TECHCON TS8100 Series User manual
CONTENTS
1. PC PUMP SPECIFICATIONS ................................................................................................................3
2. DIMENSIONS AND TYPICAL SETUP....................................................................................................4
3. PC PUMP UNPACKING AND INSPECTION..........................................................................................5
4. DESCRIPTION.....................................................................................................................................6
5. THEORY OF OPERATION....................................................................................................................7
6. SET-UP INSTRUCTIONS......................................................................................................................8
6.1 Install the Stator..............................................................................................................................8
6.2 Mechanical Mounting.....................................................................................................................9
6.3 Connect the Pump to the Controller.............................................................................................10
6.4 Prime the Pump ............................................................................................................................11
6.5 Dispensing.....................................................................................................................................12
7. MAINTENANCE AND CLEANING..........................................................................................................14
7.1 Pump Purging................................................................................................................................14
7.2 Thorough Cleaning........................................................................................................................14
8. SPARE & REPLACEMENT PARTS ..........................................................................................................17
9. STANDARD ACCESSORIES....................................................................................................................18
10. OPTIONAL ACCESSORIES...................................................................................................................18
11. TROUBLE SHOOTING.........................................................................................................................18
12. TS588R SMART CONTROLLER SPECS.................................................................................................19
13. LIMITED WARRANTY .........................................................................................................................20
techcon.com/contact-us 2
TS8100 Series
Progressive Cavity (PC) Pump User Guide
1. PC PUMP SPECIFICATIONS
1 Volumetric dispensing as absolute deviation per complete revolution and depends on dispensing fluid.
2 For fluid with viscosity of 1000 cps or lower. The pump can handle up to 5.5 bar for 300K cps viscosity fluid.
techcon.com/contact-us 3
TS8100 Series
Progressive Cavity (PC) Pump User Guide
SPECIFICATIONS
Size (mm) 250 mm L X 34 mm W
Size (inches) 9.8” L X 1.3” W
Weight (g) 589g
Weight (oz) 20.8 oz
Wetted Parts Delrin, PFE, Stainless Steel, UHMWPE, Carbine
100 Series 200 Series 300 Series
Dispense Volume Per Rotation 0.012 ml average 0.047 ml average 0.07 ml average
Flow Rate 0.15 – 1.04 ml/min. 0.47 – 4.46 ml/min. 0.74 – 6.7 ml/min.
Minimum Dispense Amount 0.001 ml 0.0045 ml 0.0068 ml
Fluid Viscosity 1-300K cps
Precision ±, Absolute1±1%
Self-sealing22 Bars
Material Outlet Port Male Luer Lock
Direct Mount Material Reservoir 3 to 55 cc
3. PC PUMP UNPACKING AND INSPECTION
Carefully unpack the pump and examine the items contained in the carton (Figure 3).
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
7509-9201
7509-9202
7509-9203
PC PUMP/TS8100-100 (without Stator)
PC PUMP/TS8100-200 (without Stator)
PC PUMP/TS8100-300 (without Stator)
1
2
8100‐CLEANKIT
Cleaning Kit
1
3
8100‐SYBRACKET
Syringe Mounting Bracket
1
4
8100‐MBRACKET
Mounting Bracket Kit
1
5
A0100488‐2
700 Series, 30 cc Receiver Head
1
6
8100‐100‐002
8100‐200‐002
8100‐300‐002
Stator
1
7
Fitting Kit: Includes 3 fittings below
1
TSD931‐96
Female Luer with 1/8” NPT Thread
1
TSD931‐82B
Male Adapter Luer Lock, Black Nylon
1
TSD931‐81B
Elbow 90° Luer Lock, Black‐ Nylon
1
TSD931-105
FITTING, FEMALE LUER, ¼ HEX TO 10-32
1
8
8 9000‐000‐100
Sample Needle Kit For Valves
1
9
Cap/Nut Kit: Includes 3 nut and caps below
1
7509‐0090
Retainer Nut
1
7509‐0130
Stator Cap Bottom
1
7090‐0030
Needle Cap
1
10
7000-6650
Instruction, Seal Stator for Hi Pressure
1
Figure 3
techcon.com/contact-us 5
TS8100 Series
Progressive Cavity (PC) Pump User Guide
PLEASE NOTE: Inspect the unit for any damage which may have occurred in transit. If damage has
occurred, notify the carrier at once. Claims for damage must be made by the consignee to the carrier
and should be reported to the manufacturer.
