'Y - MAIN BD 62-10654X-00F UNI - TIE (2.5MMX95MM
)
C12
08-29704T-MAN ASS'Y - MAIN BD 62-227680-0UA HOLDER CABLE FOR FBT (2) C 1
08-29704T-MAN ASS'Y - MAIN BD 67-H27292-1A0 HEAT SINK-REGULATOR & DPC A=60 C 1 FOR Q722
08-29704T-MAN ASS'Y - MAIN BD 18-CB0201-JNX RES. C.F. 200 OHM 1/6W +/-5% C 1 R993
08-29704T-MAN ASS'Y - MAIN BD 18-CD0100-JNX RES. C.F. 10 OHM 1/4W +/-5% C 1 R064
08-29704T-MAN ASS'Y - MAIN BD 18-CE0470-JNX RES. C.F. 47 OHM 1/2W +/-5% C 1 R103
08-29704T-MAN ASS'Y - MAIN BD 26-AIM103-KB
X
CAP. CER 0.01 UF 500V +/-10% B C 1 C401
08-29704T-MAN ASS'Y - MAIN BD 18-FE0121-JNX RES. M.O. 120 OHM 1/2W +/-5% C 1 R306
08-29704T-MAN ASS'Y - MAIN BD 25-BCB220-M1
X
CAP. ELEC 22 UF 16V +/-20% C 1 C278
08-29704T-MAN ASS'Y - MAIN BD 25-BEA221-M1
X
CAP. ELEC 220 UF 35V +/-20% C 1 C306
08-29704T-MAN ASS'Y - MAIN BD 25-BEB101-M1
X
CAP. ELEC 100 UF 35V +/-20% C 1 C731
08-29704T-MAN ASS'Y - MAIN BD 25-BEG222-M1
X
CAP. ELEC 2200 UF 35V +/-20% C 2 C303, C309
08-29704T-MAN ASS'Y - MAIN BD 25-BFB100-M1
X
CAP. ELEC 10 UF 50V +/-20% C 2 C222, C311
08-29704T-MAN ASS'Y - MAIN BD 25-BFB108-M1
X
CAP. ELEC 0.1 UF 50V +/-20% C 1 C271
08-29704T-MAN ASS'Y - MAIN BD 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% C 8 C206, C253, C631, C654, C663, C664, C665, C672
08-29704T-MAN ASS'Y - MAIN BD 25-BFB478-M1
X
CAP. ELEC 0.47 UF 50V +/-20% C 1 C208
08-29704T-MAN ASS'Y - MAIN BD 25-BFB479-M1
X
CAP. ELEC 4.7 UF 50V +/-20% C 2 C101, C124
08-29704T-MAN ASS'Y - MAIN BD 25-BKA100-M1
X
CAP. ELEC 10 UF 200V +/-20% C 1 C421
08-29704T-MAN ASS'Y - MAIN BD 25-BKG101-M1
X
CAP. ELEC 100 UF 200V +/-20% C 1 C422
08-29704T-MAN ASS'Y - MAIN BD 25-BLA100-M1
X
CAP. ELEC 10 UF 250V +/-20% C 1 C442
08-29704T-MAN ASS'Y - MAIN BD 38-236560-00X COIL I.F.T. 236560 FOR VCO C 1 T271
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0190-B00 WIRE BARE JUMPER 19MM C 1 J823
08-29704T-MAN ASS'Y - MAIN BD 25-BFB101-M1
X
CAP. ELEC 100 UF 50V +/-20% C 1 C605
08-29704T-MAN ASS'Y - MAIN BD 18-CB0302-JNX RES. C.F. 3K OHM 1/6W +/-5% C 2 R601, R602
15

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 18-FE0472-JNX RES. M.O. 4.7K OHM 1/2W +/-5% C 1 R471
08-29704T-MAN ASS'Y - MAIN BD 25-GFB109-K1X CAP. ELEC 1UF 50V +/-10% C 1 C223
08-29704T-MAN ASS'Y - MAIN BD 18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% C 1 R431
08-29704T-MAN ASS'Y - MAIN BD 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% C 5 R021, R077, R084, R085, R940
08-29704T-MAN ASS'Y - MAIN BD 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C 12
C074, C106, C214, C227, C276,
