Technical Concepts AutoFlush Maintenance and service guide

AutoFlush®
L
o
o
k
s
C
l
e
a
n
-
I
s
C
l
e
a
n
.
™
Installation&Maintenance
forTANKTOILETWirelessModel
TECHNICALCONCEPTS
®

A.Motor
B. MotorMount
C. HexBoltinMotorMount
D. MotorArm
E.PlasticSpacer
F. AllenWrench
G. OverflowPipeClip
H. BeadChainwithClip
I. RemoteSensor
J.SensorCoverKey
K. BatteryCompartment
L. BatteryCompartmentscrewsand
 anchors(large-2ea)
M.WireGuides(3ea)
N. ScrewsandAnchorsforWireGuides
 (small-3ea)
O. SensorAdjustmentTool
P.Four(4)"D"cellAlkalineBatteries
Q.Four(4)"AA"cellAlkalineBatteries
R.ClearPlasticShim(2ea)
S.Double-sidedTape
A
B
C
D
G
F
H
I
J
K
L
M
P
Q
O
1.1 RemovetheAutoFlushcomponentsfromtheboxandchecktomakesureyouhavealltheparts.
Components
1
Toolsrequired:SmallPhillipsscrewdriver,pencil
E
N
R
S

2.1 Checkthatallexistingtoiletplumbingcomponentsarefunctioningproperly. Itisrecommendedtowearprotectivegloves
 whenworkinginsidethetoilettank.
2.2 Shutoffwatertotoilet(usuallyfoundonthewalldirectlyunderthetankonthesamesideastheflushhandle).
2.3 Flushtoiletandholdhandledowntoremoveasmuchwaterfromthetankaspossible. Listentohearifthetankisrefilling. 
 Ifso,makesurethewateriscompletelyturnedoff.
2.4 Markwallforsensorinstallation. Beforeremovingthetankcoverliftupthetoiletseatcover,ifthecovercomesabovethe
 tankmakeasmallpencilmarkonthewalldirectlybackfromthetopofthetoiletseatcover. Ifthetoiletseatdoesnotcome
 abovethetopofthetoilettank,thenusethecenterandtopofthetoilettankasaguideandmakeasmallmarkonthewall. 
 Thenmark21/2"directlyabovethemarkyoujustmade.Themarkwillbeusedlaterintheinstallationasaguideline.
2.5REMOVEthetoilettankcoverandplaceitoutoftheway.
2.6CLOSEtoiletseatcovertoavoiddroppingcomponentsintoilet!
3.1 Detachthewaterfilltubefromtheoverflowpipeandinserttheoverflowpipeclip(G).
Thisclipwillattachtothesideoftheoverflowpipeafterthemotorinstallationiscomplete.
3.2 Loosenhexbolt(C)inthemotormount(B).
3.3 Slidemotormount(B)ontotheoverflowpipe(makesurethehexboltisatthetop). 
 Themotormountmayrequirethe plasticspacer(E)foratightfit. Theplasticspacer
 shouldbeplacedfirstontheoverflowpipeandthenslidethemotormount(B)over
 thespacer(E).
3.4 Alignthetopofthemotormount(B)tothetopoftheoverflowpipe.Tightenhexbolt(C)
 byhand. 3.3 3.4
Prior to Installation
2
Motor Mount Installation
3
21/2"
2.4 2.4
TopAlignment
SlideMotorMount(B)
21/2"
or
3.1
G

