Technaxx TX-201 Quick start guide

1
Model: TX-201/202 Article No. 5010/5011, 08/2022
Technaxx® * operating instructions
Technaxx 300W/600W Powerstation TX-
201/TX-202
Before using the appliance for the first time, please read the instructions
for use and safety information carefully.
Service phone No. for technical support: 01805 012643* (14
cent/minute from German fixed-line and 42 cent/minute from
mobile networks).
Free Email: [e-mail]
*The support hotline is available Mon-Fri from 9 am to 1 pm & 2
pm to 5 pm.
Keep this user manual for future reference or product sharing
carefully. Do the same with the original accessories for this
product. In case of warranty, please contact the dealer or the
store where you bought this product.
Enjoy your product * Share your experience and opinion on
one of the well-known internet portals.
Table of contents
Explanation of Warning Symbols and Notes .............................................................................. 2
Danger! .................................................................................................................................................. 2
Hints ....................................................................................................................................................... 3
Safety Instructions ............................................................................................................................. 4

2
Model: TX-201/202 Article No. 5010/5011, 08/2022
Features ................................................................................................................................................ 4
Product overview TX-201 300W ...................................................................................................... 5
Product overview TX-202 600W ...................................................................................................... 6
Display ................................................................................................................................................... 7
How to charge the device ................................................................................................................. 9
By Car Adapter .................................................................................................................................... 9
By Solar panel ..................................................................................................................................... 9
By battery reactivation port. .......................................................................................................... 10
Example of usage ............................................................................................................................. 11
The table above should give you an indication, depending on your devices, capacity of the
batteries you may get different results with your products. Mini refrigerator may not start if
they are driven by compressor, due to high current during starting process. ........................... 12
Cleaning and maintenance ............................................................................................................ 12
Declaration of conformaty .................................................................................................................... 12
Disposal ................................................................................................................................................. 12
Explanation of Warning Symbols and Notes
Risk of electric shock
This symbol indicates product parts energized with a dangerous
voltage of sufficient magnitude to constitute a risk of electric shock.
Warning
This symbol is used to indicate safety instructions or to draw your
attention to specific hazards and risks.
This symbol is used to indicate additional
information or important notes.
Danger!
When using the equipment, a few safety precautions must be observed to
avoid injuries and damage. Please read the complete operating
instructions and safety regulations with due care. Keep this manual in a
safe place, so that the information is available at all times. If you give the

3
Model: TX-201/202 Article No. 5010/5011, 08/2022
equipment to any other person, hand over these operating instructions and
safety regulations as well. We cannot accept any liability for damage or
accidents which arise due to a failure to follow these instructions and the
safety instructions. Do not use this product near heat sources such as fires
or stoves.
Avoid contact with any liquid. Do not immerse the product in water or get
it wet. Do not use this product in rain or wet conditions. Do not use this
product in environments with strong static electricity/magnetic fields.
Do not disassemble the product in any way or pierce the product with
sharp objects. Do not insert any metal objects inside this product, as this
creates a risk of electric shock and can cause irreparable damage to the
product. Do not use any unofficial components or accessories. For
replacement of any parts or accessories, please contact your dealer for
advice. When using the product, please strictly abide by the ambient
temperature specified in this user manual. If the temperature is too high, it
may cause a fire or explosion; if the temperature is too low, the
performance of the product may be severely degraded, or the product may
stop working. Do not place any heavy objects on top of the product.
During use, do not forcibly block the fan operation or place the product in
a non-ventilated or dusty place. Please avoid shock, drop or severe
vibration when using the product. In case of severe external shock,
immediately turn off the power and stop using the product. Make sure the
product is securely fastened during transportation to avoid vibration and
shock. If the product is accidentally dropped into water during use,
please place it in a safe and open place and keep it away from it until it is
completely dry. Dried product should not be reused and should be
disposed of properly in accordance with Disposal Guidelines below. If the
product catches fire, we recommend that you use the fire extinguisher in
the following order: water or mist, sand, fire blanket, dry chemical, and
finally a carbon dioxide fire extinguisher. Use a dry cloth to remove dirt
from the product ports. Place the product on a flat surface to prevent
damage from tipping over the product. If the product is overturned and
seriously damaged, turn it off immediately, place the battery in an open
place, away from flammable objects and people, and dispose of it in
accordance with local laws and regulations Make sure to keep the
product out of the reach of children and pets.
Hints
The device is intended exclusively for private and not for commercial
use. Only use this device as described in this user manual. Do not
place any part of this device in water or any other liquid. Do not handle

