Teac CT-M5110H User manual

TEAC
SERVICE MANUAL
1. Caution……………………………………………………………2
2. Specification………………………………………………………6
3. BOM List ……………………… ……………...............................9
4. Alignment Procedure………………………………………….…29
5. Block Diagram……………………………………………………36
6. Schematic Diagram………………………………………………37
7. PCB Layout………….……………………………………………38
8. Explode Diagram…….……………………………………………39
This manual is the latest at the time of
p
rintin
g
, and does not
include the modification which ma
y
be made after the
p
rintin
g
, b
y
the constant improvement of product.
CTM5110H

WARNING: TOREDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SER VICING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CAUTION
RISKRISK OFOF ELECTRIELECTRICC
SHOCKSHOCK DODO NOTNOT OPEN.OPEN.
2
dangerous

3
FOR YOUR PERSONAL SAFETY
1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance.Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Save these instructions for later use.Follow all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions- All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
IMPORTANT SAFETY INSTRUCTIONS

4
PROTECTION AND LOCATION OF YOUR SET
11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water.If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
PROTECTION AND LOCATION OF YOUR SET
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits.When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s

OPERATION OF YOUR SET
18. This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
IF THE SET DOES NOT OPERATE PROPERLY
21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off.If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
FOR SERVICE AND MODIFICATION
24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.
25.When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
5
off

PFS2 FORMAT-1 Report
Date: 2003-9-16 15:12
ProductView......:
Re
p
ort b
y
............:
Specs / Products
MasterData
Customer Id TEAC AUSTRALIA PTY LTD
Version 0.1
Status New
Brand TEAC
EAN \
UPC \
Rece
p
tion
+Tunin
g
-
p
resets/channels 100
+Tunin
g
- technolo
gy
VST
+Tunin
g
- Indication X
+Fre
q
Bands UVSH
+Channels 100
+IF Fre
q
+TV S
y
stems Off Ai
r
PAL B/G
+Add Systems Ext In NTSC 3.58, NTSC 4.43, NTSC
Play Back, PAL 60
+TV S
y
stems Multi PAL-Multi
+Sound S
y
stems AV Stereo
Picture - Processin
g
+Scan Standard
+Scan Modes 4;3
+Wide Screen Switchin
g
+Combfilter
+Picture Control Brightness, Colour, Contrast,
Color Temperature, Hue,
Sharpness Cont Var, Smart Pict.
4 Modes
+Pict Enhancement Black Stretch
+Pict Noise Reduction
Picture - Dis
p
la
y
+Dis
p
la
y
T
ype
DV - CRT - RF
+Screen Format 4:3
+Size
(
Visual
)
" - size/vis. cm 21"
+Deflection S
y
stem
(
CRT onl
y)
+Tube Technolo
gy
(
CRT onl
y)
Black Matrix, Iron
+CRT Defl
+CRT Gun Stand Gun
+CRT Ma
g
n field Neutral
+Resolution
+Coatin
g
(
onl
y
for D.V. sets
)
+White Point
Sound
+RMS Power Intern
+RMS Power Extern
+Surround Sound
+Sound Features Mute
+Sound Control Volume
Sound - S
p
eakers
+S
p
eaker confi
g
uration 2
+S
p
eakers used Normal
+S
p
eaker Size
User Interface
+Interface Name L01- Full Interface
+Voice Control
+Menu Cursor Control
+Menu Colours
+Menu Lan
g
ua
g
es English
+Special Features No signal Auto Standby,Timer
Power ON/OFF, Favorite
Channel, Sleep timer, Game,
Calendar, Notebook, Hotel lock ,
Auto Search
+O
p
erational Features
+PP Features
+Tuning/Install Features Auto Store, Factory Mode, Fine
Tuning, Manual Search/Store,
Manual Sort, Service Mode
+Clock/Timer Functions Clock, On/off timer, Sleep timer
Product:
CT-M5110H
2003-9-16 15:13 21166 PFS 1 of 3