4.1 Slidemotor(A)ontothemotormount(B). Rotatethetwocomponentstogether
 tofitinthetankandavoidinterferingwithexistingvalvecomponents. Ensurethe
 topofthemotormount(B)isstillalignedwiththetopoftheoverflowpipe. Keepthe
 electricalsensorcordontheoutsideofthetankwheninstallingthemotor(A).
4.2 Rotatetheactuatorarm(D)onthemotor(A)andalignabovetherubberflapper. 
 Oncethearmisaligned,andthemotor(A)isnotinterferingwithanyoftheinternal
 plumbingcomponents,thentightenthehexbolt(C)usingtheprovidedAllenwrench(F). 
Donotovertorque.
4.3 Determinewhichofthethreeholesonthemotorarm(D), ismostdirectlyalignedabovethe
 flapperchainconnection. Flipthemotorarm(D)upsoyoucaninsertthebeadchainintheselected
 holeandlockthechainintheholeslot. Returnthearmtothepreviouslyalignedposition.
4.4 Attachchainclip(H)onflapperchain2"aboveflapper. Unlockbeadchain(H)from
 motorarm(D)andpulluptotakeoutmostoftheslack. Lockbeadchaininholeslot. 
 Excesschaincanbewrappedaroundmotorarm(D)andsecuredinavailableholeslot.
4.5Installoverflowpipeclip(G)withattachedwaterflowtubeintooverflowpipe.
NOTE:Leavechainattachedtohandle,soflushhandlecanbeusedfor"courtesyflush".
5.1 Alignthesensorsothetopofthesensorassemblycoversthemarkpreviouslymadeonthewall(StepandDiagram2.4).
5.2 Peeloffadhesivebackingfromsensorassemblyandadheretowall. Ifyouhavewallpaperordrywallyoumaywanttousethe
 smallscrews(N)provided(foundinthebatterycompartment)tomounttheremotesensor(I),insteadofusingtheadhesive. 
5.3 Removetheremotesensorcover(I)bytakingthesensorcoverkey(J)andinsertingitintothetwosmallholesatthebottom. Pushin
 androtateupward.
5.4 Installfour(4)"AA"cellalkalinebatteries(Q). Notingthebatterypositionmarksontheinsideofthecompartment.
 Replacecoveronremotesensor.
Remote Sensor Installation
5
Motor Installation
4
4.3
A
H
D
4.4
D
AB
H
2"
ChainClip
4.2ArmRotates360˚
TOPVIEW
A
D
4.1
A
B
4.5
A
G
B

Install Battery Compartment
6.1Checktomakesurethesensorcordandmotorcordwillreachthebatterycompartmentbeforemounting.
6.2RemovebatterycompartmentcoverbyunscrewingthetwoPhillipsscrews. Insidethebatterybox(K)therearetwolarge
 screwsandanchors(L). Placethebatterycompartment(K)inaconvenientlocationunderthetank,ensuringeasyaccess.
6.3Securetowallwithscrewsandanchors,ordouble-sidedtape(R). Note:Thebatterycompartmentmaybemountedusingone
 screwandanchorwiththetopslotfacilitatingeasyremovalforbatteryreplacement. Makesurethemotorcordisplacedinthe
 notchatthebackedgeofthetoilettank(6.3a). Ifthereisnotanotchthenusethetwoclearplasticshims(Q)(6.3b).
6.4Pluginthecordfromthemotor(A)intoeitheroneofthereceptaclesinthebatterycompartment.
6.5Installfour(4)"D"cellalkalinebatteries(P). Notingthebatterypositionmarksontheinsideofthecompartment.Replace
 coveronbatterybox.
7.1Turnwateronandreplacetoilettankcover.
7.2YourAutoFlushunitcomespresetfromthefactory. Ifspecialcircumstancesrequireadjustmentoftheactivationdistance,seeAppendixA–Adjusting
 YourAutoFlush. TheAutoFlushunithasa7minutestart-upsequenceinwhichtheObjectLockSensorwillactivatetheUser-In-ViewgreenL.E.D.
 continuouslyaslongasauserorobjectisinview. Afterthestart-upsequenceiscompletedandwhentheObjectLockSensorhasauserinview,the
 User-In-ViewgreenL.E.D.willflash3timesoncetheuserisinfrontoftheunitforaminimumof5seconds.Thispreventsneedlessflusheswhen
 someonewalksby.
GreenL.E.D.(light)flashes3times
whentherearenousers.
YellowL.E.D.(light)flashes.
FrontofObjectLockSensoris
coveredorObjectLockSensor
issettoofarout,registering
unwantedobject.
Batteriesneedreplacing.
Removeitemcoveringsensor
oradjustObjectLock
Sensoractivationdistance.
(SeeAppendixA-AdjustingtheAutoFlush)
Replacebatteries. UseOnlyAlkalineBatteries. USER-IN-VIEWL.E.D.- Greenlightflashes
3times,after5seconddelay,whenauser
isinview.Thegreenlightflashesconstantly
whenauserisinviewduringthe7minute
startupsequence.
BATTERYL.E.D.-Yellowlightflashes
indicatingitistimetoreplacethebatteries.
OBJECTLOCKSENSOR-Detectsuser
orobject.
6
Activation
7
Troubleshooting Guide
8
PROBLEM CAUSE SOLUTIONTOPROBLEM
NOTE: Donotusein-tankcleanerswhichmaydamagethemotorhousingandothertankcomponents.
2"2"
motor cord
motor cord
TANK TOILET WITH NOTCH
TANK TOILET WITHOUT NOTCH
clear plastic shim
6.3a 6.3b