4. DESCRIPTION
The TS8100 Series Progressive Cavity (PC) Pump is a continuously volumetric dispense pump based on
the progressive cavity (PC) technology. The pump is designed to dispense a wide range of fluids, from
low viscosity coatings to high viscosity greases. The many advantages of PC technology will simplify your
dispense process and improve reliability and quality in the long run.
The TS8100 Series PC Pump provides a consistent dispensing output due to a special design of sealed
cavities in the fluid chamber which create a volumetric fluid flow. Two main components are the stator
and rotor. The metal rotor seals tightly against the flexible rubber stator as it rotates, forming tightly
sealed cavities which move toward the pump outlet, carrying the fluid. The pumped fluid does not
change in shape or size during the dispense process. An accuracy and repeatability rate of +/-1% is
achievable.
techcon.com/contact-us 6
TS8100 Series
Progressive Cavity (PC) Pump User Guide
5. THEORY OF OPERATION
The TS8100 Series PC Pump dispenses fluid with a positive displacement action using a progressive
cavity technology (Figure 4). Fluid is held in a feed reservoir (2) under a positive head of air pressure, up
to 30 psi (2.07 bar), depending upon the viscosity of the fluid. This positive air pressure, supplied by the
air line (1), forces the fluid out of the barrel (2) into the fluid feed path (3) then to the rotor/stator
chamber assembly (4). Fluid flows from this point (4) to the dispense tip outlet and is controlled by the
rotor rotation in the feed direction. The rotor is driven by the encoder DC motor (5). Applying a voltage
signal to the motor (5) will rotate the rotor and the fluid will be forced out the dispense tip. The actual
fluid deposited is dependent upon adhesion of the dispensed fluid to the substrate. Shearing of the fluid
is achieved by reverse Z-motion (tip retraction). When the motor stops, the unit remains in position for a
fraction of a second (dwell) to allow the last drop of fluid to flow out of the dispense tip. After the dwell
period, the automation equipment moves the pump to the next position.
Figure 4
techcon.com/contact-us 7
TS8100 Series
Progressive Cavity (PC) Pump User Guide
6. SET-UP INSTRUCTIONS
6.1 Install the Stator
To ensure the safety of the pump’s components, the TS8100 is shipped without the stator attached to
the motor/rotor assembly. Follow the instructions below to install the stator (Figure 5).
Figure 5
1. Wet the rotor (2) by applying the dispensing fluid (or any appropriate lube that is compatible with
the dispensing fluid) to the exposed portion of the rotor surface.
2. Wet the stator (3) by squeezing a small amount of the dispensing fluid (or any appropriate lube that
is compatible with the dispensing fluid) into the stator opening.
3. Screw the stator (3) onto the rotor in the clockwise direction (2) until the 4 tabs of the stator align
with the 4 notches of the stator housing (Figure 6).
techcon.com/contact-us 8
TS8100 Series
Progressive Cavity (PC) Pump User Guide
Figure 6
4. Apply some pressure on the stator by pushing it against the stator housing to make sure it fully
seats into the notches. Check to make sure the rotor tip is flush with the stator.
Figure 7
5. Place the stator cap (4) into the retaining cap (5).
6. Install the retaining cap (5) (with the stator cap in place) by screwing it onto the stator housing (1) in
the clockwise direction.
6.2 Mechanical Mounting
Normally, the TS8100 Series PC Pump is used on an automation system such as a bench-top robot. It is
very important that the pump is mounted on the Z-axis gantry, in a secure manner, that will not allow
loosening during dispense operation. The Z-axis must move in a precise and repeatable motion for
successful dispensing.
The provided mounting bracket must be attached to the Z-axis in a manner that will provide the valve
perpendicular travel to the horizontal plane of the surface on which the fluid will be dispensed. The
mounting should provide a means of accurately adjusting the distance between the dispense tip and the
substrate surface such as a touchdown sensing device or a fixed distance standoff.
Attach the bracket to the pump as shown in Figure 8.
techcon.com/contact-us 9
TS8100 Series
Progressive Cavity (PC) Pump User Guide
Figure 10
1. Connect the power adapter to the TS588R controller.
2. Connect the air hose to the TS588R controller.
3. Connect the motor cable to Port C.
Note: Make sure the controller is turned off when connecting the motor cable to port C.