Date: 2003-9-16 15:12
ProductView......:
Re
p
ort b
y
............:
Specs / Products Product:
CT-M5110H
+Local Controls Front Channel +-, Volume +-,
TV/AV,MENU,
Power Switch,
+Local Controls To
p
+Indicators - screen
+Indicators - front RC Recvd LED, SB LED
+Numb of Loc Cont
(
incl Mains
)
7
+Number of Ind.
(
incl Mains
)
1
+Local Controls
(
Old
)
Remote Control
Connectors Rea
r
+Scart RGB+Y/C+CVBS
+Scart RGB+CVBS
+Scart CVBS+Y/C
+Com
p
onent In
(
Y/U/V
)
Cinch
+In Y/C+Cinch
(
CVBS+St
)
+In Y/C+Cinch
(
CVBS+Mo
)
+In Y/C+Cinch
(
St
)
+In BNC
(
CVBS
)
+In Cinch
(
CVBS+St
)
X
+In Cinch
(
CVBS+Mo
)
+Out Cinch
(
CVBS+St
)
+Out Cinch
(
CVBS+Mo
)
X
+Out Cinch Audio Stereo
+Out Cinch Audio Mono
+Out Cinch Dolb
y
Surround
+Out Cinch Subwoofer
+Di
g
Audio Out
+Louds
p
eakers
+Control Busses
+Feature Slot
+ITV Smart Port
+Terr. Antenna in 75 Ohms (IEC type)
Guide + IR Blaster Jack
Connectors Fron
t
+In Y/C + Cinch
(
CVBS+St
)
+In Y/C + Cinch Stereo
+In Cinch
(
CVBS + St+ Mo
)
+In Cinch
(
CVBS+Mo
)
+Head
p
hone Out
+Feature Slot
Connectors Side
+In Y/C + Cinch
(
CVBS+St
)
+In Y/C + Cinch Stereo
+In Cinch
(
CVBS + St+ Mo
)
X
+IN Cinch
(
CVBS + Mo
)
+Head
p
hone Out
Connectors To
p
+In Cinch
(
CVBS + St
)
+Head
p
hone Out
Connectors Mechanical
+Head
p
hone
+Cinch A/V in/out
+Cinch Com
p
onent
+Cinch Y/C
St
y
lin
g
+Cabinet Name 21166
+Confi
g
uration
+Gra
p
hics/Lo
g
o's
-Cabinet Colour and Finish
Silver Frost
+Mechanics
+S
p
eaker Visibilit
y
Standard
General
+Se
g
ment Standard 4:3
+Chassis M28
+Software Deliver
y
Mode
+Software Version
+Mains Volta
g
e240V
+Mains Fre
q
uenc
y
50Hz
+T
yp
e Mains Cord
Power Consum
p
tion
(
P
)
TV in On
2003-9-16 15:13 21166 PFS 2 of 3

Date: 2003-9-16 15:12
ProductView......:
Re
p
ort b
y
............:
Specs / Products Product:
CT-M5110H
Power Consum
p
tion SB in Watts Less then 3W
Power Consum
p
tion Semi SB in W
+Power in "ON" for
+Power in Standb
y
for
+Power in "OFF" for
Wei
g
ht
(
P
)
TV
(
incl. Packa
g
in
g)
Wei
g
ht
(
P
)
TV
(
excl. Packa
g
e
)
Wei
g
ht AVUnit excl Packa
g
in
g
+INDICATION on BACKCOVE
R
+Channel
Final E
q
ui
p
ment
+Packa
g
in
g
- methods
+Documents and manuals
+Lan
g
ua
g
es DFU
+Cables Su
pp
lied
+Antenna Su
pp
lied
+Stand Su
pp
lied
+Aux E
q
ui
p
m Su
pp
lied
Packa
g
in
g
- width cm
Packa
g
in
g
- hei
g
ht cm
Packa
g
in
g
- de
p
th cm
Miscellaneous
+EAN Indication
+A
pp
robation
+Tests
+Local Inte
g
ration
V
arious Perf. Param.
+Service Call-Rate
PIP/POP
+T
ype
+Features No
Di
g
ital Rece
p
tion
+Transmission
Built-in Data S
y
stem
+Text Standard
+
(
Tele
)
text Features No
+Nbr bck
g
rnd
p
a
g
e / Mem Size No
+Text Technolo
gy
No
+Di
g
ital Data handlin
g
+Pro
g
ram Guide
Built-in Clock/Timer
+T
ype
+Features
Built-in Radio
+T
ype
Built-in PC dis
p
la
y
+PC S
y
nch
+PC Control
Built-in DVD drive
+T
yp
e of Medium
+T
yp
e of Dec
k
+Version of Deck
Phased Out Items
+Tuner/Frontend
+Sensitivit
y
+CRT EHT
+Li
g
htnin
g
Protection
+Accoun
t
+XX
(
Radio Antenna in
)
+Non Volatile Memor
y
+In Y/C + Cinch
(
CVBS+Mo
)
Version of deck
2003-9-16 15:13 21166 PFS 3 of 3