4
Model: TX-201/202 Article No. 5010/5011, 08/2022
the device with wet hands. When disconnecting the cable, always pull
at the plug. Do not pull on the cable itself. Do not let the cord on the
edge of a table or work surface. Prevent it comes into contact with hot
surfaces. Keep it away from heat sources to avoid deformation of plastic
parts.
Safety Instructions
Children are not allowed to play or use the equipment. Unless
supervised, children are not allowed to clean the equipment and carry
out user-level maintenance work. Any errors made in following the
safety regulations and instructions may result in an electric shock, fire
and/or serious injury. The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils or small parts.
There is a danger of swallowing or suffocating! The device is intended
only for private use. Only operate the product indoors or under dry
condition Keep children and bystanders away from your work area.
Do not use the unit in a damp or wet environment. Ensure that there
is sufficient lighting. Do not expose the unit to direct sunlight, rain or
snow. Do not use the charger near explosive gases or liquids. Keep
the item in a dry, safe place out of the reach of children. Do not carry
the item by the cable and do not pull on the cable to pull the plug out of
the socket. the plug from the socket. Protect the cable from heat, oil
and sharp edges. Before use, make sure that the unit and all cables are
in perfect condition. If the cable is damaged, have it replaced by an
authorised specialist workshop. Do not attempt to carry out any repairs
yourself. Always disconnect the item from the mains when not in use.
Keep all the ventilation slots clean.
Features
TX-201 TX-202
Output 300W/ 230V,50Hz pure
sine wave
600W/ 230V,50Hz pure sine
wave
Socket 1 x Schuko 2 x Schuko
USB
USB-A 2 x 5V 3.1A max. 15W shared
USB-A 2 x USB-A (QC 3.0),
DC5V,3A, DC9V,2A,
DC12V,1.5A, max 18W
(shared)
USB-C 1 x 60W max, (5-20V 3A max.)

5
Model: TX-201/202 Article No. 5010/5011, 08/2022
1 x PD (DC 5V 3A, 9V 3A,
12V 3A, 15V 3A, 20V 5A)
(Max 100W)
Cigarette
port
1 x 12V 10A (120W max.) 1 x 12V 10A
2 x 12V 10A
(120W max. shared)
LED Light 3 different function 2W
Input
Hollow
Socket
1 X
7909
DC 11-30V, 5A (100W
max)
DC 11-30V, 6A (150W max)
XT60 non DC 11-30V (max.150W)
USB-C 1 x Battery activation port max. 5V, 2A max.
Battery Li Ion
Capacity 12,5AH/ 315Wh 20Ah, 504Wh
Voltage
25,2V
Safety
function
Overload-, Over Voltage- Over Current-, Short
Circuit-, and Low Voltage- Protection
Display Remaining Power, Input Power, output Power,
remaining run time, remaining charging time,
Inverter Rated Power, Temperature Status, Fan icon,
Warning
Dimensions 27 x 15 x 18.2 cm 28.7 x 20.5 x 19.8 cm
Weight 3.9kg 6.25kg
Product overview TX-201 300W
1 Battery reactivation port 6 Display
2 DC Input 7 Cigarette lighter port

6
Model: TX-201/202 Article No. 5010/5011, 08/2022
3 Schuko Socket 8 USB ports
4 AC switch 9 LED Light
5 Display switch 10 LED switch
11 DC switch
Product overview TX-202 600W
1 Battery reactivation port 6 Display
2 DC Input 7 Cigarette lighter port
3 Schuko Socket 8 USB ports
4 AC switch 9 LED Light
5 Display switch 10 LED switch
11 DC switch 12 XT 60 Solar input
13 2 x DC Out 12V 10A max. 120W
shared

7
Model: TX-201/202 Article No. 5010/5011, 08/2022
Display
Figure
Number
Figure Fault Description and Handling Methods
1
Inverter fault icon, displayed when fault occurs (Including: short circuit,
overload, under voltage, over voltage, over temperature, etc.)
When the voltage is undervoltage, there will be a "di...di..." alarm sound (10
seconds), and the AC icon on the LCD screen will flash, and the green light
on the AC switch button will flash.
2 Battery failure icon
3
Normal temperature
Figure 3 The pointer
points to the middle
Low temperature fault,
icon 1
and 3 appear at the same
time
Figure 3 The pointer points
to L
High temperature
fault, icon 1 and 3
appear at the same
time
Figure 3 The pointer
points to H
In low temperature environment, battery discharge failure:
When -20+/-3 , the batt
ery is protected at low temperature level I, and the
icons 1, 2, and 3 are displayed at the same time,
-25+/-3 C, battery level II low temperature protection, LCD breath-
holding
screen, no display, and red light flashing on AC switch button,
Recovery temperature after discharge low temperature protection: -10+/-3

