TechOrbits OF-32R User manual

150kg (330lbs)
min 630mm
max 1290mm
INSTALLATION MANUAL
ELECTRIC
SIT-STAND DESK
OF-32R

A (x2) B (x3)
H (x3)
C (x1)
S-A (x32)
1
2
S-D (x5)S-B (x20) S-C (x4) S-E (x20)
S-F (x1)
D (x1) E (x1) F (x1) G (x1)
I (x6) J (x1) K (x1) L (x1)
S-G (x1)
S-G
C

2
3
3
F
120°90°
OR
E
S-A
S-F
S-E
S-E
FE
A
C/D

4
5
4
A
H
S-A
S-F

5
6
B
I
7
S-F
BS-A

8
6
S-F

7
10
9
S-B

8
12
11
1 & 2 & 3 P
AC
A C
J
K
G
J
S-C
1
2

1 2 3
9
13
S-C
L
S-D

10
14
S-G

11
15
16

12
Plug the Power Cord into a 110v or 220v outlet
IMPORTANT! You must Reset the desk prior to use:
Press and hold the “ “ button on the Handset until the desk reaches its lowest height.
Release the “ “ button. Press and hold the “ “ button again for about 10 seconds until the
desk lowers a little bit more, slightly rises and stops. Release the “ “ button.
Your desk is now ready to use.
To program up to four presets:
Use the “ / “ buttons to nd a desired height, then press “ ”followed by a number 1-4.
User Guide
Digital Control Panel For
Electric Height Adjustable Desk
TECHNICAL SPECIFICATIONS
Height Range
Travel Speed
Weight Capacity
Duty Cycle
63cm(24.8”) - 129cm(50.8”)
38mm(1.5”)per second
150kg(330lbs)
10%, Max. 2 mins on, 18 mins off
4 Memory presets
Soft Start/Stop
Adjustable leveling studs
MEMORY SETTINGS
Save up to four commonly used desk heights and recall them quickly.
Use the UP or DOWN button to move the desk to the desired height.
Press the “S” button.
Press the “1, 2, 3, or 4” button to assign the current height to a number on the handset.
To bring the desk back to any of those assigned heights, press the numbered button.
PROGRAMMING INSTRUCTIONS
1
2
3
4

13
HANDSET LOCK
The handset can be locked to prevent accidental activation or movement of the desk and to prevent desk
settings from being accidentally changed by children or coworkers
TO LOCK: Press and hold the “ ” and” ” buttons simultaneously for 5 seconds until the LED reads “Loc”.
TO UNLOCK: Press and hold the “UP” and”Down” buttons simultaneously for 5 seconds until the LED switches
from “Loc” to the height display.
ADVANCED SETTING
Press the “ ” button for 5 seconds until the LED ashes. The menu contains 7 items as the table below.
Short press the “ ” button to select the item you’d like to set, then use the “ / ” buttons to adjust
the value. Long press the “ ” button to save the setting and a progress bar will appear. “SUS” will be
displayed if it is saved successfully, and “FAL” will be displayed if it fails. The menu will return to the display
height automatically if no operation within 10 seconds.
MENU
The setting value should be at least 10cm(39.”) less than
the Maximum Height
SETTING RANGE REMARKS
Minimum Height 63.0cm~119cm
(24.8”~46.9”)
The setting Value should be at least 10cm(3.9”) more than the
Minimum Height
Maximum Height 72.0cm~122cm
(28.3”~48”)
Increase the Starting Height to the current height rangeStarting Height 0.0~30.0cm
(11.8”)
0:shut down
1~5: The higher the number, the higher the sensitivity
Upward Anti-Collision PC0~PC5
0:shout down
1~5: The higher the number, the higher the sensitivity
Downward Anti-Collision dC0~dC5
0:shout down
1~5: The higher the number, the higher the sensitivity
Sensor Anti-Collision SS0~SS50
Change the numeric display to show heights in centimeters
Display Unit
U-0
Change the numeric display to show heights in inches
U-1
TROUBLESHOOTING
If your desk does not respond when you try to raise it or lower it, or if the handset displays error messages,
check to make sure all the cables are secure(Legs to cables, cables to Control box). If the problem persists,
perform the reset procedure below.
RESET PROCEDURE
Unplug the power cord and hold the “ ” button on the Handset for 30 seconds.
Plug the power cord back in.
Hold the “ “ button until the desk reaches its lowest height, then release. Hold the “ ” button
again for about 10 seconds until the desk lowers a bit more, then slightly rises and stops then release.
1
2
3

The handset will then display the current height, and you should be able to operate the desk.
You may also need to do this if the desktop is ever unplugged or loses power.
4
5
If the error message persists after performing the Reset procedure, contact us or local distributors to get support.
DESCRIPTION CODE TROUBLESHOOTING SOLUTION
Abnormal Standby Current SC0 Power on again. If the code persists, replace the Control Box
Abnormal Power Supply Board SC1 Power on again. If the code persists, replace the Control Box
Abnormal Memory SC2 Power on again. If the code persists, replace the Control Box
Abnormal Sensor SC3 Power on again. If the code persists, replace the Control Box
Collision Protection by Sensor R-2 The desktop will stop and retract 5cm(2”)
Unsynchronized legs R-3 Perform Reset procedure
Overheated HOT Let the desk rest for 18 minutes
Communication Failure R-5 Check the connection between Handset and Control Box or replace Handset
Abnormal Voltage R-6 Power on again. If the code persists, replace the Control Box
Mechanical Failure R-8 Perform Reset procedure. If the code persists, replace the Leg
Rest not completed RST Perform Reset procedure
Short Circuit EX0 Power on again. If the code persists, replace the Control Box
Overload EX1 Reduce the load on desk
Wrong Running Direction EX3 Perform Reset procedure. If the code persists, replace the Leg
Collision Protection EX4 The desktop will stop and retract 5cm (2”)
Motor Stalling EX5 Perform Reset procedure. If the code persists, replace the Leg
Motor Open Phase EX2 Perform Reset procedure. If the code persists, replace the Leg
Disconnections of Motor Cable EX6 Check the connection between leg and control box
Remarks: X means 1(the rst leg), 2(the second leg), 3(the third leg)
In the event of a power outage or if the power cord is unplugged, a manual reset may
be necessary (see Reset Instructions above)
This product is designed with a duty cycle of 10% (2 min. On, 18 min. off)
Keep Children away from electric height-adjustable desks, control units and handsets.
There is a risk of injury and electric shock
Do not open any of components: lifting columns, control box, or handset.
There is a danger of electric shock
Keep all electrical components away from liquids