Item No. Description Quantity Req. Designator Remarks
08-HS46F0-M28A ASS'Y - IR HANDSET 1
13-00AS12-13B IC AS1213B 1 IC1501
14-IRE05B-XX0 IR EMITTING DIODE TSAL6200 1 D1501
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R1502
18-CB0229-JNX RES. C.F. 2.2 OHM 1/6W +/-5% 1 R1501
25-HBB479-M1X CAP. ELEC 4.7 UF 10V +/-20% 1 C1502
26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1503
26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1504
40-113SLF-RMB P.C.B. REMOTE HANDSET BD 1
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J1501
45-COS455-KY1 CERAMIC RESONATOR 455KHz 1 X1501
49-HS46F0-00X RUBBER PAD KEYS 1
55-HS46FB-0HA CASE LOWER - REMOTE HANDSET 1
55-HS46FD-0HA DOOR BATT. - REMOTE HANDSET 1
55-HS46FT-0HA CASE UPPER - REMOTE HANDSET 1
58-HS46F3-7UI INLAY REMOTE HANDSET 1
63-B26060-BT2 S/T SCREW B 2.6 X 6 BT 1
67-X26968-0E2 BATT. TERMINAL (+/-) 1
67-X31028-0E2 SPRING - BATTERY (-) 1
67-X31029-0E2 SPRING - BATTERY (+) 1
74-009022-60C POLYBAG HANDSET (9CMX22CM) 1
11-0BC337-0BX TRANSISTOR (NPN) BC337-40 1 Q1501
08-02135H-CRY ASS'Y - CRT BD 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q510
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q501
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q502
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q503
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R501
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R504
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R507
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R522
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R524
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R502
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R505
9

Item No. Description Quantity Req. Designator Remarks
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R508
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R525
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R526
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R527
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R523
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R503
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R506
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R509
18-CD0104-JNX RES. C.F. 100K OHM 1/4W +/-5% 1 R521
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R514
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R515
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R518
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R510
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R511
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R512
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C507
26-EBP181-JCX CAP. CER 180PF 50V +/-5% CH 1 C510
26-EBP181-JCX CAP. CER 180PF 50V +/-5% CH 1 C511
26-EBP181-JCX CAP. CER 180PF 50V +/-5% CH 1 C512
26-EBP681-JCX CAP. CER 680 pF 50V +/-5% 1 C501
26-EBP681-JCX CAP. CER 680 pF 50V +/-5% 1 C502
26-EBP681-JCX CAP. CER 680 pF 50V +/-5% 1 C503
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C504
26-AMK221-KBX CAP. CER 220PF 2KV +/-10% B 1 C505
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C514
35-139730-00X FERR. BEAD BF60 2 FOR C514 (L505 & L506)
40-02135S-CRD P.C.B. CRT BD 1
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 FOR Q509 (B - E)
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 FOR Q507 (B - E)
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 FOR Q505 (B - E)
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J502
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J503
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J501
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J504
46-10967W-01X PIN BASE *1 TJC1-1A 1 P503
46-30615H-04X HS 4P24 460 F/W TJC3-4Y/SCN-4 1 P502 FOR M. BD P402
10