8
Model: TX-201/202 Article No. 5010/5011, 08/2022
.
In low temperature environment, battery charging failure:
When -10+/-3
, the battery is under low temperature protection, the icons
1, 2, and 3 are displayed at the same time, and the icon 3 is flashing,
Recovery temperature after charging low temperature protection: 0+/-3 .
High temperature environment, battery discharge failure:
When the temperature is 60+/-3
, the battery is protected against high
temperature level I, and the icons 1, 2, and 3 are displayed at the same time,
When the temperature is 65+/-3
, the battery is protected against high
temperature level II, and the LCD screen will hold the breath without any
display. At the same time, the red light on the AC switch button flashes,
Recovery temperature after discharge high temperature protection: 55+/-3
.
Battery charging failure in high temperature environment
When the temperature is 60+/-3
, the battery is protected against high
temperature, the icons 1, 2, and 3 are displa
yed at the same time, and the
icon 3 is flashing,
Recovery temperature after charging high temperature
protection: 50+/-3 .
4
Time required to fully charge the battery
Battery life time
5 Fan icon (appears when the fan is working)
6~9
Figure 6: Battery level display (about 10% per grid);
When charging, the bar corresponding to the battery will flash; if the
battery shows 0%, the Figure 6 will flash.
Figure 7: Battery charging icon (appears while charging)
Figure 8: Battery charging power (appears while charging
Figure 9: Battery Percentage
10~12
Figure 10: Energy Storage Power Specifications (Inverter Power
Figure 11: Appears when the DC switch is open, flashes when overloaded
or short-circuited,
Figure 12: Appears when the AC switch is turned on, and flashes when
there is a fault (Including: short circuit, overload, under voltage, over
voltage, over temperature, etc.)
13~15
Figure 13: Display of total load power (about 10% per grid
Figure 14: Total load power (sum of all loads, including: AC, USB-A, TYPE-C,
DC, LED lights
Figure 15: AC output voltage
When the unit is charged and under load at the same time, it may
happen that the display shows unreasonable values on input and output
Display, e.g. if the unit get charged with a power of 100W and

9
Model: TX-201/202 Article No. 5010/5011, 08/2022
discharged with a power of 50W, the display shows less than 50W
charging power. This happen because of a priority connection of the
input power circuit, this input power get directly used to operate the item
on the 230V output port.
If the output power is bigger than the input power you may see that the
Display show a smaller number of consumed power, e.g. charge with
100W, discharged power is 200W, the display show ~100W on the
output Display.
How to charge the device
The battery power of the energy storage power supply will be consumed
during use. You can choose the following methods to charge the energy
storage power supply Note: All models do not support multiple
charging methods at the same time, only one of them can be selected for
charging.
By AC-Adapter
Connect the AC plug cord
to the adapter
Insert the adapter DC output plug
into the device charging port
Insert the adapter AC plug
into the mains outlet
By Car Adapter
Insert the DC output plug
into the device charging
port
Insert the car
cigarette lighter
plug into the car
cigarette lighter
By Solar panel
Make sure the solar panel output is in the range of the allowed input parameter (see table
above) we suggest to use the 100W Solar Panel TX-206 foldable Solar Panel or TX-208

10
Model: TX-201/202 Article No. 5010/5011, 08/2022
Powestation TX-201 and TX-202.
By battery reactivation port.
The battery reactivation port (1) is for rescue charging only, use this
charging method if other way of charging is not possible only!
Remove the protective cover with a screwdriver, plug the Type-C charging
cable (not included) into the charging port, and plug the charger (not
included) into the mains socket. It takes a long time to charge here (about
10-14 hours) until the LCD screen lights up.
Use of Product
The Products have different function units inside, each is equipped with a
switch to switch the relevant function on or off
Display:
To activate the Display, hold the switch for ~1 second, the Display lights
up and show the relevant status-information for further details go to the
point Display. It will automatically turn off if there is no operation for 5
minutes; you can press any button to wake up.
DC unit:
To activate the DC ports USB and 12V), hold the DC power switch for ~1
second, the switch will light up and show the DC unit is ready to use.
AC Unit.
To activate the AC ports, hold the AC power switch for ~1 second, the
switch will light up and show the AC unit is ready to use. We suggest to
switch the AC ports off as long as they are not used, the internal inverter
need battery power as well as no item is connected.
LED:
To activate the LED hold the LED switch for ~1 second, the LED will light
up, press the switch again to change the different functions.
Troubleshooting
Fault
Category Fault Description and Handling Methods
Battery High
Temperature
Protection
Put the device in a cool and ventilated place, and it can be restored after
the temperature is lowered.
Notice: Do not directly cool the equipment by freezing, so as not to damage
the equipment!!!
Battery Low
Temperature
Protection
Put the device in a warm environment, and it can be restored after the
temperature rises.