4. Connect the syringe air hose to port B.
5. Set air pressure to feed the material to the pump.
Note: for low viscosity material the pressure setting should be 1 - 9 psi; for medium viscosity material
the pressure range setting should be 10 - 19 psi; for high viscosity material the pressure range should be
20 - 80 psi.
6. Press the Power button to turn on the unit.
1.4 Prime the Pump
1. Enter the appropriate flow rate setting in the TS588R Controller.
2. Select the “Purge” mode.
techcon.com/contact-us 11
TS8100 Series
Progressive Cavity (PC) Pump User Guide
MOTOR CABLE AIR HOSE
TO AIR SOURCE
3. Press and hold the foot switch until a steady stream of material is flowing out the pump outlet
without air bubbles.
4. Attach a dispense needle to the pump outlet.
5. Repeat step #2.
Figure 11
6. If air bubbles still appear in the material, open the vent hole by turning the vent screw
counterclockwise to allow air bubbles to escape.
Figure 12
6.5 Dispensing
1. Select the “Volume” Mode on the TS588R controller.
techcon.com/contact-us 12
TS8100 Series
Progressive Cavity (PC) Pump User Guide
7. MAINTENANCE AND CLEANING
7.1 Pump Purging
Purging the pump with dispensing conditioner (Techcon Part Number 7305XCON) after each shift is
recommended. The conditioner removes material residue from the material path and conditions the
pump for future use.
1. Release the material feed pressure.
2. Remove material from the pump.
3. Remove the dispense tip.
4. Install a barrel of the dispensing conditioner to the pump inlet and set air pressure at 10.0 psi.
5. Set the controller to “PURGE” mode.
6. Press the foot switch to let the pump run until the conditioner is the only material being dispensed
at the pump outlet. If the conditioner is unable to force the dispense material out the pump outlet,
then proceed to the “Thorough Cleaning” section.
7. Release the foot switch to stop pump.
8. Release the conditioner feed pressure.
7.2 Thorough Cleaning
Thorough cleaning procedures should be done whenever the following occur:
•When the dispense material is changed to different type
•When the dispense material is started to cure in the pump
•When Pump has been dispensing for one month.
•When the dispense tip clogged frequently
Refer to diagram below (Figure 14). Recommended cleaning solvent: IPA or Acetone.
techcon.com/contact-us 14
TS8100 Series
Progressive Cavity (PC) Pump User Guide
Figure 14
1. Perform the pump purging process by follow steps 1-6 in Section 9.1 “Purging.”
2. Remove the 1/8 NPT Inlet Fitting
3. Rotate the retaining cap (3) counterclockwise until it completely detaches from the stator housing
(7).
4. Pull the retaining cap (3), stator cap (5), and needle cap (4) straight out from the stator housing (7).
5. Remove the stator (10) by rotating it counterclockwise. If necessary, turn on the motor while
rotating the stator.
6. Using the 2 mm hex key to remove 4 mounting screws (13).
7. Pull the stator housing straight out (7); take care not to damage the seal.
8. Submerge the stator (10) in a bath of cleaning solvent and use the cleaning brush (included in the
cleaning kit) to clean the stator. Insert the brush into the center of the stator and rotate it until all
residue is cleaned out.
techcon.com/contact-us 15
TS8100 Series
Progressive Cavity (PC) Pump User Guide
9. Use the same cleaning brush to clean the internal chamber of the stator cap.
10. Use a soft cloth to wipe off material residue on the rotor (2) surface.
11. Continue to clean the rotor by dipping it in a solvent bath, then use the brush to remove any
leftover residue.