Item No. Description Quantity Req. Designator Remarks
46-28816H-05X HS 5P24 500 TJC3-5Y/SCN-5Y 1 P501 FOR M. BD P201
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C508
47-CRT004-XX0 CRT SOCKET GZS10-2-108 1 FOR CRT
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J505
08-0D166H-AVY ASS'Y - AV BD 1
40-21166F-SIA P.C.B. SIDE AV BD 1
46-30790H-06X HS 6P24 400 TJC3-6Y/SCN-6Y 1 P1104B FOR M.BD P904
47-RCA001-XX0 RCA SOCKET AV-8.4-6 (RED) 1 P1103
47-RCA002-XX0 RCA SOCKET AV-8.4-6 (WHITE) 1 P1102
47-RCA003-XX0 RCA SOCKET AV-8.4-6 (YELLOW) 1 P1101
08-0D166H-KEY ASS'Y - KEY BD 1
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R022A
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R023A
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R024A
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5% 1 R025A
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R026A
46-38628H-02X HS 2P 2468#24 850 TJC3-2Y/JC25-2Y 1 P001A FOR M.BD P001
48-TAC001-XX0 TACT SWITCH 1 S001A
48-TAC001-XX0 TACT SWITCH 1 S002A
48-TAC001-XX0 TACT SWITCH 1 S003B
48-TAC001-XX0 TACT SWITCH 1 S004A
48-TAC001-XX0 TACT SWITCH 1 S005A
48-TAC001-XX0 TACT SWITCH 1 S006A
40-21166H-KEB P.C.B. KEY BD 1
08-0D166H-PW2 ASS'Y - POWER PARTS (AUST,220UF) 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D830
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D802
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D833
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D805
10-1SS136-ABX DIODE 1SS136 1 D804
10-1SS136-ABX DIODE 1SS136 1 D835
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D839
10-HER108-FBX DIODE HER108 1 D806
10-HS16VC-DBX DIODE 500mW 16HSC 1 D838
10-HS6V2B-DBX DIODE 6V2 500mW 1 D840
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q832
11

Item No. Description Quantity Req. Designator Remarks
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q831
11-SC2688-LAX TRANSISTOR 2SC2688L (NPN) 1 Q830
11-SK2996-0AX TRANSISTOR 2SK2996 (MOS) 1 Q801
13-0HPC92-2CP PHOTO COUPLER HPC922-C 1 IC802
13-44608P-40P IC MC44608P40 1 IC801
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R809
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R844
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R834
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R838
18-CB0362-JNX RES. C.F. 3.6K OHM 1/6W +/-5% 1 R807
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R806
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R850
18-CD0123-JNX RES. C.F. 12K OHM 1/4W +/-5% 1 R804A
18-CD0220-JNX RES. C.F. 22 OHM 1/4W +/-5% 1 R811A
18-CD0221-JNX RES. C.F. 220 OHM 1/4W +/-5% 1 R833
18-CD0392-JNX RES. C.F. 3.9K OHM 1/4W +/-5% 1 R835
18-CD0471-JNX RES. C.F. 470 OHM 1/4W +/-5% 1 R811
18-CE0479-JNX RES. C.F. 4.7 OHM 1/2W +/-5% 1 R832
18-CE0563-JNX RES. C.F. 56k OHM 1/2W +/-5% 1 R831
18-DD0104-FNX RES. M.F. 0.1M OHM 1/4W +/-1% 1 R804
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R837
18-GJ0103-KTX RES. CEMENT 10K OHM 5W +/-10% 1 R836
18-GJ0223-KTX RES. WIRE ROUND 5W 22K OHM +/-10% 1 R808
18-KF0825-JH3 RES. H.VOLT.CC 8.2M OHM 1W +/-5% 1 R812
20-TR103H-5CX TRIMMER B10K HORIZ TYPE 1 VR830
22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14 1 RT802
25-382890-M1X CAP. ELEC 150UF 400V +/-20% 30X30 1 C806
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C849
25-BEB100-M1X CAP. ELEC 10 UF 35V +/-20% 1 C812
25-BJG101-M1X CAP. ELEC 100 UF 160V +/-20% 1 C835
26-ABC221-JZX CAP. CER 220 PF 50V +/-5% SL 1 C841
26-AGK221-KRX CAP. CER 220 PF 250V +/-10% 1 C830
26-AIC472-KBX CAP. CER 4700 PF 500V +/-10% B 1 C807
26-AIC472-KBX CAP. CER 4700 PF 500V +/-10% B 1 C808
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C834
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C805
12