11
Model: TX-201/202 Article No. 5010/5011, 08/2022
Notice: Do not put the device into the oven, or directly heat the device by
other means to avoid danger!!!
DC does not
charge (Car /
Solar /
Adapter
Please check if the charging voltage meets the device requirements:
(Car/Solar charging DC charging voltage requirements 11-30VDC
Please check if the indicator light on th
e power adapter is on, if not, please
check:
Is the adapter connected,
Whether the AC socket is normal, and whether the AC mains is normal;
(Note: The inspection requires professionals and professional equipment
to avoid electric shock)
Battery high temp
erature or low temperature protection, please refer to the
corresponding method.
No AC output
Check that the AC switch is on. (On: the green indicator light on the button
is on, off: the indicator light is off)
Check whether the load device is connected to the AC output
The equipment is overloaded or short-circuit protected. After reducing the
load or eliminating the fault, it can be restored after restarting.
Battery under-voltage protection, need to be charged before use; AC switch
should be turned off and then turned on.
Cigarette
lighter, DC
Ports, USB,
TYPE-C no
output
Whether the DC switch is on. (On: the green indicator light on the button is
on, off: the indicator light is off)
Check whether the green indicator on the switch button is flashing. If it
flashes, it may be caused by overload or short circuit or over temperature of
the DC module. After checking and troubleshooting, it can return to normal.
Overload recovery: reduce the load to within the rated range,
Short-circuit recovery: check the load equipment and eliminate the short-
circuit fault,
Module over-temperature recovery: suspend use and resume after cooling.
Battery under-voltage protection, need to be charged before use
Battery high temperature or low temperature protection, please refer to
the corresponding method
LED light
does not light
up
Whether the LED switch is on. (On: the green indicator light on the button is
on, off: the indicator light is off)
Battery under-voltage protection, need to be charged before use
Battery high temperature or low temperature protection, please refer to
the corresponding method
LCD not
responding
Battery high temperature or low temperature protection, please refer to the
corresponding method
If the battery is seriously short of powe
r, charge it through the battery rescue
port until the LCD screen is lit, and then fully charge it in the usual way
Example of usage
TX-201 300W TX-202 600W
Min. loading time 45 min.

12
Model: TX-201/202 Article No. 5010/5011, 08/2022
Mobile phone 23 x 37 x
Tablet 11 x 18 x
Drone 21 x 34 x
Camera 18 x 29 x
Notebook 5 x 8 x
Run mini Refrigerator 4h 6h
The table above should give you an indication, depending on your
devices, capacity of the batteries you may get different results with your
products. Mini refrigerator may not start if they are driven by compressor,
due to high current during starting process.
Cleaning and maintenance
Danger! Always pull out the mains power plug before starting any cleaning work. Keep all
safety devices, air vents and the housing free of dirt and dust as far as possible. Wipe the
recommend that you clean the device immediately each time you have finished using it.
nd some soft soap. Do not use cleaning
agents or solvents; these could attack the plastic parts of the equipment. Ensure that no
water can seep into the device. The ingress of water into an electric tool increases the risk of
er should be placed in a dry room for storage. Any corrosion
must be cleaned off the charging terminals.
Declaration of conformaty
The EU declaration of conformity can be obtained from the
address given www.technaxx.de/ (in bottom bar
Disposal
Dispose of packaging. Dispose of the packaging according to type.
Dispose of cardboard and carton in the waste paper foils to the
recyclables collection.
Dispose of old appliance (Applicable in the European Union and other European
countries with separate collection (collection of recyclable materials) Old
appliances must not be disposed of with household waste! If the product
can no longer be used, every consumer is legally obliged to dispose of old
appliances separately from household waste, e.g. at a collection point in
his or her municipality or district. e.g. at a collection point in his or her

13
Model: TX-201/202 Article No. 5010/5011, 08/2022
municipality/borough. This ensures that old appliances are recycled properly and that
negative impacts on the environment are avoided. This is why electrical appliances are
marked with the symbol shown here.
Made in China
Vertrieben durch:
Technaxx Deutschland GmbH & Co. KG
Konrad-Zuse-Ring 16-18,
61137 Schöneck Germany