12. Use a soft cloth to wipe off material residue on the cup seal (11).
13. Inspect parts for wear or damage and replace if necessary.
techcon.com/contact-us 16
TS8100 Series
Progressive Cavity (PC) Pump User Guide
8. SPARE & REPLACEMENT PARTS
Figure 15
Item
Part Number
Description
1
8100-100-007
Cable Assembly
2
7509-0340
Motor Sleeve
3
2800-0903
M3 x 6mm Set Screw
4
7509-0610
Flexible Coupling
5
3300-0586
U-Seal (x2)
6
2800-0836
M2.5 x 3mm Set Screw
7*
8100-100-001
Rotor, TS8100-100
7*
8100-200-001
Rotor, TS8100-200
7*
8100-300-001
Rotor, TS8100-300
8
8100-MPLATE
Motor Mount Plate, Inc. Pin
9
2800-0295
Washer, M2.5, Lock, SS (x4)
10
8100-100-005
Stator Housing
11*
8100-100-002
Stator, TS8100-100
11*
8100-200-002
Stator, TS8100-200
11*
8100-300-002
Stator, TS8100-300
12
7509-0090
Lock Nut
13
7090-0030
Locking Cap, TE and TT
14
8100-100-006
Stator Cap Bottom
15
2800-0897
M2.5 x 14mm Socket Screw (x4)
16
2800-0917
Washer #4 NAS 620 (x4)
17
3300-0616
Vent Shaft O-Ring, Small
18
3300-0617
Vent Shaft O-Ring, Large
19
7509-0570
Vent Screw
20
2800-0901
M3 x 6mm Machine Screw (x3)
21
8100-100-004
Motor
22
2800-0900
4-20 x 1/4" Forming Screw (x3)
23
8100-CLEANKIT
Cleaning Kit (Not Shown)
24
TS8100-SYBRACKET
Syringe Bracket (Not Shown)
25
TS8100-MBRACKET
Mounting Bracket (Not Shown)
26
TSD931-81B
Luer Lock, Elbow (Not Shown)
27
TSD931-82B
Luer Lock, Straight (Not Shown)
28
TSD931-96
Luer x 1/8" NPT (Not Shown)
29
TSD931-105
Luer x 10-32 (Not Shown)
Note: When refitting stator (11), wet the rotor (7) by
applying the dispensing fluid, or appropriate lube that is
compatible with the dispensing fluid, to the rotor surface.
techcon.com/contact-us 17
TS8100 Series
Progressive Cavity (PC) Pump User Guide
9. STANDARD ACCESSORIES
PART NUMBER
DESCRIPTION
8100‐CLEANKIT
Cleaning Kit
8100‐SYBRACKET
Syringe Bracket Kit
8100‐MBRACKET
Mounting Bracket
TSD931‐96
Female Luer with 1/8 NPT Thread
TSD931‐82B
Male Adapter Luer Lock, Black Nylon
TSD931‐81B
Elbow 90°Luer Lock, Black‐Nylon
10. OPTIONAL ACCESSORIES
PART NUMBER
DESCRIPTION
TN00DKIT
Complete Dispensing Tip Kit
9000-000-112
Sample Tip Kit
7105XCON
Conditioning Cream, 10 cc
7305XCON
Conditioning Cream, 30 cc
71003RHB
10cc Receiver Head, 0.9 m (3 ft)
73003RHB
30cc Receiver Head, 0.9 m (3 ft)
11. TROUBLE SHOOTING
PROBLEM
POSSIBLE CAUSE
CORRECTION
No Fluid Flow
Dispense tip is clogged
Replace tip
Motor does not receive signal
Make sure all connections are
secured
Motor running in reverse
Reverse motor cable connection
Barrel of dispense fluid is empty
Replace with new fluid barrel
Fluid feed pressure is too low
Increase feed pressure
Inconsistent Shot Size
Fluid dried or cured
Replace with new fresh fluid
Fluid pressure fluctuating
Make sure fluid pressure is
constant
Valve On Time is too short
Increase valve On Time
Excessive motor Reverse Time
Reduce Reverse Time or turn off
completely.
Air trapped in fluid
Purge valve properly
Skipped Dots
Intermittent motor signal
Check and replace motor
Air trapped in fluid
De-air fluid
Fluids Drool After Valve is
Turned Off
Air trapped in fluid chamber
Purge valve properly
Air trapped in fluid reservoir
Remove air from reservoir
techcon.com/contact-us 18
TS8100 Series
Progressive Cavity (PC) Pump User Guide
12. TS588R SMART CONTROLLER SPECS
SPECIFICATIONS
Size (mm)
290 mm x 212 mm x 98 mm
Size (inches)
11.4” X 8.3” X 3.9”
Weight (kg)
2.8 kg
Weight (lbs)
6.17 lbs
Input Voltage
24 VDC
Output Voltage Range
0-24 VDC
Rated Power
15 W
Air Input
100 psi (6.9 bar) Max.