Item No. Description Quantity Req. Designator Remarks
26-AKK221-KRX CAP. CER 220 PF 1KV +/-10% R 1 C833
26-AMK102-KRX CAP. CER 1000 pF 2KV +/-10% R 1 C815
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C816
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C803
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C804
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C848
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C804A
27-AQT224-MVH CAP. M.PP 0.22 UF 250VAC 20% 1 C801
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C836
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C850
27-MHM104-K0X CAP. METAL P.E. 0.1UF 400V 10% 1 C802A
27-RJP472-J0X CAP. PP 4700 PF 630V +/-5% 1 C809
34-R101K2-1BX COIL CHOKE 100 UH +/-10% 1 L804
34-R330J2-0EX COIL PL - 33 UH +/-5% 1 L843
35-139730-00X FERR. BEAD BF60 2 FOR D806
35-139730-00X FERR. BEAD BF60 2 FOR D833
35-139730-00X FERR. BEAD BF60 2 FOR D831
35-139730-00X FERR. BEAD BF60 2 FOR D830
36-LIF004-AX0 LINE FILTER 1 T801
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J800A
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J800B
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J800C
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J800D
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J801A
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J801B
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J801C
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J801D
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J810
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J809
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J812
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J805
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 R804B
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J822
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J827
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 R807A
41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J824
13

Item No. Description Quantity Req. Designator Remarks
41-WJ0110-B00 WIRE BARE JUMPER 11MM 2 FOR S801
41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J823
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J804
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J808
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J832
41-WJ0145-B00 WIRE BARE JUMPER 14.5MM 1 J826
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J802
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J821
41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J825
41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J830
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J807
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J831
41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J811
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J828
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J829
46-10962W-02X PIN BASE *2 TJC2-2A 1 P801
46-28559W-02X PIN BASE *2 TJC1-2A 1 P802
50-02000D-1VS7 FUSE 250V/2A 1 F801
64-B30100-104 M/C SCREW B 3 X 10 1 FOR Q801
66-20516X-0B0 FUSE HOLDER 2 FOR FUSE
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR C835
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T803
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR RT801
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 6 FOR D830,D831,L804
71-DYP000-WX1 LABEL 1 STICK ON H.SINK(Q801)
90-209770-SR1 SILICONE GREASE G-746 0.0006
66-382330-0B7 RIVET 2.0X3.7X3.5 8 FOR R808,R836,C806,P801
67-H35984-5A0 HEAT SINK 1 FOR Q801
18-RG0228-JHX RES. WIRE ROUND 0.22 OHM 2W +/-5% 1 R810
26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C814
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C843
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C832
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C851
10-0RU3AM-F0X DIODE RU3AM (FAST RECOVERY) 1 D831
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C813
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C831
14