C651, C655, C661, C662, C666,
C671, C952
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0160-B00 WIRE BARE JUMPER 16MM C 4 J238, J325, J334, J431
08-29704T-MAN ASS'Y - MAIN BD 18-CB0472-JNX RES. C.F. 4.7K OHM 1/6W +/-5% C 4 R066, R211, R965, R967
08-29704T-MAN ASS'Y - MAIN BD 18-CB0332-JNX RES. C.F. 3.3K OHM 1/6W +/-5% C 8 R013, R014, R074, R076, R111, R254, R302, R472
08-29704T-MAN ASS'Y - MAIN BD 67-H30147-1A0 HEAT SINK FOR HORIZ C 1 FOR Q412
08-29704T-MAN ASS'Y - MAIN BD 67-H30179-3A0 HEAT SIN
K
C 1 FOR IC301
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0090-B00 WIRE BARE JUMPER 9MM C 2 J031, J634
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0170-B00 WIRE BARE JUMPER 17MM C 3 J231, J240, J835
08-29704T-MAN ASS'Y - MAIN BD 67-H30705-3A0 HEAT SIN
K
C 1 FOR IC601
08-29704T-MAN ASS'Y - MAIN BD 18-CB0223-JNX RES. C.F. 22K OHM 1/6W +/-5% C 7 R092, R631, R915, R916, R920, R925, R952
08-29704T-MAN ASS'Y - MAIN BD 71-270870-0A9 LABEL H 2
08-29704T-MAN ASS'Y - MAIN BD 25-BEA102-M1
X
CAP. ELEC 1000 UF 35V +/-20% C 4 C432, C607, C608, C610
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM C 8 J410, J511, J514, J615, J632, J725, J729, R238
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0110-B00 WIRE BARE JUMPER 11MM C 11 J227, J228, J244, J302, J313, J322, J324, J612, J614, J625,
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0200-B00 WIRE BARE JUMPER 20MM C 8 J312, J332, J427, J624, J626, J727, J824, J831
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM C 13
J131, J206, J218, J222, J225,
J233, J263, J352, J643, J772,
J813, J951, J981
08-29704T-MAN ASS'Y - MAIN BD 10-0BY228-F0X DIODE BY228 (FAST RECTIFIER) C 1 D411
08-29704T-MAN ASS'Y - MAIN BD 10-1N4001-EBX DIODE 1N4001 (RECTIFIER) C 1 D301
08-29704T-MAN ASS'Y - MAIN BD 10-55C12V-DBX DIODE ZENER 12V 1/2W +/-5% C 2 D731, D732
08-29704T-MAN ASS'Y - MAIN BD 10-55C4V7-DBX DIODE ZENER 4.7V 1/2W +/-5% C 1 D222
08-29704T-MAN ASS'Y - MAIN BD 10-55C5V1-DBX DIODE ZENER 5V1 1/2W +/-5% C 2 D061, D101
08-29704T-MAN ASS'Y - MAIN BD 10-55C8V2-DBX DIODE ZENER 8V2 1/2W +/-5% C 2 D240, D471
08-29704T-MAN ASS'Y - MAIN BD 10-CW574C-DJX DIODE CW574CS C 1 D111
08-29704T-MAN ASS'Y - MAIN BD 10-TFR104-FBX DIODE TFR104 (FAST RECOVERY) C 4 D412, D421, D431, D441
08-29704T-MAN ASS'Y - MAIN BD 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% C 4 R114, R208, R289, R714
08-29704T-MAN ASS'Y - MAIN BD 18-CB0124-JNX RES. C.F. 120K OHM 1/6W +/-5% C 1 R287
08-29704T-MAN ASS'Y - MAIN BD 18-CB0752-JNX RES. C.F. 7.5K OHM 1/6W +/-5% C 1 R221