107184
-+
SensorRange
AdjustmentScrew Short Long
SensorRangeResetButton
Sensor
Range
Adjustment
UseSensor
Adjustment
Tool
BatteryL.E.D.(Yellow)
FlashingYellowL.E.D.=ChangeBatteries.
User-In-ViewL.E.D.(Green)
Flashes3Times=Useracknowledged&ready
tooperate.
ObjectLockSensor 
DetectsUserorObject.
TochangeactivationdistancefortheObjectLockSensor:
1 Removethecoverofthesensorassembly(I)bytakingthesensorcoverkey(J)andinsertingitintothetwosmallholesunderthesensorlens. Pushinandrotateupward.
2 Removetherubberseallocatedontheleftsideofthesensorlens.
3 Presssensorrangeresetbuttonshowninabovediagram. Note:thegreenL.E.D.willflashcontinuouslywhenithasanobjectinviewforthesevenminuteresetperiod. 
 Thisallowsyoutoselectthecorrectrange.
4 Standatdesiredactivationdistance.
5 UsesensoradjustmenttoolandturnSensorRangeAdjustmentScrewallthewaydown(counterclockwise)andthenturnslowlyup(clockwise)untilgreenL.E.D.beginstoflash.
6 EnsureObjectLockSensorisnotdetectingunwantedobjects,bysteppingoutofsensorpathandmakingsuregreenL.E.D.isnotflashing. Ifsensorlocksontoanunwanted
 object,unitwillnotflushproperly. Shortenactivationdistance.
7 Replacesensorcover.
8 After7minutestart-upsequence,thegreenL.E.D.willflashonly3timeswhenauserisinview(aftera5seconddelay).
AppendixA-AdjustingYourAutoFlush
9
TollFree:1-800-551-5155 Web:www.technicalconcepts.com Email:[e-mail]
®
WorldHeadquarters:
ServingNorth&SouthAmerica
TechnicalConceptsLLC.
1301AllansonRoad
Mundelein,Illinois60060U.S.A.
☎ 847-837-4100
Fax:[phone]
EuropeanHeadquarters:
ServingEurope,Africa&MiddleEast
TechnicalConceptsInternationalLtd.
PinGreenBusinessParkEastmanWay
Stevenage,HertsSG14UH,England
☎ [phone]
Fax:[phone]
AsianHeadquarters:
ServingAsia&Pacific
TechnicalConceptsAsia
51(B)LorongPerindustrianBukitminyak9
14100BukitMertajam,Penang,Malaysia
☎ (60)45085008
Fax: [phone]
SpanishandFrenchinstallationinstructionsareavailableatwww.technicalconcepts.com
InstrucciónesdeinstalacionenFrancesyenEspañolestarandisponiblesenlapaginawww.techicalconcepts.com
Lesinstructionspourl`instalationsontdisponiblesenfrancaisetenespagnolsurnotresiteweb;www.technicalconcepts.com
ThisdevicecomplieswithPart15oftheFCCRules.
Operationissubjecttothefollowingtwoconditions:(1)
Thisdevicemaynotcauseharmfulinterference;and(2)
thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation
FCC ID: RNV0009919150