Item No. Description Quantity Req. Designator Remarks
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C842
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D815
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D816
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D817
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D818
22-PTC200-XX1 PTC 20 OHM +/-20% 1 RT801
36-TRF133-AX0 TRANSFORMER CONV.BCK-3546 1 T803
08-D1664H-FC1 ASS'Y - FRONT CAB(94V0,LS-SG1A) 1
02-GND021-XX0 ASS"Y - CRT GND WIRE&HOUSE 1 FOR CRT GROUNDING
36-DEG210-BX3 DEGAUSSING COIL 2500mm 1
42-50908D-XX0 SPEAKER 8 OHM 5W (50mmX90mm) 1 W601
42-50908D-XX0 SPEAKER 8 OHM 5W (50mmX90mm) 1 W602
44-21OFLS-SG1A CRT A51JSY63X13(CR)RED (AUST) 1 CRT01
46-27250H-02X HS 2P24 450/5 F/W TJC3-02H 1 P602H FOR M. BD P602
46-27688H-04X HS 4P A/B 400/13 RBGW TJC1/4Y 1 P401H FOR D.Y COIL
46-37144H-02X HS 2P 2468#22 450mm S11-2Y/7mm 1 P601H FOR M. BD P601
54-113970-0U0 PVC TUBE #5 L=ROLL 0.32 FOR SPK HOUSING
54-205140-000 SPACER CRT MOUNTING T=2MM 4
54-271620-000 SPACER CRT MOUNTING T=1mm 4 MTG CRT & F. CAB.
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 16
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 8 FOR CRT & F. CAB.
56-D166FB-0HA PUSH BUTTON (II) 1
56-D166LS-0HC LENS 1
56-D166PK-0HA POWER KNOB 1
59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK ON F. CAB.(FOOTING)
62-10654X-00F UNI-TIE (2.5mmX95mm) 13
62-369290-0CN CRT BRACKET 2
63-B30080-AB4 S/T SCREW B 3 X 8 AB 3 MTG KEY BD & PUSH BUTTON
63-B40150-AB4 S/T SCREW B 4 X 15 AB 2 MTG CRT HOLDER TO F. CAB.
63-H60300-BT4 S/T SCREW H 6 X 30 BT 4 MTG CRT & F.CAB
63-W30100-AB4 S/T SCREW W 3 X 10 AB 4 MTG TRACK TO F. CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2 MTG PUSH BUTTON & F.CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 8 MTG SPK & F. CAB.
63-W35100-AB4 S/T SCREW W 3.5 X 10 AB 2 MTG F. CTL BKT & F. CAB.
65-A60200-20E WASHER 6 X 20 X 2MM 4 MTG CRT
62-216340-0UA HOLDER POWER CORD HIPS-KINGFA 113(VO) 1
15

Item No. Description Quantity Req. Designator Remarks
62-378080-1UN TRACK 1
62-345690-1UN ASSISTANT RAIL HIPS-KINGFA 113 (VO) 1
67-X12668-0E0 SPRING CRT 6mmX40mmX0.5mm 1
67-X24970-0E0 SPRING 1
55-D166FC-2AN FRONT CABINET 1
18-CB0225-JNX RES. C.F. 2.2M OHM 1/6W +/-5% 1 R1
41-BF0450-0BB WIRE UL1007#24 450 BLACK 1 FOR R1
54-343300-0X0 HEAT SHRINKABLE TUBE 3 X 0.25 0.02 FOR R1
67-105580-0E2 SOLDERING TAG 1 FOR R1
08-D1664H-MA2 ASS'Y -MAIN BD 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D401
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D402
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301
10-1N4002-EBX DIODE 1N4002 (RECTIFIER) 1 D405
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D005
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D206
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D006
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D007
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D601
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D008
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D002
10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D001
10-79C6V2-DBX DIODE ZENER 6V2 1/2W 5% 1 D404
11-2N3904-0BX TRANSISTOR 2N3904 (NPN) 1 Q103
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q604
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q606
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q607
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q211
11-DD1555-0AX TRANSISTOR 3DD1555 1 Q402
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q003
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q202
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q005
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q209
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q210
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q605
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q203
16