08-29704T-MAN ASS'Y - MAIN BD 11-SK2541-0BX TRANSISTOR 2SK2541 (N-CHANNEL) H 1 Q052
16

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM C 7 J223, J249A, J251, J661, J811, J912, J913
08-29704T-MAN ASS'Y - MAIN BD 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% C 13
C202, C274, C911, C912, C913,
C921, C922, C923, C931, C932,
C943, C981, C991
08-29704T-MAN ASS'Y - MAIN BD 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% C 22
R005
,
R012A
,
R017
,
R029
,
R031
,
R040, R051, R054, R055, R061,
R101, R102, R225, R237, R633,
R716 R722, R757, R960, R961, R962, R989
08-29704T-MAN ASS'Y - MAIN BD 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% C 8 C064, C217, C228, C257, C658, C934, C944, C969
08-29704T-MAN ASS'Y - MAIN BD 25-BCB221-M1
X
CAP. ELEC 220 UF 16V +/-20% C 2 C634, C933
08-29704T-MAN ASS'Y - MAIN BD 10-1N4148-ABX DIODE 1N4148 (SWITCHING) C 13
D041, D042, D043, D044, D211,
D212, D213, D221, D223, D280,
D632, D711, D721
08-29704T-MAN ASS'Y - MAIN BD 18-CB0222-JNX RES. C.F. 2.2K OHM 1/6W +/-5% C 16
D215
,
D631
,
R041
,
R042
,
R043
,
R044, R242, R603, R604, R713,
R914, R924, R972, R982, R988,
R991
08-29704T-MAN ASS'Y - MAIN BD 27-MBC224-J0X CAP. M.P.E. 0.22 UF 50V +/-5% C 2 C113, C307
08-29704T-MAN ASS'Y - MAIN BD 11-SA1015-YBX TRANSISTOR 2SA1015Y C 6 Q061, Q211, Q242, Q633, Q721, Q934
08-29704T-MAN ASS'Y - MAIN BD 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% C 24
R062
,
R067
,
R071
,
R091
,
R124
,
R220, R269, R271, R301, R304,
R451, R911, R912, R921, R922,
R936 R938, R939, R945, R946, R947, R948, R966, R968
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0050-B00 WIRE BARE JUMPER 5MM C 1 FOR Q241 (B - E)
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-06X PIN BASE *6 TJC3-6A C 1 P002 FOR W.BAL. ADJUST
08-29704T-MAN ASS'Y - MAIN BD 46-12866W-02X PIN BASE *2 S11-02W C 1 P601 FOR FRONT CAB.(SPK)
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-02X PIN BASE *2 TJC3-2A C 1 P602 FOR FRONT CAB.(SPK)
08-29704T-MAN ASS'Y - MAIN BD 11-0BC337-0BX TRANSISTOR BC337-40 (NPN) C 1 Q062
08-29704T-MAN ASS'Y - MAIN BD 11-2N3904-0BX TRANSISTOR 2N3904 (NPN) C 1 Q091
08-29704T-MAN ASS'Y - MAIN BD 11-SC1815-YBX TRANSISTOR 2SC1815Y C 24
Q001
,
Q002
,
Q031
,
Q051
,
Q251
,
Q252, Q261, Q451, Q631, Q711,
Q911, Q912, Q913, Q921, Q922,
Q923 Q931, Q932, Q933, Q963, Q964, Q971, Q981, Q991
08-29704T-MAN ASS'Y - MAIN BD 11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) H 1 Q121
08-29704T-MAN ASS'Y - MAIN BD 11-SC4544-0AX TRANSISTOR 2SC4544 (NPN) C 1 Q401