Air Output
0-99.9 psi (6.9 bar)
Pollution Degree
II
Installation Category
I
Indoor Use
Altitude up to 2,000 m (6,562 ft)
Operating Temperature
0˚C to 50 ˚C (32 ˚F to 122 ˚F)
Storage Temperature
-10 ˚C to 60 ˚C (14 ˚F to 140 ˚F)
Max. Relative Humidity
80% for temperature up to 31 ˚C (87.8 ˚F)
Decreasing linearly to 50% relative humidity at
40 ˚C (104 ˚F)
Timer
0.008-99.99 seconds
Cycle Mode
Timed, Interrupt, Teach, Purge
Timing Repeat Tolerance
+/- 0.001%
Cycle Rate
Up to 900 cycles/min
Display
Touch Screen, Resistive
Certification
CE, TUV, NRTL
techcon.com/contact-us 19
TS8100 Series
Progressive Cavity (PC) Pump User Guide
13. LIMITED WARRANTY
Manufacturer warrants this product to the original purchaser for a period of one (1) year from date of
purchase to befree from defects in fluid and workmanship, but not against damages bymisuse, negligence,
accident, faulty installations and instructions. Manufacturer will repair or replace (at factory’s option),
free of charge, any component of the equipment thus found to be defective, on return of the component,
“PREPAID” to the factory during the warranty period. In no event shall any liability or obligation of the
Manufacturer arising from this warranty exceed the purchase price of the equipment. This warranty is
only valid if the defective product is returned as a complete assembly without physical damage. The
Manufacturer’s liability, as stated herein, cannot be altered or enlarged except by a written statement
signed by an officer of the company. In no event shall the Manufacturer be liable for consequential or
incidental damages. A return authorization is required from Techcon Systems prior to shipping a defective
unit to the factory.
Manufacturer reserves the right to make engineering product modifications without notice.
All returns must be issued a Returns Authorization number prior to return. Send warranty returns to:
Americas
Techcon/OK International
10800 Valley View Street
Cypress, CA 90630
USA
Delrin®, Viton® and Teflon® are registered trademarks of E.I. DuPont. PROGRESSIVE CAVITY (PC) PUMP USER GUIDE | 20220125
Europe
Techcon/OK International
Eagle Close
Chandler’s Ford Ind Est
Eastleigh Hampshire
SO53 4NF
United Kingdom
Asia
Techcon/OK International
4th floor East, Electronic Building
Yanxiang Industrial Zone, High
Tech Road
Guangming New District,
Shenzhen P.R.C.
Techcon C orporate H eadquarters
10800 Valley View Street, Cypress,
Cypress, California, 90630, USA
Tel: 1-714-799-9910 | Fax: 1-714-828-2001
E-mail:[email protected]
Visit ou r website for more information and to
contact the Techcon office nearest you. We
have several offices worldwide that are ready
to serve your needs.
techcon.com/contact-us
For Saleses
and Support:
TS8100 Series
Progressive Cavity (PC) Pump User Guide
Table of contents
Other TECHCON Water Pump manuals
Popular Water Pump manuals by other brands
Gude
Gude GP 18-0 Translation of the original instructions
DYI SHENG
DYI SHENG DS04-S operating manual
Agilent Technologies
Agilent Technologies Turbo-V 81-T user manual
Doheny's
Doheny's 2716 Installation, operation & parts
fluid-o-tech
fluid-o-tech FG Series instruction manual
Espa
Espa WATERDRIVE instruction manual
Blue Angel Pumps
Blue Angel Pumps Professional BEFL33 Operating instructions and parts manual
GORMAN-RUPP PUMPS
GORMAN-RUPP PUMPS 6500 Series Installation, operation, and maintenance manual with parts list
Grundfos
Grundfos MS Series manual
Piusi
Piusi E300 Instructions for installation, use and maintenance manual
Baoding Shenchen
Baoding Shenchen F Series manual
SprayTECH
SprayTECH EP2300SE 0294083 owner's manual
Dover
Dover Mouvex CC8-65 EP Installation operation & maintenance
Ryobi
Ryobi R18TP Original instructions
Wilo
Wilo Rexa CUT GI Series Installation and operating instructions
Little Giant
Little Giant 5 Series owner's manual
Wesco
Wesco 272397 Operating instructions and parts manual
Ecoflo
Ecoflo E130V6 owner's manual