Item No. Description Quantity Req. Designator Remarks
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q002
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q208
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q905
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q609
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q603
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q608
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q401
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) 1 Q101
13-000040-66P IC 4066 (ANALOG SW.) 1 IC603
13-00M24C-08P IC EEPROM 8K M24C08 1 IC001
13-L7809C-VAP IC L7809CV 1 IC401
13-LA7840-00S IC LA7840 1 IC301
13-TDA705-7AS IC TDA7057AQ (R/L AUDIO O/P) 1 IC601
13-UA7805-C0S IC UA7805C 1 IC402
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R001A
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R033
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R034
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R047
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R218
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R005
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R013
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R015
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R029
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R116
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R415
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R604A
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R610
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R622
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R637
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R901
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R912
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R961
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R962
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R003
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R004
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R009
17

Item No. Description Quantity Req. Designator Remarks
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R001
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R019
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R030
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R032
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R611
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R614
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R406
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R017
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R031
18-CB0122-JNX RES. C.F. 1.2k OHM 1/6W +/-5% 1 R010
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R212
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R217
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R115
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R117
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R111
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R112
18-CB0183-JNX RES. C.F. 18k OHM 1/6W +/-5% 1 R414
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R201
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R202
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R203
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R016
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R042
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R014
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R215
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R633
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R636
18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R206
18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R233
18-CB0273-JNX RES. C.F. 27k OHM 1/6W +/-5% 1 R922A
18-CB0303-JNX RES. C.F. 30K OHM 1/6W +/-5% 1 R205
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R219
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R228
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R227
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R220
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R218A
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R046
18

Item No. Description Quantity Req. Designator Remarks
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R110
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R602
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R922
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R232
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R213
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R307
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R214
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R007
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R002
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R119
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R238
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R243
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R401
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R923
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R020
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R244
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R308
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R612
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R613
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R011
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R109
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R216
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R245
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R924
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R927
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R925
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R926
18-CB0560-JNX RES. C.F. 56 OHM 1/6W +/-5% 1 R114
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R209
18-CB0564-JNX RES. C.F. 560K OHM 1/6W +/-5% 1 R210
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R028
18-CB0683-JNX RES. C.F. 68K OHM 1/6W +/-5% 1 R211
18-CB0750-JNX RES. C.F. 75 OHM 1/6W +/-5% 1 R904
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R914
18-CB0821-JNX RES. C.F. 820 OHM 1/6W +/-5% 1 R118
18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R237
19

Item No. Description Quantity Req. Designator Remarks
18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R006
18-CB0912-JNX RES. C.F. 9.1K OHM 1/6W +/-5% 1 R312
18-CD0100-JNX RES. C.F. 10 OHM 1/4W +/-5% 1 R027
18-CD0479-JNX RES. C.F. 4.7 OHM 1/4W +/-5% 1 R640
18-CD0682-JNX RES. C.F. 6.8k OHM 1/4W +/-5% 1 R310
18-CD0822-JNX RES. C.F. 8.2K OHM 1/4W +/-5% 1 R309
18-CE0109-JNX RES. C.F. 1 OHM 1/2W +/-5% 1 R314
18-CE0122-JNX RES. C.F. 1.2k OHM 1/2W +/-5% 1 R316
18-CE0331-JNX RES. C.F. 330 OHM 1/2W +/-5% 1 R409
18-CE0560-JNX RES. C.F. 56 OHM 1/2W +/-5% 1 R317
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R403
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R405
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R418
18-EG0159-JHX RES. FUS. 1.5 OHM 2W +/-5% 1 R407
18-FF0103-JGX RES. M.O. 10k OHM 1W +/-5% 1 R410
18-FF0122-JGX RES. M.O. 1.2k OHM 1W +/-5% 1 R441
18-FF0123-JGX RES. M.O. 12k OHM 1W +/-5% 1 R408
18-FF0221-JGX RES. M.O. 220 OHM 1W +/-5% 1 R336
18-FF0560-JGX RES. M.O. 56 OHM 1W +/-5% 1 R108
18-FG0129-JHX RES. M.O. 1.2 OHM 2W +/-5% 1 R313
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R404
18-GJ0332-JTX RES. CEMENT 3.3K OHM 5W +/-5% 1 R402
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C004
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C023
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C227
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C242
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C907
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C908
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C220
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C016
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C240
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C605
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C211
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C416
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C009
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C909
20