08-29704T-MAN ASS'Y - MAIN BD 11-DD2553-0AX TRANSISTOR 3DD2553 (HORIZ O/P) C 1 Q412
08-29704T-MAN ASS'Y - MAIN BD 11-SD1499-QAX TRANSISTOR 2SD1499Q (POWER) H 1 Q722
08-29704T-MAN ASS'Y - MAIN BD 26-EBP101-JCX CAP. CER 100 PF 50V +/-5% CH H 5 C032, C071, C254, C255, C272
17

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B H 16
C001
,
C002
,
C013
,
C061
,
C062
,
C127, C224, C305, C312, C411,
C602, C606, C936, C937, C942,
C971
08-29704T-MAN ASS'Y - MAIN BD 26-EBP103-ZFX CAP. CER 0.01UF 50V +80-20% F H 19
C075
,
C083
,
C111
,
C121
,
C125
,
C126, C203, C205, C215, C226,
C229, C256, C273, C275, C657,
C732 C935, C961, C962
08-29704T-MAN ASS'Y - MAIN BD 26-EBP104-ZFX CAP. CER 0.1UF 50V +80-20% F H 10 C107, C114, C204, C609, C635, C673, C674, C675, C745, C945
08-29704T-MAN ASS'Y - MAIN BD 26-EBP120-JCX CAP. CER 12 PF 50V +/-5% CH H 1 C209
08-29704T-MAN ASS'Y - MAIN BD 26-EBP150-JCX CAP. CER 15 PF 50V +/-5% CH H 4 C041, C042, C043, C044
08-29704T-MAN ASS'Y - MAIN BD 26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B H 1 C452
08-29704T-MAN ASS'Y - MAIN BD 26-EBP300-JZX CAP. CER 30 PF 50V +/-5% SL H 2 C055, C056
08-29704T-MAN ASS'Y - MAIN BD 26-EBP330-JZX CAP. CER 33 PF 50V 5% SL TUBU H 2 C128, C953
08-29704T-MAN ASS'Y - MAIN BD 26-EBP331-JCX CAP. CER 330 PF 50V +/-5% CH H 6 C004, C063, C084, C085, C091, C301
08-29704T-MAN ASS'Y - MAIN BD 26-EBP390-JCX CAP. CER 39 PF 50V +/-5% CH H 1 C051
08-29704T-MAN ASS'Y - MAIN BD 26-EBP470-JZX CAP. CER 47 PF 50V +/-5% SL H 4 C072, C073, C261, T141
08-29704T-MAN ASS'Y - MAIN BD 27-MCC562-J0
X
CAP. M.P.E 5.6NF 100V +/-20% C 1 C471
08-29704T-MAN ASS'Y - MAIN BD 45-OSC4M4-3Y0 CRYSTAL 4.43 MH
Z
C 1 X201
08-29704T-MAN ASS'Y - MAIN BD 45-TRA5M5-0Y0 CER. TRAP 5.5 MHZ C 1 Z254
08-29704T-MAN ASS'Y - MAIN BD 45-OSC8M0-0Y0 CRYSTAL 8.0MH
Z
C 1 X051
08-29704T-MAN ASS'Y - MAIN BD 47-SVI002-XX0 SOCKET S-W16-J C 1 P981
08-29704T-MAN ASS'Y - MAIN BD 63-B30100-BT4 S/T SCREW B 3 X 10 BT C 2 MTG M.BD & FB
T
08-29704T-MAN ASS'Y - MAIN BD 63-W30100-AB4 S/T SCREW W 3 X 10 AB C 6 MTG M.BD & BK
T
08-29704T-MAN ASS'Y - MAIN BD 64-P30080-104 M/C SCREW P 3 X 8 C 1 FOR Q722
08-29704T-MAN ASS'Y - MAIN BD 64-P30080-104 M/C SCREW P 3 X 8 C 1 FOR IC301
08-29704T-MAN ASS'Y - MAIN BD 64-P30080-104 M/C SCREW P 3 X 8 C 1 FOR Q412
08-29704T-MAN ASS'Y - MAIN BD 64-P30100-104 M/C SCREW P 3 X 10 C 2 FOR IC601
08-29704T-MAN ASS'Y - MAIN BD 65-Z30050-23M NUT M 3 C 2 FOR IC301 & Q412
08-29704T-MAN ASS'Y - MAIN BD 65-Z30050-23M NUT M 3 C 2 FOR IC601
08-29704T-MAN ASS'Y - MAIN BD 46-20598W-04X PIN BASE *4 TJC1-4A C 1 P411 FOR DY CONNECT.
08-29704T-MAN ASS'Y - MAIN BD 40-2916MT-MAH P.C.B. MAIN BD C 1
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0050-B00 WIRE BARE JUMPER 5MM C 19
C262, C946, J022, J410A, J415,
J416, J417, J418, J419, J420,
J435, J436, J437, J636, J637, J773 J871, J954, J955
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM C 14
J122, J204, J205, J348, J409,
J424, J441, J502, J503, J553,
J554, J621, J723, J822
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM C 7 J224, J236, J247, J248A, J345, J411, R228A
18

Sheet1
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0130-B00 WIRE BARE JUMPER 13MM C 3 J239, J346, J413
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0150-B00 WIRE BARE JUMPER 15MM C 18
J032, J133, J153, J235, J237,
J243, J245, J255, J262, J347,
J461, J542, J714, J721A, J722A, J782, J931
08-29704T-MAN ASS'Y - MAIN BD 26-EBP221-JCX CAP. CER 220 PF 50V +/-5% CH H 5 C011, C021, C092, C112, C228A
08-29704T-MAN ASS'Y - MAIN BD 18-CB0153-JNX RES. C.F. 15K OHM 1/6W +/-5% C 7 R057, R072, R112, R113, R288, R632A, R987
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-03X PIN BASE *3 TJC3-3A C 1 P401 FOR VM BD P504
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-04X PIN BASE *4 TJC3-4A C 1 P202 FOR VM BD P505
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-04X PIN BASE *4 TJC3-4A C 1 P421 FOR CRT BD P502
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-05X PIN BASE *5 TJC3-5A C 1 P001 FOR RECEIVE BD P001B
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-05X PIN BASE *5 TJC3-5A C 1 P201 FOR CRT BD P503
08-29704T-MAN ASS'Y - MAIN BD 46-33079W-06X PIN BASE *6 TJC3-6A C 1 P003 FOR SIDE AV BD P902
08-29704T-MAN ASS'Y - MAIN BD 26-EBP220-JCX CAP. CER 22 PF 50V +/-5% CH H 2 C053, C054
08-29704T-MAN ASS'Y - MAIN BD 47-RCA023-XX1 RCA JACK 3PV YEL WHI RED/SW H 2 P911, P931
08-29704T-MAN ASS'Y - MAIN BD 46-20600H-04X HS 4P A/B 360/13 RBGW TJC1-4Y C 1 FOR D.F BD (A1' & A2 & A5 & A6)
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0100-B00 WIRE BARE JUMPER 10MM C 17
J001, J002, J061, J134, J203,
J402, J423, J432, J501, J611,
J631, J652, J653, J692, J728,
08-29704T-MAN ASS'Y - MAIN BD 18-CD0272-JNX RES. C.F. 2.7K OHM 1/4W +/-5% C 1 J691
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM C 4 J323, J355, J641, J731
08-29704T-MAN ASS'Y - MAIN BD 26-ABC104-ZFX CAP. CER 0.1 UF 50V +80-20% F C 1 FOR R038(R040) TO R036(GND)
08-29704T-MAN ASS'Y - MAIN BD 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM C 35
D046, D141, J041, J043, J124,
J151, J152, J154, J207, J208,
J217, J241, J331, J351, J405, J406
J407
,
J408
,
J412
,
J414
,
J541, J544, J551, J642,
J651, J656, J693, J712,
J734, J812, J821, J833 J851, J915, J941
08-29704T-MAN ASS'Y - MAIN BD 41-RE0050-1BB WIRE UL 1672 #22 50MM BROWN C 1 FOR P602(GND) TO C610(GND)
08-29704T-MAN ASS'Y - MAIN BD 36-HDR001-XX1 TRANSFORMER HORIZ DRIVE C 1 T401
08-29704T-MAN ASS'Y - MAIN BD 07-389VI5-NX4 TUNER UV1355-BK2(BG/HB/IEC/5V) H 1 TU101
08-29704T-MAN ASS'Y - MAIN BD 90-209770-SR1 SILICONE GREASE G-746 (1KG/CAN H 0.0009 FOR IC601 & Q412 & Q722
08-29704T-MAN ASS'Y - MAIN BD 90-269080-ZU0 CLEAN COATING TC-131L 14KG/BAR H 0.0001
08-29704T-MAN ASS'Y - MAIN BD 13-00M24C-08P IC M24C08 EEPROM 8
K
1 IC002
08-29704T-MAN ASS'Y - MAIN BD 13-0TA842-7KS IC TA8427K 1 IC301
08-29704T-MAN ASS'Y - MAIN BD 34-A109K2-1IX COIL CHOKE 1 UH +/-10% (5MM) C 2 L121, L141
08-29704T-MAN ASS'Y - MAIN BD 25-BCA471-M1
X
CAP. ELEC 470 UF 16V +/-20% C 1 C082
08-29704T-MAN ASS'Y - MAIN BD 45-SAWK33-50K SAW FILTER K3350K (38.9MHZ) H 1 Z141
08-29704T-MAN ASS'Y - MAIN BD 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% C 14
R003, R006, R007, R008, R009,
R015, R016, R038, R065, R073,
R075, R253, R651, R652
19
